  • Page 1 Back MULTI-PURPOSE LCD DISPLAY MU-120C...
  • Page 3 Continued use of the equipment can cause fire or electrical shock. Contact a FURUNO CAUTION agent for service. Observe the following compass safe distances to prevent interference to a...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS FOREWORD ......................iii SYSTEM CONFIGURATION................iv EQUIPMENT LISTS ....................v 1 MOUNTING ...................... 1 1.1 Display Unit........................1 1.2 Remote Controller ......................4 2 WIRING......................5 3 ADJUSTMENTS ....................7 3.1 RGB/DVI Setting ......................7 3.2 VIDEO Setting......................... 9 3.3 Menu Window Setting ....................

  • Page 5: Foreword

    A Word to the Owner of the MU-120C FURUNO Electric Company thanks you for purchasing the MU-120C 12.1” Multi-Purpose LCD Display. We are confident you will discover why the FURUNO name has become synonymous with quality and reliability. For over 50 years FURUNO Electric Company has enjoyed an enviable reputation for quality and reliability throughout the world.

  • Page 6: System Configuration

    MODEL 1833C-BB series Analog *= Not available for the portrait type. Note: The resolution of MU-120C is SVGA. VGA, XGA and SXGA signal may not be sharp in character or scan line. About the TFT LCD The TFT LCD is constructed using the latest LCD techniques, and displays 99.99% of its pixels.

  • Page 7: Equipment Lists

    EQUIPMENT LISTS Standard supply Name Type Code No. Remarks Display Unit MU-120C − w/LCD cover Remote Controller RMC-200 000-012-629 Spare Parts* SP19-00101 001-403-170 1 set Installation Materials* CP19-00100 000-012-630 1 set Power cable Accessories* FP19-00601 001-403-200 1 set Option Name Type Code No.

  • Page 9: Mounting

    1 MOUNTING Refer to the outline drawing at the end of the manual for mounting dimensions. Note: A grass plate covers the LCD. For this reason, handle the unit carefully. 1.1 Display Unit The display unit may be mounted on a desktop (optional hanger required) or flush mounted in a panel.

  • Page 10: Flush Mounting

    Flush mounting See the outline drawing at the end of the manual for mounting dimensions. CAUTION Hold the cover and display unit together when lifting the display unit. The display unit may fall out if only the cover is held. 1.
  • Page 11 Desktop mounting The display unit can be mounted on a desktop, using the optional hanger, Type: FP19-00700, Code No.: 001-403-240. Contents of hanger mounting kit Name Type Code No. Hanger FP19-00701 001-403-250 Knob bolt FP03-09204 008-523-650 Self-tapping screw 5x20 000-802-081 1.

  • Page 12: Remote Controller

    1.2 Remote Controller Write the device name (ex. “FCV-1200L”) for each “signal” key on the sticker supplied with the remote controller. Attach the sticker to the remote controller, at the location shown below. RGB1 RGB2 VIDEO1 VIDEO2 VIDEO3 PIP1 PIP2 PIP3 BRILL MENU...

  • Page 13: Wiring

    2 WIRING Connect external equipment to the MU-120C by referring to the drawings below, the table on the next page and the interconnection diagram at the back of this manual. Ground terminal 12-24VDC 12-24 DVC MJ-A3SPF0025-035C (Supplied) VIDEO1 VIDEO2 DVI-D...
  • Page 14 Port, cable and connectable equipment Used cable Port Connectable Equipment Standard/ Name Name Type Code No. Option 12-24 Power MJ-A3SPF0025- 000-156-059- Standard Power source cable 035C DVI-D/D PC, FAR-21X7 series, DVI-D 000-149-054 Option Cable SINGLELINK5M FEA-2107 FCV-1200L, CH-250, CH-270, CSH-5L/8L, 3COX-2P-6C RGB1 000-146-500...

  • Page 15: Adjustments

    3 ADJUSTMENTS Adjust the MU-120C according to the equipment connected. Note that you can adjust the display currently selected, at the DISP selection window. (See section 4.3.) 3.1 RGB/DVI Setting RGB1 and RGB2 screens can be adjusted independently. Also, DVI screen can be adjusted similarly.
  • Page 16 Menu item Function Setting range H_SIZE*** Adjusts the image size horizontally. Variable depending on signal type V_SIZE*** Adjusts the image size vertically. PHASE Adjusts the characters and graphic lines. 1-32 CONTRAST Increases or decrease contrast level. 1-64 H_POSITION Moves the image position horizontally. 1-50 (DVI), 1-99 (RGB1, 2) V_POSITION Moves the image position vertically.

  • Page 17: Video Setting

    3.2 VIDEO Setting VIDEO1, VIDEO2 and VIDEO3 screens; that is, the picture-in-picture windows can be adjusted as below. 1. Press the [MENU] key to show the menu. 2. Press [◄] or [►] to select VIDEO1, VIDEO2 or VIDEO3 as appropriate. RGB1 RGB2 VIDEO1...

  • Page 18: Menu Window Setting

    3.3 Menu Window Setting 3.3.1 Adjusting the menu window The menu window can be moved and translucentized on the OSD (On Screen Display) menu. 1. Press the [MENU] key to show the menu. 2. Press the [◄] or [►] key to select OSD. RGB1 RGB2 VIDEO1...

