Chapiter 1
Introduction
And' besides available on CDRom a Quick Start Guide for a fast configuration.
1.1 An Overview of the I-Fly Wireless Broadband Router
The device for a total freedom of movement without losing the connection. Easy to be installed and
fast and flexible, with I-Fly Wireless Broadband Router there is no more obligation for a fixed
working place: you can easily work or navigate for fun from your own garden or in different rooms of
your office, always in wireless connection.
I-Fly Wireless Router is extremely flexible and you can choose the technology for your connection to
internet, i.e. through an ISDN device or through the fast solution of the broadband. Your whole office
can be connected to the web simultaneously and throughout, thanks to our I-Fly Wireless Router,
which can serve up to 253 users. The Roaming function gives you a complete freedom of movement
and two or more Wireless Router can serve wireless also large headquarters.
Thanks to advanced security functions which are integrated and thanks to the troughput of the protocol
IEE802.11G you are going to have a fast and flexible wireless net, hacker safe.
The chipsets fully support Wi-Fi Protected Access (WPA) and the IEEE 802.11i draft security
standards in hardware and high-speed encryption engines for both the Temporal Key Integrity Protocol
(TKIP) and the Advanced Encryption Standard (AES) with no performance degradation.
Last, but not least, this product implements Atheros Super G™ (available for devices with chipset
Atheros) capabilities to deliver 108 Mbps raw data rates and 90 Mbps TCP/IP throughput for 802.11g
wireless LANs (Real-time hardware data compression, Dynamic transmit and modulation optimization
and Standards-compliant bursting mode adapts to the network).
This product also serves as an Internet firewall, protecting your network from being accessed by
outside users. Not only provides the natural firewall function (Network Address Translation, NAT), it
also provides rich firewall features to secure a user's network. All incoming data packets are
monitored and filtered. Besides, it can also be configured to block internal users from accessing to the
Internet.
The product provides three levels of security support. First, it masks LAN users' IP addresses which
are invisible to outside users on the Internet, making it much more difficult for a hacker to target a
machine on your network. Secondly it can block and redirect certain ports to limit the services that
outside users can access. For example, to ensure that games and other Internet applications will run
properly, a user can open some specific ports for outside users to access internal services in the
network. Finally it can also detect and block many Hacker Patterns and not allow hackers into your
network.
Integrated DHCP services, client and server, allows up to 253 users to get their IP addresses
automatically on boot up from the product. Simply set local machines as a DHCP client to accept a
dynamically assigned IP address from DHCP server and reboot. Each time a local machine is powered
up; the router will recognize it and assign an IP address to instantly connect it to the LAN.
For advanced users, The Virtual Server function allows the product to provide limited visibility to
local machines with specific services for outside users. An ISP provided IP address can be set to the
