Page 1 PowerScan™ PD9530 Industrial Corded Handheld Area Imager Bar Code Reader Product Reference Guide...
Page 2 Datalogic representative. Electronic versions may either be downloadable from the Datalogic website (www.datalogic.com) or provided on appropriate media. If you visit our website and would like to make comments or suggestions about this or other Datalogic publi- cations, please let us know via the "Contact Datalogic" page.
Page 3: Table Of Contents
About this Manual ..........................................9 Overview ............................................9 Manual Conventions......................................... 10 References ..............................................10 Technical Support ..........................................10 Datalogic Website Support ....................................10 Reseller Technical Support..................................... 10 Telephone Technical Support....................................10 About the Reader ..........................................11 Programming the Reader .........................................12 Configuration Methods ......................................12 Setup ................................
Page 4 Contents Caps Lock State........................................... 41 Numlock ............................................41 USB Keyboard Speed........................................ 42 USB Keyboard Numeric Keypad ................................... 43 USB-OEM Interface ..........................................45 USB-OEM Device Usage......................................46 Interface Options ........................................46 Data Format ............................................47 Global Prefix/Suffix ..........................................48 Global AIM ID ............................................49 Set AIM ID Individually for GS1-128 ..................................51 Label ID ..............................................52 Label ID: Pre-Loaded Sets .......................................
Page 5 Contents UPC-E Check Character Transmission................................. 85 UPC-E 2D Component......................................85 Expand UPC-E to EAN-13 ......................................86 Expand UPC-E to UPC-A ......................................86 UPC-E Number System Character Transmission............................. 87 GTIN Formatting ..........................................87 EAN 13 (Jan 13) ..........................................88 EAN 13 Enable/Disable ......................................88 EAN 13 Check Character Transmission ................................
Page 6 Contents GS1-128 ............................................116 GS1-128 Enable........................................116 GS1-128 2D Component ...................................... 116 Code ISBT 128 ..........................................117 ISBT 128 Concatenation ....................................... 117 ISBT 128 Force Concatenation ................................... 117 ISBT 128 Concatenation Mode................................... 118 ISBT 128 Dynamic Concatenation Timeout..............................119 ISBT 128 Advanced Concatenation Options..............................119 Interleaved 2 of 5 (I 2 of 5) ......................................
Page 7 Contents GS1 DataBar™ Omnidirectional Enable/Disable ............................148 GS1 DataBar™ Omnidirectional GS1-128 Emulation..........................148 GS1 DataBar™ Omnidirectional 2D Component ............................149 GS1 DataBar™ Expanded ......................................149 GS1 DataBar™ Expanded Enable/Disable............................... 149 GS1 DataBar™ Expanded GS1-128 Emulation .............................. 150 GS1 DataBar™ Expanded 2D Component..............................150 GS1 DataBar™...
Page 8 Contents Maxicode Length Control ....................................183 Maxicode Set Length 1 ......................................183 Maxicode Set Length 2 ......................................184 PDF417 ............................................. 185 PDF417 Enable / Disable ...................................... 185 PDF417 Length Control ......................................185 PDF417 Set Length 1 ......................................186 PDF417 Set Length 2 ......................................187 Micro PDF417 ..........................................
Page 9 Contents Motionless Timeout ....................................... 236 Technical Specifications ........................... 237 Imager Labeling ..........................................241 Standard Cable Pinouts ........................................242 LED and Beeper Indications ......................................243 Error Codes ............................................244 Sample Bar Codes............................245 GS1 DataBar™ (RSS)........................................ 247 GS1 DataBar™-14........................................247 Standard Defaults ............................. 249 Keypad ...............................
Page 10 Contents NOTES PowerScan™ PD9530...
Page 11: Introduction
Chapter 1 Introduction About this Manual This Product Reference Guide (PRG) is provided for users seeking advanced technical information, including connection, programming, maintenance and specifications. The Quick Reference Guide (QRG) and other publications associated with this product are downloadable free of charge from the website listed on the back cover of this manual. Overview (this chapter) presents information about manual conventions, and an overview of Chapter 1,...
Page 12: Manual Conventions
Telephone Technical Support If you do not have internet or email access, you may contact Datalogic technical support at (541) 349-8283 or check the back cover of your manual for more contact information.
Page 13: About The Reader
Typically, units are factory-programmed for the most common terminal and communications settings. If you need to modify any programmable settings, custom configuration can be done by scanning the programming barcodes within this guide or with Datalogic Aladdin™, available from the Datalogic website. See "Datalogic Aladdin™" on for more information.
Page 14: Programming The Reader
In addition, Aladdin makes it easy to upgrade the handheld’s firmware, to attain the benefits of new reader features. Reference the Datalogic Aladdin™ Online Help for more details. Aladdin is available for download free of charge on the Datalogic website.
Page 15: Setup
Setup Unpacking Check carefully to ensure the reader and any accessories ordered are present and undamaged. If any damage occurred during shipment, contact Datalogic Technical Support. Information is shown on page 10 KEEP THE PACKAGING. Should the unit ever require service, it should be returned in its original shipping container.
Page 16: Connecting The Cable
Setup Connecting the Cable A. Rubber gasket B. Cable Holder C. Cover D. Connector Holder 1. Slip the cable through the Cover. 2. Push the Rubber Gasket onto the Cable Holder. FRONT>> 3. Push the Cable Holder and gasket into the handle. Ensure that the “Front”...
Page 17 Select USB COM-STD Set USB-OEM $P,HA45,P(CR) Interface USB-OEM Features (can be used for OPOS/UPOS/JavaPOS) starting on page 45 Select USB-OEM $P,HA35,P(CR) USB Keyboard with standard key encoding Select USB Keyboard a. Download the correct USB Com driver from www.datalogic.com Product Reference Guide...
Page 18 Setup USB (continued) FEATURES $P,HA2B,P(CR) USB Keyboard with alternate key encoding Set USB-OEM Interface Select USB Alternate Keyboard Features starting on page $P,HA2C,P(CR) USB Keyboard for Apple computers Select USB-KBD-APPLE KEYBOARD FEATURES $P,HA2B,P(CR) USB Keyboard with alternate key encoding Select USB Alternate Keyboard $P,HA2C,P(CR) USB Keyboard for Apple computers Select USB-KBD-APPLE...
Page 19: Customizing Configuration Settings
Customizing Configuration Settings Customizing Configuration Settings Configure Interface Settings If after scanning the interface bar code from the previous table, your installation requires you to select options to further customize your reader, turn to the appropriate section for your interface type in "Configuration Parameters"...
Page 20: Resetting The Product Configuration To Defaults
Setup Resetting the Product Configuration to Defaults Restore Custom Defaults If you aren’t sure what programming options are in your imager, or you’ve changed some options and want to restore the Custom Default Configuration that may have been saved in the scanner, scan the Restore Custom Default Configuration bar code below.
Page 21: Configuration Using Bar Codes
Chapter 3 Configuration Using Bar Codes This and following sections provide programming bar codes to configure your reader by changing the default settings. For details about additional methods of programming, see " Configuration Methods" on page 12 You must first enable your reader to read bar codes in order to use this section.
Page 22 Enter/Exit Programming Mode To program features: 1. Scan the ENTER/EXIT PROGRAMMING bar code, available at the top of each programming page, when applicable. 2. Scan the bar code to set the desired programming feature. You may need to cover unused bar codes on the page, and possibly the facing page, to ensure that the reader reads only the bar code you intend to scan.
Page 23: Global Interface Features
Enter/Exit Programming Mode GLOBAL INTERFACE FEATURES The following interface features are configurable by all interface types. Host Commands — Obey/Ignore This option specifies whether the reader will obey or ignore host commands. When set to ignore, the reader will ignore all host commands except for those necessary for: •...
Page 24 Enter/Exit Programming Mode NOTES PowerScan™ PD9530...
Page 25: Rs-232 Only Interface
RS-232 ONLY INTERFACE on page 24 on page 25 on page 25 ARITY on page 26 ANDSHAKING ONTROL on page 27 Use the programming bar codes in this section if modifications to the standard RS-232 interface settings are necessary to meet your system’s requirements. Additional settings which apply to both the RS-232 and USB interfaces are available in the next section, "RS-232/USB-Com Interfaces"...
Page 26: Baud Rate
Enter/Exit Programming Mode Baud Rate for information on this feature. page 204 $CR2BA00(CR) Baud Rate = 1200 $CR2BA01(CR) Baud Rate = 2400 $CR2BA02(CR) Baud Rate = 4800 $CR2BA03(CR) Baud Rate = 9600 $CR2BA04(CR) Baud Rate = 19,200 $CR2BA05(CR) Baud Rate = 38,400 $CR2BA06(CR) Baud Rate = 57,600 $CR2BA07(CR)
Page 27: Data Bits
Enter/Exit Programming Mode Data Bits This parameter allows the reader to interface with devices requiring a 7-bit or 8-bit ASCII protocol for sending and receiving data. $CR2DA00(CR) 7 Data Bits $CR2DA01(CR) DEFAULT 8 Data Bits Stop Bits Set the number of stop bits to match host device requirements. See for more page 204 information on this feature.
Page 28: Parity
Enter/Exit Programming Mode Parity This feature specifies parity required for sending and receiving data. Select the parity type according to host device requirements. See for more information. page 204 $CR2PA00(CR) DEFAULT Parity = None $CR2PA01(CR) Parity = Even $CR2PA02(CR) Parity = Odd PowerScan™...
Page 29: Handshaking Control
Enter/Exit Programming Mode Handshaking Control for more information about this feature. page 204 $CR2HC00(CR) DEFAULT Handshaking Control = RTS $CR2HC01(CR) Handshaking Control = RTS/CTS $CR2HC02(CR) Handshaking Control = RTS/XON/XOFF $CR2HC03(CR) Handshaking Control = RTS On/CTS $CR2HC04(CR) Handshaking Control = RTS/CTS Scan Control Product Reference Guide...
