Product View; Power Cord - Bissell CLEANVIEW POWER 1540 User Manual

A

Product View

Do not plug in your cleaner until you have
completely assembled it per the following
instructions and are familiar with all instructions
and operating procedures.
1 Handle
2 Air Flow Regulator
3 Extension Wand
4 Hose
5 Carry Handle
6 Dirt Cup Release Button
7 Hose Connector
8 Dirt Cup Filter
9 Easy Empty™ Dirt Cup
B
Assembly
1. Connect hose to vacuum by inserting hose
connector on the end of the hose into the
suction inlet. Make sure the hose is positioned
so the tabs on the hose connector line up
with the notches on the suction inlet. Once
inserted into the suction inlet, turn counter
clockwise to lock into place.
2. Connect hose handle to the end of the
extention wand and twist slightly to tighten.
3. Connect floor nozzle to the end of the
extension wand and twist slightly to tighten.
4. Once assembled, you can store your
vacuum by inserting the storage clip
(located on the back of the floor nozzle) into
the storage slot on the rear of the vacuum.
Colours may vary from models shown.
C
Operations

Power cord

The power cord is located at the rear of the
vacuum. Gently pull out the power cord,
watching for the yellow line. Stop pulling the
power cord once the yellow line is visible.
There is also a red line, which indicates the
end of the usable cord. Do not pull the
power cord out beyond the red line.
Before using your vacuum, make sure that the dirt
cup and all filters are in place. Do not operate your
vacuum without the dirt cup and filters.
Be careful to avoid injury as cord retracts very quickly.
Plastic film can be dangerous. To avoid danger of
suffocation, keep away from babies and children.
10 Emptying Button
11 Brush Switch
12 Multi-Surface Floor Nozzle
a. Up / b. Down
13 Combination Crevice Tool/
Dusting Brush
14 TurboBrush™ Tool
15 Hard Floor Brush
16 Turbine Nozzle
C1 - Automatic cord rewind
Your vacuum is equipped with an automatic
cord rewind. When cleaning is finished, press
the power button OFF and grasp the plug to
disconnect from the electrical outlet. Hold
the plug and press the automatic cord rewind
button to rewind the cord automatically.
C2 - Power button
Turn the power ON or OFF by pressing lightly
downward on the power button (
Special tools
Your BISSELL CleanView Power vacuum is
not only a powerful carpet and rug vacuum
cleaner, it's also a versatile bare floor and
above floor vacuum cleaner when you select
one of the special tools.
Floor nozzle (12)
Use to vacuum carpets, rugs and bare floors.
Swivel head turns to get into tight spaces
and fits under cabinets.
1. To vacuum carpets and rugs, push the brush
switch to the carpet position
pull the brushes up into the floor nozzle.
2. To vacuum bare floors, push the brush
switch to the bare floor position
This will extend the brus hes down from
the floor nozzle.
Combination crevice
tool/dusting brush (13)
Use the crevice tool in tight, narrow spaces.
Use the dusting brush to clean curtains,
draperies, cushions and fabrics.
TurboBrush™ Tool (14)
(select models only)
Use rotating brush action for small, flat areas
such as cushions and beds.
NOTE: Press down gently and pull toward
you in a raking motion. Too much pressure
will cause the brush to stop rotating.
Turbine Head (16)
Use to vacuum carpets and rugs. Swivel
head turns to get into tight spaces and fits
under tight cabinets. Easy-to-remove nozzle
window for cleaning threads and debris from
the brush roll. Squeeze the 2 small tabs at
the side of the foot to release the window.
To replace, align the window tabs at the top
with the 2 openings of the foot and push
into place until you hear a snap and the
window is securely in place.
Hard Floor Brush (15)
Specially designed to vacuum bare floors.
www.BISSELL.com
).
. This will
.
(select models only)
(select models only)
5
