PANEL DESCRIPTION

Programmable function keys

■
The following functions can be assigned to [Emer], [Side1],
[Side2], [Side3], [P0], [P1], [P2] and [P3] programmable
function keys.
Consult your Icom dealer or system operator for details con-
cerning your transceiver's programming.
CH UP AND DOWN
As described in the following topics, after pushing a pro-
grammed key, push [CH Up] or [CH Down] to select an op-
tion, setting, and so on.
ZONE
Push this key, then select the desired zone using [CH Up]/
[CH Down].
What is a "zone"?— Certain channels are grouped to-
gether and assigned to a zone, according to their intended
use. For example, 'Staff A' and 'Staff B' are assigned to a
"Business" zone, and 'John' and 'Cindy' are assigned to a
"Private" zone.
5
SCAN START/STOP
Push to start and cancel a scan.
➥
• When a scan is started with the Power ON Scan or Automatic
scan function, push this key to cancel it. The cancelled scan re-
sumes after a preprogrammed time period.
➥ Hold down this key for 1 second to display the scan group,
then push [CH Up] or [CH Down] to select the desired
group.
SCAN ADD/DEL (TAG)
Push to add the channel to, or delete it from, the current
➥
scan group.
1. Push to display the scan group, then push [CH Up] or [CH Down]
to select the desired one.
2. Push to add the channel to, or delete it from, the selected scan
group.
3. Hold down for 1 second to exit the scan list selection mode.
While a scan is paused on a non-priority channel, push this
➥
key to delete the selected channel from the scan group.
Depending on the setting, the cleared channel may be
automatically added to the scan group again after the
scan is cancelled.