Page 30: Rs-232/Usb-Com Interfaces
RS-232/USB-COM INTERFACES NTERCHARACTER ELAY on page 29 ASCII BEL on page 29 OT ON on page 30 ACK NAK O PTIONS on page 30 ACK C HARACTER on page 31 NAK C HARACTER on page 31 ACK NAK T IMEOUT ALUE on page 32 ACK NAK R...
Page 31: Intercharacter Delay
Enter/Exit Programming Mode Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay. for more information.
Page 32: Beep On Not On File
Enter/Exit Programming Mode Beep On Not on File This option enables/disables the action of the reader to sound a three beep sequence upon receiving a Not-On-File (NOF) host command. $CBPNF00(CR) Beep On Not On File = Disable $CBPNF01(CR) DEFAULT Beep On Not On File = Enable ACK NAK Options This enables/disables the ability of the reader to support the RS-232 ACK/NAK protocol.
Page 33: Ack Character
Enter/Exit Programming Mode ACK Character This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex value from 0 to 0xFF can be selected. See for more page 206 information. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
Page 34: Ack Nak Timeout Value
Enter/Exit Programming Mode ACK NAK Timeout Value This option specifies the amount of time the reader waits for an ACK character from the host following label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A selection of 0 disables the timeout. for more information on setting this feature.
Page 35: Ack Nak Error Handling
Enter/Exit Programming Mode ACK NAK Error Handling This feature specifies the method the reader uses to handle receive errors detected while waiting for an ACK character from the host. $CR2EH00(CR) DEFAULT ACK NAK Error Handling = Ignore Errors Detected $CR2EH01(CR) ACK NAK Error Handling = Process Error as Valid ACK Character $CR2EH02(CR)
Page 36: Disable Character
Enter/Exit Programming Mode Disable Character Specifies the value of the RS-232 host command used to disable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
Page 37: Keyboard Settings
KEYBOARD SETTINGS OUNTRY on page 36 ONTROL HARACTERS on page 39 EDGE UIET NTERVAL on page 40 NTERCODE ELAY on page 40 TATE on page 41 UMLOCK on page 41 USB K EYBOARD PEED on page 42 USB K EYBOARD UMERIC EYPAD on page 43...
Page 38: Country Mode
Enter/Exit Programming Mode Country Mode This feature specifies the country/language supported by the keyboard. Several languages are supported: $CKBCO00(CR) DEFAULT Country Mode = U.S. $CKBCO01(CR) Country Mode = Belgium $CKBCO02(CR) Country Mode = Britain $CKBCO11(CR) Supports only the interfaces listed in the Country Mode feature description.
Page 39 Enter/Exit Programming Mode Country Mode (continued) $CKBCO13(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = French Canadian $CKBCO05(CR) Country Mode = Germany $CKBCO0D(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = Hungary $CKBCO06(CR) Country Mode = Italy...
Page 40 Enter/Exit Programming Mode Country Mode (continued) $CKBCO12(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = Poland $CKBCO08(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = Portugal $CKBCO10(CR) Supports only the interfaces listed in the Country Mode feature description.
Page 41: Send Control Characters
Enter/Exit Programming Mode Send Control Characters This feature specifies how the reader transmits ASCII control characters to the host. Reference for more information about control characters. Appendix E, Scancode Tables Options are as follows: Control Character 00 : Characters from 00 to 0x1F are sent as control character Ctrl+Keys, special keys are located from 0x80 to 0xA1.
Page 42: Wedge Quiet Interval
Enter/Exit Programming Mode Wedge Quiet Interval Specifies amount of time to look for keyboard activity before scanner breaks keyboard connection in order to transmit data to host. The selectable range for this setting is 00 to 990 milliseconds (00-0x63 by 01) in increments of ten milliseconds. See page 212 “References”...
Page 43: Caps Lock State
Enter/Exit Programming Mode Caps Lock State This option specifies the format in which the reader sends character data. This does not apply when an alternate key encoding keyboard is selected. $CKBCL00(CR) DEFAULT Caps Lock State = Caps Lock OFF $CKBCL01(CR) Caps Lock State = Caps Lock ON $CKBCL02(CR) Caps Lock State = AUTO Caps Lock Enable...
Page 44: Usb Keyboard Speed
Enter/Exit Programming Mode USB Keyboard Speed This option specifies the USB poll rate for a USB keyboard. This feature applies ONLY to the USB Keyboard interface. $CKBSP01(CR) DEFAULT USB Keyboard Speed = 1ms $CKBSP02(CR) USB Keyboard Speed = 2ms $CKBSP03(CR) USB Keyboard Speed = 3ms $CKBSP04(CR) USB Keyboard Speed = 4ms...
Page 45: Usb Keyboard Numeric Keypad
Enter/Exit Programming Mode USB Keyboard Speed (continued) $CKBSP07(CR) USB Keyboard Speed = 7ms $CKBSP08(CR) USB Keyboard Speed = 8ms $CKBSP09(CR) USB Keyboard Speed = 9ms $CKBSP0A(CR) USB Keyboard Speed = 10ms USB Keyboard Numeric Keypad This option Controls whether numeric characters will be sent using standard keys or the numeric keypad.
Page 46 Enter/Exit Programming Mode NOTES PowerScan™ PD9530...
Page 47: Usb-Oem Interface
USB-OEM INTERFACE USB-OEM D EVICE SAGE on page 46 NTERFACE PTIONS on page 46 Feature settings for USB interfaces differ depending upon which host type the reader will be connected with. Use the feature settings in this chapter to specifically configure for the USB- OEM interface.
Page 48: Usb-Oem Device Usage
Enter/Exit Programming Mode USB-OEM Device Usage The USB-OEM protocol allows for the reader to be identified as one of two different types of bar code scanners. Depending on what other scanners you may already have connected to a USB-OEM POS, you may need to change this setting to enable all devices to communicate.
Page 49: Data Format
DATA FORMAT LOBAL REFIX UFFIX on page 48 AIM ID LOBAL on page 49 ABEL starting on page 52 • Label ID: Pre-Loaded Sets • Individually Set Label ID • Label ID Control • Label ID Symbology Selection − 1D Symbologies •...
Page 50: Global Prefix/Suffix
Enter/Exit Programming Mode Global Prefix/Suffix Global Prefix/Suffix This option sets up to 20 characters each from the set of ASCII characters or any hex value from 00 to FF. The characters may be added as a prefix (in a position before the bar code data, also called a header) and/or as a suffix (in a position following the bar code data, also called a footer).
Page 51: Global Aim Id
Global AIM ID Enter/Exit Programming Mode Global AIM ID This feature enables/disables addition of AIM IDs for all symbology types. AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. See Table 2 on page for a 3-49 listing of AIM IDs.
Page 52 Enter/Exit Programming Mode Global AIM ID DATA MATRIX EAN128 EAN128 COMPOSITE EAN13 EAN13 P2 EAN13 P5 EAN13 COMPOSITE EAN8 EAN8 P2 EAN8 P5 EAN8 COMPOSITE FOLLET 2OF5 I2OF5 IATA INDUSTRIAL 2OF5 INDUSTRIAL 2OF5 ISBN ISBT128 CONCAT ISSN MAXICODE MICRO QR MICRO PDF PDF417 PLESSEY...
Page 53: Set Aim Id Individually For Gs1-128
Global AIM ID Enter/Exit Programming Mode Set AIM ID Individually for GS1-128 This feature configures a Label ID individually for the GS1-128 symbology and the programming for this works the same way as Label ID. See Label ID: Set Individually Per for detailed instructions on setting this feature.
Page 54: Label Id
Enter/Exit Programming Mode Label ID Label ID A Label ID is a customizable code of up to three ASCII characters (convert to Hex using the ASCII Chart on the inside back cover of this manual), used to identify a bar code symbology type.
Page 55: Individually Set Label Id
Label ID Enter/Exit Programming Mode Individually Set Label ID This feature configures a Label ID individually for a single symbology. To set, first define whether you want it as a prefix or suffix by scanning a label below. Then turn to Label ID to select the symbology you want to Symbology Selection −...
Page 56: Label Id Symbology Selection − 1D Symbologies
Enter/Exit Programming Mode Label ID Label ID Symbology Selection 1D Symbologies − This option selects the symbology for which a Label ID is to be configured. See "Label ID" on or page 223 in “References” for more detailed instructions. page 52 If less than the expected string of 3 characters are selected, scan the ENTER/ EXIT bar code twice to accept the selection and exit Programming Mode.
Page 57: Label Id Symbology Selection − 1D Symbologies
Label ID Enter/Exit Programming Mode Label ID Symbology Selection − 1D Symbologies (continued) $CXCID $C8BID Set EAN 8 Label ID Character(s) Set GS1 DataBar Expanded Composite Label ID Character(s) $C8MID $CU8ID Set EAN 8 Composite Label ID Character(s) Set GS1-128 Label ID Character(s) $CUMID $C82ID Set EAN 8 P2 Label ID Character(s)
Page 58 Enter/Exit Programming Mode Label ID Label ID Symbology Selection − 1D Symbologies (continued) $CPMID $CMSID Set IMB Postal Code Label ID Character(s) Set MSI Label ID Character(s) $CU2ID $CPPID Set Industrial 2 of 5 Label ID Character(s) Set Planet Postal Code Label ID Character(s) $CI2ID $CPLID Set Interleaved 2 of 5 Label ID Character(s)
Page 59 Label ID Enter/Exit Programming Mode Label ID Symbology Selection − 1D Symbologies (continued) $CPSID $CA5ID Set Swedish Postal Code Label ID Character(s) Set UPC-A P5 Label ID Character(s) $CCTID $CEBID Set Trioptic Code Label ID Character(s) Set UPC-E Label ID Character(s) $CE5ID $CABID Set UPC-A Label ID Character(s)
Page 60: Advanced Formatting: User Label Edit
Enter/Exit Programming Mode Label ID Advanced Formatting: User Label Edit Advanced formatting is available to create user label edit scripts. See the Datalogic Aladdin configuration application or contact Technical Support. Case Conversion This feature allows conversion of the case of all alphabetic characters to upper or lower case.
