1.1. PREFACE ................................................................................. 1-1
1.2. KEY FEATURES ....................................................................... 1-1
1.3. PERFORMANCE LIST .............................................................. 1-3
1.4. BLOCK DIAGRAM..................................................................... 1-4
1.5. INTRODUCE THE PCI - BUS .................................................... 1-5
1.6. FEATURES ............................................................................... 1-5
2.
2.1. HARDWARE ............................................................................. 2-1
2.2. SOFTWARE.............................................................................. 2-2
2.3. ENVIRONMENT ........................................................................ 2-2
3.
3.1. UNPACKING ............................................................................. 3-1
3.2. MAINBOARD LAYOUT.............................................................. 3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS .......... 3-2
3.4. SRAM INSTALLATION DRAM INSTALLATION.......................... 3-6
3.5. DRAM INSTALLATION.............................................................. 3-6
3.6. CPU INSTALLATION AND JUMPERS SETUP ........................... 3-7
3.7. CMOS RTC & ISA CFG CMOS SRAM....................................... 3-8
3.8. SPEAKER CONNECTOR INSTALLATION................................. 3-9
TABLE OF CONTENTS
1
Advertisement
Chapters
Table of Contents
Related Manuals for Gigabyte GA-5SMM
Summary of Contents for Gigabyte GA-5SMM
-
Page 1: Table Of Contents
5SMM TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE ................. 1-1 1.2. KEY FEATURES ............... 1-1 1.3. PERFORMANCE LIST .............. 1-3 1.4. BLOCK DIAGRAM..............1-4 1.5. INTRODUCE THE PCI - BUS ............ 1-5 1.6. FEATURES ................1-5 SPECIFICATION 2.1. HARDWARE ................2-1 2.2. - Page 2 5SMM USER'S MANUAL Support Intel Pentium, MMX, Cyrix/IBM 6x86MX, MII, AMD K6, K6-2, K6-III, IDT Winchip 2, IDT Winchip 3 & RISE MP6 CPUs. Support auto detect four positive Voltages and Fan Speed. Support 66/75/83/90/95 MHz and 100MHz. System power on by Keyboard: If your ATX power supply supports 300 mA 5V Stand-By current(dependent on the specification of keyboards), you can power on your system by entering password from the Keyboard after setting the “Keyboard power on”...
- Page 4 5SMM The author assumes no responsibility for any errors or omissions which may appear in this document nor does it make a commitment to update the information contained herein. ¯THIRD-PARTY BRANDS AND NAMES ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. Nov.
- Page 5 Quick Installation Guide CPU Jumper Setting Table: SW: CPU INT./ EXT. FREQ. RATIO O: ON X: OFF 1.3V 2.5V 1.4V 2.6V 1.5V 2.7V 1.6V 2.8V 1.7V 2.9V 1.8V 3.0V 1.9V 3.1V 2.0V 3.2V 2.1V 3.3V 2.2V 3.4V 2.3V 3.5V 2.4V X1.5 X2.5 X3.5...
- Page 6 5SMM SW 1 : SDRAM 66.8 33.4 66.8 83.3 33.3 83.3 31.7 32.33 33.4 37.3 33.3 ♦Note : It’ s strongly recommended that set the system speed according to your hardware configuration: CPU, SDRAM, Cards, etc. ♦Note : 97MHz is support in motherboard version 1.3 and above.
- Page 7 Quick Installation Guide II. Quick Installation Guide: O: ON X: OFF SWITCH SW 2 SW 1 S1 S2 S3 S4 S5 S6 S7 S8 ® 1. Pentium 133 MHz ® 2. Pentium 166 MHz ® 3. Pentium 200 MHz 4. Intel MMX-166MHz 5.
