Operator's Manual
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
Warning
: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved
forest-covered, brush-covered or grass-covered land unless the engine's exhaust system is equipped with a spark
arrester meeting applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective
working order by the operator. In the State of California the above is required by law (Section 4442 of the California Public
Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the
muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box
361131 Cleveland, Ohio 44136-0019.
CUB CADET LLC P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 [www.cubcadet.com]
PRINTED IN U.S.A.
ECO 16878
S
ERIES
TRACTOR
MODEL 5252
w/60" MOWER DECK
5000
FORM NO. 769-00867B
(4/04)

Advertisement

Table of Contents
loading

Summary of Contents for Cub Cadet 5252

  • Page 1 Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-0019. CUB CADET LLC P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 [www.cubcadet.com] PRINTED IN U.S.A. FORM NO. 769-00867B...
  • Page 2 NOTES...
  • Page 3: Table Of Contents

    The dealer has trained service personnel familiar with the latest servicing information, is equipped with the latest tools, and has a complete line of genuine Cub Cadet service parts which assure proper fit and high quality.
  • Page 4: Recording Model And Serial Number Information

    Transmission Serial Plate: Serial Number ROPS Information Plate: ROPS Serial No. TRANSMISSION SERIAL PLATE TRACTOR MODEL PLATE XXXXXXXXXXX XXXXXXXXXX Model Number Mfg. Date CUB CADET LLC P. O. BOX 361131 www.cubcadet.com CLEVELAND, OH 44136 DEALER LOCATOR PHONE NUMBER: 877-282-8684 ROPS INFORMATION PLATE...
  • Page 5: Important Safe Operation Practices

    IMPORTANT SAFE OPERATION PRACTICES WARNING: THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH, IF NOT FOLLOWED, COULD ENDANGER THE PERSONAL SAFETY AND/OR PROPERTY OF YOURSELF AND OTHERS. READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE YOUR UNIT. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
  • Page 6: Slope Operation

    • only accessories approved this Slopes are a major factor related to loss of control machine by Cub Cadet. Read, understand and and tip-over accidents which can result in severe follow instructions provided with injury or death. All slopes require extra caution. If approved accessory.
  • Page 7 3. CHILDREN • Never secure any parts on the main frame or attach the safety frame with anything other than • Tragic accidents can occur if the operator is not the special fasteners specified. alert to the presence of children. Children are •...
  • Page 8 • After striking a foreign object, stop the engine, Environmental Protection Agency. Recycling and thoroughly inspect the mower for any centers are established to properly dispose of damage. Repair the damage before restarting materials in an environmentally safe fashion. and operating the mower. •...
  • Page 9: Safety Labels

    SAFETY LABELS WARNING AVOID SERIOUS INJURY OR DEATH GO UP AND DOWN SLOPES, NOT ACROSS. AVOID SUDDEN TURNS. DO NOT OPERATE UNIT WHERE IT COULD SLIP OR TIP. IF MACHINE STOPS GOING UPHILL, STOP PTO AND BACK DOWN HILL SLOWLY. DO NOT MOW WHEN CHILDREN OR OTHERS ARE AROUND.
  • Page 10 SAFETY LABELS (Cont.) WARNING To avoid personal injury, keep PTO shield in place. Pull only from draw bar. pulling from any other point can cause rear overturn. Disengage PTO and stop engine before servicing tractor, or implements, or attaching or detaching implements. FAILURE TO FOLLOW ANY OF THE INSTRUCTIONS ABOVE CAN CAUSE SERIOUS INJURY TO THE OPERATOR, OR OTHER PERSONS.
  • Page 11: Section 1: Controls And Features