Page 61: Reading Parameters
READING PARAMETERS OUBLE IMEOUT CANNING CTIVE on page 60 on page 70 EEPER NDICATORS TAND LLUMINATION ONTROL on page 62 on page 71 OWER LERT LASH on page 62 on page 71 HEN TO NDICATE LASH on page 62 on page 72 IMING OINTER on page 63...
Page 62: Double Read Timeout
Enter/Exit Programming Mode Double Read Timeout Double Read Timeout prevents a double read of the same label by setting the minimum time allowed between reads of labels of the same symbology and data. If the unit reads a label and sees the same label again within the specified timeout, the second read is ignored. Double Read Timeout does not apply to scan modes that require a trigger pull for each label read.
Page 63 Enter/Exit Programming Mode Double Read Timeout (continued) $CSNDR50(CR) Double Read Timeout = 0.8 Second $CSNDR5A(CR) Double Read Timeout = 0.9 Second $CSNDR64(CR) Double Read Timeout = 1 Second Product Reference Guide...
Page 64: Led And Beeper Indicators
Enter/Exit Programming Mode LED AND BEEPER INDICATORS Power On Alert Disables or enables the indication (from the Beeper) that the reader is receiving power. $CBPPU00(CR) Power On Alert = Disable (No Audible Indication) $CBPPU01(CR) DEFAULT Power On Alert = Power-up Beep Good Read: When to Indicate This feature specifies when the reader will provide indication (beep and/or flash its green LED) upon successfully reading a bar code.
Page 65: Good Read Beep Type
Enter/Exit Programming Mode Good Read Beep Type Specifies whether the good read beep has a mono or bitonal beep sound. $CBPTY00(CR) DEFAULT Good Read Beep Type = Mono $CBPTY01(CR) Good Read Beep Type = Bitonal Good Read Beep Frequency Adjusts the good read beep to sound at a selectable low, medium or high frequency, selectable from the list below.
Page 66: Good Read Beep Length
Enter/Exit Programming Mode Good Read Beep Length $CBPLE06(CR) Good Read Beep Length = 60 msec $CBPLE08(CR) DEFAULT Good Read Beep Length = 80 msec $CBPLE0A(CR) Good Read Beep Length = 100 msec $CBPLE0C(CR) Good Read Beep Length = 120 msec $CBPLE0E(CR) Good Read Beep Length = 140 msec $CBPLE10(CR)
Page 67: Good Read Beep Volume
Enter/Exit Programming Mode Good Read Beep Volume Selects the beeper volume (loudness) upon a good read beep. There are three selectable volume levels. $CBPVO00CR) Good Read Beep Volume = Beeper Off $CBPVO01CR) Good Read Beep Volume = Low $CBPVO02CR) Good Read Beep Volume = Medium $CBPVO03CR) DEFAULT Good Read Beep Volume = High...
Page 68: Good Read Led Duration
Enter/Exit Programming Mode Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 100 milliseconds to 25,500 milliseconds (0.1 to 25.5 seconds) in 100ms increments.
Page 69: Scanning Features
Enter/Exit Programming Mode SCANNING FEATURES Scan Mode Selects the reader’s scan operating mode. See in “References” for descriptions. page 228 $CSNRM00(CR) DEFAULT Scan Mode = Trigger Single $CSN- Scan Mode = Trigger Hold Multiple $CSNRM02(CR) Scan Mode = Trigger Pulse Multiple $CSN- Scan Mode = Flashing $CSN-...
Page 70: Stand Mode Indication
Enter/Exit Programming Mode Stand Mode Indication This operation is useful for indicating when the reader is in Stand Mode. If enabled, the blue indicator will blink when Stand Mode scanning is active. If reader detects motion and switches out of Stand Mode into Triggered Mode, blinking will stop until Stand Mode is active again.
Page 71: Pick Mode
Enter/Exit Programming Mode Pick Mode Specifies the ability of the reader to decode labels only when they are close to the center of the aiming pattern. This allows the reader to accurately target labels when they are placed close together, such as on a pick sheet. This feature is not compatible with Multiple Labels Reading in a Volume.
Page 72: Stand Mode Illumination Off Time
Enter/Exit Programming Mode Stand Mode Illumination Off Time Specifies the amount of time reader illumination stays off after pulling the trigger when in Stand Mode. The configurable range is 01 to 32 by 01 in increments of 500ms (500ms to 16 seconds).
Page 73: Stand Illumination Control
Enter/Exit Programming Mode Stand Illumination Control Controls the illumination status while the reading mode is stand mode and the reader is attempting to detect objects. $CSMIL00(CR) DEFAULT Stand Illumination Control = OFF $CSMIL01(CR) Stand Illumination Control = ON $CSMIL02(CR) Stand Illumination Control = Dim Flash On Time This feature specifies the ON time for the indicator LED while in Flash Mode.
Page 74: Flash Off Time
Enter/Exit Programming Mode Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. See in “References” for detailed information on setting this feature. page 233 To configure this feature, scan the ENTER/EXIT PRO- $CSNFF...
Page 75: Aiming Duration Timer
Enter/Exit Programming Mode Aiming Duration Timer Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger single mode.The range for this setting is from 1 to 255 seconds in 1-second increments. See in “References” for a description of this feature. page 231 LSTM00 DEFAULT...
Page 76: Green Spot Duration
Enter/Exit Programming Mode Green Spot Duration Specifies the duration of the good read pointer beam after a good read. $CLSSP00(CR) Green Spot Duration = Disable (Green Spot is Off ) $CLSSP01(CR) DEFAULT Green Spot Duration = Short (300 msec) $CLSSP02(CR) Green Spot Duration = Medium (500 msec) $CLSSP03(CR) Green Spot Duration = Long (800 msec)
Page 77: Partial Label Reading Control
Enter/Exit Programming Mode Partial Label Reading Control Enable/Disable the option to ignore partial labels to be read within the boundary of the field of view. IPPL00 Partial Label Reading Control = Disable IPPL01 Partial Label Reading Control = Enable Decode Negative Image Enable/Disable the ability to decode a negative image for all symbologies.
Page 78: Image Capture
Image Capture Image capature is supported by RS-232 and USB-COM interfaces only. For information and a list of options for Image Capture, use the Datalogic Aladdin configuration application, available for free download from the Datalogic Scanning website. MULTIPLE LABEL READING In standard (default) mode, when the reader’s aiming system is activated (by a trigger pull,...
Page 79: Multiple Labels Ordering By Code Symbology
Enter/Exit Programming Mode Multiple Labels Ordering by Code Symbology This feature allows you to specify the order multiple labels are transmitted by symbology type, when Multiple Labels per Frame is enabled. See in “References” for detailed page 234 information on setting this feature. To configure this feature, scan the ENTER/EXIT PRO- $CSNMS GRAMMING MODE bar code above, then the bar code at...
Page 80 Enter/Exit Programming Mode NOTES PowerScan™ PD9530...
Page 81: 1D Symbologies
1D SYMBOLOGIES The reader supports the following 1D symbologies (bar code types). See "2D Symbologies" starting for 2D bar codes. Symbology-dependent options are included in each chapter. on page 169 GS1-128 YMBOLOGIES , page 80 , page 116 ISABLE EAN/UPC ISBT 128 , page 81 , page 117...
Page 82: Disable All Symbologies
Enter/Exit Programming Mode DISABLE ALL SYMBOLOGIES Use this feature to disable all symbologies. 1. Scan the ENTER/EXIT PROGRAMMING Mode bar code. 2. Scan the Disable All Symbologies bar code. 3. Complete the programming sequence by scanning the ENTER/EXIT PROGRAM- MING bar code. $AD(CR) Disable All Symbologies This does not disable the reading of programming labels.
Page 83: Code Ean/Upc
Enter/Exit Programming Mode CODE EAN/UPC Coupon Control This feature is used to control the reader’s method of processing coupon labels. $CCPLC00(CR) Coupon Control = Allow all coupon bar codes to be decoded $CCPLC01(CR) DEFAULT Coupon Control = Enable only UPCA coupon decoding $CCPLC02(CR) Coupon Control = Enable only GS1 DataBar™...
Page 84: Upc-A
Enter/Exit Programming Mode UPC-A The following options apply to the UPC-A symbology. UPC-A Enable/Disable When disabled, the reader will not read UPC-A bar codes. $CABEN00(CR) UPC-A = Disable $CABEN01(CR) DEFAULT UPC-A = Enable UPC-A Check Character Transmission Enable this option to transmit the check character along with UPC-A bar code data. $CABCT00(CR) UPC-A Check Character Transmission = Don’t Send $CABCT01(CR)
Page 85: Expand Upc-A To Ean-13
Enter/Exit Programming Mode Expand UPC-A to EAN-13 Expands UPC-A data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13. $CAB3B00(CR) DEFAULT UPC-A to EAN-13 = Don’t Expand $CAB3B01(CR) UPC-A to EAN-13 = Expand UPC-A Number System Character Transmission This feature enables/disables transmission of the UPC-A number system character.
Page 86: Upc-A 2D Component
Enter/Exit Programming Mode UPC-A 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. $CAB2D00(CR) DEFAULT EAN-13 2D Component = Disable (2D component not required) $CAB2D01(CR) EAN-13 2D Component = 2D component must be decoded UPC-E The following options apply to the UPC-E symbology.
Page 87: Upc-E Check Character Transmission
Enter/Exit Programming Mode UPC-E Check Character Transmission Enable this option to transmit the check character along with UPC-E bar code data. $CEBCT00(CR) UPC-E Check Character Transmission = Don’t Send $CEBCT01(CR) DEFAULT UPC-E Check Character Transmission = Send UPC-E 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded.
Page 88: Expand Upc-E To Ean-13
Enter/Exit Programming Mode Expand UPC-E to EAN-13 Expands UPC-E data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13. $CEB3B00(CR) DEFAULT UPC-E to EAN-13 = Don’t Expand $CEB3B01(CR) UPC-E to EAN-13 = Expand Expand UPC-E to UPC-A Expands UPC-E data to the UPC-A data format.
