Summary of Contents for Datalogic PowerScan D8330

  • Page 2 An Unpublished Work - All rights reserved. No part of the contents of this documentation or the procedures described therein may be reproduced or transmitted in any form or by any means without prior written permission of Datalogic Scanning, Inc. or its subsidiaries or affiliates ("Datalogic" or “Datalogic Scanning”).

  • Page 3: Table Of Contents

    Master BC-8000 Network Troubleshooting ..........23 CONFIGURATION..................24 Configuration Methods ................24 4.1.1 Reading Configuration Barcodes ..............24 4.1.2 Using Datalogic Aladdin™ ................24 4.1.3 Copy Command ..................24 4.1.4 Sending Configuration Strings from Host ............ 25 Setup Procedures ..................25 ®...
  • Page 4 ® PowerScan M8300/STAR-System™ Setup ..........31 BC-8000 STAR-System™ Network Setup ..........33 Interface Selection ..................35 USB Reader Configuration................38 4.10 Changing Default Settings ................40 REFERENCES ..................139 RS-232 Parameters .................. 139 5.1.1 Handshaking ..................... 139 5.1.2 ACK/NACK Protocol ................. 140 5.1.3 FIFO......................
  • Page 5 5.9.1 Radio Protocol Timeout ................158 5.9.2 Radio RX Timeout..................159 5.9.3 Power-Off Timeout..................159 5.9.4 Transmission Mode................... 160 5.9.5 Beeper Control for Radio Response ............160 5.9.6 Single Store ....................161 5.9.7 Batch Mode....................161 ® 5.9.8 Find Me (PowerScan M8300 only) ............

  • Page 6: General View

    GENERAL VIEW ® POWERSCAN D8330/M8300 READERS LEDs ® POWERSCAN D8330 Cable Connector ® POWERSCAN M8300 Battery Cover Laser Output Window Trigger ® Figure A – PowerScan D8330/M8300 Series Readers LEDs Keypad Display Laser Output Window ® Figure B – PowerScan M8300 Series Readers with Display...
  • Page 7 BC-80X0 / C-8000 CRADLES Scan Finder Button LEDs Figure C – BC-8000 The label on the cradle contains LED indicators and a scan finder button. When the button is pressed, the cradle transmits a “broadcast” message. All properly configured scanners (Radio RX Timeout set to keep the radio “awake”) linked to that base (through a bind or a join sequence) and within radio range coverage will emit a beep sequence once every 2 seconds for 30 seconds.

  • Page 9: Introduction

    INTRODUCTION INTRODUCTION ® Datalogic renews its range of industrial laser scanners introducing the PowerScan ® ® family: PowerScan D8330 and PowerScan M8300. Robustness and ergonomics remain unsurpassed: clearly audible beeper and bright "good read" LEDs for areas where noise levels are normally high; the aim mode, which helps point to the right ®...

  • Page 10: Installation

    ® POWERSCAN D8330/M8300 INSTALLATION Connections should always be made with power OFF! CAUTION ® POWERSCAN D8330 INTERFACE CABLE CONNECTIONS ® The PowerScan D8330 reader incorporates a multi-standard interface, which can be connected to a Host by plugging the correct interface cable into the connector and closing the cable cover.
  • Page 11 INSTALLATION Follow the given procedure for correct cable insertion: Align Notch Arrow Slip the cover over the cable. Push the plastic boot into the rubber gasket. Take care that the tab on the plastic boot is aligned with the notch in the rubber gasket. Push the plastic boot and gasket into the handle.

  • Page 12: Bc-80X0 Interface Cable Connections

    ® POWERSCAN D8330/M8300 BC-80X0 INTERFACE CABLE CONNECTIONS Power Interface Cable BC-80X0 Connectors The BC-80X0 incorporates a multi-standard interface, which can be connected to a Host by simply plugging the correct interface cable into the Host connector, placed on the base of the cradle. In addition the cradle must be connected to an external power supply.

  • Page 13: Connection

    INSTALLATION RS-232 CONNECTION (if required)

  • Page 14: Ibm Usb Pos

    ® POWERSCAN D8330/M8300 IBM USB POS (if required)

  • Page 15: Wedge Connection

    INSTALLATION WEDGE CONNECTION PEN EMULATION CONNECTION...

  • Page 16: Network Connections

    RS-232, USB, Wedge, (BC-8060only) PEN Emulation All cradles are connected together within the bus system through the Datalogic RS-485 splitter cable (CAB-428, part number 90A051950), which must be inserted in the RS-485 cradle connector. Obviously cable length is to be kept to a minimum as with all bus systems.

  • Page 17: Network Cabling

    INSTALLATION 2.8.2 Network Cabling The Multidrop line is made using RJ45 connectors and a cable having the following specifications: • twisted pair AWG 24 wires • 120 Ω impedance • maximum network cable length 1200 meters Function Multidrop Cables RS-485 + Pin 1 Data RS-485 -...

  • Page 18: Network Termination

    ® POWERSCAN D8330/M8300 2.8.3 Network Termination The first and last cradles of the chain (the two ends of the bus) must be properly terminated. The cradle has an internal terminator that can be selected via jumper. For this selection you must open the device. No Termination Static Dynamic...

  • Page 19: Powerscan ® M8300 Battery Maintenance

    INSTALLATION ® POWERSCAN M8300 BATTERY MAINTENANCE 2.9.1 Battery Charging ® Once the system is connected and powered, you can place the PowerScan M8300 into the cradle to charge the battery. When the reader is correctly inserted in the cradle, the "Reader" red LED on the cradle goes on to indicate that the battery is charging.

  • Page 20: 2.10 Mounting The Bc-80X0 / C-8000 Cradle

    ® POWERSCAN D8330/M8300 2.10 MOUNTING THE BC-80X0 / C-8000 CRADLE The cradle package contains the following items: BC-80X0 / C-8000 Cradle BC-80X0 Quick Reference / C-8000 Quick Reference BC-8000 Antenna 2 wall-mounting lock hinges 2 adhesive strips 4 rubber feet 1 horizontal base 1 inclined base The cradle (either BC-80X0 or C-8000) can be mounted for portable or fixed desktop...

  • Page 21: Desktop Mounting

    INSTALLATION 2.10.1 Desktop Mounting For desktop usage, you can mount the cradle either on the horizontal base, for reduced overall dimensions, or on the inclined base for a more ergonomic taking out and insertion of the reader onto the cradle. Horizontal base Rubber Foot Mounting...

  • Page 22: Fixed Desktop Use

    ® POWERSCAN D8330/M8300 Portable Desktop Use Correctly position the BC-80X0/C-8000 onto the base by sliding it along the mounting tabs until aligned. Carefully clean the rubber foot seats of the base to remove any impurities that could reduce adhesion. Remove the protective plastic from the rubber feet and stick them onto the bottom surface of the base.
  • Page 23 INSTALLATION Position the cables to be connected to the BC-80X0/C-8000 cradle along the dedicated channels, as shown in the figures below: Horizontal Base Inclined Base Remove the plastic from the other side of the strips and affix the base to the table.

  • Page 24: Wall Mounting

    ® POWERSCAN D8330/M8300 2.10.2 Wall Mounting Remove the yellow caps and insert the two wall mounting lock hinges provided with your cradle. Position the cables to be connected to the BC-80X0/C-8000 cradle along the dedicated channels (see figures at page 14).
  • Page 25 INSTALLATION If using the adhesive strips: If using the mounting screws: Carefully clean the adhesive strip Using the mounting holes on the seats of the base to remove any base as a pattern, mark the wall impurities that could reduce where you desire to mount the BC- adhesion.

  • Page 26: Stand-Alone Layouts

    ® POWERSCAN D8330/M8300 ® POWERSCAN M8300 SYSTEM AND NETWORK LAYOUTS There are two basic system layouts that can be employed: Stand-alone systems (including Point-to-Point layouts) and Multidrop STAR-System™ Networks. STAND-ALONE LAYOUTS 3.1.1 Point-to-Point Reader Layout ® PowerScan M8300 BIND Host BC-80X0 3.1.2 Stand-Alone Layout with Multiple Readers...

  • Page 27: Multiple Stand-Alone Layouts

    ® POWERSCAN M8300 SYSTEM AND NETWORK LAYOUTS 3.1.3 Multiple Stand-Alone Layouts Many stand-alone connections can operate in the same physical area without interference, provided all readers and cradles in the system have different addresses. JOIN ® PowerScan M8300 ® PowerScan JOIN M8300 Host...

  • Page 28: C-Box Layout

    ® POWERSCAN D8330/M8300 3.1.4 C-BOX Layout ® PowerScan M8300 JOIN Scanner BIND C-Box BC-80X0 System cables to Host In this layout the BC-80X0 cradle is connected by a dedicated cable using the RS-232 interface to a C-BOX connection box as part of a fixed scanner network. This allows the flexibility of a hand-held reading station integrated into a variety of fixed scanning applications so that all readers (both fixed and hand-held), in the system provide communications to the Host.

