Dear customer

Thank you for purchasing this product. For optimum performance
and safety, please read these instructions carefully.
Before connecting, operating or adjusting this product, please read
the instructions completely.
Please keep this manual for future reference.
Region number supported by this unit
Region numbers are allocated to DVD players and software
according to where they are sold.
•
The region number of this unit is "1".
•
The unit will play DVDs marked with labels containing "1" or
"ALL".
Example:
P
PC
Downloaded From Disc-Player.com Panasonic Manuals
1
1
ALL
2
4

Operating Instructions

Model No.
If you have any questions contact
In the U.S.A.:
1-800-211-PANA(7262)
In Canada:
1-800-561-5505
For U.S.A. only
The warranty can be found on page 43.
For Canada only
The warranty can be found on page 43.
La referencia rápida en español se puede encontrar
en la página 44–47.

DVD Recorder

DMR-ES20
RQT8152-3P