Page 89: Upc-E Number System Character Transmission
Enter/Exit Programming Mode UPC-E Number System Character Transmission This feature enables/disables transmission of the UPC-E system number character. $CEBNS00(CR) UPC-E Number System Character = Do not transmit $CEBNS01(CR) DEFAULT UPC-E Number System Character = Transmit GTIN FORMATTING This feature enables/disables the ability to convert UPC-E, UPC-A, EAN 8, and EAN 13 labels into the GTIN 14-character format.
Page 90: Ean 13 (Jan 13)
Enter/Exit Programming Mode EAN 13 (JAN 13) The following options apply to the EAN 13 (Jan 13) symbology. EAN 13 Enable/Disable When disabled, the reader will not read EAN 13/JAN 13 bar codes. $C3BEN00(CR) EAN 13 = Disable $C3BEN01(CR) DEFAULT EAN 13 = Enable EAN 13 Check Character Transmission Enable this option to transmit the check character along with EAN 13 bar code data.
Page 91: Ean-13 Flag 1 Character
Enter/Exit Programming Mode EAN-13 Flag 1 Character Enables/disables transmission of an EAN/JAN13 Flag1 character. The Flag 1 character is the first character of the label. $C3BF100(CR) EAN-13 Flag 1 Char= Don’t transmit $C3BF101(CR) DEFAULT EAN-13 Flag 1 Char= Transmit EAN-13 ISBN Conversion This option enables/disables conversion of EAN 13/JAN 13 Bookland labels starting with 978 to ISBN labels.
Page 92: Ean-13 2D Component
Enter/Exit Programming Mode EAN-13 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. $C3B2D00(CR) DEFAULT EAN-13 2D Component = Disable (2D component not required) $C3B2D01(CR) EAN-13 2D Component = 2D component must be decoded ISSN The following options apply to the ISSN symbology.
Page 93: Ean 8 (Jan 8)
Enter/Exit Programming Mode EAN 8 (JAN 8) The following options apply to the EAN 8 (Jan 8) symbology. EAN 8 Enable/Disable When disabled, the reader will not read EAN 8/JAN 8 bar codes. $C8BEN00(CR) EAN 8 = Disable $C8BEN01(CR) DEFAULT EAN 8 = Enable EAN 8 Check Character Transmission Enable this option to transmit the check character along with EAN 8 bar code data.
Page 94: Expand Ean 8 To Ean 13
Enter/Exit Programming Mode Expand EAN 8 to EAN 13 Enable this option to expand EAN 8/JAN 8 labels to EAN 13/JAN 13. $C8B3B00(CR) DEFAULT Expand EAN 8 to EAN 13 = Disable $C8B3B01(CR) Expand EAN 8 to EAN 13 = Enable EAN 8 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded.
Page 95: Upc/Ean Global Settings
Enter/Exit Programming Mode UPC/EAN GLOBAL SETTINGS This section provides configuration settings for UPC-A, UPC-E, EAN 13 and EAN 8 symbologies, and affects all of these unless otherwise marked for each feature description. UPC/EAN Price Weight Check This feature enables/disables calculation and verification of price/weight check digits. $CPWEN00(CR) DEFAULT Price Weight Check = Disabled...
Page 96: Upc/Ean Quiet Zones
Enter/Exit Programming Mode UPC/EAN Quiet Zones This feature specifies the number of quiet zones for UPC/EAN labels. Quiet zones are blank areas at the ends of a bar code, typically 10 times the width of the narrowest bar or space in the label.
Page 97: Add-Ons
Enter/Exit Programming Mode ADD-ONS Contact Customer Support for advanced programming of optional and conditional add- ons. Optional Add-ons The reader can be enabled to optionally read the following add-ons (supplementals): If a UPC/EAN base label and an add-on are both decoded, the reader will transmit the base label and add-on.
Page 98: Optional Add-On Timer
Enter/Exit Programming Mode Optional Add-On Timer This option sets the time the reader will look for an add-on when an add-on fragment has been seen and optional add-ons are enabled. (Also see "Optional GS1-128 Add-On Timer" on page 98 $CADOT01(CR) Optional Add-on Timer = 10ms $CADOT02(CR) Optional Add-on Timer = 20ms...
Page 99 Enter/Exit Programming Mode Optional Add-On Timer (continued) $CADOT0C(CR) Optional Add-on Timer = 120ms $CADOT0E(CR) Optional Add-on Timer = 140ms $CADOT10(CR) Optional Add-on Timer = 160ms $CADOT12(CR) Optional Add-on Timer = 180ms $CADOT14(CR) Optional Add-on Timer = 200ms $CADOT16(CR) Optional Add-on Timer = 220ms $CADOT18(CR) Optional Add-on Timer = 240ms $CADOT1A(CR)
Page 100: Optional Gs1-128 Add-On Timer
Enter/Exit Programming Mode Optional Add-On Timer (continued) $CADOT1C(CR) Optional Add-on Timer = 280ms $CADOT1E(CR) Optional Add-on Timer = 300ms Optional GS1-128 Add-On Timer This option sets the timer expiration value to read the added part after reading the linear EAN/UPC part. For UPC/EAN add-ons other than those of that type, see "Optional Add-On Timer"...
Page 101 Enter/Exit Programming Mode Optional GS1-128 Add-On Timer (continued) $CADUT04(CR) Optional GS1-128 Add-On Timer = 40ms $CADUT05(CR) Optional GS1-128 Add-On Timer = 50ms $CADUT06(CR) Optional GS1-128 Add-On Timer = 60ms $CADUT07(CR) Optional GS1-128 Add-On Timer = 70ms $CADUT0A(CR) Optional GS1-128 Add-On Timer = 100ms $CADUT0C(CR) Optional GS1-128 Add-On Timer = 120ms $CADUT0E(CR)
Page 102 Enter/Exit Programming Mode Optional GS1-128 Add-On Timer (continued) $CADUT12(CR) Optional GS1-128 Add-On Timer = 180ms $CADUT14(CR) Optional GS1-128 Add-On Timer = 200ms $CADUT16(CR) Optional GS1-128 Add-On Timer = 220ms $CADUT18(CR) Optional GS1-128 Add-On Timer = 240ms $CADUT1A(CR) Optional GS1-128 Add-On Timer = 260ms $CADUT1C(CR) Optional GS1-128 Add-On Timer = 280ms $CADUT1E(CR)
Page 103: Code 39
Enter/Exit Programming Mode CODE 39 The following options apply to the Code 39 symbology. Code 39 Enable/Disable $CC3EN00(CR) Code 39 = Disable $CC3EN01(CR) DEFAULT Code 39 = Enable Code 39 Check Character Calculation Enable this option to enables/disables calculation and verification of an optional Code 39 check character.
Page 104: Code 39 Check Character Transmission
Enter/Exit Programming Mode Code 39 Check Character Calculation (continued) $CC3CC04(CR) Code 39 Check Character Calculation = Enable Italian Post Check $CC3CC08(CR) Code 39 Check Character Calculation = Enable Daimler Chrysler Check Code 39 Check Character Transmission Enable this option to transmit the check character along with Code 39 bar code data. $CC3CT00(CR) Code 39 Check Character Transmission = Don’t Send $CC3CT01(CR)
Page 105: Code 39 Start/Stop Character Transmission
Enter/Exit Programming Mode Code 39 Start/Stop Character Transmission Enable this option to enable/disable transmission of Code 39 start and stop characters $CC3SS00(CR) DEFAULT Code 39 Start/Stop Character Transmission = Don’t Transmit $CC3SS01(CR) Code 39 Start/Stop Character Transmission = Transmit Code 39 Full ASCII Enables/disables the translation of Code 39 characters to Code 39 full-ASCII characters.
Page 106: Code 39 Quiet Zones
Enter/Exit Programming Mode Code 39 Quiet Zones This feature specifies the number of quiet zones for Code 39 labels. Quiet zones are blank areas at the ends of a bar code, typically 10 times the width of the narrowest bar or space in the label.
Page 107: Code 39 Set Length 1
Enter/Exit Programming Mode Code 39 Set Length 1 This feature specifies one of the bar code lengths for . Length 1 is the Code 39 Length Control minimum label length if in Mode, or the first fixed length if in Variable Length Fixed Length Mode.
Page 108: Code 39 Set Length 2
Enter/Exit Programming Mode Code 39 Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the Code 39 Length Control maximum label length if in Mode, or the second fixed length if in Variable Length Fixed Length Mode.
Page 109: Trioptic Code
Enter/Exit Programming Mode TRIOPTIC CODE The following options apply to the Trioptic symbology. Trioptic Code Enable/Disable $CCTEN00(CR) DEFAULT Trioptic Code = Disable $CCTEN01(CR) Trioptic Code = Enable CODE 32 (ITAL PHARMACEUTICAL CODE) The following options apply to the Code 32 (Italian Pharmaceutical Code) symbology. Code 32 Enable/Disable When disabled, the reader will not read Code 32 bar codes.
Page 110: Code 32 Check Char Transmission
Enter/Exit Programming Mode Code 32 Check Char Transmission Enable this option to transmit the check character along with Code 32 bar code data. $CP3CT00(CR) DEFAULT Code 32 Check Character Transmission = Don’t Send $CP3CT01(CR) Code 32 Check Character Transmission = Send Code 32 Start/Stop Character Transmission This option enables/disables transmission of Code 32 start and stop characters $CP3SS00(CR)
Page 111: Code 39 Cip (French Pharmaceutical)
Enter/Exit Programming Mode CODE 39 CIP (FRENCH PHARMACEUTICAL) The following options apply to the Code 39 CIP symbology. Code 39 CIP Enable/Disable Enables/Disables ability of the reader to decode Code 39 CIP labels. $CCCEN00(CR) DEFAULT Code 39 CIP = Disable $CCCEN01(CR) Code 39 CIP = Enable CODE 39 DANISH PPT...
Page 112: Code 39 Laposte
Enter/Exit Programming Mode CODE 39 LAPOSTE The following options apply to the Code 39 LaPoste symbology. Code 39 LaPoste Enable/Disable Enables/disables the ability of the scanner to decode Code39 La Poste labels. $CLPEN00(CR) DEFAULT Code 39 LaPoste = Disable $CLPEN01(CR) Code 39 LaPoste = Enable CODE 39 PZN The following options apply to the Code 39 PZN symbology.
