Specifications; General Specifications; Copy Specifications - Canon MX920 Series Online Manual

Specifications

General Specifications

Printing resolution (dpi)
Interface
Print width
Operating environment
Storage environment
Power supply
Power consumption
External dimensions
Weight
Print Head/Ink
ADF capacity

Copy Specifications

Multiple copy
Intensity adjustment
Reduction/Enlargement
9600* (horizontal) x 2400 (vertical)
* Ink droplets can be placed with a pitch of 1/9600 inch at minimum.
USB Port:
Hi-Speed USB *1
USB Flash Drive Port:
Bluetooth v2.0 (Option) *2*3
USB flash drive
LAN Port:
Wired LAN: 100BASE-TX/10BASE-T
Wireless LAN: IEEE802.11n/IEEE802.11g/IEEE802.11b *4
*1 A computer that complies with Hi-Speed USB standard is required.
Since the Hi-Speed USB interface is fully upwardly compatible with
USB 1.1, it can be used at USB 1.1.
*2 Maximum speed: 1.44 Mbps
*3 Bluetooth connection is for printing only.
*4 Setup possible through Standard setup, WPS (Wi-Fi Protected
Setup) or WCN (Windows Connect Now).
8 inches/203.2 mm
(for Borderless Printing: 8.5 inches/216 mm)
Temperature: 5 to 35 °C (41 to 95 °F)
Humidity: 10 to 90 % RH (no condensation)
Temperature: 0 to 40 °C (32 to 104 °F)
Humidity: 5 to 95 % RH (no condensation)
AC 100-240 V, 50/60 Hz
Printing (Copy): Approx. 17 W
Standby (minimum): Approx. 1.0 W *1*2
OFF: Approx. 0.4 W *1
*1 USB connection to PC
*2 The wait time for standby cannot be changed.
Approx. 19.4 (W) x 15.6 (D) x 9.1 (H) inches
Approx. 491 (W) x 396 (D) x 231 (H) mm
* With the Paper Output Tray retracted.
Approx. 11.7 kg (Approx. 25.7 lb)
* With the Print Head and ink tanks installed.
Total 5120 nozzles (PgBK 1024 nozzles, Y/DyeBK each 512 nozzles,
C/M each 1536 nozzles)
A4 or Letter size: max. 35 sheets (20 lb/75 g /m
inches/5 mm in height
Legal size: max. 30 sheets (20 lb/75 g /m
mm in height
Other sizes: 1 sheet
max. 99 pages
9 positions, Auto intensity (AE copy)
25 % - 400 % (1 % unit)
2
paper), up to 0.20
2
paper), up to 0.16 inches/4
