DL9600 Viper™
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Datalogic DL9600 Viper

Summary of Contents for Datalogic DL9600 Viper

  • Page 1 DL9600 Viper™ User’s Manual...
  • Page 3 DL9600 Viper™ USER'S MANUAL...
  • Page 4 ALL RIGHTS RESERVED Datalogic reserves the right to make modifications and improvements without prior notification. Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material.

  • Page 5: Table Of Contents

    General Safety Rules ..................vi Laser Safety....................vii Radio Compliance..................xi FCC Compliance..................xii GENERAL VIEW ..................xiii INTRODUCTION ..................1 DL9600 Viper™ Terminal Description............1 Package Contents..................3 Accessories....................4 CONNECTIONS ................... 5 Terminal Connection to the Host Computer ..........5 2.1.1 Connection Through CC9600 Cradle............5 2.1.2...
  • Page 6 4.2.2 2D Barcode Scanning ................. 19 Description of the Keys (32-key Models)............. 20 4.3.1 Display Control and Power Keys..............20 4.3.2 Key Selection ....................21 4.3.3 Special Key Sequences ................22 Description of the Keys (48-key Models)............. 24 4.4.1 Display Control and Power Keys..............24 4.4.2 Key Selection ....................

  • Page 7: References

    “Device” refers to the DL9600 Viper™. “You” refers to the System Administrator or Technical Support person using this manual to install, mount, operate, maintain or troubleshoot a DL9600 Viper™. REFERENCE DOCUMENTATION For further details refer to the Development System Manual of DS for Mobile@work.

  • Page 8: Safety Regulations

    Use only the components supplied by the manufacturer for the specific DL9600 Viper™ terminal being used. The use of cradles other than those supplied with the DL9600 Viper™ terminal or indicated in the list in the appendix could cause serious damage to the DL9600 Viper™ terminal.

  • Page 9: Laser Safety

    MAX. OUTPUT RADIATION 1.4 mW - EMITTED WAVE LENGTH 630~680 nm WHEN OPEN THIS APERTURE EN60825-1:2001 DO NOT STARE INTO BEAM Laser output window Model No. DL9600 XXXXXXX S/N. DATALOGIC S.P.A. Via Candini, 2 Calderara di Reno (BO) Italy N2468...
  • Page 10 La luce laser è visibile Die Laserstrahlung ist für Le rayon laser est visible La luz láser es visible al all'occhio umano e das menschliche Auge à l'oeil nu et il est émis ojo humano y es emitida viene emessa dalla sichtbar und wird am par la fenêtre désignée por la ventana indicada...
  • Page 11 ITALIANO Le seguenti informazioni vengono fornite dietro direttive delle autorità internazionali e si riferiscono all’uso corretto del terminale. NORMATIVE STANDARD PER LA SICUREZZA LASER Questo prodotto risulta conforme alle normative vigenti sulla sicurezza laser alla data di produzione: CDRH 21 CFR 1040 e EN 60825-1. Non si rende mai necessario aprire l’appa-recchio per motivi di installazione, utilizzo o manutenzione.
  • Page 12 FRANÇAIS Les informations suivantes sont fournies selon les règles fixées par les autorités internationales et se refèrent à une correcte utilisation du terminal. NORMES DE SECURITE LASER Ce produit est conforme aux normes de sécurité laser en vigueur à sa date de fabrication: CDRH 21 CFR 1040 et EN 60825-1.

  • Page 13: Radio Compliance

    For RadioReady versions, the correct conformity label for your radio model must be applied to the DL9600 Viper™ terminal to indicate that the terminal is in conformity with the directives related to the DL9600 Viper™/RF version.

  • Page 14: Fcc Compliance

    FCC COMPLIANCE This compliance refers only to the DL9600 Viper™ batch version. This device complies with PART 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference which may cause undesired operation.

  • Page 15: General View

    GENERAL VIEW Key: A) Good Read LED B) Keyboard status/Battery low LED C) Display D) Charging status LED E) Keyboard Connector for direct RS232 connection and battery charging G) Laser beam output window H) Recharge contacts for CC9600 cradle Trigger IrDA port xiii...