    SECTION 1: CONTROLS AND FEATURES Figure 1 Steering Wheel Hand Holds PTO Reverse Override Switch Throttle Handle Hydraulic Lift Lever Parking Brake Lever PTO Switch Cup Holder Differential Lock Pedal Ignition Switch Seat Adjustment Lever Choke Control Knob Brake Pedal Seat Belt Headlight Switch Reverse Pedal...
  • Page 12 NOTE: References to LEFT and RIGHT indicate that side of the tractor when facing forward while STOP seated in the drivers seat. Reference to FRONT indicates the grille end of the tractor; to REAR, the tow plate end. START A. Steering Wheel The steering wheel is centered on the dash panel, Figure 3 and used to change the direction (left or right) of...
  • Page 13 G. Forward Pedal N. Fuel Fill Cap The fuel fill cap is located on the left fender beside the operator’s seat. Forward Pedal O. Transmission Hi/Lo Range Shift Lever Symbol The Hi/Lo range shift lever is located on the left fender.
  • Page 14 R. Differential Lock Pedal S. Choke Control Knob Choke Diff. Lock Knob Pedal Symbol Figure 9 Figure 8 The choke knob controls the position of the engine Located at the front of the left running board, the choke. Pull the knob out to choke the engine; push differential lock pedal engages the transmission the knob in to open the choke.
  • Page 15 The hourmeter is activated whenever the operation, check the charging system for possible tractor engine is running. Keep a record of the hours causes and/or contact your Cub Cadet dealer. of operation and maintenance performed to ensure all maintenance procedures are completed accord- 4.
  • Page 16: Section 2: Operation

    30 days to assure fuel freshness. Do not use carefully inspected and, if necessary, replaced gasoline left over from the previous season to by your Cub Cadet dealer. Do not attempt to minimize gum deposits in the fuel system. repair the ROPS.
  • Page 17 If WARNING: Always sit in the operator’s the noise persists, contact your Cub Cadet dealer. seat when starting the tractor, Never attempt to start the engine while WARNING: If the starter disengages the standing beside the tractor.
  • Page 18 Have the tractor WARNING: Do not leave the seat of the inspected by your Cub Cadet dealer. tractor without disengaging the PTO and engaging the parking brake. If...
  • Page 19 USING THE FORWARD AND REVERSE PEDALS USING THE HI/LO RANGE SHIFT LEVER The hydrostatic transmission provides constantly WARNING: tractor must variable ground speeds within the speed rating of stopped before engaging or disengag- each transmission range. The tractor speed is ing the transmission Hi/Lo range shift controlled by the forward and reverse pedals on the lever.
  • Page 20 DRIVING ON SLOPES WARNING: Do not operate on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). The tractor could overturn and DIFFERENTIAL cause serious injury. LOCK PEDAL (Depress and Hold to Engage) IMPORTANT: Always shift the transmission into the LOW speed range BEFORE beginning...
  • Page 21 ENGAGING THE PTO IMPORTANT: Once activated, the reverse override will remain activated until the ignition WARNING: The operator must be in the switch is turned to the OFF position for a seat at all times when the PTO is minimum duration of 20 seconds, regardless of engaged.
  • Page 22 USING THE HITCH PLATE • When finished using the rear PTO, slide the cover fully onto the shaft; then slide the cover Use only the hitch plate (See Figure 21), for towing to the left until the slots are underneath the pull-behind equipment (carts, trailers, etc.) or drag- screw heads.
  • Page 23 To counterbalance three point hitch mounted equipment, a weight bracket/bumper kit and cast rear of the tractor, the normal balance of the tractor iron weights are available from your Cub Cadet is altered. dealer. Refer to the Weighting Table for the proper •...
  • Page 24: Section 3: Adjustments

    SECTION 3: ADJUSTMENTS ADJUSTING THE SEAT Adjust the final length of the seat belt using the adjuster clip, buckle link, and upper belt webbing on For the comfort of the operator, a single lever the right half of the belt. adjustable seat is provided to set the fore to aft •...
  • Page 25 • The length of the upper hitch link is normally • Distance ‘A’ should be 1/8"-1/4" less than determined by the design of each implement. distance ‘B’ if the toe-in is correct. If it is not, To adjust the upper hitch link, loosen the lock- readjust the toe-in.
  • Page 26 ADJUSTING THE BRAKES puck and the brake disc. The gap should mea- sure between .012 and .015". See Figure 28. The tractor brakes are adjusted at the factory and should experience minimal wear if the tractor is • If the gap is greater than .015", tighten the hex operated normally.
  • Page 27: Section 4: Tractor Maintenance

