INSTRUCTIONS FOR FINAL ASSEMBLY
The Modeltech Simply Magic 40 ARF is distributed
exclusively by Global Hobby Distributors 18480
Bandilier Circle, Fountain Valley, CA 92708
All contents copyright © 2002, Global Hobby
Distributors Version V1.0 December 2002
Kit Product Number 123742
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at service@globalhobby.net
Specifications:
Wing Span: 50 Inches
Wing Area: 730 Square Inches
Wing Loading: 16-18 Ounces Per Square Foot
Length: 49.5 Inches
Weight RTF: 5.0 - 5.5 Pounds
Functions: Ailerons, Elevator, Rudder and Throttle
Power: .40 - .52 Two Stroke or .52 - .70 Four Stroke
Radio: 4 Channel w/5 Standard Servos
1
Advertisement
Table of Contents
Related Manuals for Model Tech Simply Magic
Summary of Contents for Model Tech Simply Magic
-
Page 1: Specifications
INSTRUCTIONS FOR FINAL ASSEMBLY Specifications: The Modeltech Simply Magic 40 ARF is distributed Wing Span: 50 Inches exclusively by Global Hobby Distributors 18480 Wing Area: 730 Square Inches Bandilier Circle, Fountain Valley, CA 92708 Wing Loading: 16-18 Ounces Per Square Foot Length: 49.5 Inches... -
Page 2: Table Of Contents
Section 19: Aileron Control System Installation ....30 Section 20: Final Assembly ........... 31 Section 21: Balancing the Simply Magic 40 ......34 Section 22: Lateral Balancing the Simply Magic 40 .... 35 Section 23: Control Throws ........... 34 Section 24: Preflight Check & Safety ........36 Section 25: Flying the Simply Magic 40 ....... -
Page 3: Introduction
INTRODUCTION Thank you for purchasing the new Modeltech Simply Magic 40 ARF. Before completing the final assembly of your new airplane, please carefully read through this instruction manual in its entirety. Doing so will ensure your success the first time around! -
Page 4: Section 1: Our Recommendations
What Engine Should I Use? The Simply Magic will accept a wide variety of engines, so which engine you choose really depends on how you want to fly the airplane. For general sport flying, a .40 to .52 2-stroke engine with a 10 x 6 propeller (for a .40) or an 11 x 6 propeller (for a .46 or .52) would be perfect. -
Page 5: Section 2: Tools And Supplies Required
SECTION 2: TOOLS AND SUPPLIES REQUIRED The tools and supplies listed below will be necessary to finish the final assembly of your Simply Magic 40. We suggest having these items onhand before beginning assembly. Kwik Bond Thin C/A # 887500... -
Page 6: Section 4: Metric Conversion Chart
LANDING GEAR ASSEMBLY RUDDER CONTROL SYSTEM 17" Threaded Wires w/90º Bend Prebent Aluminum Main Gear Strut Nylon Control Horns Blow-Molded Wheel Pants M2 x 15 Machine Screws Main Gear Wheels M2 Hex Nuts M4 x 16 Machine Screws Nylon Clevises M4 x 35 Smooth-Shank Machine Screws Nylon 90º... -
Page 7: Section 5: Replacement Parts
SECTION 5: REPLACEMENT PARTS Global stocks a complete line of replacement parts for your Modeltech Simply Magic 40 ARF. Listed below are the replacement parts that are available along with their respective part numbers for easy ordering convenience. We suggest ordering directly from your local dealer. -
Page 8: Section 7: Wing Assembly
SECTION 7: WING ASSEMBLY YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT: (1) Hardwood Wing Joiner (1) Right Wing Panel w/Aileron (1) Left Wing Panel w/Aileron YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES: Kwik Bond 30 Minute Epoxy Masking Tape Excel Modeling Knife Paper Towels Ruler... - Page 9 Slide both wing panels together with the wing joiner temporarily installed (without using glue). Look carefully at the center section joint: the wing panels should fit together tightly with few or no gaps in the joint. If the wing panels do not fit together properly, remove the wing joiner and use 220 grit sandpaper with a sanding block to lightly sand the edges and tips of the joiner, until you are satisfied with the fit.
-
Page 10: Section 8: Wing Mounting
SECTION 8: WING MOUNTING YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT: (1) Fuselage w/Hatch Covers & Belly Pan (2) M4 Flat Washers (1) Plywood Wing-Screw Doubler (2) M4 Blind Nuts (2) M4 x 35 Machine Screws YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES: Kwik Bond Thick C/A Ernst Airplane Stand # 2 Phillips Head Screwdriver... - Page 11 Step 2: Installing the Blind Nuts Remove the wing from the fuselage and enlarge only the two holes in the plywood wing hold-down block using a 15/64" diameter drill bit. Enlarging the holes will make it much easier to install the blind nuts. Install the two blind nuts into the bottom of the plywood block, using one of the wing mounting screws and washers to draw the blind nuts firmly up into place.
