• This Service Manual is the “Supplement” and replaces “Simple Manual” XR-MS3 (EZ,K), (S/M Code No. 09-004-422-6T2). • This Service Manual is for XR-MS3 (EZBM) Black color. • This Service Manual contains information about the difference between XR-MS3 (EZBM,KSM) and XR-MS3 (EZ). If requiring the other information, see Service Manual of XR-MS3 (U,EZ), (S/M Code No.
SPECIFICATIONS <FM tuner section> <General> Tuning range 87.5 MHz to 108 MHz Power requirements 230 V AC, 50 Hz Usable sensitivity (IHF) 16.8 dBf Power consumption EZ : 57 W Antenna terminals 75 ohms (unbalanced) K : 68 W Standby power consumption EZ : 1.7 W (power-economizing <MW tuner section>...
