Sheet Removed; Sheet Printing Is Selected; Regular Printing Is Selected, But A Roll Is Loaded - Canon imagePROGRAF iPF830 User Manual

Sheet removed.

There is remaining roll paper, but because it could not be
advanced, it could not be detected.
Sheet removed.
Sheet removed.
Cause
A sheet has come out of
the printer during printing.

Sheet printing is selected.

Sheet printing is selected.
You have attempted to print on a sheet, but
no sheet is loaded.

Regular printing is selected, but a roll is loaded.

Regular printing is selected, but a roll is loaded.
Cause
A print job for printing on sheets
was sent when a roll is loaded.
You are using a roll with the
Media Take-up Unit, but a print
job requiring sheets was sent.
644
Cause
1.
Lift the Release Lever and remove the paper.
2.
If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press
the OK button.
Printing will resume, starting from the page on which the error occurred.
Cause
Press ▲ or ▼ to select Load Paper, and then press the OK button. Load a sheet,
and then print.
(See "Loading and Printing on Sheets.")
Press ▲ or ▼ and select Stop Printing or press the Stop button to stop printing.
1.
Press ▲ or ▼ to select Remove Roll Paper, and then press the OK button to stop printing.
2.
After removing the roll, load and print on a sheet of the type and size of paper you have speci-
fied in the printer driver.
(See "Removing the Roll from the Printer.")
(See "Loading and Printing on Sheets.")
Press ▲ or ▼ to select Stop Printing, and then press the OK button to stop printing.
1.
Press the OK button to stop printing.
2.
After removing the roll, load and print on a sheet of the type and size of paper you have speci-
fied in the printer driver.
(See "Removing Printed Documents from the Media Take-up Unit (Optional).")
(See "Loading and Printing on Sheets.")
Corrective Action
(See "Attaching the Roll Holder to Rolls.")
(See "Loading Rolls in the Printer.")
3.
If no barcode was printed on the roll, specify the type of paper.
(See "Changing the Type of Paper.")
4.
If no barcode was printed on the roll, specify the paper length.
(See "Specifying the Paper Length.")
5.
If "Not finished printing. Finish printing remaining jobs?" is
shown on the Display Screen, press the OK button.
Printing will resume, starting from the page on which the error oc-
curred.
The unused portion of the roll is heavy, and this is placing a burden on
the printer. It may be helpful to change the printing mode, which will
change the paper feed timing.
Choose a higher level of Print Quality in the Advanced Settings of
the printer driver.
(See "Giving Priority to Particular Graphic Elements and Colors for
Printing.")
P.54
➔
Corrective Action
Corrective Action
P.20
➔
Corrective Action
P.338
➔
P.20
➔
P.20
➔
iPF830
P.330
➔
P.333
➔
P.336
➔
P.337
➔
P.372
➔
User's Guide