Page 113: Code 128
Enter/Exit Programming Mode CODE 128 The following options apply to the Code 128 symbology. Code 128 Enable/Disable When disabled, the reader will not read Code 128 bar codes. $CC8EN00(CR) Code 128 = Disable $CC8EN01(CR) DEFAULT Code 128 = Enable Expand Code 128 to Code 39 This feature enables/disables expansion of Code 128 labels to Code 39 labels.
Page 114: Code 128 Check Character Transmission
Enter/Exit Programming Mode Code 128 Check Character Transmission Enable this option to transmit the check character along with Code 128 bar code data. $CC8CT00(CR) DEFAULT Code 128 Check Character Transmission = Don’t Send $CC8CT01(CR) Code 128 Check Character Transmission = Send Code 128 Function Character Transmission Enables/disables transmission of Code128 function characters 1, 2, 3, and 4.
Page 115: Code 128 Quiet Zones
Enter/Exit Programming Mode Code 128 Quiet Zones This feature specifies the number of quiet zones for Code 128 labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the label.
Page 116: Code 128 Set Length 1
Enter/Exit Programming Mode Code 128 Set Length 1 Specifies one of the bar code lengths for . Length 1 is the minimum Code 128 Length Control label length if in Mode, or the first fixed length if in Mode. Variable Length Fixed Length Length includes the bar code’s data characters only.
Page 117: Code 128 Set Length 2
Enter/Exit Programming Mode Code 128 Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the Code 128 Length Control maximum label length if in Mode, or the second fixed length if in Variable Length Fixed Length Mode.
Page 118: Gs1-128
Enter/Exit Programming Mode GS1-128 The following options apply to the GS1-128 symbology. (Also known as USS-128, GS1- 128, GTIN-128, UCC-128, EAN-128.) GS1-128 Enable This option enables/disables the ability of the reader to translate GS1-128 labels to the GS1- 128 data format. Options are: •...
Page 119: Code Isbt 128
Enter/Exit Programming Mode CODE ISBT 128 The following options apply to the ISBT 128 symbology. ISBT 128 Concatenation Use this option to enable/disable ISBT128 concatenation of 2 labels. $CI8CE00(CR) DEFAULT ISBN 128 Concatenation = Disable $CI8CE01(CR) ISBN 128 Concatenation = Enable ISBT 128 Force Concatenation When enabled, this feature forces concatenation for ISBT.
Page 120: Isbt 128 Concatenation Mode
Enter/Exit Programming Mode ISBT 128 Concatenation Mode Specifies the concatenation mode between Static and Dynamic. This option is only valid when ISBT 128 Concatenation is enabled (see "ISBT 128 Concatena- tion" on page 117). $CI8CM00CR) DEFAULT ISBT 128 Concatenation Mode = Static $CI8CM01CR) ISBT 128 Concatenation Mode = Dynamic PowerScan™...
Page 121: Isbt 128 Dynamic Concatenation Timeout
$CI8DT64(CR) ISBT 128 Dynamic Concatenation Timeout = 1 second ISBT 128 Advanced Concatenation Options To set up pairs of label types for concatenation, use the Datalogic Aladdin configuration application or contact Datalogic Technical Support, as described on page Product Reference Guide...
Page 122: Interleaved 2 Of 5 (I 2 Of 5)
Enter/Exit Programming Mode INTERLEAVED 2 OF 5 (I 2 OF 5) The following options apply to the I 2 of 5 symbology. I 2 of 5 Enable/Disable When disabled, the reader will not read I 2 of 5 bar codes. $CI2EN00(CR) DEFAULT I 2 of 5 = Disable...
Page 123: I 2 Of 5 Check Character Calculation
Enter/Exit Programming Mode I 2 of 5 Check Character Calculation This option enables/disables calculation and verification of an optional I 2 of 5 check character. Combinations of these settings are possible via the Aladdin configuration utility, or contact Technical Support. $CI2CC00(CR) DEFAULT I 2 of 5 Check Character Calculation = Disable...
Page 124: I 2 Of 5 Check Character Transmission
Enter/Exit Programming Mode I 2 of 5 Check Character Transmission Enable this option to transmit the check character along with I 2 of 5 bar code data. $CI2CT00(CR) I 2 of 5 Check Character Transmission = Don’t Send $CI2CT01(CR) DEFAULT I 2 of 5 Check Character Transmission = Send I 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the I 2 of...
Page 125: I 2 Of 5 Set Length 1
Enter/Exit Programming Mode I 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for . Length 1 is the I 2 of 5 Length Control minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 126: I 2 Of 5 Set Length 2
Enter/Exit Programming Mode I 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the I 2 of 5 Length Control maximum label length if in Mode, or the second fixed length if in Variable Length Fixed Length Mode.
Page 127: Interleaved 2 Of 5 Cip Hr
Enter/Exit Programming Mode INTERLEAVED 2 OF 5 CIP HR The following options apply to the Interleaved 2 of 5 CIP HR symbology. Interleaved 2 of 5 CIP HR Enable/Disable Enables/Disables ability of reader to decode Interleaved 2 of 5 CIP HR labels. $CCHEN00(CR) DEFAULT Interleaved 2 of 5 CIP HR = Disable...
Page 128: Standard 2 Of 5
Enter/Exit Programming Mode STANDARD 2 OF 5 The following options apply to the Standard 2 of 5 symbology. Standard 2 of 5 Enable/Disable When disabled, the reader will not read Standard 2 of 5 bar codes. $C2SEN00(CR) DEFAULT Standard 2 of 5 = Disable $C2SEN01(CR) Standard 2 of 5 = Enable Standard 2 of 5 Check Character Calculation...
Page 129: Standard 2 Of 5 Check Character Transmission
Enter/Exit Programming Mode Standard 2 of 5 Check Character Transmission This feature enables/disables transmission of an optional Standard 2 of 5 check character. $CS2CT00(CR) Standard 2 of 5 Check Character Transmission = Don’t Send $CS2CT01(CR) DEFAULT Standard 2 of 5 Check Character Transmission = Send Standard 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the Standard 2 of 5 symbology.
Page 130: Standard 2 Of 5 Set Length 1
Enter/Exit Programming Mode Standard 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for . Length 1 is Standard 2 of 5 Length Control the minimum label length if in Mode, or the first fixed length if in Variable Length Fixed Mode.
Page 131: Standard 2 Of 5 Set Length 2
Enter/Exit Programming Mode Standard 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is Standard 2 of 5 Length Control the maximum label length if in Mode, or the second fixed length if in Variable Length Fixed Mode.
Page 132: Industrial 2 Of 5
Enter/Exit Programming Mode INDUSTRIAL 2 OF 5 The following options apply to the Industrial 2 of 5 symbology. Industrial 2 of 5 Enable/Disable Enables/Disables ability of reader to decode Industrial 2 of 5 labels. $CU2EN00(CR) DEFAULT Industrial 2 of 5 = Disable $CU2EN01(CR) Industrial 2 of 5 = Enable Industrial 2 of 5 Check Character Calculation...
Page 133: Industrial 2 Of 5 Check Character Transmission
Enter/Exit Programming Mode Industrial 2 of 5 Check Character Transmission Enables/disables transmission of an Industrial 2 of 5 check character. $CU2CT00(CR) Industrial 2 of 5 Check Character Transmission = Disable $CU2CT01(CR) DEFAULT Industrial 2 of 5 Check Character Transmission = Enable Industrial 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the Industrial 2 of 5 symbology.
Page 134: Industrial 2 Of 5 Set Length 1
Enter/Exit Programming Mode Industrial 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for . Length 1 is Industrial 2 of 5 Length Control the minimum label length if in Mode, or the first fixed length if in Variable Length Fixed Mode.
Page 135: Industrial 2 Of 5 Set Length 2
Enter/Exit Programming Mode Industrial 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for . Length 2 Industrial 2 of 5 Length Control is the maximum label length if in Mode, or the second fixed length if in Variable Length Fixed Mode.
Page 136: Code Iata
Enter/Exit Programming Mode CODE IATA The following options apply to the IATA symbology. IATA Enable/Disable Enables/Disables the ability of the reader to decode IATA labels. $CIAEN00(CR) DEFAULT IATA = Disable $CIAEN01(CR) IATA = Enable IATA Check Character Transmission Enables/Disables calculation and verification of an optional Industrial 2 of 5 check character.
Page 137: Codabar
Enter/Exit Programming Mode CODABAR The following options apply to the Codabar symbology. Codabar Enable/Disable When disabled, the reader will not read Codabar bar codes. $CCBEN00(CR) DEFAULT Codabar = Disable $CCBEN01(CR) Codabar = Enable Codabar Check Character Calculation Enable this option to enables/disables calculation and verification of an optional Codabar check character.
Page 138: Codabar Check Character Transmission
Enter/Exit Programming Mode Codabar Check Character Transmission Enable this option to transmit the check character along with Codabar bar code data. $CCBCT00(CR) Codabar Check Character Transmission = Don’t Send $CCBCT01(CR) DEFAULT Codabar Check Character Transmission = Send Codabar Start/Stop Character Transmission Enable this option to enable/disable transmission of Codabar start and stop characters $CCBSS00(CR) Codabar Start/Stop Character Transmission =...
Page 139: Codabar Start/Stop Character Set
Enter/Exit Programming Mode Codabar Start/Stop Character Set This option specifies the format of transmitted Codabar start/stop characters $CCBSC00(CR) Codabar Check Character Set = ABCD/TN*E $CCBSC01(CR) Codabar Check Character Set = ABCD/ABCD $CCBSC02(CR) Codabar Check Character Set = abcd/tn*e $CCBSC03(CR) DEFAULT Codabar Check Character Set = abcd/abcd Codabar Start/Stop Character Match When enabled, this option requires that start and stop characters match...
Page 140: Codabar Quiet Zones
Enter/Exit Programming Mode Codabar Quiet Zones Specifies the number of quiet zones for Codabar labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the label.
