User Manual
5SMM
1.
1.1. PREFACE ................................................................................. 1-1
1.2. KEY FEATURES ....................................................................... 1-1
1.3. PERFORMANCE LIST .............................................................. 1-3
1.4. BLOCK DIAGRAM..................................................................... 1-4
1.5. INTRODUCE THE PCI - BUS .................................................... 1-5
1.6. FEATURES ............................................................................... 1-5
2.
2.1. HARDWARE ............................................................................. 2-1
2.2. SOFTWARE.............................................................................. 2-2
2.3. ENVIRONMENT ........................................................................ 2-2
3.
3.1. UNPACKING ............................................................................. 3-1
3.2. MAINBOARD LAYOUT.............................................................. 3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS .......... 3-2
3.4. SRAM INSTALLATION DRAM INSTALLATION.......................... 3-6
3.5. DRAM INSTALLATION.............................................................. 3-6
3.6. CPU INSTALLATION AND JUMPERS SETUP........................... 3-7
3.7. CMOS RTC & ISA CFG CMOS SRAM....................................... 3-8
3.8. SPEAKER CONNECTOR INSTALLATION................................. 3-9
TABLE OF CONTENTS
1
Advertisement
Table of Contents
Related Manuals for Gigabyte 5SMM
Summary of Contents for Gigabyte 5SMM
-
Page 1: Table Of Contents
5SMM TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE ................. 1-1 1.2. KEY FEATURES ............... 1-1 1.3. PERFORMANCE LIST .............. 1-3 1.4. BLOCK DIAGRAM..............1-4 1.5. INTRODUCE THE PCI - BUS ............ 1-5 1.6. FEATURES ................1-5 SPECIFICATION 2.1. HARDWARE ................2-1 2.2. - Page 2 Table Of Contents 3.10. GREEN FUNCTION INSTALLATION ........3-9 3.11. PERIPHERAL DEVICE INSTALLATION........3-9 BIOS CONFIGURATION 4.1. ENTERING SETUP ..............4-1 4.2. CONTROL KEYS ..............4-2 4.3. GETTING HELP ................ 4-3 4.3.1.Main Menu ............... 4-3 4.3.2.Status Page Setup Menu / Option Page Setup Menu..4-3 4.4.
-
Page 3: Introduction
1. INTRODUCTION 1.1. PREFACE Welcome to use the 5SMM motherboard. The motherboard is a Pipeline 512 KB CACHE Pentium ® Processor based PC / AT compatible system with ISA bus and PCI Local Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with the performance you want. - Page 4 Introduction Support Modem Ring-On. (Include internal Modem and external modem on COM A) Supports Wake-up on LAN (JP4). Supports 16 - 768 MB DRAM memory on board. Supports 3x168 pin 64/72 Bit DIMM module. Supports 2-channel Enhanced PCI IDE ports for 4 IDE Devices. Supports 1xCOM (16550), 1xLPT (EPP / ECP), 1x1.44MB Floppy port.
