Nortel VoIP 1120E/1140E Quick Reference Guide
The following quick reference guide will get you started using your Nortel VoIP 1120E/1140E telephone. The 1120E and
1140E are very similar; however the 1140E has a larger screen and two additional System Defined Keys.
Menu Option Navigation
Note: Some menu options may not be visible. Use the up
or down Navigation Keys to navigate to all menu options.
To select a menu option:
1. Press the up or down navigation keys to align the
menu option to a System Defined Key.
2. Press the System Defined Key next to the menu
option.
Answer Voice Mail
1. Pick up the handset.
2. Use the Navigations Keys to scroll to the Msg Wait.
3. Press the key next to Msg Wait.
4. Enter your mailbox password.
NUIT Network Operations Center (Repair)
Call NUIT repair at 611 from any campus phone.
Off Campus Phone: 847-467-6662
Northwestern University Information Technology
Figure 1 Nortel 1140E

How to Use the Navigation Keys

There are five keys to navigate the menus, and to help you
to enter text in the display.
• up key—return to the previous menu item
• down key—go to the next menu item
• left/right key—active when you can enter text. To move
the cursor to the left, press the left key. Press the right key
to move the cursor to the right.
• Center key —select the menu item

Call Forwarding

Use the Forward menu option to forward your incoming
calls to another phone.
1. To turn on, press the key next to Forward (icon
blinks).
2. Enter the phone number where you would like to
receive calls.
3. Press the key next to Forward again (icon solid).
4. To turn off, press key next to Forward (icon
disappears).
