Basic Operation Guide
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Using the Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Control Panel Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Copying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Loading Paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Copying Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Standard Copying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Borderless Copying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Small margin copying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Fit to page copying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Canceling Copying. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Printing or Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Printing Directly from a Memory Card. . . . . . . . . . . . . . . . . . . . . . . . . . .8
Printing from Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Scanning to Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Canceling Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Replacing Ink Cartridges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Choosing Ink Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Precautions on Ink Cartridge Replacement . . . . . . . . . . . . . . . . . . . . . .11
Replacing an Ink Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning the Print Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Aligning the Print Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Clearing Jammed Paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Contacting Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Regional Customer Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
4049812-00
xxx

Advertisement

Table of Contents
loading

Related Manuals for Epson stylus cx4500 series

Summary of Contents for Epson stylus cx4500 series

  • Page 1: Table Of Contents

    All in One Product Basic Operation Guide Safety Instructions ........1 Using the Control Panel .
  • Page 2 Seiko Epson Corporation. The information contained herein is paper support designed only for use with this product. Epson is not responsible for any use of this information as applied to other printers. feeder guard Neither Seiko Epson Corporation nor its affiliates shall be liable...

  • Page 3: Safety Instructions

    Safety Instructions When using a memory card Do not remove the memory card or turn off this product while the computer and the memory Read all of the instructions in this section when card are communicating (when the memory setting up and using this product. card access light or On light is flashing).
  • Page 4 Never spill liquid on this product. Do not leave this product with the ink cartridges uninstalled. If it has been left with ink cartridges uninstalled for a long time, the ink remaining in the print head nozzle dries out; this product may become unable to print.

  • Page 5: Using The Control Panel

    Using the Control Panel Memory Enters the Memory Card Mode and selects the memory card print options. Card The memory card print options are: Print Index Sheet: This is selected when you press the button and the paper Control Panel Functions type and size are set to Plain Paper and Print From Index Sheet: This is selected automatically after printing the index...
  • Page 6 Lights Plain Paper Indicates the selected Photo Paper paper type. Note: Indicates the selected All lights will turn off if no buttons have been pressed for 10× 15 paper size. 15 minutes. When a button is pressed, the lights will 10×...

  • Page 7: Copying

    Copying Load the paper with the printable side up so it is against the right edge guide, and slide it into the sheet feeder. This section describes how to make copies using the control panel. For information on copying using a computer, see the Online Reference Guide.

  • Page 8: Placing A Photo Or Document On The Document Table

    Fit to page: Placing a Photo or Document on reduces or enlarges the size of the copy so that the × the Document Table scanned image fits to A4 or 10 15 cm. Each of the above copying modes is available by Press the P On button to turn on this product.

  • Page 9: Borderless Copying

    Note: Small margin copying Do not pull the paper out of this product. The copied image may not have exactly the same size Follow steps 1 to 3 in “Standard Copying” on as the original. page 6. If the ink light flashes to indicate low ink while you Press the paper type button to select Photo are copying, you can either continue making copies Paper.

  • Page 10: Printing Or Scanning

    Printing or Scanning The types of memory cards loadable for each slot are shown below. Slot Card This section describes how to print photos directly from a memory card without using a computer, print Memory Stick/MagicGate Memory Stick/ from your computer and scan images to your Memory Stick Duo*/ computer.

  • Page 11: Printing All Photos On A Memory Card

    Printing All Photos on a Memory Note: You can only use A4 plain paper to print an Card Index Sheet. Using this feature, you can print all photos stored on You cannot print more than one Index Sheet at a memory card. a time, and cannot select the layout.

  • Page 12: Printing From Your Computer

    Document on the Document Table” on page 6. Start EPSON Smart Panel. For more information, see “Starting EPSON Smart Panel” in the Online Reference Guide. Click the Scan and Save icon on the EPSON Smart Panel. Specify the Location, File Name, and Image Format settings.

  • Page 13: Replacing Ink Cartridges

    Yellow T0474 cartridge. This can damage the ink cartridge. Caution: Epson recommends the use of genuine Epson ink cartridges. Epson warranties do not cover damage to your product caused by the use of ink cartridges not manufactured by Epson. To check when it is time to replace an ink cartridge using the control panel, see H in “Lights”...

  • Page 14: Replacing An Ink Cartridge

    Press the H Ink button. Replacing an Ink Cartridge If more than one ink cartridge is empty or low, the print head moves so that the empty or low ink cartridge is indicated by the _ mark. This To replace an ink cartridge using the Ink button, occurs each time the H Ink button is pressed until follow the steps below.

  • Page 15: Maintenance

    Maintenance Warning: If ink gets on your hands, wash them thoroughly with soap and water. If ink gets into your eyes, flush them immediately with water. If discomfort or vision problems Checking the Print Head continue after a thorough flushing, see a doctor immediately.

  • Page 16: Cleaning The Print Head

    Cleaning the Print Head Aligning the Print Head If you find that the nozzle check result is If you notice vertical lines are not aligned properly unexpectedly faint or some dots in the printed image on the nozzle check result, you may be able to solve are missing, you may be able to solve these problems this problem by aligning the print head.

  • Page 17: Troubleshooting

    Troubleshooting Error light Cause Solution status Flashing/All A memory card Remove the Memory not supported incompatible memory Card lights by this product card. See the Online Using the Error Light and Other flashing/“1” has been Reference Guide for flashing in inserted.

  • Page 18: Clearing Jammed Paper

    Press the x Start Color button to eject the jammed paper. If the jammed paper is not If your Epson product is not operating properly and ejected, go on to the next step. you cannot solve the problem using the troubleshooting information in your product Locate where the paper is jammed.

  • Page 19: Product Information

    50 to 60 Hz Since the quality of any particular brand or type of paper frequency range may be changed by the manufacturer at any time, EPSON cannot guarantee the quality of any non-EPSON brand Power Approx. 11 W Approx. 11 W or type of paper.

  • Page 20: Printable Area

    Printable area The diagonal lines in the following illustration indicates the printable area of a single sheet when using copy mode. Standard Small Borderless Copy Margins Copy Copy A: top margin 3.0 mm 1.5 mm 0 mm (0.12") (0.6") B-L: left 3.0 mm 1.5 mm 0 mm...
