OEM SALES
CORPORATE OFFICE
www.
8 Shackleford Plaza,
1020 Owen Loop South
Suite 201
Eugene, OR 97402
rosenaviation
Little Rock, AR 72211
1-888-668-4955
.com
1-888-523-7523
Fax (541) 342-4912
Fax (501) 225-1015
Document # 9002751 Rev D
DEALER & OPERATOR SALES
1121 Warren Ave, Suite 240
Downers Grove, IL 60515
1-800-859-5058
Fax (630) 963-4405
9002751
6.5
DISPLAY
DISPLAY
6500
Compliant to DO-160D
SlimLine
Model Number
6500
www.
rosenaviation
.com
Advertisement
Table of Contents
Related Manuals for Rosen 6500
Summary of Contents for Rosen 6500
- Page 1 SlimLine Model Number 6500 DISPLAY DISPLAY 6500 OEM SALES CORPORATE OFFICE DEALER & OPERATOR SALES www. www. 8 Shackleford Plaza, 1121 Warren Ave, Suite 240 1020 Owen Loop South Suite 201 Eugene, OR 97402 Downers Grove, IL 60515 rosenaviation rosenaviation...
-
Page 2: Table Of Contents
Table of Contents Introduction and Display Overview ....3 Pinouts ..............4 Installation Guidelines........6 Operation ............8 Technician Mode.............14 Troubleshooting ..........16 Technical Support ..........17 Specifications ........... 18 Disclaimer ............19 6.5” SlimLine LCD Page 1... - Page 3 1020 Owen Loop South Eugene OR 97402 541-342-3802 www.rosenaviation.com...
-
Page 4: Introduction And Display Overview
Introduction and Display Overview Introduction and Display Overview Welcome to the 6500 Technical Manual for the 6.5" LCD display. This manual provides an overview of the following information: • Pinouts • Installation • Operation • Technician Mode • Troubleshooting •... -
Page 5: Pinouts
SlimLine Base Receptacle Models: 0100-002, 0100-004, 0100-041, and 0100-042 Connector: 9 Pin Male D-Subminiature Mate: 9 Pin Female D-Subminiature Rosen Connector Kit part number 0300-022 Pin # Monitor Signal Chassis Ground +28V DC DC Return... - Page 6 Pinouts SlimLine Base Receptacle Models: 0100-005 and 0100-040 Video Connector: BNC Jack, AMP part number 221199-5 Mating Video Connector: BNC Plug, AMP part number 221185-8 P P P P P in # Monitor Signal BNC signal Video Signal BNC shield Video Return Power Connector: Female 3 pin, .062"...
-
Page 7: Installation Guidelines
Installation Guidelines The following drawings are provided to assist the installation process for your 6.5 display. Pay close attention to dimensions and rotations when considering installation requirements. Note: The dimensions listed are listed in inches. Rosen Aviation Displays Page 6... - Page 8 Installation 6.5” SlimLine LCD Page 7...
-
Page 9: Operation
Slot Set Screw Use the buttons on your 6.5” Display to control screen setup and choose between video source options. Buttons and screen options are defined in this section on page 9. Rosen Aviation Displays Page 8... - Page 10 Operation 6.5" Display Button Functions Display buttons are shown and defined below. Select Switch/ Sub-Menu Scroll/ Status LED Menu Scroll Increase Value Decrease Value Power ON/OFF OSD ON/OFF Select Switch/Menu Scroll: Press this button to switch between video source options , or to scroll down when viewing On Screen Display (OSD) menu options.
- Page 11 This Option is not available with this Display Restore Defaults Select this option to restore factory default settings Video Formats Scroll to this selection’s sub-menu to view video format options (shown on the next page) Rosen Aviation Displays Page 10...
- Page 12 Operation Advanced Menu Options Description Select Switch Adjust Relay Active Time to set the time delay when pressing the Select Switch to change video sources Adjust Repeat Delay to set the time delay when pressing and holding the Select Switch to change video sources Monitor Info Scroll to this selection’s sub-menu to...
- Page 13 Over Temp This option displays the number of over-temperature shut downs that have occurred. *A safety feature shuts down the monitor if it reaches or exceeds 140 degrees Fahrenheit continued... Rosen Aviation Displays Page 12...
- Page 14 Operation Temperature Sub-Menu Options Continued... Description Under Temp This option displays the number of under-temperature shut downs that have occurred. *A safety feature shuts down the monitor if it reaches or drops below 32 degrees Fahrenheit Back Select this option to return to the Monitor Info sub-menu *If an Over Temp or Under Temp shut down occurs, Temp Shutdown is shown on the OSD for approximately 30...
-
Page 15: Technician Mode
Highlight the desired menu option. Press and hold the Select switch in for 5 seconds. Release the Select switch; the next option becomes highlighted and the word OFF appears next to the disabled menu option. Rosen Aviation Displays Page 14... - Page 16 Technician Mode Enabling/Disabling Individual Menu Items Continued... Enable a menu option as follows: Highlight the desired menu option. Press and hold the Select switch in for 5 seconds. Release the Select switch; the next option becomes highlighted and the word ON appears next to the enabled menu option.
-
Page 17: Troubleshooting
Troubleshooting Troubleshooting If the monitor does not function properly, refer to the following troubleshooting table for symptoms and possible solutions before contacting Rosen field support. Notes: • Always use an oscilloscope to verify the video signal • Always use a multimeter to verify voltages •... -
Page 18: Technical Support
SECAM to PAL video switching standard, press the Select switch between SECAM and PAL Technical Support For field support or to order parts, contact Rosen Aviation Displays at: 1-888-668-4955 or visit us at: www.rosenaviation.com 6.5” SlimLine LCD Page 17... -
Page 19: Specifications
Free Air Installation 0ºC - 40ºC Insulated Installation Warranty 2 year DO-160D Testing This Display is compliant with and has been tested to applicable DO-160D standards. For specific information contact a Rosen Customer Service Representative at 1.888.668.4955. Rosen Aviation Displays Page 18... -
Page 20: Disclaimer
Rosen’s only obligations are those in the Rosen Standard Terms and Conditions of Sales for this product, and in no case will Rosen be liable for any incidental, indirect or consequential damages arising from the sale, resale, use or misuse of the product.