  • Page 29: Multidrop Star-System™ Network Layouts

    The Slaves at the ends of the network must be terminated (see the STARGATE™ and STAR-Box™ Installation Manuals and par. 2.8.3). See par. 4.6 and 4.7 or the Datalogic Aladdin™ Help On-Line for system configuration specifications.

  • Page 30: Bc-8000 Master Layout

    STARGATE™ base stations can also be used as slaves in this network. The devices at the ends of the network must be terminated (see par. 2.8.3). See pars. 4.6 and 4.7 or the Datalogic Aladdin™ Help On-Line for system configuration specifications.

  • Page 31: Master Bc-8000 Network Troubleshooting

    ® POWERSCAN M8300 SYSTEM AND NETWORK LAYOUTS 3.2.3 Master BC-8060 Network Troubleshooting Two diagnostic strings can be sent via RS-232 from the Host to the Master cradle in order to have feedback about the network itself. #+LSlave Returns a list of all the Slaves recognized at boot up. Example: In a network where the Master cradle has address 0188 and one Slave cradle with address 0001, the response is:...

  • Page 32: Configuration

    Using Datalogic Aladdin™ Datalogic Aladdin™ is a multi-platform utility program providing a quick and user- friendly configuration method via the RS-232/USB-COM interface. It also allows upgrading the software of the connected device (see the Datalogic Aladdin™ Help On-Line for more details). 4.1.3...

  • Page 33: Sending Configuration Strings From Host

    CONFIGURATION 4.1.4 Sending Configuration Strings from Host An alternative configuration method is provided in Appendix A using the RS-232 interface. This method is particularly useful when many devices need to be configured with the same settings. Batch files containing the desired parameter settings can be prepared to configure devices quickly and easily.

  • Page 34: Powerscan D8330 Setup

    ® POWERSCAN D8330/M8300 ® POWERSCAN D8330 SETUP Read the restore default parameters code below. ® Restore PowerScan D8330 Default Ì$+$*oÎ After reading the above code, go to par. 4.8 Interface Selection. ® POWERSCAN M8300/BC-80X0 POINT-TO-POINT SETUP A rapid configuration procedure has been devised for point-to-point applications where a single reader is associated exclusively with its own BC-80x0 base station and where it is not necessary to set the Date and Time parameters.

  • Page 35: M8300/Bc-80X0 Stand-Alone Setup

    CONFIGURATION ® POWERSCAN M8300/BC-80X0 STAND-ALONE SETUP Read the restore default parameters code below. ® Restore PowerScan M8300 Default Ì$+$*oÎ ® Follow the procedure below to set the radio address and bind PowerScan M8300 to the BC-80X0 cradle. Enter Configuration Ì$+;Î Set Date ÌIA%Î...
  • Page 36 ® POWERSCAN D8330/M8300 Set Radio Address ÌRA0RFHÎ ® four digits for the PowerScan M8300 Address (from 0000 to 1999). All readers used in the same area must have different addresses. Exit and Save Configuration Ì$-?Î ® Read the Bind code to pair the PowerScan M8300 to the BC-80X0 cradle.

  • Page 37: Using Multiple M-Series Readers With Same Cradle

    CONFIGURATION Read the BC-80X0 restore default code: Restore BC-80X0 Default Ì$+RX0$-qÎ Go to par. 4.8 Interface Selection. 4.5.1 Using Multiple M-Series Readers with Same Cradle If you want to use several M-Series readers with the same BC-80X0 cradle, you must first Bind the cradle with one of the readers (see previously described configuration procedure).

  • Page 38: Powerscan ® M8300/Star-Modem™ In Stand-Alone Mode

    ® POWERSCAN D8330/M8300 ® 4.5.2 PowerScan M8300/STAR-Modem™ in Stand-Alone Mode ® To configure a PowerScan M8300 reader to communicate with STAR-Modem™ in Stand-alone Mode, follow the procedure in par. 4.5 substituting steps 6 and 7 with those below: STAR-Modem™ Address ÌRSRÎ...

  • Page 39: Powerscan ® M8300/Star-System™ Setup

    CONFIGURATION ® POWERSCAN M8300/STAR-SYSTEM™ SETUP ® The following procedure allows configuring a PowerScan M8300 reader to communicate with various STAR-System™ devices such as STARGATE™ RF base stations. ® Restore PowerScan M8300 Default Ì$+$*oÎ Enter Configuration Ì$+;Î Set Date ÌIA%Î six digits for Day, Month and Year (DDMMYY) Set Time ÌIB'Î...
  • Page 40 ® POWERSCAN D8330/M8300 Set Radio Address ÌRF8Î four digits from the Numeric Table in the range 0000-1999. All readers must have different addresses. First STAR-System™ Address ÌRSRÎ Read the code above and the four-digit address of the First STAR-System™ device in the system. Set Last STAR-System™...

  • Page 41: Bc-8000 Star-System™ Network Setup

    CONFIGURATION BC-8060 STAR-SYSTEM™ NETWORK SETUP When the BC-8060 cradle model is used in an RS-485 network, it must be initially configured. To do this using configuration barcodes, follow the procedure below ® using any PowerScan M8300 reader. Set BC-8060 Address Ì$+RF4Î...
  • Page 42 For BC-8060 Master Network Layouts (see par. 3.2), The network configuration parameters can be changed either through the Datalogic Aladdin™ configuration software running on the PC or by reading the barcode selections in the Network section of this manual starting on page 64. If using configuration barcodes, it is ®...

  • Page 43: Interface Selection

    CONFIGURATION INTERFACE SELECTION Read the interface selection code for your application. RS-232 Standard Ì$+CP0$-$Î POS TERMINALS Nixdorf Mode A Ì$+CM2EC0$->Î Fujitsu Ì$+CM1$-ÈÎ ICL Mode Ì$+CM0$-ÃÎ For POS terminal default settings refer to par. 5.15. Ì$+CP6$-BÎ...
  • Page 44 ® POWERSCAN D8330/M8300 WEDGE IBM AT or PS/2 PCs Ì$+CP500$-aÎ IBM XT Ì$+CP503$-vÎ PC Notebook Ì$+CP505$-ÈÎ IBM SURE1 Ì$+CP506$-$Î IBM Terminal 3153 Ì$+CP504$-}Î IBM Terminals 31xx, 32xx, 34xx, 37xx: To select the interface for these IBM Terminals, read the correct KEY TRANSMISSION code. Select the KEYBOARD TYPE if necessary (default = advanced keyboard).
  • Page 45 CONFIGURATION WEDGE (CONTINUED) ALT MODE The ALT-mode selection allows barcodes sent to the PC to be interpreted correctly independently from the Keyboard Nationality used. You do not need to make a Keyboard Nationality selection. (default = Num Lock Unchanged). Make sure the Num Lock key on your keyboard is ON.

  • Page 46: Usb Reader Configuration

    Load drivers from the O.S. (if requested). When configuring the USB-COM interface, the relevant files and drivers must be installed from the USB Device Installation software, which can be downloaded from the web page http://www.scanning.datalogic.com. The device is ready. Successive start-ups will automatically recognize the previously loaded drivers.
  • Page 47 USB-KBD Ì$+UA03$-:Î USB-KBD-ALT-MODE Ì$+UA04$-@Î USB-KBD-APPLE Ì$+UA05$-FÎ USB-COM* Ì$+UA02$-4Î USB-IBM-Table Top Ì$+UA00$-(Î USB-IBM-Hand Held Ì$+UA01$-.Î When configuring USB-COM, the relevant files and drivers must be installed from the USB Device Installation software, which can be downloaded from the web site http://www.scanning.datalogic.com.

  • Page 48: Changing Default Settings

    ® POWERSCAN D8330/M8300 4.10 CHANGING DEFAULT SETTINGS Once your reader is setup, you can change the default parameters to meet your application needs. Refer to the preceding paragraphs for initial configuration in order to set the default values and select the interface for your application. In this manual, the configuration parameters are divided into logical groups making it easy to find the desired function based on its reference group.

