Nortel Circuit Card Installation Manual page 863

Nortel networks circuit card description and installation
Table of Contents

Advertisement

Table 270
ESDI card address switch settings (Part 2 of 2)
Device Number
Port 1
12
14
* Switch S2, position 4 is not used on style B cards.
DTE/DCE mode jumper settings
The interface for each ESDI port is configured independently. Ports must be
configured both for electrical interface (RS-232-C or high-speed) and mode
(DTE or DCE). With the proper options set:
An ESDI port configured as DTE appears as a terminal to the user
equipment.
An ESDI port configured as DCE appears as a modem to the user
equipment.
Interface options are set by installing option jumper plugs into the sockets
indicated in Table 271 on
QPC513 Enhanced Serial Data Interface card
Port 2
1
13
off
15
on
page 865
Switch S2
style A
2
3
4
on
on
on
on
on
on
and Table 272 on
Circuit Card
Description and Installation
Page 863 of 906
Switch S2
style B
1
2
3
on
on
off
on
on
on
page
865.
4
*
*
