Page 1: Instruction Manual
Microwave Oven INSTRUCTION MANUAL Model: MRMWO34GC Read these instructions carefully before using your microwave oven. STORE THESE INSTRUCTIONS CAREFULLY www.morphyrichards.com.au... -
Page 2: Precautions To Avoid Possible Exposure To Excessive Microwave Energy
If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the apparatus and lead to a dangerous situation. SPECIFICATIONS Model: MRMWO34GC Rated Voltage: 230-240V~50Hz Rated Input Power (Microwave): 1550W... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following: Read and follow the specific: “PRECAUTIONS TO AVOID • POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY”. This appliance can be used by children aged from 8 years and •... - Page 4 Do not heat food in plastic or paper containers, due to the possibility of • ignition. Only use utensils that are suitable for use in microwave ovens. • If smoke is emitted, switch off or unplug the appliance and keep the •...
-
Page 5: Read Carefully And Keep For Future Reference
Metallic containers for food and beverages are not allowed during • microwave cooking. The appliance shall not be cleaned with a steam cleaner. • The appliance is intended to be used freestanding. • The rear surface of appliances shall be placed against a wall. •... -
Page 6: Electric Shock Hazard
DANGER ELECTRIC SHOCK HAZARD Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance. WARNING ELECTRIC SHOCK HAZARD Improper use of the grounding can If it is necessary to use an extension result in electric shock. -
Page 7: Utensils Caution
CLEANING BE SURE TO UNPLUG THE APPLIANCE FROM THE POWER SUPPLY. Clean the cavity of the oven after using with a slightly damp cloth. Clean the accessories in the usual way in soapy water. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty. -
Page 8: Materials You Can Use In Microwave Oven
MATERIALS YOU CAN USE IN MICROWAVE OVEN Utensils Remarks Browning dish Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break. Dinnerware Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes. -
Page 9: Materials To Be Avoided In Microwave Oven
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with May cause arcing. Transfer food into microwave-safe dish. metal handle Metal or metal Metal shields the food from microwave energy. trimmed utensils Metal trim may cause arcing. -
Page 10: Setting Up Your Oven
SETTING UP YOUR OVEN NAMES OF OVEN PARTS AND ACCESSORIES Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray Turntable ring assembly Instruction Manual Control panel Turntable shaft Turntable ring assembly Glass tray Grill Rack (Can not be used in microwave Observation window... -
Page 11: Countertop Installation
COUNTERTOP INSTALLATION Remove all packing material and Cabinet: Remove any protective film found accessories. Examine the oven for any on the microwave oven cabinet surface. damage such as dents or broken door. Do Do not remove the light brown Mica cover not install if oven is damaged. -
Page 12: Clock Settings
OPERATION INSTRUCTION CLOCK SETTINGS When the microwave oven is electrified,the oven will display “0:00”, buzzer will ring once. The input time should be within 0:00--23:59 (24 Hour). Example: To set 12:12 . Press “KITCHEN TIMER /CLOCK” twice, “00:00” will flash. Press the number buttons of “1”, “2”, “1”, “2” in order. Press “KITCHEN TIMER /CLOCK”... -
Page 13: Kitchen Timer
KITCHEN TIMER Press “KITCHEN TIMER/CLOCK” once, LED will display 00:00. Press the number buttons and enter the correct time. (the maximum cooking time is 99 minutes and 99 seconds) Press “START/+30SEC.” to confirm setting. When the kitchen time is reached, the buzzer will ring 5 times. Then turn back to waiting state. If the clock is set (24-hour system), LED will display the current time. -
Page 14: Convection Cooking (Without Preheating Function)
CONVECTION COOKING (WITHOUT PREHEATING FUNCTION) Press the “CONVEC.” button once, “150 ” will flash. Press the “CONVEC.” button several times to select the temperature from 150 C to 240 Press the “START/+30SEC.” button to confirm the temperature. Press the number buttons to set the cooking time. Press the “START/+30SEC.”... -
Page 15: Defrost By Weight
DEFROST BY WEIGHT Press “DEFROST.” pad twice, the oven will display “D-02”. Press “START/+30SEC.” button to confirm the setting. Input the figure of the weight of food. (The input figure of the weight should be within 100--2000g) Press “START/+30SEC.” button to start defrosting. DEFROST GROUND MEAT Press “DEFROST.”... -
Page 16: Auto Menu Chart
AUTO MENU CHART Menu Weight Press Times Display 150g Once VEGETABLE 350g Twice 500g 3 times 150g Once 250g Twice FISH 350g 3 times 450g 4 times 650g 5 times 150g Once 300g Twice MEAT 450g 3 times 600g 4 times 50g (with cold water 450 Once PASTA... -
Page 17: Multi-Stage Cooking
MEMORY Press “MEMORY.” button one to three times to set memory “1”, memory “2” or memory “3” program, and the oven will display “1”, “2” or “3”. Set one or two stages to program you want. (Reheat or Auto menu cannot be set as memory program). Example: •... -
Page 18: Reheat Chart
REHEAT Press “REHEAT.” pad , the “H-01” will flash and “AUTO.” indicator will light (Press the “REHEAT.” pad several times to select the cooking program you wanted.) Press “START/+30SEC.” button to confirm. Press the “REHEAT.” pad several times t o select th e the weight of the cooking food. Press “START/+30SEC.”... -
Page 19: Inquiring Function
INQUIRING FUNCTION In cooking state, press “COMBI.”, “MICROWAVE.”, or “CONVEC.”, and the current power will be displayed for 3 seconds. In cooking state, press “CLOCK/KITCHEN TIMER.” to inquire the time. The time will flash for 3 seconds. LOCK-OUT FUNCTION FOR CHILDREN LOCK: In waiting state, press “STOP/CLEAR”... -
Page 20: Troubleshooting
TROUBLE SHOOTING Normal Microwave oven Radio and TV reception may be interfered with when microwave interfering TV reception oven is operating. It is similar to the interference of small electrical appliances, like mixer, vacuum cleaner, and electric fan. It is normal. Dim oven light In low power microwave cooking, oven light may become dim.