Page 141: Codabar Set Length 1
Enter/Exit Programming Mode Codabar Set Length 1 This feature specifies one of the bar code lengths for Codabar Length ControlCodabar Length . Length 1 is the minimum label length if in Mode, or the first fixed Control Variable Length length if in Mode.
Page 142: Codabar Set Length 2
Enter/Exit Programming Mode Codabar Set Length 2 This feature specifies one of the bar code lengths for Codabar Length ControlCodabar Length . Length 2 is the maximum label length if in Mode, or the second fixed Control Variable Length length if in Mode.
Page 143: Abc Codabar
Enter/Exit Programming Mode ABC CODABAR The following options apply to the ABC Codabar symbology. ABC Codabar Enable/Disable Enables/Disables ability of reader to decode ABC Codabar labels. $CCBAB00(CR) DEFAULT ABC Codabar = Disable $CCBAB01(CR) ABC Codabar = Enable ABC Codabar Concatenation Mode Specifies the concatenation mode between Static and Dynamic.
Page 144: Abc Codabar Dynamic Concatenation Timeout
Enter/Exit Programming Mode ABC Codabar Dynamic Concatenation Timeout Specifies the timeout in 10-millisecond ticks used by the ABC Codabar Dynamic Concatenation Mode. $CCBDT05(CR) ABC Codabar Dynamic Concatenation Timeout = 50 msec $CCBDT0A(CR) ABC Codabar Dynamic Concatenation Timeout = 100 msec $CCBDT14(CR) DEFAULT ABC Codabar Dynamic Concatenation Timeout =...
Page 145: Abc Codabar Force Concatenation
Enter/Exit Programming Mode ABC Codabar Force Concatenation Forces labels starting or ending with D to be concatenated. $CCBFC00(CR) DEFAULT ABC Codabar Force Concatenation = Disable $CCBFC01(CR) ABC Codabar Force Concatenation = Enable Product Reference Guide...
Page 146: Code 11
Enter/Exit Programming Mode CODE 11 The following options apply to the Code 11 symbology. Code 11 Enable/Disable When disabled, the reader will not read Code 11 bar codes. $CC1EN00(CR) DEFAULT Code 11 = Disable $CC1EN01(CR) Code 11 = Enable Code 11 Check Character Calculation This option enables/disables calculation and verification of optional Code 11 check character.
Page 147: Code 11 Check Character Transmission
Enter/Exit Programming Mode Code 11 Check Character Transmission This feature enables/disables transmission of an optional Code 11 check character. $CC1CT00(CR) Code 11 Check Character Transmission = Don’t Send $CC1CT01(CR) DEFAULT Code 11 Check Character Transmission = Send Code 11 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 11 symbology.
Page 148: Code 11 Set Length 1
Enter/Exit Programming Mode Code 11 Set Length 1 This feature specifies one of the bar code lengths for . Length 1 is the Code 11 Length Control minimum label length if in Mode, or the first fixed length if in Variable Length Fixed Length Mode.
Page 149: Code 11 Set Length 2
Enter/Exit Programming Mode Code 11 Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the Code 11 Length Control maximum label length if in Mode, or the second fixed length if in Variable Length Fixed Length Mode.
Page 150: Gs1 Databar™ Omnidirectional
Enter/Exit Programming Mode GS1 DATABAR™ OMNIDIRECTIONAL The following options apply to the GS1 DataBar™ Omnidirectional (formerly RSS-14) symbology. GS1 DataBar™ Omnidirectional Enable/Disable When disabled, the reader will not read GS1 DataBar™ Omnidirectional bar codes. $C4BEN00(CR) DEFAULT GS1 DataBar™ Omnidirectional = Disable $C4BEN01(CR) GS1 DataBar™...
Page 151: Gs1 Databar™ Omnidirectional 2D Component
Enter/Exit Programming Mode GS1 DataBar™ Omnidirectional 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded. $C4B2D00(CR) DEFAULT GS1 DataBar™ Omnidirectional 2D Component = Disable (2D component not required) $C4B2D01(CR) GS1 DataBar™...
Page 152: Gs1 Databar™ Expanded Gs1-128 Emulation
Enter/Exit Programming Mode GS1 DataBar™ Expanded GS1-128 Emulation When enabled, GS1 DataBar™ Expanded bar codes will be translated to the GS1-128 label data format. $CXBU800(CR) DEFAULT GS1 DataBar™ Expanded GS1-128 Emulation = Disable $CXBU801(CR) GS1 DataBar™ Expanded GS1-128 Emulation = Enable GS1 DataBar™...
Page 153: Gs1 Databar™ Expanded Length Control
Enter/Exit Programming Mode GS1 DataBar™ Expanded Length Control This feature specifies either variable length decoding or fixed length decoding for the GS1 DataBar™ Expanded symbology. Variable Length: For variable-length decoding, a minimum length may be set. Fixed Length: For fixed-length decoding, two different lengths may be set. $CXBLC00(CR) DEFAULT GS1 DataBar™...
Page 154: Gs1 Databar™ Expanded Set Length 1
Enter/Exit Programming Mode GS1 DataBar™ Expanded Set Length 1 This feature specifies one of the bar code lengths for GS1 DataBar™ Expanded Length Control Length 1 is the minimum label length if in Mode, or the first fixed length if Variable Length Mode.
Page 155: Gs1 Databar™ Expanded Set Length 2
Enter/Exit Programming Mode GS1 DataBar™ Expanded Set Length 2 This feature specifies one of the bar code lengths for GS1 DataBar™ Expanded Length Control Length 2 is the maximum label length if in Mode, or the second fixed length Variable Length if in Mode.
Page 156: Gs1 Databar™ Limited
Enter/Exit Programming Mode GS1 DATABAR™ LIMITED The following options apply to the GS1 DataBar™ Limited (formerly RSS Limited) symbology. GS1 DataBar™ Limited Enable/Disable When disabled, the reader will not read GS1 DataBar™ Limited bar codes. $CLBEN00(CR) DEFAULT GS1 DataBar™ Limited = Disable $CLBEN01(CR) GS1 DataBar™...
Page 157: Gs1 Databar™ Limited 2D Component
Enter/Exit Programming Mode GS1 DataBar™ Limited 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. $CLB2D00(CR) DEFAULT GS1 DataBar™ Limited 2D Component = Disable (2D component not required) $CLB2D01(CR) GS1 DataBar™...
Page 158: Code 93 Check Character Calculation
Enter/Exit Programming Mode Code 93 Check Character Calculation Enables/disables calculation and verification of an optional Code 93 check character. $CC9CC00(CR) Code 93 Check Character Calculation = Disable $CC9CC01(CR) Code 93 Check Character Calculation = Enable Check C $CC9CC02(CR) Code 93 Check Character Calculation = Enable Check K $CC9CC03(CR) DEFAULT Code 93 Check Character Calculation =...
Page 159: Code 93 Length Control
Enter/Exit Programming Mode Code 93 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 93 symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CC9LC00(CR) DEFAULT Code 93 Length Control = Variable Length...
Page 160: Code 93 Set Length 1
Enter/Exit Programming Mode Code 93 Set Length 1 Specifies one of the bar code lengths for . Length 1 is the minimum Code 93 Length Control label length if in Mode, or the first fixed length if in Mode. Variable Length Fixed Length Length includes the bar code’s data characters only.
Page 161: Code 93 Set Length 2
Enter/Exit Programming Mode Code 93 Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the Code 93 Length Control maximum label length if in Mode, or the second fixed length if in Variable Length Fixed Length Mode.
Page 162: Code 93 Quiet Zones
Enter/Exit Programming Mode Code 93 Quiet Zones Enables/disables quiet zones for Code 93. $CC9LO02(CR) Code 93 Quiet Zones = Quiet Zones on two sides $CC9LO03(CR) DEFAULT Code 93 Quiet Zones = Small Quiet Zones on two sides The following options apply to the MSI symbology. MSI Enable/Disable Enables/Disables ability of reader to decode MSI labels.
Page 163: Msi Check Character Calculation
Enter/Exit Programming Mode MSI Check Character Calculation Enables/Disables calculation and verification of an optional MSI check character. $CMSCC00(CR) MSI Check Character Calculation = Disable $CMSCC01(CR) DEFAULT MSI Check Character Calculation = Enable Mod10 $CMSCC02(CR) MSI Check Character Calculation = Enable Mod11/10 $CMSCC03(CR) MSI Check Character Calculation = Enable Mod10/10 MSI Check Character Transmission...
Page 164: Msi Length Control
Enter/Exit Programming Mode MSI Length Control This feature specifies either variable length decoding or fixed length decoding for the MSI symbology. For variable length decoding, a minimum and maximum length may Variable Length: be set. For fixed length decoding, two different lengths may be set. Fixed Length: $CMSLC00(CR) DEFAULT...
Page 165: Msi Set Length 1
Enter/Exit Programming Mode MSI Set Length 1 This feature specifies one of the bar code lengths for . Length 1 is the MSI Length Control minimum label length if in Mode, or the first fixed length if in Variable Length Fixed Mode.
Page 166: Msi Set Length 2
Enter/Exit Programming Mode MSI Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the MSI Length Control maximum label length if in Mode, or the second fixed length if in Variable Length Fixed Mode.
Page 167: Plessey
Enter/Exit Programming Mode PLESSEY The following options apply to the Plessey symbology. Plessey Enable/Disable Enables/Disables ability of reader to decode Plessey labels. $CPLEN00CR) DEFAULT Plessey = Disable $CPLEN01CR) Plessey = Enable Plessey Check Character Calculation Enables/Disables calculation and verification of an optional Plessey check character. $CPLCC00(CR) Plessey Check Character Calculation = Disable $CPLCC01(CR)
Page 168: Plessey Check Character Transmission
Enter/Exit Programming Mode Plessey Check Character Transmission Enables/disables transmission of an MSI check character. $CPLCT00(CR) Plessey Check Character Transmission = Disable $CPLCT01(CR) DEFAULT Plessey Check Character Transmission = Enable Plessey Length Control This feature specifies either variable length decoding or fixed length decoding for the Plessey symbology.