  • Page 49: Handshaking

    RS-232 PARAMETERS ® All PowerScan D8330 Series readers ® PowerScan M8300/BC-80X0 configurations only ARITY ANDSHAKING ROTOCOL NTER CHARACTER ELAY IMEOUT ERIAL RIGGER Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of...
  • Page 50 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS-232 300 baud ÌCD1XÎ 600 baud ÌCD2[Î 1200 baud ÌCD3^Î 2400 baud ÌCD4aÎ 4800 baud ÌCD5dÎ 9600 baud ÌCD6gÎ 19200 baud ÌCD7jÎ 38400 baud ÌCD8mÎ ARITY none ÌCC0SÎ even parity ÌCC1VÎ odd parity ÌCC2YÎ...
  • Page 51 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS-232 7 bits ÌCA0OÎ 8 bits ÌCA1RÎ 9 bits ÌCA2UÎ 1 stop bit ÌCB0QÎ 2 stop bits ÌCB1TÎ ANDSHAKING disable ÌCE0WÎ hardware (RTS/CTS) ÌCE1ZÎ software (XON/XOFF) ÌCE2]Î RTS always ON ÌCE3`Î See par. 5.1.1 for details.

  • Page 52: Fifo

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS-232 ROTOCOL disable ÌER0sÎ enable ÌER1vÎ ® See par. 5.1.2 for details, particularly on implementing this parameter with PowerScan M8300. FIFO disable ÌEC0UÎ enable ÌEC1XÎ See par. 5.1.3 for details. NTER CHARACTER ELAY delay between characters transmitted to Host ÌCK3Î...

  • Page 53: Rx Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS-232 IMEOUT timeout control in reception from Host ÌCL5Î Read 2 numbers from the table where: 00 = TIMEOUT disabled 01-99 = TIMEOUT from .1 to 9.9 seconds rx timeout 5 seconds See par.

  • Page 54: Usb Parameters

    USB PARAMETERS USB-COM Handshaking, Ack/Nack protocol, FIFO, Inter-character delay, Rx timeout, Serial trigger lock USB-KBD Keyboard nationality, FIFO, Inter-character delay, Inter-code delay, USB keyboard speed USB-IBM No parameter selection required. Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups.
  • Page 55 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-COM ANDSHAKING disable ÌCE0WÎ hardware (RTS/CTS) ÌCE1ZÎ software (XON/XOFF) ÌCE2]Î RTS always ON ÌCE3`Î See par. 5.1.1 for details. ROTOCOL disable ÌER0sÎ enable ÌER1vÎ ® See par. 5.1.2 for details, particularly on implementing this parameter with PowerScan M8300.
  • Page 56 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-COM NTER CHARACTER ELAY delay between characters transmitted to Host ÌCK3Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 milliseconds delay disabled IMEOUT timeout control in reception from Host ÌCL5Î...
  • Page 57 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-KBD EYBOARD ATIONALITY Not Available for USB-KBD-ALT-MODE Interface This parameter default value is restored through the Interface Selection code and not Restore Default. Belgian ÌFJ7yÎ English (UK) ÌFJ4pÎ French ÌFJ2jÎ German ÌFJ3mÎ Italian ÌFJ1gÎ...
  • Page 58 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-KBD The Japanese and Eastern Block Keyboard Nationality selections are valid only for IBM AT compatible PCs. Japanese ÌFJ8|Î Russian (Latin) ÌFJ9ÃÎ Russian (Cyrillic) ÌFJA0Î Hungarian ÌFJB3Î Slovenian, Croatian, Serbian (Latin) ÌFJC6Î Romanian ÌFJD9Î...
  • Page 59 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-KBD NTER CHARACTER ELAY delay between characters transmitted to Host ÌCK3Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 milliseconds delay disabled NTER CODE ELAY...

  • Page 60: Wedge Parameters

    WEDGE PARAMETERS ® All PowerScan D8330 Series readers ® PowerScan M8300/BC-80X0 configurations only EYBOARD ATIONALITY RECOGNITION NTER CHARACTER ELAY NTER CODE ELAY EYBOARD ETTING EDGE ONTROL HARACTER MULATION Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups.
  • Page 61 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE EYBOARD ATIONALITY Belgian ÌFJ7yÎ English (UK) ÌFJ4pÎ French ÌFJ2jÎ German ÌFJ3mÎ Italian ÌFJ1gÎ Spanish ÌFJ6vÎ Swedish ÌFJ5sÎ ÌFJ0dÎ...
  • Page 62 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE The Japanese and Eastern Block Keyboard Nationality selections are valid only for IBM AT compatible PCs. Japanese ÌFJ8|Î Russian (Latin) ÌFJ9ÃÎ Russian (Cyrillic) ÌFJA0Î Hungarian ÌFJB3Î Slovenian, Croatian, Serbian (Latin) ÌFJC6Î Romanian ÌFJD9Î...
  • Page 63 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE (IBM AT ECOGNITION COMPATIBLE ONLY disable ÌFP0pÎ enable ÌFP1sÎ toggle num lock ÌFL1kÎ num lock unchanged ÌFL0hÎ This selection is used together with the Alt Mode interface selection for AT or Notebook PCs. It changes the way the Alt Mode procedure is executed;...
  • Page 64 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE NTER CODE ELAY delay between codes transmitted to Host ÌFG.Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 seconds delay disabled EYBOARD ETTING ALPHANUMERIC KEYBOARD SETTING...
  • Page 65 WEDGE Some ASCII characters may be missing as this depends on the type of keyboard: these are generally particular characters relative to the various national symbologies. In this case: • The first 4 characters (Shift, Alt, Ctrl, and Backspace) can only be substituted with keys not used, or substituted with each other.
  • Page 66 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE ONTROL HARACTER MULATION Ctrl + Shift + Key ÌFO0nÎ Ctrl + Key ÌFO1qÎ...

  • Page 67: Minimum Output Pulse

    PEN EMULATION ® All PowerScan D8330 Series readers ® PowerScan M8300/BC-80X0 configurations only PERATING INIMUM UTPUT ULSE ONVERSION TO VERFLOW UTPUT EVEL EVEL NTER LOCK ELAY Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.
  • Page 68 PEN EMULATION The operating mode parameters are complete commands and do not require reading the Enter and Exit configuration codes. PERATING interpret mode Ì$]8Î Interprets commands without sending them to the decoder. transparent mode Ì$[4Î Sends commands to the decoder without interpreting them.
  • Page 69 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î PEN EMULATION INIMUM UTPUT ULSE high resolution code emulation 200 μs ÌDG0\Î 400 μs ÌDG1_Î 600 μs ÌDG2bÎ 800 μs ÌDG3eÎ 1 ms ÌDG4hÎ 1.2 ms ÌDG5kÎ low resolution code emulation See par. 5.2.1 for details.
  • Page 70 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î PEN EMULATION 39 (D8330 S ONVERSION TO ERIES disable conversion to Code 39 ÌDA0PÎ Transmits codes in their original enable conversion to Code 39 format. ÌDA1SÎ Converts codes read into Code 39 format. See par.
  • Page 71 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î PEN EMULATION UTPUT EVEL normal ÌDD0VÎ (white = logic level 0) inverted ÌDD1YÎ (white = logic level 1) See par. 5.2.4 for details. EVEL normal ÌDE0XÎ (black level) inverted ÌDE1[Î (white level) See par.

  • Page 72: Network Parameters

    NETWORK PARAMETERS BC-8060 model configurations only RS-485 N ETWORK ETWORK LAVE DDRESS ANGE ETWORK ARNING ESSAGE ECEPTION ARNING ESSAGE ASTER RADLE EADER ASTER RADLE ERMINATOR Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. Read the Exit and Save Configuration code ONCE, available at the top of each page.
  • Page 73 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î NETWORK PARAMETERS RS-485 N ETWORK disable RS-485 network ÌRZ0)Î enable RS-485 slave ÌRZ1,Î enable RS-485 master ÌRZ2/Î See par. 3.2 for details. If a BC-8060 cradle is errantly configured as a Slave but not connected to a network, it may not be able to receive further commands from the reader.

  • Page 74: Network Warning Message

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î NETWORK PARAMETERS LAVE DDRESS ANGE First Address ÌJB(Î Read the code above and the four-digit address of the First Slave device in the system. Last Address ÌJC*Î system. Read the code above and the four-digit address of the Last Slave device in the See par.
  • Page 75 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î NETWORK PARAMETERS ASTER RADLE EADER no header ÌJA00/Î one character header ÌJA013Î two character header ÌJA027Î three character header ÌJA03;Î four character header ÌJA04?Î five character header ÌJA05CÎ six character header ÌJA06GÎ seven character header ÌJA07KÎ...
  • Page 76 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î NETWORK PARAMETERS ASTER RADLE ERMINATOR no terminator ÌJA102Î one character terminator ÌJA116Î two character terminator ÌJA12:Î three character terminator ÌJA13>Î four character terminator ÌJA14BÎ five character terminator ÌJA15FÎ six character terminator ÌJA16JÎ seven character terminator ÌJA17NÎ...

  • Page 77: Data Format

    DATA FORMAT NOT FOR PEN INTERFACES DENTIFIER USTOM DENTIFIER EADER ERMINATOR PECIAL IELD DJUSTMENT IELD HARACTER ENGTH HARACTER EPLACEMENT DDRESS TAMPING DDRESS ELIMITER TAMPING ELIMITER Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of...