-
Page 12: Section 9: Belly Pan Installation
SECTION 9: BELLY PAN INSTALLATION YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES: Kwik Bond 30 Minute Epoxy Paper Towels Excel Modeling Knife Rubbing Alcohol Ernst Airplane Stand NHP Epoxy Mixing Sticks Pencil NHP Epoxy Mixing Cups Masking Tape Step 1: Aligning the Belly Pan Using a modeling knife, cut away and remove the covering material from over the precut wing-screw access holes in the bottom of the belly pan. -
Page 13: Section 10: Stabilizer Installation
SECTION 10: STABILIZER INSTALLATION YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT: (1) Vertical Stabilizer w/Rudder (1) Horizontal Stabilizer w/Elevator Halves YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES: Kwik Bond 30 Minute Epoxy 220 Grit Sandpaper w/Sanding Block Excel Modeling Knife Masking Tape Dubro T-Pins Paper Towels... - Page 14 With the wing mounted to the fuselage, use a ruler to measure the distance between the tips of the stabilizer and the tips of the wing. Pivot the front of the stabilizer until both of these measurements are equal. When the stabilizer is aligned properly, B should equal B-1.
- Page 15 After the epoxy has fully cured, remove the masking tape and look closely at the glue joint. If there are any gaps between the stabilizer and the fuselage, fill them using 30 minute epoxy for added strength. Again, before the epoxy sets up, remove any excess using a paper towel and rubbing alcohol.
-
Page 16: Section 11: Control Surface Hinging
SECTION 11: CONTROL SURFACE HINGING YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT: (1) Preassembled Tail Wheel Bracket (3) M3 x 12 Wood Screws (1) Tail Wheel (17) C/A Style Hinges (1) Wheel Collar w/M3 x 5 Set Screw YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES: Kwik Bond Thin C/A Ruler Kwik Bond 30 Minute Epoxy... - Page 17 Repeat the previous procedures to hinge the second aileron to the other wing panel. IMPORTANT After the C/A has fully cured, gently grasp each aileron and pull on it like you are trying to pull out the hinges. The hinges should hold securely. If one or more hinges feels loose, apply more C/A to the hinge(s) and allow it to completely cure.
-
Page 18: Section 12: Main Landing Gear Installation
Using 220 grit sandpaper, lightly sand the end of the tiller arm wire to roughen the metal. Mix a small quantity of 30 minute epoxy. Apply a thin layer to the end of the tiller arm and pack more into the hole and the groove in the leading edge of the rudder. - Page 19 Step 2: Installing the Wheels and Wheel Pants Using a modeling knife, very carefully cut the wheel opening in each of the two wheel pants. Use 220 grit sandpaper with a sanding block to sand the edges of the openings smooth. Using a 5/32"...
-
Page 20: Section 13: Engine Installation
Step 3: Adjusting the Wheel Pants With both wheels and wheel pants installed, set the airplane on its wheels on a level surface. Adjust the wheel pants so that the bottom rear portion of the wheel pants are level with the ground. Double-check that both wheel pants are level with each other. - Page 21 Using a ruler and a pencil, measure and draw one horizontal line 1/2" above the horizontal centerline and one horizontal line 13/16" below the horizontal centerline. Temporarily glue the two engine mounting beams to your engine's mounting lugs using a couple of drops of thick C/A. The location of the engine is not important at this time.
-
Page 22: Section 14: Fuel Tank Assembly & Installation
Step 3: Aligning and Installing the Engine Set the engine onto the engine mounting beams and temporarily install the spinner backplate onto the crankshaft. Using a ruler, measure the distance from the firewall to the back of the spinner backplate. Adjust the depth of the engine so the measurement is 4-1/8". - Page 23 Carefully bend the longer of the two aluminum tubes up at a 45º angle, being careful not to "kink" the tubing as you bend it. When the stopper assembly is installed in the fuel tank, the top of the vent tube (the tube you just bent) should rest just below the top of the tank.