Page 169: Plessey Set Length 1
Enter/Exit Programming Mode Plessey Set Length 1 This feature specifies one of the bar code lengths for . Length 1 is the Plessey Length Control minimum label length if in Mode, or the first fixed length if in Variable Length Fixed Length Mode.
Page 170: Plessey Set Length 2
Enter/Exit Programming Mode Plessey Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the Plessey Length Control maximum label length if in Mode, or the second fixed length if in Variable Length Fixed Length Mode.
Page 171: 2D Symbologies
2D SYMBOLOGIES 2D Global Features 2D N 2D M ORMAL NVERSE YMBOL AXIMUM ECODING IME , page ONTROL , page 171 2D S TRUCTURED PPEND , page 171 The reader supports the following 2D symbologies (bar code types). Symbology-dependent options for each symbology are included in this chapter. See "The reader supports the following 1D symbologies (bar code types).
Page 172: 2D Maximum Decoding Time
Enter/Exit Programming Mode 2D Global Features 2D Maximum Decoding Time This feature specifies the maximum amount of time the software will spend attempting to decode a 2D label. The selectable range is 10 milliseconds to 2.55 milliseconds. $CDETM0A(CR) 2D Maximum Decoding Time = 100 msec $CDETM32(CR) 2D Maximum Decoding Time = 200 msec $CDETM23(CR)
Page 173: 2D Structured Append
2D Global Features Enter/Exit Programming Mode 2D Structured Append Enables/disables ability of reader to append multiple 2D Codes labels in a structured format. The structured append property is globally applied to the following symbologies, if these are enabled: ATRIX ZTEC QR C PDF 417 $CDESA00(CR)
Page 174: Aztec Code
Enter/Exit Programming Mode 2D Global Features AZTEC CODE Aztec Code Enable / Disable Enables/disables the ability of the reader to decode Aztec Code labels. $CAZEN00(CR) DEFAULT Aztec Code = Disable $CAZEN01(CR) Aztec Code = Enable Aztec Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 175: Aztec Code Set Length 1
2D Global Features Enter/Exit Programming Mode Aztec Code Set Length 1 Specifies one of the bar code lengths for . Length 1 is the minimum Aztec Code Length Control label length if in Mode, or the first fixed length if in Fixed Length Mode. Variable Length Characters can be set from 0001 to 3,832 characters in increments of 0001 (pad with zeroes).
Page 176: Aztec Code Set Length 2
Enter/Exit Programming Mode 2D Global Features Aztec Code Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is Aztec Code Length Control the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 177: China Sensible Code
2D Global Features Enter/Exit Programming Mode CHINA SENSIBLE CODE China Sensible Code Enable / Disable Enables/disables the ability of the reader to decode China Sensible Code labels. $CCSEN00(CR) DEFAULT China Sensible Code = Disable $CCSEN01(CR) China Sensible Code = Enable China Sensible Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 178: China Sensible Code Set Length 1
Enter/Exit Programming Mode 2D Global Features China Sensible Code Set Length 1 Specifies one of the bar code lengths for . Length 1 is the China Sensible Code Length Control minimum label length if in Mode, or the first fixed length if in Fixed Length Variable Length Mode.
Page 179: China Sensible Code Set Length 2
2D Global Features Enter/Exit Programming Mode China Sensible Code Set Length 2 This feature specifies one of the bar code lengths for China Sensible Code Length Control Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 180: Data Matrix
Enter/Exit Programming Mode 2D Global Features DATA MATRIX Data Matrix Enable / Disable Enables/disables ability of reader to decode Data Matrix labels. $CDMEN00(CR) Data Matrix = Disable $CDMEN01(CR) DEFAULT Data Matrix = Enable Data Matrix Square/Rectangular Style Specifies the options available when reading Data Matrix with different form factors. Choices are: •...
Page 181: Data Matrix Dpm Decoding Safety
2D Global Features Enter/Exit Programming Mode Data Matrix DPM Decoding Safety This feature defines the tolerance of DPM decoding software to operate with poor quality labels. Decoding Safety is used to configure a barcode symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. Higher tolerance to poor quality labels increases the reading capability of the scanner.
Page 182: Data Matrix Length Control
Enter/Exit Programming Mode 2D Global Features Data Matrix Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set.
Page 183: Data Matrix Set Length 2
2D Global Features Enter/Exit Programming Mode Data Matrix Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is Data Matrix Length Control the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 184: Maxicode
Enter/Exit Programming Mode 2D Global Features MAXICODE Maxicode Enable / Disable Enables/disables ability of reader to decode Maxicode labels. $CMXEN00(CR) DEFAULT Maxicode = Disable $CMXEN01(CR) Maxicode = Enable Maxicode Primary Message Transmission Enables/disables the transmission of only the Primary Message when the Secondary Message is not readable.
Page 185: Maxicode Length Control
2D Global Features Enter/Exit Programming Mode Maxicode Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CMXLC00(CR) DEFAULT Maxicode Length Control = Variable Length...
Page 186: Maxicode Set Length 2
Enter/Exit Programming Mode 2D Global Features Maxicode Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the Maxicode Length Control maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 187: Pdf417
2D Global Features Enter/Exit Programming Mode PDF417 PDF417 Enable / Disable Enables/disables the ability of the reader to decode PDF417 labels. $CP4EN00(CR) PDF417 = Disable $CP4EN01(CR) DEFAULT PDF417 = Enable PDF417 Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 188: Pdf417 Set Length 1
Enter/Exit Programming Mode 2D Global Features PDF417 Set Length 1 Specifies one of the bar code lengths for . Length 1 is the minimum PDF417 Length Control label length if in Mode, or the first fixed length if in Fixed Length Mode. Variable Length Length includes the bar code’s data characters only.
Page 189: Pdf417 Set Length 2
2D Global Features Enter/Exit Programming Mode PDF417 Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the PDF417 Length Control maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 190: Micro Pdf417
Enter/Exit Programming Mode 2D Global Features MICRO PDF417 Micro PDF417 Enable / Disable Enables/disables the ability of the reader to decode Micro PDF417 labels $CMIEN00(CR) DEFAULT Micro PDF417 = Disable $CMIEN01(CR) Micro PDF417 = Enable Micro PDF417 Code 128 GS1-128 Emulation Specifies which AIM ID to use for MicroPDF labels when doing Code 128 or GS1-128 emulation.
Page 191: Micro Pdf417 Length Control
2D Global Features Enter/Exit Programming Mode Micro PDF417 Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set.
Page 192: Micro Pdf417 Set Length 2
Enter/Exit Programming Mode 2D Global Features Micro PDF417 Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is Micro PDF417 Length Control the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length includes the bar code’s data characters only.
Page 193: Qr Code
2D Global Features Enter/Exit Programming Mode QR CODE QR Code Enable / Disable Enables/disables the ability of the reader to decode QR Code labels $CQREN00(CR) QR Code = Disable $CQREN01(CR) DEFAULT QR Code = Enable QR Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 194: Qr Code Set Length 1
Enter/Exit Programming Mode 2D Global Features QR Code Set Length 1 Specifies one of the bar code lengths for . Length 1 is the minimum QR Code Length Control label length if in Mode, or the first fixed length if in Fixed Length Mode. Variable Length Characters can be set from 0001 to 7,089 characters in increments of 0001 (pad with zeroes).
Page 195: Qr Code Set Length 2
2D Global Features Enter/Exit Programming Mode QR Code Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the QR Code Length Control maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 196: Micro Qr Code Length Control
Enter/Exit Programming Mode 2D Global Features Micro QR Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set.
Page 197: Micro Qr Code Set Length 2
2D Global Features Enter/Exit Programming Mode Micro QR Code Set Length 2 This feature specifies one of the bar code lengths for Micro QR Code Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 198: Ucc Composite
Enter/Exit Programming Mode 2D Global Features UCC COMPOSITE UCC Composite Enable / Disable Enables/disables the ability of the reader to decode the stacked part of a UCC Composite label. This feature is not effective when Global AIM IDs are enabled (see "Global AIM ID"...
Page 199: Ucc Optional Composite Timer
2D Global Features Enter/Exit Programming Mode UCC Optional Composite Timer Specifies the amount of time the system will wait for the stacked part of a UCC Composite label before transmitting the linear label without an add-on. $CCMOT00(CR) DEFAULT UCC Optional Composite Timer = Timer Disabled $CCMOT01(CR) UCC Optional Composite Timer = 100msec $CCMOT02(CR)
Page 200: Postal Code Selection
Enter/Exit Programming Mode 2D Global Features POSTAL CODE SELECTION Enables/disables the ability of the scanner to decode labels of a specific postal symbology. ISABLE OSTAL ODES USTRALIA OSTNET APAN LANET OYAL WEDEN ORTUGAL $CPOEN00(CR) DEFAULT Postal Code Selection = Disable All Postal Codes $CPOEN01(CR) Postal Code Selection = Enable Postnet $CPOEN02(CR)
Page 201: Postnet Bb Control
2D Global Features Enter/Exit Programming Mode Postal Code Selection (continued) $CPOEN06(CR) Postal Code Selection = Enable Japan Post $CPOEN07(CR) Postal Code Selection = Enable IMB $CPOEN08(CR) Postal Code Selection = Enable Sweden Post $CPOEN09(CR) Postal Code Selection = Enable Portugal Post Postnet BB Control Controls the ability of the scanner to decode B and B' fields of Postnet labels.
Page 202 NOTES PowerScan™ PD9530...
Page 203: Motion Features
MOTION FEATURES OTION IMING ONTROL on page 201 OTION ENSITIVITY on page 202 OTIONLESS IMEOUT on page 202 Use this chapter to configure motion settings for the handheld. Reference for a listing of standard factory settings. Appendix C, Motion Aiming Control Configures the ability of the scanner to Enable/Disable the Aiming system when motion is detected.
Page 204: Motion Sensitivity
Enter/Exit Programming Mode Motion Sensitivity Defines discrete set of levels for scanner motion sensitivity when in handheld use. $CMOSY00(CR) Motion Sensitivity = Low $CMOSY01(CR) DEFAULT Motion Sensitivity = Medium $CMOSY02(CR) Motion Sensitivity = High Motionless Timeout Specifies the waiting time in 100 millisecond ticks to assume that the reader is in a motionless condition.
