Page 1: Quick Start Guide
Quick Start Guide BSG8ew and BSG12aw/ew/tw 1.0 Business Services Gateway Document Status:Standard Document Number:NN47928-105 Document Version: 01.03 Date: July 2008... - Page 2 Users must take full responsibility for their applications of any products specified in this document. The information in this document is proprietary to Nortel Networks. Trademarks Nortel, the Nortel logo, and the Globemark are trademarks of Nortel Networks. All other trademarks and registered trademarks are the property of their respective owners.
-
Page 3: Quick Start Wizard
Quick Start Wizard Use this guide to complete the basic configuration of the Business Services Gateway (BSG) and to enable remote access configuration. You will need the following information from your ISP or network administrator to complete the Wizard: Login Value information IP address of... - Page 4 Gateway IP Address Primary DNS Secondary LAN IP address Do not change Do not change LAN subnet mask DHCP Setup Server Relay None DHCP Server IP Pool Starting Address configuration IP Pool End Address Country Code Wifi Security Open System selection WPA-PSK WPA2-PSK...
-
Page 5: Remote Access
Remote Access Enable remote Telnet access Procedure Ensure that the BSG is powered up and connected to the Internet. Connect a PC to the LAN port of the BSG. Open a web browser. In the address bar of the browser, enter the LAN IP address of BSG and press Enter. Remote Access Quick Start Guide... - Page 6 The BSG login page appears. Enter the user name and password and click the login button to access the device. The system information panel appears. NN47928-105...
- Page 7 In the navigation panel on the left, click on the Quick Start Wizard option. The Quick Start Wizard opens. Click on the arrow in the middle of the page to continue. The Setting Up Your WAN configuration panel appears. The fields on your panel will be different depending on which model of BSG you are configuring.
- Page 8 BSGtw Select the interface from the drop down list. b Select the Framing. Select the Clock Source. d Enter the Time Slot. Select whether Authentication is Required. If authentication is required enter the username and password. g Once you have finished entering the information click on the Apply button at the bottom of the panel.
- Page 9 BSGew Select the interface from the drop down list. b Select the Encapsulation mode. PPPoE 1. Enter ISP name 2. Enter the user name 3. Enter the password 4. Enter the Host Name. Once you have finished entering the information click on the Apply button at the bottom of the panel.
- Page 10 BSGaw Select the DSL Name. b Select the DSL Connection Type. Enter the VPI/VCI. d Select whether Authentication is Required. Enter the username. Enter the password. g Once you have finished entering the information click on the Apply button at the bottom of the panel.
- Page 11 11 Click the Next button at the bottom of the panel to advance to the next panel. The Setting up your Wireless configuration panel appears. 12 Select the Country Code. 13 Refer to the information at the beginning of this guide for the correct security settings to enter. 14 Click on Apply to save the configuration.
- Page 12 21 You have successfully completed the BSG Quick Start Wizard. 22 Verify all of the information that you have entered is correct. If the information is correct, click Continue to save the information. If you want to make changes to the information, click on the Change button at the bottom of the page and you will run through the Wizard again.