- Page 8 5SMM 26. AMD-K6-2/533 (97*5.5 2.2V) 27. AMD-K6-2/550 (100*5.5 2.2V) SWITCH SW 2 SW 1 S1 S2 S3 S4 S5 S6 S7 S8 28. AMD-K6-III/400 (100*4 2.2V) 29.AMD-K6-III/400 (100*4 2.4V) 30.AMD-K6-III/450 (100*4.5 2.2V) 31.AMD-K6-III/450 (100*4.5 2.4V) 32.AMD-K6-III/475 (95*5 2.2V) 33.AMD-K6-III/475 (95*5 2.4V) 34.AMD-K6-III/500 (100*5 2.2V) 35.AMD-K6-III/500 (100*5 2.4V) 36.AMD-K6-III/550 (100*5.5 2.2V)
- Page 9 Quick Installation Guide 47. Cyrix M ¢ º - PR333 (66*4 2.9V) 48. Cyrix M ¢ º - PR333 (83*3 2.9V) 49. Cyrix M ¢ º - PR333 (75*3.5 2.9V) SWITCH SW 2 SW 1 S1 S2 S3 S4 S5 S6 S7 S8 50.
- Page 10 5SMM 66. RISE MP6-266 (100*2 2.8V) ¬ Note: If Cyrix 6x86 is being used, please check the CPU Date Code after 605. The default setting is 100*3 at 2.2V for AMD K6/300 and AMD K6-2/300 AMD-K6/300 (100*3 2.2V) AMD-K6-2/300 (100*3 2.2V) The settings of the processors marked with “*”...
-
Page 11: Pentium Processor 200 Mhz
Quick Installation Guide SOLO-1 ES1938S SIS530 5595 5SMM BIOS ® 2. Pentium Processor 166 MHz ® 3. Pentium Processor 200 MHz 4. Intel MMX-166 MHz... - Page 12 5SMM 5. Intel MMX-200 MHz 6. Intel MMX-233 MHz 7. AMD-K6/166 (2.9V) 8. AMD-K6/200 (2.9V) 9. AMD-K6/233 (3.2V)
- Page 13 Quick Installation Guide 10. AMD-K6/233 (66*3.5 2.2V) 11. AMD-K6/266 (66*4 2.2V); AMD-K6-2/266 (66*4 2.2V) 12. AMD-K6/300 (66*4.5 2.2V) 13. AMD-K6/300 (100*3 2.2V); AMD-K6-2/300 (100*3 2.2V)
- Page 14 5SMM 14. AMD-K6-2/333 (66*5 2.2V) 15. AMD-K6-2/333 (95*3.5 2.2V) 16. AMD-K6-2/350 (100*3.5 2.2V) 17. AMD-K6-2/366 (66*5.5 2.2V) 18. AMD-K6-2/380 (95*4 2.2V)
- Page 15 Quick Installation Guide 19. AMD-K6-2/400 (100*4 2.2V) 20. AMD-K6-2/450 (100*4.5 2.2V) 21. AMD-K6-2/450 (100*4.5 2.4V) 22. AMD-K6-2/475 (95*5 2.4V) 23. AMD-K6-2/475 (95*5 2.4V)
- Page 16 5SMM 24. AMD-K6-2/500 (100*5 2.2V) 25. AMD-K6-2/500 (100*5 2.4V) 26. AMD-K6-2/533 (97*5.5 2.2V) 27. AMD-K6-2/550 (100*5.5 2.2V) 28. AMD-K6-III/400 (100*4 2.2V)
- Page 17 Quick Installation Guide 29. AMD-K6-III/400 (100*4 2.4V) 30. AMD-K6-III/450 (100*4.5 2.2V) 31. AMD-K6-III/450 (100*4.5 2.4V) 32. AMD-K6-III/475 (95*5 2.2V) 33. AMD-K6-III/475 (95*5 2.4V)
- Page 18 5SMM 34. AMD-K6-III/500 (100*5 2.2V) 35. AMD-K6-III/500 (100*5 2.4V) 36. AMD-K6-III/550 (100*5.5 2.2V) 37. Cyrix / IBM 6x86MX-PR166 (66*2 2.9V) 38. Cyrix / IBM 6x86MX-PR200 (66*2.5 2.9V)
- Page 19 Quick Installation Guide 39. Cyrix / IBM 6x86MX-PR200 (75*2 2.9V) 40. Cyrix / IBM 6x86MX-PR233 (66*3 2.9V) 41. Cyrix / IBM 6x86MX-PR233 (75*2.5 2.9V) 42. Cyrix / IBM 6x86MX-PR233 (83*2 2.9V) 43. Cyrix / IBM 6x86MX-PR266 (66*3.5 2.9V)