-
Page 5: Performance List
5SMM 1.3. PERFORMANCE LIST The following list of performance data is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) -
Page 6: Block Diagram
Introduction 1.4. BLOCK DIAGRAM HOST Bus 3.3V SDRAM DIMM Sockets DRAM Bus 33MHz CHIPSET 66~100 MHz 66~100 IDE BUS CLOCK 33 MHz Ultra DMA/33 IDE Ports 14.318 33 MHz 48MHz 5595 14.318MHz CHIPSET USB Bus 14.318MHz ISA Bus 24MHz 33MHz COM Ports LPT Port CHIPSET... -
Page 7: Introduce The Pci - Bus
5SMM 1.5. INTRODUCE THE PCI - BUS Connecting devices to a CPU local bus can dramatically increase the speed of I/O- bound peripherals with only a slight increase in cost over traditional systems. This price / Performance point has created a vast market potential for local bus products. -
Page 9: Specification
Specification 2. SPECIFICATION 2.1. HARDWARE • ® − Pentium Processor 133 / 166 / 200 MHz ; MMX(166 / 200 / 233) − AMD K6 (166 / 200 / 233 / 266 / 300) K6-2 (266 / 300 / 333 / 350 / 366 / 380 / 400 / 450 / 475 / 500 / 550) K6-III (400 / 450 /475 / 500 / 550) −... -
Page 10: Software
5SMM • − Supports 1 x16550 COM ports. (Using IRQ4, 3) I/O PORTS − Supports 1 x EPP/ECP LPT port. (Using IRQ7 or 5 and DMA3) − Supports 1 x 1.44/2.88 MB Floppy port. (Using DMA2 & IRQ6) − Supports PS/2 Mouse. (Using IRQ12 ) •... -
Page 11: Hardware Installation
Hardware Installation 3. HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: • The 5SMM mainboard. • USER’ S MANUAL for mainboard. • Cable set for IDE ¡ B Floppy. • CD for Mainboard Utility. The mainboard contains sensitive electric components which can be easily damaged by static electricity, so the mainboard should be left in its original packing until it is installed. -
Page 12: Mainboard Layout
5SMM 3.2 MAINBOARD LAYOUT GAME & COM A PS/2 Audio SOLO-1 ES1938S SW 1 SIS530 5595 5SMM ATX POWER BAT 1 IDE 2 SYSTEM BIOS IDE 1 FLOPPY ×Figure 3.1Ø 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector IDE 1 For Primary IDE port. - Page 13 Hardware Installation JP4: Wake on Lan Function +5V SB Signal JP5 :Internal MODEN WAKE UP Function Signal FAN1: CPU cooling FAN Power Connector Function +12V Signal JP2: Keyboard Power On Connector Function 1,2 Close Enabled Keyboard power on. 2,3 Close Disabled Keyboard power on.
- Page 14 5SMM JP1 : On-Board Sound Function Connector Pin No. Function Enabled On-Board Sound Function. Disabled On-Board Sound Function. JP3 : Infrared Connector (Optional) Pin No. Function IR Data Output IR Data Input Power (+) J9 : PS/2 Mouse by Connector (Optional)
- Page 15 Hardware Installation J2 : CD Audio Line In Function Right Left J4 : 2*11 PIN Jumper PW P+P− P− PW : Soft Power Connector On – Off : For POWER ON or Suspend IN / OUT. On 4 sec : For POWER OFF before VGA Enable or CMOS setup select “...
-
Page 16: Dram Installation
5SMM PIN 4: Data HD: IDE Hard Disk Active LED PIN 1: LED anode (+) PIN 2: LED cathode (−) GN: Green Switch Open: Normal operation Short: Entering Green Mode GD: Green Function Active LED PIN 1: LED athode (+) PIN 2: LED cathode (−) -
Page 17: Cpu Installation And Jumpers Setup
Hardware Installation 3.6. CPU INSTALLATION AND JUMPERS SETUP The system speed depends on the frequency of CLOCK GENERATOR. The user can change SW selection to set up the system speed to 66 / 75 / 83 / 90 / 95 / 100MHz for 3.3V/2.5V Pentium ®... -
Page 18: Cmos Rtc & Isa Cfg Cmos Sram
5SMM 2.4V X1.5 X2.5 X3.5 X4.5 X5.5 SW 1 : SDRAM 66.8 33.4 66.8 83.3 33.3 83.3 31.7 33.4 37.3 33.3 ♦Note: If Cyrix 6x86 is being used, please check the CPU Date Code after 605. ♦Note: It’ s strongly recommended that set the system speed according to your hardware configuration: CPU, SDRAM, Cards, etc. -
Page 19: Speaker Connector Installation
Hardware Installation 3.8. SPEAKER CONNECTOR INSTALLATION There is a speaker in AT system for sound purpose. The 4 - Pins connector SPK is used to connect speaker. The speaker can work well in both direction of connector when it is installed to the connector SPK on mainboard. 3.9.
