INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
THIS FIREPLACE HAS BEEN TESTED AND LISTED BY WARNOCK HERSEY LTD. TO STANDARDS: ULC S610-M87, UL 127-1992, FOR ZERO CLEARANCE FIREPLACES,
TO ULC S639-M87 FOR STEEL LINER ASSEMBLIES FOR SOLID FUEL BURNING MASONRY FIREPLACES AND TO CAN/ULC-S627-M90 FOR SPACE HEATERS FOR USE
WITH SOLID FUELS.
SOLID FUEL BURNING - ZERO CLEARANCE
INSTALLATION AND OPERATION INSTRUCTIONS
FOR HI-TECH LISTED FIREPLACE
NZ25
MODEL
WARNING:
If this fireplace is not properly installed, a house fire may result.
FOR YOUR SAFETY
Follow the installation directions. This fireplace can be very hot when burning. Combustible mate-
rials such as firewood, wet clothing, etc. placed too close can catch fire. Children and pets must be
kept from touching the fireplace when it is hot. The chimney must be sound and free of cracks.
Before installing this unit, contact the local building or fire authority and follow their guidelines.
Operate only with the door tightly closed. Burn wood behind the log retainer directly on the fire-
bricks. Do not use an elevated grate or otherwise raise the fire. This fireplace is designed to burn
natural wood only. Higher efficiencies and lower emissions generally result when burning air dried
seasoned hardwoods, as compared to softwoods or to green or freshly cut hardwoods. Do not
start a fire with chemicals or fluids such as gasoline, engine oil, etc. Do not burn treated wood,
coal, charcoal, coloured paper, cardboard, solvents or garbage. Do not let the fireplace become
hot enough for any part to glow red.
Wolf Steel Ltd., RR#1, 9 Napoleon Rd.,
Barrie, ON., Canada L4M 4Y8 (705)721-1212
Fax: (705)722-6031 Email: ask@napoleon.on.ca
Web: www.napoleon.on.ca
WS-415-71 / 09.07.00
Advertisement
Table of Contents
Related Manuals for Napoleon NZ25
Summary of Contents for Napoleon NZ25
-
Page 1: For Your Safety
TO ULC S639-M87 FOR STEEL LINER ASSEMBLIES FOR SOLID FUEL BURNING MASONRY FIREPLACES AND TO CAN/ULC-S627-M90 FOR SPACE HEATERS FOR USE WITH SOLID FUELS. SOLID FUEL BURNING - ZERO CLEARANCE INSTALLATION AND OPERATION INSTRUCTIONS FOR HI-TECH LISTED FIREPLACE NZ25 MODEL WARNING: If this fireplace is not properly installed, a house fire may result. FOR YOUR SAFETY Follow the installation directions. -
Page 2: Table Of Contents
Canadian and American laboratories. WS-415-71 / 09.07.00 TABLE of CONTENTS PG 11 12-13 OPERATING INSTRUCTIONS 14-15 REPLACEMENTS OPTIONAL BLOWER NZ25 FEATURES Controlling Combustion Air Achieving Proper Draft Fuel Loading and Burn Cycle Ash Removal Procedures Operating Instructions MAINTENANCE... - Page 3 NAPOLEON wood fireplaces are manufactured under the strict Standard of the World Recognized NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen who take great pride in their work. The complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that you, the customer, receives the quality product that you expect from NAPOLEON.
-
Page 4: Introduction
INTRODUCTION GENERAL INFORMATION FIGURES 1 This is the most efficient, sim- woodburning system we know of and works as follows: Primary combustion air enters through the air control inlet box regulated by a draft control, travels up the side through a duct and enters the top center of the combustion chamber into a preheating airwash lo-... -
Page 5: Care Of Glass & Plated Parts
This can be especially important if the fireplace is to be used as a major source of heat. Without the use of blowers, the Napoleon Model NZ25 will operate as a regular hi-efficiency fireplace. A BLOWER KIT (NZ62) may be purchased with the option of adding up to one additional blower. -
Page 6: Installation / Framing
These options may be incorporated with one another. If the optional blowers are to be installed, make provision dur- ing framing to route a 110 volt power line to the fireplace. Detailed installation instructions are included with each venting kit. FIGURE 4 LOCATION AND CLEARANCES The fireplace must be installed against finished walls. -
Page 7: Outside Combustion Air
Do not add a hood. OUTSIDE COMBUSTION AIR The Napoleon Model NZ25 has the option of taking out- side air directly into the fireplace through the opening on the left hand side or taking inside air through the lower front louvres or a combination of both. -
Page 8: Chimney Installation
CHIMNEY INSTALLATION This fireplace was tested to CAN/ULC S610-M87 Zero Clearance Fireplace Safety Test Standard. In accordance with this standard, the unit may be connected to any accepted chimney listed to ULC S-629. The following 7" factory-built chimney systems may be used: MANUFACTURER OLIVER MACLEOD HT 6103(... -
Page 9: Adding Chimney Sections
1. Move the fireplace into position. Try to center the ex- haust flue of the fireplace, midpoint between two joists to prevent having to cut them. Use a plumb bob to line up the centre. 2. Cut and frame an opening in the ceiling to provide a minimum clearance of 2"... -
Page 10: Finishing
Ensure there are no leaks. FIGURE 17 In no case is the masonry enclosure to be supported by the NZ25 fireplace. Allow a 1" (one inch) air cavity for expansion. WS-415-71 / 09.07.00 FINISHING... - Page 11 OPTIONAL B L O W E R INSTALL ATION NSTALLATION TO BE DONE BY A QUALIFIED INSTALLER and must be electrically connected and grounded in ac- cordance with local codes. In the absence of local codes, use the current CSA C22.1 CANADIAN ELECTRICAL CODE.
-
Page 12: Nz25 Features
NZ25 FEATURES CONTROLLING COMBUSTION AIR: If the outside combustion air kit is not used, air may still be drawn directly into the fireplace through the lower louvres. Outside and inside air may be combined by pulling the outside air lever out as far as possible, and turning the lever 90°... -
Page 13: Ash Removal Procedures
ASH REMOVAL PROCEDURES A bed of ashes approximately 1 inch deep should be left on the firebox bottom to help maintain a hot charcoal bed. When the fire has burned down and cooled, remove any excess ashes. To use your ash pan, pull the ash dump handle forward to an open position. -
Page 14: Maintenance
MAINTENANCE GASKET / BAFFLE REPLACEMENT At the end of each burning season inspect the baffle lo- cated above the secondary air tubes for deterioration. Re- place if necessary. At this time also check that the door gasket is not worn or loose. Replace with 1/2" fibreglass rope if necessary. -
Page 15: Replacement Parts
REPLACEMENT PARTS PART NO. DESCRIPTION NZ-H333 BLACK DOOR & W HANDLE NZ-H333G GOLD PLATED DOOR W HANDLE WS-300-04 DOOR GLASS ONLY EP-562.010 DOOR GASKET EP-562.016 GLASS GASKET WS-325-07 LARGE SPRING HANDLE WS-325-02 SMALL SPRING HANDLE GA GD-715.11 UPPER LOUVRE - POLISHED BRASS EP-NZ-018.41 2 PC TOP FIREBRICK BAFFLE... -
Page 16: Trouble Shooting
TROUBLE SHOOTING Build your fire on the floor of the firebox and be- hind the log retainer only. Do not block or restrict the hot air outlets or air inlets. This will cause the fireplace to overheat. Keep fires away from the door . DOs: Build a hot fire.