- Page 20 5SMM 44. Cyrix / IBM 6x86MX-PR266 (75*3 2.9V) 45. Cyrix / IBM 6x86MX-PR266 (83*2.5 2.9V) 46. Cyrix MII-PR300 (66*3.5 2.9V) 47. Cyrix MII-PR333 (66*4 2.9V) 48. Cyrix MII-PR333 (83*3 2.9V)
- Page 21 Quick Installation Guide 49. Cyrix MII-PR333 (75*3.5 2.9V) 50. Cyrix MII-PR333 (100*2.5 2.9V) 51. Cyrix MII-PR350 (90*3 2.9V) 52. Cyrix MII-PR366 (75*4 2.9V) 53. Cyrix MII-PR366 (83*3.5 2.9V)
- Page 22 5SMM 54. Cyrix MII-PR366 (100*3 2.9V) 55. Cyrix MII-PR400 (90*4 2.9V) 56. Cyrix MII-PR400 (100*3.5 2.9V) 57. IDT Winchip 2-200 (66*3 3.5V) 58. IDT Winchip 2-200 (100*2 3.5V)
- Page 23 Quick Installation Guide 59. IDT Winchip 2-225 (75*3 3.5V) 60. IDT Winchip 2-233 (66*3.5 3.5V) 61. IDT Winchip 2-233 (100*2.33 3.5V) 62. IDT Winchip 2-266 (66*4 3.5V) 63. IDT Winchip 2-266 (100*2.66 3.5V)
- Page 24 5SMM 64. IDT Winchip 2-300 (100*2.5 3.5V) 65. IDT Winchip 3-266 (100*2.33 2.8V) 66. RISE MP6-266 (100*2 2.8V) III. Quick Installation Guide of Jumper setting: SPK : Speaker Connector...
-
Page 25: Solo
Quick Installation Guide SOLO-1 ES1938S SIS530 Function 5595 Data 5SMM BIOS RE : Reset Switch SOLO-1 ES1938S SIS530 Open: Normal Operation Short: For Hardware Reset System 5595 5SMM BIOS PWR LED : Power LED... - Page 26 5SMM SOLO-1 ES1938S SIS530 Function LED anode (+) LED cathode (−) LED cathode (−) 5595 5SMM BIOS HD : IDE Hard Disk Active LED SOLO-1 ES1938S Function SIS530 LED anode (+) LED cathode (−) 5595 5SMM BIOS GN : Green Function Switch...
- Page 27 Quick Installation Guide SOLO-1 ES1938S Open: SIS530 Normal Operation Short: Entering Green Mode. 5595 5SMM BIOS GD : Green LED SOLO-1 ES1938S Function SIS530 LED anode (+) LED cathode (−) 5595 5SMM BIOS PW : Power On/Off Switch...
-
Page 28: Atx Power Connector
5SMM SOLO-1 ES1938S Open: SIS530 Normal Operation Short: Power On/Off 5595 5SMM BIOS ATX Power Connector SOLO-1 ES1938S Function 3,5,7,13,15-17 4,6,19,20 VCC (+5V) +12V SIS530 −12V −5V Power Good 5V SB (Stand by ) PS-ON (Soft ON/OFF) 5595 5SMM BIOS FAN 1 : CPU Cooling Fan Power Connector... - Page 29 Quick Installation Guide SOLO-1 ES1938S Function +12V Signal SIS530 5595 5SMM BIOS FAN2 : SYSTEM FAN SOLO-1 ES1938S Function +12V Signal SIS530 5595 5SMM BIOS JP4: Wake On Lan...
- Page 30 5SMM SOLO-1 ES1938S Function SIS530 +5V SB Signal 5595 5SMM BIOS LPT / COM A / VGA PORT PORT SOLO-1 ES1938S COM A SIS530 5595 5SMM BIOS USB : USB Port...