  • Page 19: Changing The Signal Name

    3.3.2 Changing the signal name You can change the signal name which is shown on the DISP or PIP menu, described in the next chapter. It is useful to use the name of the device connected (ex. “FCV-1200L”). For detailed information about these menus, see Chapter 4. 1.

  • Page 20: Remote Controller Setting

    3.4 Remote Controller Setting A remote controller can be set to be operative with a specific display unit, in the case of multiple MU-120C display units. Set the remote controller mode desired on the SYSTEM menu as follows; 1. Press the [MENU] key to show the main menu.

  • Page 21: Operation

    4 OPERATION 4.1 Controls Display unit DISP key Shows the DISPLAY selection window. MENU key Shows the main menu. Power key Turns the power on/off. Optical sensor PIP key Arrow keys Shows the PIP selection window. Selects menu item. BRILL key Shows the BRILL adjustment window.
  • Page 22 Remote controller RGB1 RGB2 VIDEO2 VIDEO3 VIDEO1 PIP1 PIP2 PIP3 BRILL MENU Remote controller Key name Function RGB1* Shows the RGB1 signal. RGB2* Shows the RGB2 signal. Shows the DVI signal. VIDEO1** Shows the VIDEO1 signal on the entire screen. VIDEO2** Shows the VIDEO2 signal on the entire screen.

  • Page 23: Adjusting Display Brilliance

    4.2 Adjusting Display Brilliance The display brilliance can be adjusted as follows. 1. Press the [BRILL] key on the display unit to show the BRILL adjustment window. BRILL BRILL window 3. Press the [◄] or [►] key to adjust the brilliance. (Setting range: 1 to 50) You can also adjust brilliance by pressing the [BRILL] key.

  • Page 24: Choosing Source For Main Picture

    4.3 Choosing Source for Main Picture Choose the signal to display on the entire screen as follows: 1. Press the [DISP] key to show the DISP selection window. Signal names can be changed. For detail, see “3.3.2 Changing the signal name”. RGB1 RGB2 VIDEO1...

  • Page 25: Choosing Source For Picture-In-Picture

    4.4 Choosing Source for Picture-in-Picture Choose the source for the picture-in-picture window as follows: Note: The size of the picture-in-picture window can be adjusted on the VIDEO1, 2 and 3 menus. For details, see section 3.2. 1. With the RGB1, RGB2 or DVI display shown, press the [PIP] key. The PIP selection window appears.

  • Page 26: Maintenance, Troubleshooting

    5 MAINTENANCE, TROUBLESHOOTING WARNING ELECTRICAL SHOCK HAZARD Do not open the equipment. Only qualified personnel should work inside the equipment. 5.1 Maintenance Routine maintenance Regular maintenance is important for good performance. Check the following on a regular basis to keep the equipment in good operating condition. •...

  • Page 27: Troubleshooting

    Remedy Ship’s battery voltage too high Check battery voltage. Fuse has blown. Replace fuse. Cable between MU-120C and external Refasten cable. equipment has loosened. Power cable has loosened. Refasten cable. You can confirm which signals are currently input in the SYSTEM menu.

  • Page 28: Clearing The Memory

    5.3 Clearing the Memory You may want to clear the memory to start afresh with default settings. You can do this as follows: 1. Press the [MENU] key to show the main menu. 2. Press the [►] keys to open the SYSTEM menu. 3.

  • Page 29: Specifications

    SPECIFICATIONS OF MULTI-PURPOSE LCD DISPLAY MU-120C 1 GENERAL 1.1 Display 12.1 inch SVGA color TFT-LCD, 246 x 185 mm 1.2 Brightness 1,000 cd/m maximum, 5 cd/m minimum 1.3 Resolution 800 x 600 (SVGA) 1.4 Viewing Angle left/right: 70°, up: 60°, down: 50°...
  • Page 32 001-403-200 19AR-X-9501 CODE NO. TYPE FP19-00601 付属品表 ACCESSORIES 数量 番 号 名  称 略  図 型名／規格 用途／備考 Q'TY OUTLINE NAME DESCRIPTIONS REMARKS ﾊﾟﾈﾙｶﾊﾞｰ(12) 19-024-1014-0 COSMETIC CAP CODE NO. 100-314-990 +ﾄﾗｽﾀｯﾋﾟﾝﾈｼﾞ 5X40 SUS304 SELF-TAPPING SCREW CODE NO. 000-150-749 19AR-X-9501 ＦＵＲＵＮＯ ＥＬＥＣＴＲＩＣ ＣＯ ．，ＬＴＤ. （略図の寸法は、参考値です。 DIMENSIONS IN DRAWING FOR REFERENCE ONLY.）...
  • Page 36 *00014909000* *00014909000* *00014909000* *00014909000* ( ( YOSH YOSH ) ) MU-120C MU-120C * 0 0 0 1 4 9 0 9 0 0 0 * * 0 0 0 1 4 9 0 9 0 0 0 * *OME20290A50* *OME20290A50*...