  • Page 78: Code Identifier Table

    (check digit tested or not, check digit tx or not, etc.). • When customizing the Datalogic Standard code identifiers, 1 or 2 identifier characters can be defined for each code type. If only 1 identifier character is required, the second character must be selected as FF (disabled).
  • Page 79 DENTIFIER define custom code identifier(s) ÌEH/Î Read the above code. (Code Identifiers default to Datalogic standard, see table on previous page). Select the code type from the code table in Appendix for the identifier you want to change. You can define 1 or 2 identifier characters for each code type. If only 1 identifier character is required, the second character must be selected as FF (disabled).
  • Page 80 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT EADER no header ÌEA00*Î one character header ÌEA01.Î two character header ÌEA022Î three character header ÌEA036Î four character header ÌEA04:Î five character header ÌEA05>Î six character header ÌEA06BÎ seven character header ÌEA07FÎ...
  • Page 81 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT ERMINATOR no terminator ÌEA10-Î one character terminator ÌEA111Î two character terminator ÌEA125Î three character terminator ÌEA139Î four character terminator ÌEA14=Î five character terminator ÌEA15AÎ six character terminator ÌEA16EÎ seven character terminator ÌEA17IÎ...
  • Page 82 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT PECIAL Available only for Wedge IBM AT-PS/2 and USB-KBD Interfaces It is necessary to define each Special Key by following the procedure given in par. 5.4.2. NOTE Select one or more of the following Special Keys according to your needs. Special Key 1 Ì9CÄÎ...
  • Page 83 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT IELD DJUSTMENT disable field adjustment ÌEF0[Î Field adjustment allows a number of characters n, to be added to or subtracted from the barcode read. The adjustment can be different for each enabled code type. To define the field adjustment: Read the enable field adjustment code: enable field adjustment...
  • Page 84 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT IELD DJUSTMENT HARACTER Read the field adjustment character code: field adjustment character ÌEG-Î Read the hexadecimal value corresponding to the character you want to use for field adjustment. Valid characters are in the range 00-FE. For Wedge and USB-KBD interfaces, it is also possible to read the Special Key(s) on page 74.
  • Page 85 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT HARACTER EPLACEMENT disable character replacement ÌEO0mÎ This parameter allows up to three characters to be replaced from the barcode read. These substitutions are stored in memory. To define each character replacement: Read one of the following character replacement codes: first character replacement ÌEO1pÎ...
  • Page 86 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT Example: The following strings define: First Character Replacement: substitution in Code 39 barcodes of all occurrences of the 0 character with the 1 character. Second Character Replacement: substitution in Code 39 barcodes of all occurrences of the A character with the B character.
  • Page 87 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT (M8300 S DDRESS TAMPING ERIES disable reader address stamping ÌRU0ÊÎ disable cradle address stamping ÌRW0#Î enable reader address stamping ÌRU1"Î enable cradle address stamping ÌRW1&Î See par. 5.4.3 for details. (M8300 S DDRESS ELIMITER...
  • Page 88 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT (M8300 S TAMPING ERIES disable ÌIL0kÎ hour/minutes/seconds month/day/year ÌIL1nÎ hour/minutes/seconds day/month/year ÌIL2qÎ hour/minutes/seconds ÌIL3tÎ month/day/year ÌIL4wÎ day/month/year ÌIL5zÎ See par. 5.4.5 for details. (M8300 S TAMPING ELIMITER ERIES disable ÌIM0mÎ select delimiter ÌIM1pÎ...
  • Page 89 POWER SAVE LEEP TATE NTER LEEP IMEOUT Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 90: Power Save

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î POWER SAVE LEEP TATE disable ÌBQ0nÎ enable ÌBQ1qÎ See par. 5.5.1 for details. For M8300 series readers, sleep state is entered immediately after reading a code and is not configurable. NTER LEEP IMEOUT enter sleep timeout ÌBR@Î...

  • Page 91: Trigger Signal

    READING PARAMETERS RIGGER RIGGER IGNAL RIGGER LICK RIGGER IMEOUT LASH EADS PER YCLE AFETY EEPER NTENSITY EEPER EEPER EEPER ENGTH URATION IMING YSTEM RADLE EEPER NTENSITY Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of...
  • Page 92 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS RIGGER hardware trigger ÌBK1eÎ Restores TRIGGER MODE software trigger ÌBK0bÎ Enables FLASH MODE always on ÌBK3kÎ RIGGER IGNAL trigger active level ÌBA0NÎ trigger active pulse ÌBA1QÎ See par. 5.6.1 for details. RIGGER LICK disable...

  • Page 93: Trigger-Off Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS RIGGER IMEOUT trigger-off timeout ÌBD$Î Read 2 numbers in the range 00-99: 00 = disables the trigger-off timeout 01-99 = corresponds to a max. 99-sec. delay after the trigger press to allow the reader to turn off automatically. trigger-off timeout disabled See par.

  • Page 94: Safety Time

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS AFETY safety time ÌBE&Î Limits same code consecutive reading. Read 2 numbers in the range 00-99: 00 = no same code consecutive reading until reader is removed (no decoding) for at least 400 ms. 01-99 = timeout from .1 to 9.9 seconds before a consecutive read on same code.
  • Page 95 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS EEPER tone 1 ÌBH0\Î tone 2 ÌBH1_Î tone 3 ÌBH2bÎ tone 4 ÌBH3eÎ EEPER monotone ÌBJ0`Î bitonal ÌBJ1cÎ EEPER ENGTH long ÌBI0^Î short ÌBI1aÎ...
  • Page 96 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS URATION disable ÌBV0xÎ short ÌBV1{Î medium ÌBV2~Î long ÌBV3ÅÎ IMING YSTEM disabled ÌBj09Î enabled ÌBj1<Î RADLE EEPER NTENSITY disable ÌJI0fÎ low intensity ÌJI1iÎ medium intensity ÌJI2lÎ high intensity ÌJI3oÎ...

  • Page 97: Decoding Parameters

    DECODING PARAMETERS PREAD VERFLOW ONTROL NTERDIGIT ONTROL ECODING AFETY ™ UZZLE OLVER Before changing these parameter values read the descriptions in par. 5.7. CAUTION Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.
  • Page 98 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DECODING PARAMETERS PREAD disable ÌAX0{Î enable ÌAX1~Î See par. 5.7.1 for details. VERFLOW ONTROL disable ÌAW1|Î enable ÌAW0yÎ See par. 5.7.2 for details. NTERDIGIT ONTROL disable ÌAV0wÎ enable ÌAV1zÎ See par. 5.7.3 for details.
  • Page 99 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DECODING PARAMETERS ECODING AFETY one read ÌED0WÎ (decoding safety disabled) two reads ÌED1ZÎ three reads ÌED2]Î four reads ÌED3`Î Required number of good reads before accepting code. ™ UZZLE OLVER disable ÌAU0uÎ enable ÌAU1xÎ...