- Page 31 Quick Installation Guide SOLO-1 ES1938S SIS530 1 2 3 4 5595 5SMM BIOS PS/2 : PS/2 Mouse / Keyboard Connector PS/2 Mouse SOLO-1 ES1938S SIS530 PS/2 Keyboard PS/2 Mouse / Keyboard Function Key Data 5595 5SMM VCC (+5V) Key Clock. BIOS FLOPPY : FLOPPY PORT...
- Page 32 5SMM SOLO-1 RED LINE SIS530 5595 5SMM BIOS IDE 1 : For Primary IDE port SOLO-1 ES1938S RED LINE 5595 BIOS IDE 2 : For Secondary IDE port...
- Page 33 Quick Installation Guide SOLO-1 ES1938S RED LINE SIS530 5595 5SMM BIOS GAME & AUDIO PORT (External) SOLO-1 ES1938S GAME Line Out SIS530 Line In 5595 5SMM BIOS IR : Infrared Connector (Optional)
- Page 34 5SMM SOLO-1 ES1938S Function IR Data SIS530 Output IR Data Input 5595 5SMM POWER (+) BIOS JP2 : Keyboard Power On Select SOLO-1 ES1938S SIS530 Keyboard Power On Default : Disabled Enabled Disabled 5595 5SMM BIOS J1 / J2 : CD Audio Line in Connector...
- Page 35 Quick Installation Guide SOLO-1 ES1938S SIS530 5595 5SMM BIOS JP1 : On-Board Sound Function Selection SOLO-1 ES1938S Default: 1-2 Short SIS530 1-2 Short : Onboard Sound Enable 5595 5SMM 2-3 Short : Onboard Sound Disable BIOS JP7 : CLEAR CMOS Function...
- Page 36 SOLO-1 ES1938S Default: 2-3 Short 1-2 Short : Clear CMOS SIS530 2-3 Short : NORMAL 5595 5SMM BIOS JP5 : Internal MODEM Wake Up SOLO-1 ES1938S SIS530 5595 5SMM Function Signal BIOS J9 : PS/2 Mouse By Connector (Optional)
- Page 37 Quick Installation Guide SOLO-1 ES1938S Function SIS530 Data Clock 5595 5SMM BIOS TEL :The Connector is for Modem with internal Voice Connector SOLO-1 ES1938S Function SIS530 Signal Signal 5595 5SMM BIOS JP8 : BIOS Flash ROM Write Protection...
- Page 38 5SMM (This function is support in PCB version 1.3 and above) SOLO-1 ES1938S Function Open Normal Close Write Protection SIS530 5595 5SMM BIOS BAT1 : For Battery ES1938S SIS530 5595 5SMM BAT1 MDanger of explosion if battery is incorrectly replaced. MReplace only with the same or equivalent type recommended by the manufacturer.
- Page 39 Quick Installation Guide for top performance setting. Each value of items as above depends on your hardware configuration : CPU , SDRAM , Cards , etc. Please modify each value of items If your system does not work properly.
- Page 40 5SMM PERFORMANCE LIST The following list of performance data is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Pentium ®...
- Page 41 3.10. GREEN FUNCTION INSTALLATION ........ 3.11. PERIPHERAL DEVICE INSTALLATION ... 3 9 BIOS CONFIGURATION 4.1. ENTERING SETUP ........4 1 ..............4.3. GETTING HELP ........-3 4.3.1.Main Menu ........4 3 ..4 3 ..............4.5. STANDARD CMOS SETUP MENU ....
-
Page 42: Introduction
5SMM 1. INTRODUCTION 1.1. PREFACE Welcome to use the 5SMM motherboard. The motherboard is a Pipeline 512 KB CACHE Pentium ® Processor based PC / AT compatible system with ISA bus and PCI Local Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with the performance you want. - Page 43 Support Modem Ring On. (Include internal Modem and external modem Supports Wake up on LAN (JP4). Supports 16 768 MB DRAM memory on board. Supports 3x168 pin 64/72 Bit DIMM module. -channel Enhanced PCI IDE ports for 4 IDE Devices. Supports Green function, Plug &...