    Quality Engine Oil Engine Engine 2.1 Qts. Cub Cadet w/Filter 0°F to 100°F 10W-30 † 737-3030A (1Qt.) Hydrostatic Use Cub Cadet Approx. Transmission Cub Cadet Drive System Fluid Plus 20 Qts. Drive System 737-3120 (1 Qt.) Hydraulic (5.0 Gal.) Fluid Plus 737-3121 (1 Gal.)
  • Page 28 LUBRICATION AND MAINTENANCE CHART (ILLUSTRATION)
  • Page 29 LUBRICATION AND MAINTENANCE CHART Service Intervals Ref. Operation to be Performed • Check Engine Oil Level Check Air Cleaner • Clean Air Cleaner Foam † Precleaner Element Change Engine Oil and Replace • • Oil Filter Retorque Front Wheel Lug Bolts first •...
  • Page 30 ACCESSING THE ENGINE COMPARTMENT QUICK FASTENER WARNING: If the tractor has been recently operated, engine surfaces Pivot Flip up (including the radiator) will be HOT. Allow the engine to cool before open- ing the hood, or use extreme caution Turn to avoid burns when the hood is open.
  • Page 31 BATTERY REMOVAL CHARGING THE BATTERY Test and, if necessary, recharge the battery after WARNING: Battery posts, terminals the tractor has been stored for a period of time. and related accessories contain lead and lead compounds. Wash hands • A voltmeter or load tester should read 12.6 volts after handling.
  • Page 32 If the electrical system does not func- STARTER tion, check for blown fuses. See Figure 34 RELAY If you have a recurring problem with blown fuses, have the tractor’s electrical system checked by your PTO RELAY Cub Cadet dealer. FUSE CENTER GOOD Figure 34 Figure 36...
  • Page 33 Insert a funnel (preferably one with a flexible spout) into the fill hole of the transmission housing. • Add Cub Cadet Drive System Plus oil until the oil level can be seen through the sight glass. DASH Do not overfill the transmission.
  • Page 34 Changing Hydro Transmission Oil Filter • Clean the area around the hydraulic system oil filter to prevent debris from entering the trans- The hydro transmission oil filter should be changed mission housing. after the first 25 of tractor operation, and after every •...
  • Page 35 • Reinsert the oil fill plug into the transmission • Pour Cub Cadet Drive System Plus oil into the housing and turn clockwise until tight. transmission housing until the oil level can be seen through the sight glass. Do not overfill the •...
  • Page 36 WARNING: Servicing tires can be dan- inspect the ROPS for damage and loose fasteners. gerous. Whenever possible, trained If damage is noted, contact your Cub Cadet dealer. personnel should service and mount If an accident has occurred which may have tires.
  • Page 37 TRACTOR STORAGE Emptying the fuel system: • Prior to putting the tractor in storage, monitor If your tractor is not going to be operated for an fuel consumption with the goal of running the extended period of time (thirty days to approxi- fuel tank empty.
  • Page 38: Section 5: Engine Information And Maintenance

    SECTION 5: ENGINE INFORMATION AND MAINTENANCE KOHLER CO. FEDERAL AND CALIFORNIA EMISSION CONTROL SYSTEMS LIMITED WARRANTY SMALL OFF-ROAD EQUIPMENT ENGINES The U.S. Environmental Protection Agency (EPA), the California Air Resources Board (CARB), and Kohler Co. are pleased to explain the Federal and California Emission Control Systems Warranty on your small off-road equipment engine.
  • Page 39 ENGINE MAINTENANCE DIPSTICK WARNING: Use care when servicing any component in the engine area. If the engine has recently been operated, OIL FILL CAP components will be hot and could cause burns. Allow the engine to cool before servicing. WARNING: Before servicing the engine, place the tractor on a level surface, stop the engine, engage the parking brake, and remove the key from the...
  • Page 40 • Place the tractor on a level surface and engage the parking brake. Stop the tractor engine and DIPSTICK FILL remove the ignition key. • Clean the area around the oil filler cap to prevent debris from entering the crankcase. Refer to Figure 42.
  • Page 41 • Start the engine and run for about 3 minutes. WARNING: Operating the engine with Stop the engine and check for leaks at the oil loose or damaged air cleaner compo- filter and drain valve. nents will allow unfiltered air into the carburetor, causing extensive wear and •...
  • Page 42 SERVICING THE PAPER ELEMENT • Use a spark plug wrench to remove spark plugs. Replace the paper air cleaner element after every • Clean carbon deposits from the electrodes 100 hours of operation. Replace the element more using a soft wire brush. often if operating the tractor under extremely dusty •...
  • Page 43: Section 6: Mower Deck