  • Page 100: Code Selection

    CODE SELECTION CONFIGURATION EAN/UPC F AMILY 2/5 F AMILY 39 F AMILY 128 F AMILY ODABAR AMILY GS1 DATABAR C ODES Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of...
  • Page 101 Code selections may be performed according to two different procedures: Auto-configuration, allowing an automatic recognition and selection of the code families to be read; Manual configuration, requiring configuration and selection of each code family to be read. CONFIGURATION The following codes do not require reading the Enter and Exit configuration codes. In auto-configuration mode the reader enters a particular state, during which it reads, recognizes and saves all information received from the decoding of an existing code (with the exception of MSI, Code 49 and Code 16k code types).
  • Page 102 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION DISABLE ALL CODE FAMILIES ÌAZ0ÃÎ The reader allows up to 10 code selections. This does not limit the number of CODES enabled to 10, as it depends on the code family. NOTE SINGLE •...
  • Page 103 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION EAN/UPC F AMILY disable the family ÌAA0MÎ Read the desired family code Note: Since the EAN/UPC without ADD ON code selection is enabled by default, to correctly enable another selection, first disable the family. EAN 8/EAN 13/UPC A/UPC E with and without ADD ON ÌAA8eÎ...
  • Page 104 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION WITH ADD ON 2 ONLY EAN 8/EAN 13 ÌAAK7Î UPC A/UPC E ÌAAM=Î WITH ADD ON 5 ONLY EAN 8/EAN 13 ÌAAL:Î UPC A/UPC E ÌAAN@Î WITH AND WITHOUT ADD ON EAN/UPC with and without ADD ON no Autodiscrimination ÌAA8Ad03Î...
  • Page 105 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION SELECT EAN/UPC PREFIXES When scanning the following codes, barcodes starting with the selected prefixes will be read and transmitted only if the ADD ON is present. If no ADD ON is found, the barcode will not be read. Barcodes starting with different characters are read regardless of ADD ON presence and transmitted always NOTE without ADD ON.
  • Page 106 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION Example: The following string allows reading and transmitting with ADD ON all EAN/UPC starting with the 434/439, 977 and 978 prefixes: EAN/UPC Autodiscrimination ADD ON by Prefix. 434/439: enables reading and transmission with ADD ON of all EAN/UPC barcodes starting with 434/439 prefixes.
  • Page 107 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION EAN/UPC CHECK DIGIT TX SELECTIONS For each code type in this family you can choose to transmit the check digit or not CHECK DIGIT TRANSMISSION NO CHECK DIGIT TRANSMISSION EAN 8 ÌAAG1oÎ...
  • Page 108 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION CONVERSION OPTIONS UPC E to UPC A conversion ÌAAAÄÎ UPC E to EAN 13 conversion ÌAABÇÎ UPC A to EAN 13 conversion ÌAACÊÎ EAN 8 to EAN 13 conversion ÌAAD"Î Enable only ISBN conversion ÌAP1nÎ...
  • Page 109 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION 2/5 F AMILY disable the family ÌAC0QÎ Read the desired family code Read a check digit selection Interleaved 2/5 ÌAC1TÎ CHECK DIGIT TABLE no check digit control Ì12Î Normal 2/5 (5 Bars) ÌAC2WÎ...
  • Page 110 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION 39 F AMILY disables the family ÌAB0OÎ Read the desired family code Read a check digit selection CHECK DIGIT TABLE Standard Code 39 no check digit control ÌAB1RÎ Ì12Î check digit control Full ASCII Code 39 and transmission ÌAB2UÎ...
  • Page 111 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION 128 F AMILY disable the family ÌAI0]Î Read the desired family code Code 128 ÌAI11=Î control without transmission of ISBT 128 check digit ÌAI31CÎ enabling ISBT 128 automatically EAN 128 disables Puzzle Solver™.
  • Page 112 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disable the code ÌAK0aÎ Code 93 ÌAK1dÎ control without transmission of check digit ODABAR AMILY disable the family ÌAD0SÎ Read the desired equality control code Read a start/stop transmission selection START/STOP CHARACTER TRANSMISSION Standard Codabar...
  • Page 113 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION The Codabar ABC code below uses a fixed start/stop character transmission selection. Codabar ABC ÌAD212)Î no start/stop character equality control but transmission. Codabar ABC Forced Concatenation enable Codabar ABC with forced concatenation ÌAD2321Î...
  • Page 114 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disable the family ÌAE0UÎ Enable the code by selecting one of the check digit selections. no check digit control ÌAE1XÎ MOD10 check digit control no check digit transmission ÌAE2[Î MOD10 check digit control check digit transmission ÌAE3^Î...
  • Page 115 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disable the family ÌAG0YÎ Enable the code by selecting one of the check digit selections. no check digit control ÌAG1\Î Type C check digit control check digit transmitted ÌAG21<Î Type C check digit control check digit not transmitted ÌAG22@Î...
  • Page 116 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disable the code ÌAJ0_Î Code 16K ÌAJ1bÎ To read stacked codes, simply move the reader over the code so that each line of the code is scanned. During this process a series of brief “ticks” indicates that reading is proceeding correctly.
  • Page 117 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION GS1 D ™ C ODES disable the family ÌAQ0mÎ DISABLE CODE ENABLE CODE disable GS1 DataBar Expanded Linear and Stacked ÌAQ10IÎ enable GS1 DataBar Expanded Linear and Stacked ÌAQ11MÎ disable GS1 DataBar Limited ÌAQ20LÎ...

  • Page 118: Advanced Formatting

    ADVANCED FORMATTING NOT FOR PEN INTERFACES ONCATENATION DVANCED ORMATTING Please follow the setup procedure carefully for these parameters. NOTE The Advanced Formatting parameters may not be compatible with the IBM USB POS interface selection. NOTE Read the Enter Configuration code ONCE, available at the top of page. Read configuration codes precisely following the numbered procedure given.
  • Page 119 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING ONCATENATION disable ÌEI0aÎ enable ÌEI1dÎ Permits the concatenation of two codes defined by code type and length. It is possible to set a timeout for the second code reading and to define code transmission if the timeout expires. The order of transmission is CODE 1-CODE 2.
  • Page 120 Since you can concatenate codes from different families, you must select the Code ID character of the resulting code. The Code ID character will be sent in the output message only if it is enabled according to the Code Identifier selection (Datalogic, AIM, or Custom). Concatenation Timeout timeout ÌEJ3Î...
  • Page 121 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Transmission after Timeout no code transmitted after timeout ÌEM0iÎ only code 1 transmitted (if read) after timeout ÌEM1lÎ only code 2 transmitted (if read) after timeout ÌEM2oÎ either code 1 or code 2 transmitted after timeout ÌEM3rÎ...
  • Page 122 ADVANCED FORMATTING DVANCED ORMATTING Advanced formatting has been designed to offer you complete flexibility in changing the format of barcode data before transmitting it to the host system. This formatting will be performed when the barcode data meets certain criteria, which you will define in the following procedure. Up to 4 advanced code management formats can be defined and saved in memory.
  • Page 123 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING Begin Format Definition begin Format 1 definition ÌHA0TÎ begin Format 2 definition ÌHA1WÎ begin Format 3 definition ÌHA2ZÎ begin Format 4 definition ÌHA3]Î Match Code Type match code type ÌHB&Î Read the above code + the code type to match from the Code Identifier Table in Appendix any code type ÌHB0VÎ...
  • Page 124 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Match with Predefined Characters no match ÌHD0HE00ÄÎ match with 1 character ÌHD1]Î match with a 2-character string ÌHD2`Î match with a 3-character string ÌHD3cÎ match with a 4-character string ÌHD4fÎ After selecting the predefined match code, read the character(s) from the HEX table. Range of characters = 00-FE.
  • Page 125 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Divide Code into Fields divide code into fields ÌHF.Î Read one number in the range 1 to 5 to divide the code into fields. Define Code Fields define code fields Each code field length can be set by either: a) defining a field separator character to be found in the code itself.
  • Page 126 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 1 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 00-FE. discard separator include separator Ì01Î Ì12Î match character ÌHG3iÎ Read the match character from the HEX table. Range of characters = 00-FE. field length ÌHG1cÎ...
  • Page 127 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 2 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 00-FE. discard separator include separator Ì01Î Ì12Î match character ÌHG3iÎ Read the match character from the HEX table. Range of characters = 00-FE. field length ÌHG1cÎ...
  • Page 128 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 3 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 00-FE. discard separator include separator Ì01Î Ì12Î match character ÌHG3iÎ Read the match character from the HEX table. Range of characters = 00-FE. field length ÌHG1cÎ...
  • Page 129 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 4 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 00-FE. discard separator include separator Ì01Î Ì12Î match character ÌHG3iÎ Read the match character from the HEX table. Range of characters = 00-FE. field length ÌHG1cÎ...
  • Page 130 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 5 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 00-FE. discard separator include separator Ì01Î Ì12Î match character ÌHG3iÎ Read the match character from the HEX table. Range of characters = 00-FE. field length ÌHG1cÎ...
  • Page 131 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING First Additional Fixed Field no fixed field ÌHI0dÎ 1 character fixed field ÌHI1gÎ 2 character fixed field ÌHI2jÎ 3 character fixed field ÌHI3mÎ 4 character fixed field ÌHI4pÎ 5 character fixed field ÌHI5sÎ 6 character fixed field ÌHI6vÎ...
  • Page 132 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Second Additional Fixed Field no fixed field ÌHJ0fÎ 1 character fixed field ÌHJ1iÎ 2 character fixed field ÌHJ2lÎ 3 character fixed field ÌHJ3oÎ 4 character fixed field ÌHJ4rÎ 5 character fixed field ÌHJ5uÎ 6 character fixed field ÌHJ6xÎ...
  • Page 133 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Field Transmission number of fields to transmit ÌHK8Î Read one number in the range 1 to 7 for the number of fields to transmit. Include only fields to be transmitted. Field Order Transmission Read the codes corresponding to the fields to transmit in the order in which they are to be transmitted.
  • Page 134 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Standard Formatting do not apply standard formatting ÌHL0jÎ apply standard formatting ÌHL1mÎ ® POWERSCAN D8330: After performing Advanced Formatting on the barcode read, Standard Formatting (Headers, Code Length, Code ID, Terminators) can be applied to the message to be transmitted.
  • Page 135 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING Enable Advanced Format no Advanced Formats enabled ÌHN0nÎ Advanced Format 1 enable ÌHN11NÎ disable ÌHN10JÎ Advanced Format 2 enable ÌHN21QÎ disable ÌHN20MÎ Advanced Format 3 enable ÌHN31TÎ disable ÌHN30PÎ Advanced Format 4 enable ÌHN41WÎ...
  • Page 136 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING No Match Result clear data - no transmission ÌHO0pÎ transmit data using standard format ÌHO1sÎ This selection determines the action to be taken when codes read do not conform to the advanced format requisites (no match).