-
Page 44: Performance List
5SMM 1.3. PERFORMANCE LIST The following list of performance data is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Pentium ®... -
Page 45: Block Diagram
Introduction 1.4. BLOCK DIAGRAM HOST Bus 3.3V SDRAM DIMM Sockets DRAM Bus 33MHz CHIPSET 66~100 MHz 66~100 IDE BUS CLOCK 33 MHz Ultra DMA/33 IDE Ports 14.318 33 MHz 48MHz 5595 14.318MHz CHIPSET USB Bus 14.318MHz ISA Bus 24MHz 33MHz COM Ports LPT Port CHIPSET... -
Page 46: Introduce The Pci - Bus
5SMM 1.5. INTRODUCE THE PCI - BUS Connecting devices to a CPU local bus can dramatically increase the speed of I/O- bound peripherals with only a slight increase in cost over traditional systems. This price / Performance point has created a vast market potential for local bus products. -
Page 48: Specification
Specification 2. SPECIFICATION 2.1. HARDWARE ® • − Pentium Processor 133 / 166 / 200 MHz ; MMX(166 / 200 / 233) − AMD K6 (166 / 200 / 233 / 266 / 300) K6-2 (266 / 300 / 333 / 350 / 366 / 380 / 400 / 450 / 475 / 500 / 533 / 550) K6-III (400 / 450 /475 / 500 / 550) −... -
Page 49: Software
5SMM • − Supports 1 x16550 COM ports. (Using IRQ4, 3) I/O PORTS − Supports 1 x EPP/ECP LPT port. (Using IRQ7 or 5 and DMA3) − Supports 1 x 1.44/2.88 MB Floppy port. (Using DMA2 & IRQ6) − Supports PS/2 Mouse. (Using IRQ12 ) •... -
Page 50: Hardware Installation
Hardware Installation 3. HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: • The 5SMM mainboard. • USER’ S MANUAL for mainboard. • Cable set for IDE ¡ B Floppy. • CD for Mainboard Utility. The mainboard contains sensitive electric components which can be easily damaged by static electricity, so the mainboard should be left in its original packing until it is installed. -
Page 51: Mainboard Layout
5SMM 3.2 MAINBOARD LAYOUT GAME & COM A PS/2 Audio SOLO-1 ES1938S SW 1 SIS530 5595 5SMM ATX POWER BAT 1 IDE 2 SYSTEM BIOS IDE 1 FLOPPY ×Figure 3.1Ø 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector IDE 1 For Primary IDE port. - Page 52 Hardware Installation JP4: Wake on Lan Function +5V SB Signal JP5 :Internal MODEN WAKE UP Function Signal FAN1: CPU cooling FAN Power Connector Function +12V Signal JP2: Keyboard Power On Connector Function 1,2 Close Enabled Keyboard power on. 2,3 Close Disabled Keyboard power on.
- Page 53 5SMM JP1 : On-Board Sound Function Connector Function Enabled On-Board Sound Function. Disabled On-Board Sound Function. JP3 : Infrared Connector (Optional) Function IR Data Output IR Data Input Power (+) J9 : PS/2 Mouse by Connector (Optional) Function Data Clock J10 : TEL:The Connector is for Modem with internal Voice connector Function Signal...
- Page 54 Hardware Installation (This function is support in PCB version 1.3 and above) Function Open Normal Close Write Protection J2 : CD Audio Line In Function Right Left J4 : 2*11 PIN Jumper PW P+P− P− PW : Soft Power Connector On –...
-
Page 55: Dram Installation
5SMM − PIN 1: VCC PIN 2: NC PIN 3: NC PIN 4: Data HD: IDE Hard Disk Active LED PIN 1: LED anode (+) PIN 2: LED cathode (−) GN: Green Switch Open: Normal operation Short: Entering Green Mode GD: Green Function Active LED PIN 1: LED athode (+) PIN 2: LED cathode (−) - Page 56 Hardware Installation The system speed depends on the frequency of CLOCK GENERATOR. The user can change SW selection to set up the system speed to 66 / 75 / 83 / 90 / 95 / 100MHz for 3.3V/2.5V Pentium ® Processor (133 / 166 / 200 MHz) ;MMX(166 / 200 / 233 MHZ) , AMD K6-(166 / 200 / 233 / 266 / 300 ;...