    SECTION 6: MOWER DECK DECK LEVELING ADJUSTMENTS this measurement for the left blade. If the two blade heights are not within 1/16 inch, the deck The 60" mower deck is equipped with ground must be leveled. Note which blade had the following front caster wheels and is designed to be larger distance between the cutting edge operated with the front caster wheels and rear...
  • Page 44 Front To Back Leveling The front to back pitch of the deck is normally determined by the deck wheels when the deck is REAR FRONT CUTTING CUTTING operated as designed with its wheels on the EDGE EDGE ground. However, the deck pitch should be checked to ensure an even cut when mowing uneven terrain, or when mowing with the deck wheels off the ground.
  • Page 45 SETTING THE CUTTING HEIGHT • Insert the two carriage bolts and secure with the hex lock nuts. The deck cutting height is set by positioning the left and right caster wheel axles in one of the five index • Repeat the above steps for the caster wheel hole settings of the deck height adjustment bracket.
  • Page 46 • Disconnect the check chain from the LH lift arm • On each side of the tractor, flip the klik pin by removing the internal cotter pin and clevis locking ring upward and remove the klik pin pin. Reinstall the clevis pin and internal cotter from the frame mounting plate pin.
  • Page 47 • Remove the internal cotter pins and clevis pins • While noting the forms (bends) in the rod are to allow the rear deck wheels to pivot. See correctly positioned, slide the deck hanger rod Figure 60. into the slots in the front receiver brackets. Refer to Figure 59.
  • Page 48 DECK MAINTENANCE A block of wood may be placed between the deck housing and the cutting edge of the blade to assist Cleaning And Blade Care in removal of the hex nut. See Figure 62. WARNING: Before performing maintenance, place the PTO switch in the “OFF”...
  • Page 49 3&4 3&4 1. Spindle Belt Covers 2. Thumb Screws 3. Button Plugs - Access to Spindle Lube Fitting 4. Spindle Assembly Lube Fittings 5. Idler Arm Lube Fitting 6. Height Adjustment Brackets Figure 63 SPINDLE BELT REPLACEMENT • Push the movable flat idler pulley (2, Figure 64) toward the left side of the deck to relieve A worn spindle belt will affect the quality of cut from tension from the belt.
  • Page 50 Spindle Pulleys Movable Flat Idler Pulley Drive Pulley Fixed Flat Idler Pulley Spindle Belt LH Belt Cover Mntg. Strap Gear Box Mntg. Bracket Idler Arm Hex Cap Screws 10. Deck Mounting Plate Figure 64 Install New Spindle Belt 5. Route the belt as follows: •...
  • Page 51 MOWER DECK LUBRICATION GUIDE Lubricant is cheap. Use plenty of it. Worn parts can be expensive to replace. NOTE: We do not recommend the use of a pressure washer or garden hose to clean your unit. Keep your supply of lubricating oil and grease They may cause damage to spindles;...
  • Page 52 MOWING Streaking may occur when attempting to mow heavy weeds and tall grass. Under these conditions WARNING: To avoid possible injury, it may be necessary to go back over the cut area a never direct the discharge of material second time to get a clean cut. toward bystanders or allow anyone The following practices will help eliminate streaking: near the machine while in operation.
  • Page 53: Section 6: Specifications

    Oil ........
  • Page 54: Specifications

    SPECIFICATIONS Hydraulic Lift System Type ............Auxiliary Pump Control .
  • Page 55: Section 7: Optional Equipment And Accessories

    When purchasing your tractor, you probably had it equipped for your particular needs at that time. You may later wish to obtain additional equipment or accessories to perform other tasks. Refer to the chart below for a list of approved optional equipment and accessories currently available through your Cub Cadet dealer. DESCRIPTION MODEL NUMBER...
  • Page 56: Warranty

    This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state. CHANGES Cub Cadet LLC reserves the right to make changes in the design and other changes in its products at any time without notice and without incurring any obligation to product previously manufactured or purchased.