  • Page 137: Radio Parameters (M8300 Series Only)

    RADIO PARAMETERS ® PowerScan M8300 Series readers only ADIO ROTOCOL IMEOUT RX T ADIO IMEOUT OWER IMEOUT RANSMISSION EEPER ONTROL FOR ADIO ESPONSE INGLE TORE ATCH Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 138: Radio Protocol Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS ADIO ROTOCOL IMEOUT radio protocol timeout ÌRH<Î Read a number from the table where: 02-19 = timeout from 2 to 19 seconds 2 seconds See par. 5.9.1 for details. RX T ADIO IMEOUT radio RX timeout...

  • Page 139: Power-Off Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS OWER IMEOUT power-off timeout ÌRPLÎ Read 2 numbers in the range 00-99: 00 = Power-off disabled; reader always ready 01-99 = corresponds to a max. 99 hour delay before power-off. power-off after 4 hours.

  • Page 140: Beeper Control For Radio Response

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS EEPER ONTROL FOR ADIO ESPONSE normal ÌBF0XÎ only good decode ÌBF1[Î only good reception ÌBF2^Î ÌBF3aÎ See par. 5.9.5 for details.
  • Page 141 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS INGLE TORE disable ÌRO0zÎ one attempt ÌRO1}Î two attempts ÌRO2ÄÎ three attempts ÌRO3ÇÎ four attempts ÌRO4ÊÎ five attempts ÌRO5"Î six attempts ÌRO6%Î seven attempts ÌRO7(Î eight attempts ÌRO8+Î nine attempts ÌRO9.Î...
  • Page 142 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS ATCH disable batch ÌBZ0ÄÎ enable normal batch ÌBZ1ÇÎ enable automatic batch ÌBZ2ÊÎ See par. 5.9.7 for details. The following batch management parameters are complete commands and do not require reading the Enter and Exit configuration codes. start normal batch transmission Ì#+BFlush]Î...

  • Page 143: Display Parameters

    DISPLAY PARAMETERS ® PowerScan M8300 Series readers only ATE AND ONTRAST ACKLIGHT ISPLAY IMEOUT ISPLAY EYPAD Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given Read the Exit and Save Configuration code ONCE, available at the top of each page.
  • Page 144 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DISPLAY PARAMETERS ATE AND set date ÌIA%Î set time ÌIB'Î Read 6 numbers for DDMMYY Read 4 numbers for HHMM ONTRAST lighter ÌIC0YÎ darker ÌIC1\Î Read the code until the desired contrast is reached. small ÌID0[Î...
  • Page 145 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DISPLAY PARAMETERS ISPLAY IMEOUT timeout ÌIF/Î Read 2 numbers in the range 00-99: 00 = disables display timeout (always on) 01 to 99 = timeout from 1 to 99 seconds. display-off after 8 seconds. delay disabled ISPLAY normal...
  • Page 146 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DISPLAY PARAMETERS EYPAD disable reader keypad ÌIK0iÎ enable reader keypad and select characters ÌIK1lÎ Read 3 HEX characters in the range 00-FE, corresponding to the left, center and right keys respectively. FF = KeyID disabled left = '<' center = '=' right = '>'...

  • Page 147: Rs-232 Parameters

    REFERENCES REFERENCES RS-232 PARAMETERS 5.1.1 Handshaking Hardware handshaking: (RTS/CTS) The RTS line is activated by the decoder before transmitting a character. Transmission is possible only if the CTS line (controlled by the Host) is active. Signals at EIA levels Transmitted data Transmitted data Host busy RTS/CTS handshaking...
  • Page 148 ® POWERSCAN D8330/M8300 5.1.2 ACK/NACK Protocol ® PowerScan D8330 Readers This parameter sets a transmission protocol in which the Host responds to the reader after every code transmitted. The Host sends an ACK character (06 HEX) in the case of good reception or the NACK character (15 HEX) requesting re-transmission, in the case of bad reception.
  • Page 149 REFERENCES Transmission Mode = Two-Ways data data cable ® PowerScan BC-80X0 Host NACK M8300 good RX data beep ACK/NACK enabled When ACK/NACK is enabled (in Two-Way tx mode), the Host sends an ACK character (06 HEX) in the case of good reception or the NACK character (15 HEX) requesting re-transmission, in the case of bad reception.
  • Page 150 ® POWERSCAN D8330/M8300 5.1.4 RX Timeout When the RS-232 interface is selected, the Host can be used to configure the device by sending it command strings (see Appendix A). This parameter can be used to automatically end data reception from the Host after the specified period of time.
  • Page 151 REFERENCES 5.2.3 Overflow This parameter generates a white space before the first bar and after the last bar of the code. The selections are as follows: narrow = space 10 times the minimum output pulse. medium = space 20 times the minimum output pulse. wide = space 30 times the minimum output pulse.
  • Page 152 ® POWERSCAN D8330/M8300 5.2.5 Inter-Block Delay For the PEN Emulation interface, data are sent to the Host in fixed size blocks of 20 characters each. The inter-block delay parameter allows setting a delay between each block sent to the Host. NETWORK PARAMETERS 5.3.1 Slave Address Range First/Last...

  • Page 153: Data Format

    REFERENCES The message is sent in the following format: "Message" CR LF 5.3.3 Reception Warning Message The Master cradle can transmit warning messages to the Host regarding wrong reception of data. Example: /*Two-Ways Out of Sequence!(..)*/ This message is transmitted to the Host by the Master cradle when the Master cradle receives a closing string from the Host for a Two-way tx communication, but this was either not open or already closed, therefore the data will be lost.
  • Page 154 ® POWERSCAN D8330/M8300 These default values are always restored through the reading of RS-232 or WEDGE interface selection code, see chapter 2. For the WEDGE interface, the following extended keyboard values can also be configured: EXTENDED KEYBOARD TO HEX CONVERSION TABLE IBM AT IBM XT IBM 31xx, 32xx,...
  • Page 155 Enter Configuration Ì$+;Î 5.4.2 Define Special Key Sequence The Special Key(s) for Wedge IBM AT-PS/2 and USB-KBD interface users can be associated with a sequence of keyboard keys that otherwise could not be selected, i.e. ALT + F6, SHIFT + F1. These Special Keys can be used for: Headers/Terminators Character Replacement Field Adjustment...
  • Page 156 ® POWERSCAN D8330/M8300 Read only one code to be associated with the special key sequence: SHIFT Ì12Î CTRL Ì23Î Ì45Î CTRL + SHIFT Ì34Î ALT + SHIFT Ì56Î CTRL + ALT Ì67Î...
  • Page 157 Exit and Save Configuration Ì$-?Î Select the character to be associated with the Special Key sequence by reading the codes corresponding to the 3 character values from Appendix C. Then, read the Exit and Save Configuration code above to complete the Special Key sequence.
  • Page 158 ® POWERSCAN D8330/M8300 KEYB CHAR < > ’ (accent)
  • Page 159 REFERENCES KEYB CHAR To use upper case letters, it is necessary to read one of the SHIFT commands from step 2 before the value corresponding to the lower case letters. NOTE The following key values are common to all the keyboard nationalities. KEYB ENTER Home...
  • Page 160 ® POWERSCAN D8330/M8300 KEYB CHAR Up arrow 275 Down arrow Left arrow Right arrow Ctrl right € SPACE If Caps Lock Auto-Recognition is disabled, it is necessary to verify that the keyboard caps lock status matches the reader one. NOTE EXAMPLES - Defining Special Key Sequences - the following example allows defining Special Key 1 as SHIFT + F5:...
  • Page 161 REFERENCES the following example allows defining Special Key 2 as CTRL + S (upper case): enter configuration define Special Key 2 CTRL + SHIFT Ì$+;Î ÌFQ9D2BÎ Ì34Î Read codes from Appendix C corresponding to exit & save configuration the character value for s (lower case) Ì$-?Î...
  • Page 162 ® POWERSCAN D8330/M8300 the following example allows setting Special Key 2 (defined in example 2 above) as header: enter configuration one character header special key 2 exit & save configuration Ì$+;Î ÌEA01.Î Ì9DÆÎ Ì$-?Î Read the following example allows setting Special Key 3 (defined in example 3 above) as header: enter configuration one character header...
  • Page 163 REFERENCES 5.4.5 Time Stamping Format The Time Stamping parameter sets the format for hour and date information. It consists of 1 or 2 groups of numbers, each one made up of 6 decimal digits. For example, setting the Hour/Minutes/Seconds/Month/Day/Year format, the information 17:03:16 on June 12, 2002 will be formatted as 170316061202.