-
Page 57: Cmos Rtc & Isa Cfg Cmos Sram
5SMM X1.5 X2.5 X3.5 X4.5 X5.5 SW 1 : SDRAM 66.8 33.4 66.8 83.3 33.3 83.3 31.7 32.33 33.4 37.3 33.3 ♦Note : If Cyrix 6x86 is being used, please check the CPU Date Code after 605. ♦Note : It’ s strongly recommended that set the system speed according to your hardware configuration: CPU, SDRAM, Cards, etc. -
Page 58: Speaker Connector Installation
Hardware Installation 3.8. SPEAKER CONNECTOR INSTALLATION There is a speaker in AT system for sound purpose. The 4 - Pins connector SPK is used to connect speaker. The speaker can work well in both direction of connector when it is installed to the connector SPK on mainboard. 3.9. -
Page 59: Bios Configuration
5SMM BIOS CONFIGURATION Award's BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS SRAM so that it retains the Setup information when the power is turned off. 4.1. - Page 60 BIOS Configuration 4.2. CONTROL KEYS Up arrow Move to previous item. Down arrow Move to next item. Left arrow Move to the item in the left hand. Right arrow Move to the item in the right hand. Esc key Main Menu - Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu - Exit current page and return to Main Menu.
-
Page 61: Getting Help
5SMM 4.3. GETTING HELP 4.3.1. Main Menu\ The on-line description of the highlighted setup function is displayed at the bottom of the screen. 4.3.2. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. - Page 62 BIOS Configuration • Power management setup This setup page includes all the items of Green function features. • PNP/PCI configuration This setup page includes all the items of PNP/PCI configuration features. • Load BIOS defaults BIOS defaults indicates the most appropriate value of the system parameter which the system would be in safe configuration.
-
Page 63: Standard Cmos Setup Menu
5SMM 4.5. STANDARD CMOS SETUP MENU The items in Standard CMOS Setup Menu (Figure 4.2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. - Page 64 BIOS Configuration • Primary HDDs / Secondary HDDs The category identify the types of hard disk from drive C to drive F 4 devices that has been installed in the computer. There are three options for definable type; User, Auto and None . Type User is user-definable;...
- Page 65 5SMM Disable Normal Floppy Drive. Drive A Drive A is 3 mode Floppy Drive. Drive B Drive B is 3 mode Floppy Drive. Both Drive A & B are 3 mode Floppy Drive. • Video The category detects the type of adapter used for the primary system monitor that must match your video display card and monitor.
- Page 66 BIOS Configuration • Memory The category is display-only which is determined by POST (Power On Self Test) of the BIOS. Base Memory The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system. The value of the base memory is typically 512 K for systems with 512 K memory installed on the motherboard, or 640 K for systems with 640K or more memory installed on the...
- Page 67 5SMM 4.6. BIOS FEATURES SETUP Figure 4.3: BIOS Features Setup • Virus Warning This category flashes on the screen. During and after the system boots up, any attempt to write to the boot sector or partition table of the hard disk drive will halt the system and the following error message will appear, in the mean time, you can run anti-virus program to locate the problem.
- Page 68 BIOS Configuration • Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power on the computer. If it set to Enable, BIOS will skip some check items during POST. The default value is Enabled. Enabled Enabled quick POST.
- Page 69 5SMM SCSI,A,C System will first search for SCSI drive then floppy disk drive and hard disk (C) drive . SCSI,C,A System will first search for SCSI drive and hard disk (C) drive then floppy disk drive . C only System will only search for hard disk (C) drive. LS/ZIP,C System will first search for floppy disk drive (LS) or ZIP drive then hard disk (C) drive.