  • Page 17: Introduction

    DL9600 VIPER™ TERMINAL DESCRIPTION Belonging to the Datalogic Mobile@work™ family of rugged portable terminals, the DL9600 Viper™ is a powerful pistol grip terminal, based on PC-like architecture and RadioReady concept. Viper™ has been conceived to match the demanding requirements of harsh environments found in industrial applications, with no compromises in terms of reliability and robustness.
  • Page 18 DL9600 VIPER™ Key: A) Good Read LED B) Keyboard status/Battery low LED C) Display D) Charging status LED E) Keyboard Connector for direct RS232 connection and battery charging G) Laser beam output window H) Recharge contacts for CC9600 cradle Trigger...

  • Page 19: Package Contents

    INTRODUCTION PACKAGE CONTENTS The DL9600 terminal package contains: − 1 DL9600 terminal; − 1 user’s manual and attached documentation; − 1 CD-ROM Mobile@work containing Software Development System and Utility programs − 1 rechargeable battery pack; − Models including terminal emulation software may also include terminal-specific keyboard overlays.

  • Page 20: Accessories

    DL9600 VIPER™ ACCESSORIES Cradle 94A154841 CC9600 Transceiver charger Battery charger and optical transceiver for connections between terminal and host computer in RS232 and RS485. Charger 94A154840 MBC9600 multi-slot battery charger (4 slots) Batteries 94ACC4661 B-9600 LI BATTERY PACK 1800 mAh@7.2 V 94ACC4660 B-9600 NM BATTERY PACK 1000 mAh@7.2 V...

  • Page 21: Connections

    CONNECTIONS CONNECTIONS TERMINAL CONNECTION TO THE HOST COMPUTER Before continuing with this phase be sure both the computer and the DL9600 terminal are turned off. CAUTION 2.1.1 Connection Through CC9600 Cradle The terminal can be connected to a Host through the CC9600 cradle by means of an RS232 interface (with or without an Eavesdrop line), or an RS485 Multidrop interface.

  • Page 22: Rf Connection

    DL9600 VIPER™ 2.1.3 RF Connection DL9600 RF versions can communicate with the host using the on-board radio frequency module and an Access Point connected to the host computer. Key: A) DL9600 terminal B) Access point...

  • Page 23: Connection Cables

    CONNECTIONS CONNECTION CABLES The following cable is listed with its order number. RS232 Direct Connection: CAB-4001 (cable 94A054300) HOST/PC side DL9600 side 9-PIN 7-PIN (female) (male) VEXT Supply jack...

  • Page 24: Bios Setup Menu

    DL9600 VIPER™ BIOS SETUP MENU GENERAL INFORMATION The DL9600 terminal is very versatile and can be adapted to suit many special requirements by configuring certain parameters which can be changed after the DL9600 terminal’s boot sequence. The activities of accessing the parameters and their modification are commonly referred to as DL9600 terminal setup activities.

  • Page 25: Password

    BIOS SETUP MENU PASSWORD The password mechanism is used for protecting access to DL9600 terminal parameters. If BSETUP.EXE is run with the -C option, it will warn the user about an eventual CMOS corruption before asking for the password. No password is required to be warned about the CMOS memory.

  • Page 26: Changing The Values Of The Menu Items

    DL9600 VIPER™ CHANGING THE VALUES OF THE MENU ITEMS To change the values of the menu items, you must use the DL9600 terminal keyboard. To change an item, first go to its page and then select it by moving the dot.

  • Page 27: Structure Of The Dl9600 Setup

    BIOS SETUP MENU STRUCTURE OF THE DL9600 SETUP PAGES The tables below describe the SETUP pages which are available as well as the SETUP items relating to each page. In the VALUES column, an asterisk or a value in parenthesis indicates the default value.
  • Page 28 DL9600 VIPER™ Scrolling Mode The DL9600 has a CGA compatible display adapter and allows the application to write on a virtual 25 lines by 80 columns display. On the other hand, the user can see only a portion of this virtual display at a time, which we call the physical display.

