QUICK REFERENCE GUIDE
This manual illustrates Local Lonworks network applications. For other types of installations,
such as ID-NET™, Pass-Through, Multiplexer Layout, etc., refer to the DX6400 Reference
Manual available on the CD. For complete scanner configuration using the Genius™
configuration program refer to the Help On Line.
NOTE
DX6400
821001218 (Rev. J)

Advertisement

Table of Contents
loading

Related Manuals for Datalogic DX6400

Summary of Contents for Datalogic DX6400

  • Page 1 QUICK REFERENCE GUIDE This manual illustrates Local Lonworks network applications. For other types of installations, such as ID-NET™, Pass-Through, Multiplexer Layout, etc., refer to the DX6400 Reference Manual available on the CD. For complete scanner configuration using the Genius™ configuration program refer to the Help On Line.

  • Page 2: Services And Support

    - Material Return Authorization LEGAL NOTICES © 2003 - 2012 Datalogic Automation S.r.l.  ALL RIGHTS RESERVED.  Protected to the fullest extent under U.S. and international laws. Copying, or altering of this document is prohibited without express written consent from Datalogic Automation S.r.l.
  • Page 3 DX6400 QUICK GUIDE DX6400 GENERAL VIEW Figure A Laser Beam Output Window Laser Safety Label Standard Figure B Programming Keypad TX Data LED (Green) Phase On LED (Yellow) Power On LED (Red) LCD Display Ethernet Figure C Lonworks 9-pin Male Connector...
  • Page 4 DX6400 QUICK GUIDE CONNECTIVITY Examples of the most common system layouts are shown in this section, for additional layouts refer to the Reference Manual. Local Lonworks Networks CAB-Sxx CAB-610x CBX100** BT-6000 Master Local Host I/O, AUX Slave 1 P.S.* BT-6000 PWR-120 P.S.

  • Page 5: Network Termination

    When building a local Lonworks system the network must be properly terminated by positioning a BT-6000 terminator on the DX6400 Standard master reader (BT-6000 female side) and on the last slave reader (BT-6000 male side). For Fieldbus models, (Lonworks master-only), the bus is internally terminated (no BT-6000).

  • Page 6: Electrical Connections

    The details of the connector pins are indicated in the following tables: The table below gives the pinout of the CBX100/CBX500 terminal block connectors. Use this pinout when the DX6400 reader is connected by means of the CBX100/CBX500: CBX100/500 Terminal Block Connectors...
  • Page 7 DX6400 QUICK GUIDE The DX6400 scanner provides a 25-pin (26-pin for Ethernet models) male D-sub connector for connection to power supply, Host interface (Main and Aux), and input/output signals. 25-pin / 26-pin D-Sub Connector Pinout Name Function Chassis - internally connected to GND...

  • Page 8: Technical Features

    DX6400 QUICK GUIDE Ethernet Model M12 D-coded Ethernet Connector DX6400 RJ45 D-coded T X- R X- M12 D-coded Female Connector APPENDIX TECHNICAL FEATURES ELECTRICAL FEATURES Supply Voltage 15 to 30 Vdc Power Consumption 18 W typical 1.5 to 0.7 A max. (including startup current)

  • Page 9: Model Description

    Protection Class – EN 60529 IP64 PHYSICAL FEATURES Mechanical Dimensions 225.9 x 149.8 x 116.8 mm (8.89 x 5.90 x 4.60 in) 2.1 kg. (4.62 lbs) Weight MODEL DESCRIPTION DX6400 - 100 - 0XX Decoder Model 10 = Master/Slave 12 = Ethernet...
  • Page 10 Brackets FBK-6000 Fast bracket kit (2 pcs) 93ACC1721 * DX6400 application software does not support any of the CBX500 Host Interface Module accessories nor the BM150 Display accessory. Use the CBX800 Gateway for Host Interface Applications, (Fieldbus and non Fieldbus).

  • Page 11: Mechanical Installation

    DX6400 QUICK GUIDE MECHANICAL INSTALLATION The DX6400 reader can be positioned and installed in the best way possible as a result of the patented Step-A- Head feature. Thanks to the separation between Head and Base, you can modify the orientation of the decoder base, and therefore display-keypad and connector panels, while keeping the optic head in the correct reading position.

  • Page 12: Flash™ Dynamic Focus

    FLASH™ DYNAMIC FOCUS The DX6400 has an innovative linear motor designed to control the focus position of the scanner via software. This dynamic system, called FLASH™, is able to move the focus position rail to rail, from the minimum position to the maximum position.

  • Page 13: Reading Conditions

    DX6400 QUICK GUIDE READING CONDITIONS  ANSI Grade B minimum  600 scans/sec per leg The following tables describe the requirements for standard applications. Minimum Code Height for Omnidirectional Reading (mm) Conveyor Speed (m/s) 0.38 2/5 Inteleaved 0.50 Code Resolution (mm) 0.60...

  • Page 14: Reading Diagrams

    -120 -130 -140 -150 -160 -170 -180 (in) (cm) Note: x = 0 and z = 0 correspond to the edge of the DX6400 scanner as shown in the figure above. CONDITIONS Code = Interleaved 2/5 or Code 39 PCS = 0.90 DX6400-100-0XX –...

  • Page 15: Laser Safety

    DX6400 QUICK GUIDE COMPLIANCE See the DX6400 Reference Manual for the Declaration of Conformity. LASER SAFETY Figure A Figure B Laser Safety Label Warning and Device Class Label Identification Label The scanner is classified as a Class 2 laser product according to EN 60825-1 regulations and as a Class II laser product according to CDRH regulations.

  • Page 16: Power Supply

    FCC COMPLIANCE Modifications or changes to this equipment without the expressed written approval of Datalogic could void the authority to use the equipment. This device complies with PART 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference which may cause undesired operation.