- Page 70 BIOS Configuration • PCI/VGA Palette Snoop The default value are Disabled. Enabled For having Video Card on ISA Bus and VGA Card on PCI Bus. Disabled For VGA Card only. • OS Select For DRAM>64MB The default value is Non-OS2. Non-OS2 Using non-OS2 operating system.
-
Page 71: Chipset Features Setup
5SMM • C8000 - CFFFF Shadow / D0000 - DFFFF Shadow These categories determine whether optional ROM will be copied to RAM by 16 byte. The default value are Disabled. Enabled Optional shadow is enabled. Disabled Optional shadow is disabled. 4.7. - Page 72 BIOS Configuration • Refresh Rate Control The default value is 15.6us. 15.6us Set Refresh Rate Control function to 15.6us. 7.8us Set Refresh Rate Control function to 7.8us. 3.9us Set Refresh Rate Control function to 3.9us. • Ref/Act Command Delay The default value is 6T. Set Ref/Act Command Delay to 5T.
- Page 73 5SMM • SDRAM CAS Latency The default value is 3T Set SDRAM CAS Latency to 2T. Set SDRAM CAS Latency to 3T. • SDRAM WR Retire Rate The default value is X-1-1-1 X-1-1-1 Set SDRAM WR Retire Rate to X-1-1-1. X-2-2-2 Set SDRAM WR Retire Rate to X-2-2-2.
- Page 74 BIOS Configuration • CPU to PCI Post Write The default value is Enabled Enabled Enabled CPU to PCI Post Write Function. Disabled Disabled CPU to PCI Post Write Function. • AGP Aperture Size The default value is 64MB. Set AGP Aperture Size to 4MB. Set AGP Aperture Size to 8MB.
- Page 75 5SMM • Linear Mode SRAM Support The default value is Disabled. Enabled Enabled Linear Mode SRAM Support. Disabled Disabled Linear Mode SRAM Support. • PCI Post Write Buffer The default value is Disabled. Enabled Enabled PCI Post Write Buffer. Disabled Disabled PCI Post Write Buffer.
- Page 76 BIOS Configuration 4.8. POWER MANAGEMENT SETUP Figure 4.5: Power Management Setup These five items will show up when Power Up by Alarm is Enabled. • Power Management The default value is Enable. Enable Enable Green function. Disable Disable Green function. •...
- Page 77 5SMM • MODEM use IRQ The default value is 3. No use IRQ for Modem. 3~5,7,9~11 Assign Available IRQ# for Modem. • HDD Off After The default value is Disable. Disable Disable HDD Off After. 1min-15min Set HDD timer to get into power down mode. •...
- Page 78 BIOS Configuration • VGA Activity The default value is Enabled. Disabled Disabled VGA Activity. Enabled Enabled VGA Activity. • IRQ [3-7,9-15] , NMI The default value is Enabled. Disabled Disabled this function. Enabled Enabled monitor IRQ [3-7, 9-15],NMI for Green event. •...
- Page 79 5SMM • Power Up by Alarm The default value is Disabled. Disabled Disabled this function. Enabled Enabled alarm function to POWER ON system. If the default value is Enabled. Month Alarm: NA,1~12 Date of Month Alarm: 0~31 Week Alarm: SUN MON TUE WED THU FRI SAT Off Off Off Off Off Off Off Time ( hh: mm: ss) Alarm:...
- Page 80 BIOS Configuration • Reset Configuration Data The default value is Disabled. Disabled Disabled this function. Enabled Enabled clear PnP information in ESCD. • IRQ (3,4,5,7,9,10,11,12,14,15), DMA(0,1,3,5,6,7) assigned to The default value is "Legacy ISA" or "PCI/ISA PnP". Legacy ISA The resource is used by Legacy ISA device. PCI/ISA PnP The resource is used by PCI/ISA PnP device (PCI or ISA).