  • Page 29: Devices

    BIOS SETUP MENU 3.6.2 Devices ITEM VALUES DESCRIPTION NOTES CPU high 8 MHz Clock frequency in ON state See description of 16 MHz (*) Power 32 MHz Management for further information Com 1 Elect+wake (*) Select type and use of COM1 Optical Electrical Keyboard...

  • Page 30: Power

    DL9600 VIPER™ 3.6.3 Power ITEM VALUES DESCRIPTION Automatic On (*) Enable automatic power management Low speed 1 MHz (*) Clock frequency in IDLE state 2 MHz 4 MHz 8 MHz High->low tout 1/8 s (*) Select the period without Primary activity (see...

  • Page 31: Activities

    BIOS SETUP MENU 3.6.4 Activities The primary activities cause the CPU to pass to High speed, while the secondary ones allow the CPU to stay in Low speed if they are already in this state (see par. 3.6.3). ITEM VALUES DESCRIPTION Com1 Primary (*)

  • Page 32: Exit Menu

    DL9600 VIPER™ EXIT MENU ITEM DESCRIPTION NOTES CMOS+EEPROM Saves the new values in the Press [S] to activate the Save & Exit CMOS memory and function. EEPROM memory and exits. CMOS Save & Exit Saves the new values in the Press [C] to activate the CMOS memory and exits.

  • Page 33: Use And Functioning

    USE AND FUNCTIONING USE AND FUNCTIONING The use of the DL9600 terminal is subordinate to the application software loaded. Once an application is loaded, barcode scanning can be performed by pressing the trigger button. TERMINAL STARTUP The DL9600 terminal turns on when the [ON/OFF] key or trigger is pressed. For batch models, the prompt is displayed or if present the application program starts.

  • Page 34: Barcode Scanning

    DL9600 VIPER™ BARCODE SCANNING 4.2.1 Linear Barcode Scanning To scan linear barcodes, point the DL9600 terminal laser beam onto the code from a distance within the reading range while pressing the trigger. See the reading diagrams in chapter 6 for the reading range of your model.

  • Page 35: Barcode Scanning

    USE AND FUNCTIONING 4.2.2 2D Barcode Scanning To scan 2D barcodes, point the DL9600 terminal laser beam onto the code from a distance within the reading range while pressing the trigger. See the reading diagrams in chapter 6 for the reading range of your model. The lighted band emitted by the laser must completely intercept the barcode as shown in the figure below.

  • Page 36: Description Of The Keys (32-Key Models)

    DL9600 VIPER™ DESCRIPTION OF THE KEYS (32-KEY MODELS) This version of the DL9600 terminal provides a keyboard having a total of 32 keys. The keyboard can be divided as follows: Display control and power keys General and special keys 4.3.1 Display Control and Power Keys Enters or exits the OFF state.

  • Page 37: Key Selection

    USE AND FUNCTIONING 4.3.2 Key Selection The following image shows the function, numeric and special keys provided on the keyboard: A A A A B B B B C C C C D D D D H H H H SCRL SCRL SCRL...

  • Page 38: Special Key Sequences

    DL9600 VIPER™ Each section corresponds to a symbol that can be obtained using the corresponding keyboard method according to the following scheme: A) function of the key when preceded by a SHIFT key press; B) function of the key when preceded by a FUNC key press;...
  • Page 39 USE AND FUNCTIONING The FUNC and CTRL key press preceding any keyboard M M M M key corresponds to the CTRL + key press on the PC. FUNC CTRL Ex.: FUNC - CTRL - F8 corresponds to CTRL - F8 on a PC. N N N N The SHIFT key press preceding any keyboard key enables SHIFT...

  • Page 40: Description Of The Keys (48-Key Models)

    DL9600 VIPER™ DESCRIPTION OF THE KEYS (48-KEY MODELS) This version of the DL9600 terminal provides a keyboard having a total of 48 keys. The keyboard can be divided as follows: Display control and power keys General and special keys 4.4.1 Display Control and Power Keys Enters or exits the OFF state.

  • Page 41: Key Selection

    USE AND FUNCTIONING 4.4.2 Key Selection The following image shows the alphabetic, numeric and special keys provided on the keyboard: SCROLL “ ‘ SCRLK PRTSC ; ; ; ; : : : : \ \ \ \ > > > > <...

