Lighting
Replacing bulbs for low-
beam and high-beam
headlight
The positions of the plug,
the spring wire retainer and
the bulb might not be as illus-
trated below.
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Switch off the ignition.
Remove cover 1 by turning it
counter-clockwise to replace
the bulb for the low-beam
headlight.
Remove cover 1 by turning it
counter-clockwise to replace
the bulb for the high-beam
headlight.
Disconnect plug 1.
Disengage spring clip 1 and
swing it aside.
Remove bulb 2.