-
Page 81: Load Bios Defaults
5SMM 4.10. LOAD BIOS DEFAULTS Figure 4.7: Load BIOS Defaults • Load BIOS Defaults To load BIOS defaults value to CMOS SRAM, enter "Y". If not, enter "N". 4-23... -
Page 82: Load Setup Defaults
BIOS Configuration 4.11. LOAD SETUP DEFAULTS Figure 4.8: Load Setup Defaults • Load SETUP Defaults To load SETUP defaults value to CMOS SRAM, enter "Y". If not, enter "N". If there is any problem occurred, loading SETUP DEFAULTS step is recommended. - Page 83 5SMM 4.12. INTEGRATED PERIPHERALS Figure 4.9: Integrated peripherals • Internal PCI/IDE The default value is Both. Disabled Disabled Internal PCI/IDE . Primary Set Internal PCI/IDE to Primary. Secondary Set Internal PCI/IDE to Secondary . Both Set Internal PCI/IDE to Both. •...
- Page 84 BIOS Configuration • IDE Primary Slave PIO (for onboard IDE 1st channel). The default value is Auto. Auto BIOS will automatically detect the IDE HDD Accessing mode. Mode0~4 Manually set the IDE Accessing mode. • IDE Secondary Master PIO (for onboard IDE 2nd channel). The default value is Auto.
- Page 85 5SMM • Secondary Master UltraDMA (for onboard IDE 2nd channel). The default value is Auto. Auto BIOS will automatically set the IDE HDD to Ultra DMA/33 Mode. Disabled Disable Ultra DMA HDD Function. • Secondary Slave UltraDMA (for onboard IDE 2nd channel). The default value is Auto.
- Page 86 BIOS Configuration • Onboard Serial Port 1 The default value is 3F8/IRQ4. Auto BIOS will automatically setup the port 1 address. 3F8/IRQ4 Enable onboard Serial port 1 and address is 3F8. 2F8/IRQ3 Enable onboard Serial port 1 and address is 2F8. 3E8/IRQ4 Enable onboard Serial port 1 and address is 3E8.
- Page 87 5SMM • Onboard Parallel Mode The default value is SPP. Using Parallel port as Normal Printer Port. EPP/SPP Using Parallel port as Enhanced Parallel Port / Normal Printer Port. Using Parallel port as Extended Capabilities Port. ECP/EPP Using Parallel port as Extended Capabilities Port mode/Enhanced Parallel Port.
- Page 88 BIOS Configuration • VGA Memory Clock (MHz) The default value is 100. Set VGA Memory Clock to 66MHz. Set VGA Memory Clock to 75MHz. Set VGA Memory Clock to 83MHz. Set VGA Memory Clock to 90MHz. Set VGA Memory Clock to 95MHz. Set VGA Memory Clock to 100MHz.
-
Page 89: Password Setting
5SMM 4.13. PASSWORD SETTING When you select this function, the following message will appear at the center of the screen to assist you in creating a password. Figure 4.10: Password Setting Type the password, up to eight characters, and press <Enter>. The password typed now will clear previously entered password from CMOS memory. -
Page 90: Ide
BIOS Configuration 4.14. IDE HDD AUTO DETECTION Figure 4.11: IDE HDD Auto Detection Type "Y" will accept the H.D.D. parameter reported by BIOS. Type "N" will keep the old H.D.D. parameter setup. If the hard disk cylinder NO. is over 1024, then the user can select LBA mode or LARGE mode for DOS partition larger than 528 MB. - Page 91 5SMM 4.15. SAVE & EXIT SETUP Figure 4.12: Save & Exit Setup Type "Y" will quit the Setup Utility and save the user setup value to RTC CMOS SRAM. Type "N" will return to Setup Utility. 4-33...
- Page 92 BIOS Configuration 4.16. EXIT WITHOUT SAVING Figure 4.13: Exit Without Saving Type "Y" will quit the Setup Utility without saving to RTC CMOS SRAM. Type "N" will return to Setup Utility. 4-34...
- Page 93 C:\utility\ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing> ü Once the process is finished, reboot the system MNote : Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file.
- Page 94 Product Name: Mother Board generates, uses, and can radiate radio frequency GA-5SMM Model Number: energy, and if not installed and used in accordance with Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),...
-
Page 95: Declaration Of Conformity
Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-5SMM is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive...