  • Page 42: Special Key Sequences

    DL9600 VIPER™ Each section corresponds to a symbol that can be obtained using the corresponding keyboard method according to the following scheme: function of the numeric key when preceded by a SHIFT key press; if pressing an alphabetic key after the SHIFT key, it switches between lower and upper case characters;...
  • Page 43 USE AND FUNCTIONING STAT If the CTLPANEL.EXE TSR is run, this sequence FUNC activates it by default (see par. 4.5 for details). On the DL9600, the [SHIFT] key corresponds to the PC one. By pressing it with alphabetic keys it allows CAPSLK switching between upper and lower case characters.

  • Page 44: Control Panel

    DL9600 VIPER™ CONTROL PANEL If the CTLPANEL.EXE TSR runs, it is possible to visualize the control panel on the DL9600 display by pressing the FUNC - ENTER sequence (48-Key models) or the FUNC - TAB sequence (32-Key models): You can manage each item by directly pressing the following keys: <arrow up>...

  • Page 45: Status Indicators

    USE AND FUNCTIONING STATUS INDICATORS The DL9600 provides three different LEDs and a beeper signaling the terminal status. STATUS Green pulse it goes on for a few seconds when the Charging status external supply or the battery supply has (right side) been recognized.

  • Page 46: Maintenance

    DL9600 VIPER™ MAINTENANCE Rechargeable battery packs are not initially charged. Therefore the first operation to perform is to charge them. See par. 5.1. NOTE CHARGING THE BATTERIES The battery autonomy varies according to factors, such as the frequency of barcode scanning, the RF usage and of BIOS settings.

  • Page 47: Replacing The Batteries

    MAINTENANCE REPLACING THE BATTERIES To correctly replace the batteries, proceed as follows. Turn off the DL9600 terminal. Press the lock button as indicated in the figure below: Remove the battery pack by pulling down the lower part of the handle:...

  • Page 48: Cleaning The Terminal

    DL9600 VIPER™ Replace the battery pack, insert and press it back into the handle until the lock button is automatically closed: Dispose of the old batteries as required by the relevant laws in force. CAUTION CLEANING THE TERMINAL Periodically clean the DL9600 terminal with a slightly dampened cloth.

  • Page 49: Technical Features

    TECHNICAL FEATURES TECHNICAL FEATURES TECHNICAL DATA DL9600 Std DL9600 LR DL9600 2D Optical Features 0.13 mm / 5 mils 0.25 mm / 10 mils 0.17 mm / 6.6 mils Maximum resolution ± 55 ° ± 60° ± 30° Skew angle ±...

  • Page 50: Reading Diagrams

    DL9600 VIPER™ Environmental Features Working temperature -20° to +50 °C / -4° to 122 °F -20° to +70 °C / -4° to 158 °F Storage temperature 90% non condensing Humidity IP65 Protection 4 KV contact discharge, 8 KV air discharge ESD protection 1.8 m / 5.9 ft...
  • Page 51 TECHNICAL FEATURES Long Range Reading Zones (10° skew angle) 0.38 mm (15 mils) 0.50 mm (20 mils) 0.25 mm (10 mils) 1 mm (40 mils) 2000 mm 1000 1200 1400 1600 1800 Reading Zones (10° skew angle) PDF417 Code 0.17 mm (6.6 mils) 0.38 mm (15 mils)

  • Page 52: Glossary

    Access Point A device that provides transparent access between Ethernet wired networks and IEEE 802.11 interoperable radio-equipped mobile units (MUs). Datalogic hand-held computers, or other devices equipped with a PCMCIA slot, communicate with wired networks using Access Points (AP). The mobile unit may roam among the APs in the same subnet while maintaining a continuous, seamless connection to the wired network.
  • Page 53 A low power electronic light source commonly used as an indicator light. It uses less power than an incandescent light bulb but more than a Liquid Crystal Display (LCD). Random Access Memory. Data in RAM can be accessed in random order, and quickly written and read. Radio Frequency. Terminal A Datalogic portable computer product.

  • Page 54: Index
