MICROWAVE OVEN
Installation & User Instructions
800W
E
IMPORTANT
• WARNING: if the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person;
• WARNING: it is hazardous for anyone other than a competent person to
carry out any service or repair operation that involves the removal of a
cover which gives protection against exposure to microwave energy;
• WARNING: liquids and other food must not be heated in a sealed
container since they are liable to explode;
• WARNING: only allow children to use the oven without supervision when
adequate instruction have been given so that the child is able to use the
oven in a safe way and understands the hazards of improper use.
• WARNING: accessible parts may become hot during use. Young children
should be kept away.
CAREFULLY RETAIN THESE INSTRUCTIONS
–
Please keep for future reference
400/7951
Clock/
Reheat
Memory Defrost
Kitchen Timer
h-1:Auto Reheat
d-1:Defrost By Time
h-2:Dinner Plate
d-2:Defrost By Weight
h-3:Coffee
d-3:Ground Meat
d-4:Sea Food
h-4:Roll
