OPERATION MANUAL
Serial Number
GATOR
LS100L
®
Battery-powered Punch Driver
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
Register this product at www.greenlee.com
52068346 REV 3
© 2015 Greenlee Textron Inc.
4/15

Advertisement

Table of Contents
loading

Related Manuals for Greenlee GATOR LS100L

Summary of Contents for Greenlee GATOR LS100L

  • Page 1 Serial Number GATOR LS100L ® Battery-powered Punch Driver Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 52068346 REV 3 © 2015 Greenlee Textron Inc. 4/15...
