Edition Blue™ 15/30/60 DFX Content The Edition Blue™ DFX‘ channels ... 8 1.1 The Clean channel 1.2 Volume 1.3 Channel Select 1.4 The Lead channel 1.5 Lead Gain 1.6 Lead Master Congratulations on the purchase of your 1.7 Bass, Mid, Treble Hughes &...
Page 3
Edition Blue™ 15/30/60 DFX The Channels of the Edition Blue™ DFX The Effects of the Edition Blue DFX The Edition Blue™ DFX is equipped with two channels, Clean and The Edition Blue DFX is equipped with two independent „signal Lead. Its innovative circuit design, which simulates the important processors“.
(speaker simulation) from the Master control. 3.3 Footswitch (not applicable for Edition Blue 15 DFX) This jack is for a standard 1-way or 2-way Footswitch (e.g. Hughes & Kettner® FS-1 or FS-2). This allows you to switch back and forth between the Clean and Lead channels and to turn the effect section on and off as you want.
Edition Blue™ 15/30/60 DFX Before you switch on the audio playback device, turn the Master Troubleshooting control all the way down. Then turn up the Master control a little and dial in the desired balance levels. Once you‘re satisfied with these The Edition Blue™...
Edition Blue™ 15/30/60 DFX Technical Specifications Model: 15 DFX 30 DFX 60 DFX Output power into 8 ohms: 15 watts 30 watts 60 watts Max. power consumption: 55 VA 70 VA 100 VA Mains fuse: 230/240 volt configuration T 250 mA T 315 mA T 250 mA 120 volt configuration...
Page 7
Hughes & Kettner Edition Blue DFX Hughes & Kettner Edition Blue DFX July 2005 Juli 2005...
Page 8
Hughes & Kettner Postfach 1509 66595 St. Wendel Tel: +49 (0) 68 51 - 905 0 Fax: +49 (0) 68 51 - 905 103 International Inquiries: Fax: +49 - 68 51 - 905 200 hkinternational@hughes-and-kettner.com www.hughes-and-kettner.com Copyright 2005 by Music & Sales GmbH Subject to change without notice...