  • Page 164: Reading Parameters

    ® POWERSCAN D8330/M8300 5.5.2 Enter Sleep Timeout For readers that have the Sleep state enabled, this timeout determines when the reader will enter this state. READING PARAMETERS 5.6.1 Trigger Signal This mode determines how the reading phase is controlled when the hardware trigger operating mode is selected: •...
  • Page 165 REFERENCES When one read per cycle is selected, the device decodes only one code during the ON period and immediately turns the reader OFF. It is only possible to read another code when the next ON time occurs. In multiple reads per cycle, the ON period is extended so that the device can continue decoding codes until an OFF event occurs.
  • Page 166 ® POWERSCAN D8330/M8300 5.7.3 Interdigit Control The interdigit control parameter verifies the interdigit spacing for code families Code 39 and Codabar. ADVANCED FORMATTING 5.8.1 Match Conditions Selecting an Advanced Formatting and specifying a Match restriction (Code Type, Code Length, Predefined Characters) the code will be transmitted according to the order of the defined formats.
  • Page 167 REFERENCES 5.9.2 Radio RX Timeout When the scanner is used in a standalone layout (point-to-point or with multiple readers) it can be configured to receive “asynchronous” messages from the host at any time. There are two modes which can enable the scanner to receive messages from the host: Enable “2 way”...
  • Page 168 ® POWERSCAN D8330/M8300 5.9.4 Transmission Mode This parameter determines whether the reader receives responses or messages from the Host or not. In One-Way tx mode, neither Host nor cradle responds to the reader. In Two-Way tx mode, the reader must receive a response from either the cradle or the Host.

  • Page 169: Single Store

    REFERENCES 5.9.6 Single Store ® When single store mode is enabled, if the PowerScan M8300 fails to transmit a code to the cradle, it enters a special operating mode that prevents the user from reading barcodes. When such operating mode is entered, the trigger no longer enables barcode reading but is used to retry transmission itself for the number of attempts selected in configuration.

  • Page 170: Find Me (Powerscan ® M8300 Only)

    ® POWERSCAN D8330/M8300 cannot be successfully completed, then the code is added to the list. When the reader returns in range, transmission of the codes to the base station resumes automatically, according to the selected communication protocol, upon simply pressing and releasing the trigger or by successfully reading a new code. Each code is listed on the reader display together with its identifying position number and its total number of characters.

  • Page 171: Display Parameters (Some M8300 Models Only)

    REFERENCES 5.10 DISPLAY PARAMETERS (SOME M8300 MODELS ONLY) 5.10.1 Display Mode The user can control the reader display behavior according to the following selections: Normal mode: When a barcode is read with the reader: • The code is sent to the Host. •...

  • Page 172: 5.11 Configuration Editing Commands

    ® POWERSCAN D8330/M8300 5.11 CONFIGURATION EDITING COMMANDS The following commands carry out their specific function and then exit the configuration environment. Command Description ® Restore PowerScan reader default Ì$+$*oÎ configuration (see the relative Quick Reference Guide for default settings) Ì$+$!KÎ ®...

  • Page 173: 5.12 Custom Default Configuration

    REFERENCES 5.12 CUSTOM DEFAULT CONFIGURATION Read the following code to set the reader user-defined configuration as custom default configuration: Save User-defined Configuration as Custom Default Ì$+$0ÂÎ Read the following code whenever you need to restore the custom default configuration: Restore Custom Default Configuration Ì$+$1$Î...

  • Page 174: 5.14 Configuration Copying Commands

    Connect the master (correctly configured reader) and the slave (reader to be configured) together through two RS-232 serial interface cables and external power supply. Accessory cables and power supply are available from your Datalogic distributor to provide this connection. RS-232 Cables: CAB471 & CAB472 Power Supply: PG5...

  • Page 175: Copy Powerscan™ M8300 Series

    REFERENCES 5.14.2 Copy PowerScan™ M8300 Series Procedure: Using the slave reader and its BC-80X0 cradle, follow the initialization procedure in chapter 4 of this manual or from the Quick Reference Guide. With the master PowerScan™ M8300 (correctly configured reader), read the Copy Configuration barcode below.

  • Page 176: Copy Bc-80X0

    Connect the master BC-80X0 and the slave BC-80X0 (cradle to be configured) together through two RS-232 serial interface cables and external power supply. Accessory cables and power supply are available from your Datalogic distributor to provide this connection. RS-232 Cables: CAB471 & CAB472 Power Supply: PG12 Read the Configuration Copy barcode below with a reader.

  • Page 177: 5.15 Default Parameters For Pos Terminals

    REFERENCES 5.15 DEFAULT PARAMETERS FOR POS TERMINALS The default values of the RS-232 and Data Format parameters for POS terminals are listed in the following table: NIXDORF Mode A FUJITSU ICL Mode RS-232 Group Baud Rate 9600 9600 9600 Parity None Even Data Bits...

  • Page 178: 5.16 Firmware Upgrade

    POWERSCAN D8330/M8300 5.16 FIRMWARE UPGRADE Device firmware upgrades can be performed using the Downloader utility tool (downloadable from the web site: http://www.scanning.datalogic.com) from your PC through the USB communication. Procedure: Launch the Downloader tool on your PC. Connect the device to the PC via USB interface.

  • Page 179: Message Formatting

    MESSAGE FORMATTING MESSAGE FORMATTING The system always provides scanner to host data communication using the following message formatting: ® ® Output Message from PowerScan D8330 or PowerScan M8300 Stand-alone Towards Host [Header] [Scanner_Addr] [Scanner_Addr_delimiter] ] [Cradle_Addr] [Cradle_Addr_delimiter] [Time stamp] [Ts_delimiter] [Code ID] [Code Length] CODE [Terminator] [Items in square brackets are optional.] ®...

  • Page 180: Cursor Control

    ® POWERSCAN D8330/M8300 The general format for other asynchronous messages is: MESSAGE [Scanner_Addr] [Scanner_Addr_delimiter] [DC2] [CR] where DC2 is ASCII 0x12 (^R) character. • If you have not enabled the Scanner Address Stamping or the Scanner Address Delimiter, you must not specify them. In this case all messages will be implicitly addressed to the 'binded' Scanner of the cradle directly connected to the serial line.

  • Page 181: Font Selection

    MESSAGE FORMATTING • The cursor row position is not affected by the currently selected font. The display always has 4 rows, so when writing with the large font, actually two rows are written to: the current one and the one below it. You will need two ESC E commands to step from one row to the next when using the large font.

  • Page 182: Setting Rtc

    ® POWERSCAN D8330/M8300 The LED control escape sequences are intended to activate the LEDs for short periods of time and can be used in combination with the Beeper. The LED and Beeper will be controlled by the system after the entire command sequence is interpreted.
  • Page 183 MESSAGE FORMATTING The default characters associated with each key (KeyID) are shown in the following table: Default Key Identifiers KeyID ▲ (left) Key '<' ENTER (center) Key ▼ (right) Key '>'...

  • Page 184: Technical Features

    Power (max) in mW 0.9 mW 1.3 mW 13.5° ± 0.7 Scan Angle 42° PCS minimum (Datalogic Test Chart) Maximum Resolution 0.076 mm (3 mils) 0.19 mm (7.5 mils) Reading Field Width see reading diagrams (par. 7.6) Laser Safety Class...

  • Page 185: Powerscan M8300

    Power (max) in mW 0.9 mW 1.3 mW 13.5° ± 0.7 Scan Angle 42° PCS minimum (Datalogic Test Chart) Maximum Resolution 0.076 mm (3 mils) 0.19 mm (7.5 mils) Reading Field Width see reading diagrams (par. 7.6) Laser Safety Class...

  • Page 186: Bc-80X0 / C-8000

    ® POWERSCAN D8330/M8300 BC-80X0 / C-8000 BC-80X0 C-8000 Electrical and General Features Supply Voltage External Power 10 to 30 VDC Host Power 5 VDC ±10% Power Consumption External Power max. 10 W (charging)* Host Power max. 500 mA (charging) Indicators Ext.