-
Page 24: Section 15: Servo Installation
Cut and install several pieces of foam rubber between the fuel tank and the fuselage sides to secure the fuel tank into place. When you install the hatch cover later on, put a piece of foam on top of the tank so the hatch cover will hold the tank down in place. -
Page 25: Section 16: Throttle Linkage Installation
SECTION 16: THROTTLE LINKAGE INSTALLATION YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT: (1) 26-1/4" Pushrod Wire w/Z-Bend (1) Adjustable Servo Connector Assembly YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES: Kwik Bond Thin C/A Excel Modeling Knife # 1 Phillips Head Screwdriver Electric Drill Wire Cutters 5/64"... -
Page 26: Section 17: Elevator Control System Installation
Position the throttle control stick and the throttle trim lever on your transmitter at their lowest positions. Slide the adjustable servo connector/servo horn assembly over the plain end of the throttle pushrod wire. After making sure that the carburetor is in the fully closed position, angle the servo horn back about 45º... - Page 27 Partially thread the M3 x 8 set screws into the wheel collars. Slide the wheel collars onto the elevator pushrod wire and up against the snap keeper. Make a shallow bend 1-1/2" from the plain end of the 13-1/2" long pushrod wire, then slide the pushrod wire through the wheel collars as shown.
-
Page 28: Section 18: Rudder Control System Installation
Install the control horn and backplate using two M2 x 12 machine screws, being careful not to overtighten them. Repeat the previous procedures to install the second control horn and backplate on the other elevator half. Thread the clevises onto the pushrod wires and snap them into the third hole out from the base of the control horns. - Page 29 Using a modeling knife, cut away and remove the covering material from over the rudder pushrod exit holes in each side of the fuselage. They are located 6" in front of the rudder hinge line and 3/4" above the bottom of the fuselage. Connect your radio system and plug the rudder servo into the receiver.
-
Page 30: Section 19: Aileron Control System Installation
SECTION 19: AILERON CONTROL SYSTEM INSTALLATION YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT: (2) Nylon Clevises (2) 3-3/8" Threaded Wires w/90º Bend (2) Nylon Control Horns w/Backplates (2) Nylon 90º Snap Keepers (4) M2 x 12 Machine Screws YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES: # 1 Phillips Head Screwdriver 5/64"... -
Page 31: Section 20: Final Assembly
Thread the clevis onto the pushrod wire and snap it into the outermost hole from the base of the control horn. Repeat the previous procedures to install the second aileron pushrod assembly on the opposite wing panel. SECTION 20: FINAL ASSEMBLY YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT: (4) M3 x 6 Wood Screws (1) Prepainted Molded Fiberglass Cowling... - Page 32 Step 2: Installing the Cowling With the cowling held firmly in place, drill 5/64" diameter pilot holes into the cowling and through the fuselage for the four wood screws. Locate two holes on each side of the cowling, 1/4" in front of the back edge of the cowling. One hole should be 1/2"...
- Page 33 Step 4: Aligning & Installing the Canopy Using a pair of scissors, carefully cut out the canopy along the molded scribe lines. Using 220 grit sandpaper with a sanding block, carefully sand the edges of the canopy smooth and straight. Be careful not to scratch the surface of the canopy when sanding its edges.
-
Page 34: Section 21: Balancing The Simply Magic 40
Attach a piece of scrap wire to the switch that runs out the side of the fuselage. You can then turn the switch on and off by pushing and pulling the piece of wire. SECTION 21: BALANCING THE SIMPLY MAGIC 40 YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:... -
Page 35: Section 22: Lateral Balancing The Simply Magic 40
SECTION 23: CONTROL THROWS We recommend setting up the Simply Magic 40 using the control throws listed below. These control throws are suggested for initial test-flying because they will allow the airplane to fly smoother and make it easier to control. -
Page 36: Section 24: Preflight Check & Safety
SECTION 24: PREFLIGHT CHECK & SAFETY Completely charge the transmitter and receiver batteries before your first day of flying. Check every bolt and every glue joint in the airplane to ensure that everything is tight and well-bonded. This should include all of the control surface hinges as well. Double-check that you've installed and tightened all of the servo horn retaining screws. -
Page 37: Section 25: Flying The Simply Magic 40
IN THE AIR In the air the Simply Magic 40 is as smooth and docile or as wild and aerobatic as you want it to be. With the control throws set to the "Test-Flying" settings, the airplane is smooth throughout the entire flight envelope, even while moving the control sticks to the corners. -
Page 38: Section 26: Simply Magic 40 Trimming Chart
SECTION 26: SIMPLY MAGIC 40 TRIMMING CHART After you have test-flown and done the initial trim changes to the airplane, use this trimming chart to begin trimming your airplane. Following and adhering to this chart will result in the ability to diagnose trim problems and correct those problems using the simple adjustments shown below. -
Page 39: Product Evaluation Sheet
Your privacy is important to us. Was any of the assembly difficult for you? If yes, Kit: Modeltech Simply Magic 40 ARF # 123742 please explain. Where did you learn about this kit? - Page 40 _____________________________ _____________________________ Post Office will not deliver _____________________________ without proper postage (Return Address Here) Global Hobby Distributors Attn: Global Services 18480 Bandilier Circle Fountain Valley CA 92728-8610 Fold along dotted line Visit our website at http://modeltech.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com...
