Boot Menu

This page enables you to set the keyboard NumLock state.
Main
Boot Configuration
Operation System Select
Launch PXE OpROM
Launch Storage OpROM
Bootup NumLock State
Quiet Boot
Boot mode select
Set Boot Priority
Boot Option #1
Boot Option #2
Boot Option #3
Boot Option #4
Boot Option #5
Boot Option #6
Boot Option #7
Hard Disk Drive Priorities
CD/DVD ROM Drive Priorities
USB/ Floppy Drive Priorities
USB CD/DVD ROM Drive Priorities
USB HardDisk Drive Priorities
USB Flash Drive Priorities
Network Device Priorities
CSM parameters
Boot Configuration
This item shows the information of the Boot Configuration.
Operation System Select (Windows7 or other OS)
This item is used to select the operation system.
Launch PXE OpROM (Disabled)
The item enables or disables launch PXE Option ROM.
Launch Storage OpROM (Enabled)
The item enables or disables launch Storage Option ROM.
Bootup NumLock State (On)
This item enables you to select NumLock state.
Quiet Boot
This item enables or disables quiet boot.
Boot mode select (LEGACY)
Use this item to select boot mode.
Set Boot Priority
This item enables you to set boot priority for all boot devices.
Boot Option #1/2/3/4/5/6/7
These items show the boot priorities.
Advanced Chipset
Windows7 or other OS
(Enabled)
M.I.B III Boot
Disabled
Enabled
On
Enabled
LEGACY
Hard Disk
CD/DVD
USB / Floppy
USB CD/DVD
USB Hard Disk
USB Key: Ut165 1.00
Network
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
Using BIOS
Security Exit
Windows 7 or other OS:
Boot policy for Legacy OS
Windows 8: Boot Policy for
UEFI OS without
Compatibility Support
Module (CSM)
Manual: User customized
CSM parameters & boot
policy
: Select Screen
/Click: Select Item
Enter/Dbl Click : Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