  • Page 187: System And Radio Features

    TECHNICAL FEATURES SYSTEM AND RADIO FEATURES European Models USA Models Radio Features Radio Frequency 433.92 MHz 910 MHz Bit Rate 19200 36800 Range (in open air) 50 m 30 m System Configurations BC-8000 model only STARGATE™ Maximum number of devices per base station Maximum number of devices in the 2000...
  • Page 188 ® POWERSCAN D8330/M8300 ® POWERSCAN D8330/M8300 READER DATA ENTRY ¹ Good Read Spot Meaning Beeper one beep² Correct read of a code in normal mode H L long TX buffer full (when FIFO is enabled) or ® TX error between PowerScan M8300 and BC-8000 H long...
  • Page 189 TECHNICAL FEATURES BC-80X0/C-8000 POWER/COMMUNICATION Aux LED Host LED Meaning Yellow Yellow Device off Power applied through an external power supply Power applied through the Host Flashing Flashing Transmission over the Host port BC-80X0/C-8000 CHARGE STATUS Reader LED Meaning Green Beeper No reader battery inserted Reader battery in charge single beep...

  • Page 190: Reading Diagrams

    ® POWERSCAN D8330/M8300 READING DIAGRAMS ® POWERSCAN D8330/M8300 108 cm 0.13 mm 5 mils 0.19 mm 7.5 mils 0.25 mm 10 mils 0.33 mm 13 mils 0.38 mm 15 mils 0.50 mm 20 mils 1.00 mm 1.38 mm 40 mils 55 mils ®...

  • Page 191: A Host Configuration Strings

    HOST CONFIGURATION STRINGS HOST CONFIGURATION STRINGS In this section we provide a description of how to modify the device configuration using serial strings sent from the Host. This method requires the RS-232 interface. The device configuration can be changed by receiving commands from the Host through the serial interface.
  • Page 192 ® POWERSCAN D8330/M8300 SERIAL CONFIGURATION STRINGS SPECIAL CONFIGURATION COMMANDS DESCRIPTION STRING Enter Configuration Exit and Save Configuration Restore Default $+$* Transmit Software Release (not for PEN emulation) $+$! Transmit Device Configuration in ASCII (not for PEN emulation) $+$& Set Custom Default $+$0 Restore Custom Default $+$1...
  • Page 193 HOST CONFIGURATION STRINGS RS-232 DESCRIPTION STRING Baud Rate 1200 2400 4800 9600 19200 38400 Parity none even Data Bits Stop Bits Handshaking disable RTS/CTS XON/XOFF RTS always On ACK/NACK Protocol disable enable FIFO disable enable Inter-character Delay (ms) CK00 - CK99 RX Timeout (100 ms) CL00 - CL99 Serial Trigger Lock...
  • Page 194 ® POWERSCAN D8330/M8300 DESCRIPTION STRING USB-COM Handshaking disable RTS/CTS XON/XOFF RTS always ON ACK/NACK Protocol disable enable FIFO disable enable Inter-character Delay (ms) CK00 - CK99 RX Timeout (100 ms) CL00 - CL99 Serial Trigger Lock disable enable USB-KBD Keyboard Nationality Belgian (not for USB-KBD-ALT-MODE) English (UK)
  • Page 195 HOST CONFIGURATION STRINGS WEDGE DESCRIPTION STRING Keyboard Nationality Belgian English (UK) French German Italian Spanish Swedish Keyboard Nationality Japanese (IBM AT compatible only) Russian (Latin) Russian (Cyrillic) Hungarian Slovenian, Croatian, Serbian (Latin) Romanian Czech Republic Caps Lock caps Lock ON caps Lock OFF Caps Lock Auto-Recognition disable...
  • Page 196 ® POWERSCAN D8330/M8300 PEN (continued) DESCRIPTION STRING Idle Level normal inverted Overflow narrow overflow medium overflow wide overflow Inter-block Delay (100 ms) CK00-CK99 NETWORK DESCRIPTION STRING RS-485 Network Disable Network Enable RS-485 Slave Enable RS-485 Master Slave Address Range Minimum Address JB0000-1999 Maximum Address JC0000-1999...
  • Page 197 , c , x = HEX values representing an ASCII character. a = ASCII character of the DATALOGIC STANDARD Code Identifier from the table on page 70. b = Hex value of the first Custom Code Identifier character from 00 to FD;...
  • Page 198 = a number from the Hex/Numeric Table e, f, g, h = HEX values representing an ASCII character a = ASCII character of the DATALOGIC STANDARD Code Identifier from the table on page 70. d = a number in the range 01-32 from the Hex/Numeric Table...
  • Page 199 HOST CONFIGURATION STRINGS POWER SAVE DESCRIPTION STRING Sleep State disable (only for D8330 series) enable Enter Sleep Timeout (100 ms) BR00-BR99 READING PARAMETERS DESCRIPTION STRING Trigger Type software trigger hardware trigger always on Trigger Signal trigger active level trigger active pulse Trigger Click disable enable...
  • Page 200 ® POWERSCAN D8330/M8300 DECODING PARAMETERS DESCRIPTION STRING Ink-spread disable enable Overflow Control disable enable Interdigit Control disable enable Puzzle Solver disable enable Decoding Safety one read two reads three reads four reads CODE SELECTION DESCRIPTION STRING DISABLE ALL FAMILY CODES EAN/UPC disable EAN/UPC family EAN 8/EAN 13/UPC A/UPC E without ADD ON...
  • Page 201 HOST CONFIGURATION STRINGS CODE SELECTION (continued) DESCRIPTION STRING UPC A check digit transmission disable AAI0 enable AAI1 UPC E check digit transmission disable AAJ0 enable AAJ1 conversions UPC E to UPC A UPC E to EAN 13 UPC A to EAN 13 EAN 8 to EAN 13 ISBN Conversion codes enable ISBN...
  • Page 202 ® POWERSCAN D8330/M8300 CODE SELECTION (continued) DESCRIPTION STRING Codabar disable Codabar family Standard no start/stop character equality control AD111 nor transmission no start/stop character equality control AD112 but transmission start/stop character equality control AD121 but no transmission start/stop character equality control AD122 and transmission ABC Codabar...
  • Page 203 HOST CONFIGURATION STRINGS CODE SELECTION (continued) DESCRIPTION STRING Code 11 disable the family no check Type C with tx AG21 Type C no tx AG22 Type K with tx AG31 Type K no tx AG32 Type C and K with tx AG41 Type C and K no tx AG42...
  • Page 204 ® POWERSCAN D8330/M8300 DISPLAY PARAMETERS DESCRIPTION STRING ddmmyy Date hhmm Time Contrast lighter darker Font Size small medium large Backlight Display-Off Timeout Display Mode normal local echo clear display after decode Keypad disabled keys enable and select KeyID characters ddmmyy = numbers from the Hex/Numeric Table representing day, month, year hhmm = numbers from the Hex/Numeric Table representing hour, minutes...
  • Page 205 CODE IDENTIFIER TABLE CODE IDENTIFIER TABLE 2/5 Interleaved ÌNOÎ 2/5 Industrial ÌPQÎ 2/5 normal 5 bars ÌOPÎ 2/5 matrix 3 bars ÌQRÎ EAN 8 ÌABÎ EAN 13 ÌBCÎ UPC A ÌCDÎ UPC E ÌDEÎ EAN 8 with 2 ADD ON ÌJKÎ...
  • Page 206 ® POWERSCAN D8330/M8300 UPC A with 5 ADD ON ÌGHÎ UPC E with 2 ADD ON ÌHIÎ UPC E with 5 ADD ON ÌIJÎ Code 39 ÌVWÎ Code 39 Full ASCII ÌWXÎ CODABAR ÌRSÎ ABC CODABAR ÌSTÎ Code 128 ÌTUÎ EAN 128 ÌklÎ...
  • Page 207 CODE IDENTIFIER TABLE ÌZ[Î Code 16K ÌpqÎ Code 11 ÌbcÎ Code 49 ÌqrÎ GS1 DATABAR Expanded Linear and Stacked ÌtuÎ GS1 DATABAR Limited ÌvwÎ GS1 DATABAR 14 Linear and Stacked ÌuvÎ...

  • Page 208: C Hex And Numeric Table

    HEX AND NUMERIC TABLE CHARACTER TO HEX CONVERSION TABLE char char char < > SPACE " &...
  • Page 209 HEX AND NUMERIC TABLE CHARACTER TO HEX CONVERSION TABLE char char char € ª Õ « Ö ‚ ¬ × ENTER Ø ® Ù ¯ Ú ° Û ± Ü ² Ý ³ Þ ´ ß µ à ¶ á ·...
  • Page 210 HEX / NUMERIC TABLE Ì01Î Ì12Î Ì23Î Ì34Î Ì45Î Ì56Î Ì67Î Ì78Î Ì89Î Ì9:Î ÌABÎ ÌBCÎ ÌCDÎ ÌDEÎ ÌEFÎ ÌFGÎ Backspace Ì$%/Î Cancels an incomplete configuration sequence...

This manual is also suitable for:

Powerscan m8300

Table of Contents