Page 205: References
Chapter 4 References This section contains explanations and examples of selected bar code features. See for the actual bar code labels used to configure Configuration Using Bar Codes, starting on page 19 the reader. RS-232 P ARAMETERS on page 204 •...
Page 206: Rs-232 Parameters
References RS-232 Parameters RS-232 Only Baud Rate Baud rate is the number of bits of data transmitted per second. Set the reader's baud rate to match the baud rate setting of the host device. With an improper baud rate setting, data may not reach the host correctly.
Page 207: Rs-232/Usb Com Parameters
RS-232 Parameters RS-232/USB COM Parameters Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments.
Page 208 References ACK NAK Options This enables/disables the ability of the reader to support the RS-232 ACK/NAK protocol. When configured, the reader and/or host sends an “ACK” when it receives data properly, and sends “NAK” when the data is in error. Options are: •...
Page 209 RS-232 Parameters NAK Character This setting specifies an ASCII character or hex value to be used as the NAK character. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
Page 210 References ACK NAK Timeout Value This option specifies the amount of time the reader waits for an ACK character from the host following label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A selection of 0 disables the timeout. To set this value: 1.
Page 211 RS-232 Parameters ACK NAK Retry Count This feature specifies the number of times the reader retries a label transmission due to a retry condition. The selectable range is from 1 to 254 retries. A selection of 0 disables the count, and a selection of 255 specifies unlimited retries. To set this feature: 1.
Page 212 References Disable Character Specifies the value of the RS-232 host command used to disable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
Page 213 RS-232 Parameters Enable Character Specifies the value of the RS-232 host command used to enable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
Page 214: Keyboard Interface
References Keyboard Interface Wedge Quiet Interval Specifies the amount of time the reader looks for keyboard activity before it breaks the keyboard connection in order to transmit data to host. The range is from 0 to 990ms in 10ms increments. This feature applies ONLY to the Keyboard Wedge interface.
Page 215: Intercharacter Delay
Keyboard Interface Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay. This feature applies ONLY to the Keyboard Wedge interface.
Page 216: Intercode Delay
References Intercode Delay Specifies the delay between labels transmitted to the host for this interface. The selectable range for this feature is from 0 to 99 seconds. Follow these instructions to set this feature: 1. Determine the desired setting. 2. Pad the number with leading zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc 3.
Page 217: Symbologies
Symbologies Symbologies Datamatrix DPM Decoding Safety Decoding Safety is used to configure a decoder to be very aggressive to very conservative, depending on a particular customer’s needs. • Level 1 results in a very aggressive decoder. • Level 5 results in a very conservative decoder at the expense of not being able to read poorly printed or damaged labels.
Page 218 References Set Length 2 This feature allows you to set one of the bar code lengths for the specified symbology. Mode, or the second fixed length Length 2 is the maximum label length if in Variable Length if in Mode. See the page for the specific symbology for parameters. Fixed Length The length that can be set varies depending on the symbology.
Page 219: Data Editing
ID code will be transmitted before the scanned bar code data. 00 - 20 Characters (ASCII) Additional advanced editing is available. See the Advanced formatting fea- tures in the Datalogic Aladdin configuration software, or contact Technical Support (as described on page 10) for more information.
Page 220: Global Prefix/Suffix
References Global Prefix/Suffix Up to 20 ASCII characters may be added as a prefix (in a position before the bar code data) and/or as a suffix (in a position following the bar code data) as indicated in Figure 2 Figure 2. Prefix and Suffix Positions OR...
Page 221 Data Editing • A modifier character (the modifier character is symbol dependent). SYMBOLOGY CHAR SYMBOLOGY CHAR UPC/EAN Code 128/GS1-128 Code 39 and  DataBar Omnidirectional, Code 32 DataBar Expanded Codabar Standard 2 of 5 Interleaved 2 of 5 ISBN Code 93 Code 11 a.
Page 222: Label Id
References Label ID A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01-0xFF), used to identify a bar code (symbology) type. It can be appended previous to or following the transmitted bar code data depending upon how this option is enabled. This feature provides options for configuring custom Label IDs as a pre-loaded set (see "Label ID: Pre-loaded Sets"...
Page 223 Data Editing USA Label ID set EU Label ID set Symbology Default Default Default Default Character ASCII Character ASCII DATABAR EXPANDED COMPOSITE 525800 525800 DATABAR LIMITED 524C00 760000 DATABAR LIMITED COMPOSITE 524C00 524C00 DATA MATRIX 446D00 770000 EAN128 000000 6B0000 EAN128 COMPOSITE 000000 244500...
Page 224 References USA Label ID set EU Label ID set Symbology Default Default Default Default Character ASCII Character ASCII POSTAL JAPANESE 245200 245200 POSTAL KIX 245500 245500 POSTAL PLANET 245700 245700 POSTAL PORTUGAL 245000 245000 POSTAL POSTNET BB 244C00 244C00 POSTAL ROYAL MAIL 244D00 244D00 POSTAL SWEDISH...
Page 225 Data Editing Label ID: Set Individually Per Symbology To configure a Label ID individually for a single symbology: 1. Go to and scan the ENTER/EXIT bar code. page 53 2. Select Label ID position as either BEFORE (Enable as Prefix) or AFTER (Enable as suffix) by scanning the appropriate bar code in the section "Label ID Control"...
Page 226 References Table 36 . Label ID Examples STEP ACTION EXAMPLES Scan the ENTER/EXIT bar (Scanner enters Programming Mode) code Determine placement of the Label ID characters BEFORE or AFTER with regard to Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix scanned data using Label ID...
Page 227: Character Conversion
Data Editing Character Conversion Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted. The second character in the pair is the character to convert to. If the character to convert in a pair is FF, then no conversion is done.
Page 228: Reading Parameters
References Reading Parameters Label Gone Timeout This feature sets the time after the last label segment is seen before the reader prepares for a new label. The timeout can be set within a range of 10 milliseconds to 2,550 milliseconds (2.55 seconds) in 10ms increments.
Page 229: Good Read Led Duration
Reading Parameters Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 10 milliseconds to 2,550 milliseconds (0.001 to 2.55 seconds) in 100ms increments.
Page 230: Scanning Features
References Scanning Features Scan Mode This mode is associated with typical handheld reader operation. Selects the scan operating mode for the reader. The following selections are valid for all models: Trigger Single: When the trigger is pulled, scanning is activated until one of the following occurs: has elapsed Scanning Active Time...
Page 231: Stand Mode Off Time
Scanning Features Stand Mode Off Time This feature specifies the amount of time reader illumination stays off after pulling the trigger when in Stand Mode. The configurable range is 01 to 32 by 01 in increments of 500ms (500ms to 16 seconds). Follow these instructions to set this feature: 1.
Page 232: Scanning Active Time
References Scanning Active Time This setting specifies the amount of time that the reader stays in scan ON state once the state is entered. The range for this setting is from 1 to 255 seconds in 1-second increments. Follow these instructions to set this feature: 1.
Page 233: Aiming Duration Time
Scanning Features Aiming Duration Time Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger single mode. The range for this setting is from 1 to 255 seconds in 1-second increments. Follow these instructions to set this feature: 1.
Page 234: Flash On Time
References Flash On Time This feature specifies the ON time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. Follow these instructions to set this feature. 1.
Page 235: Flash Off Time
Scanning Features Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. Follow these instructions to set this feature. 1.
Page 236: Multiple Labels Ordering By Code Symbology
References Multiple Labels Ordering by Code Symbology This feature Specifies the transmission ordering by symbology type, when Multiple Labels per Frame is enabled.Up to six symbologies can be selected. Zeroes must be added to pad the string to 12 characters if not using all six symbologies. The labels are ordered first as specified in the output mask.
Page 237 Scanning Features Table 45 . Symbology Hex Values Value Symbology ID Value Symbology ID Don't care GTIN5 UPC-A GTIN8 UPC-E S2OF5 EAN8 PDF417 EAN13 CODE11 UPC2 IATA UPC5 MICRO_PDF C128_ADDON GS1 DataBar_LIM_ID EAN128 GS1 DataBar_LIM_COMP C128_PROGRAMMING_LABEL GS1 DataBar_Omnidirectional_COMP CODE128 GS1 DataBar_EXP_COMP FNC3_C128_LABEL GENERIC_DATA DATA MATRIX...
Page 238: Motion Features
References Motion Features Motionless Timeout This setting specifies the amount of time that the reader takes to assume that it is in a motionless condition. The range for this setting is from 500 msec to 25.5 seconds, in 100 millisecond increments. Follow these instructions to set this feature.
Page 239: Technical Specifications
Appendix A Technical Specifications The tables that follow contain Physical and Performance Characteristics, User Environment and Regulatory information. Table provides Standard Cable Pinouts. Table 47. Technical Specifications Item Description Physical Characteristics Height: 212 mm Dimensions Length: 110 mm Width: 74 mm Weight (without cable) 330 gr (without cable) Electrical Characteristics...
Page 240 Technical Specifications Print Contrast  15% minimum reflectance Minimum PD9530-HP / PD9530 PD9530-HPE Max resolution 1D 4 mils 1D 2.5 mil Resolution Max resolution 2D 7.5 mils 2D 4 mil Depth of Field (Typical) Symbology Standard Model High Performance 4 mils: 6-17 cm 2.5 mils: 2-6 cm Code 39 20 mils: 4-55 cm...
Page 241 Decode Capability Item Description GS1 Databar linear codes, UPC/EAN (A,E,13,8), UPC/EAN with P2/P5 Addons, UPC/EAN Coupons, ISBN, Code128, EAN128, ISBT128, Code39, 1D Bar Codes Code39 Full ASCII, Code39 CIP, Code 32, Codabar, Interleaved 2 of 5, IATA, Industrial 2 of 5, Standard 2 of 5, Code11, MSI, Plessey, Code 93, Follet 2/5 DataMatrix, MaxiCode and QR Codes(QR, Micro QR and Multiple QR codes), Aztec - Postal codes including Australian Post, China Post, Japanese Post, KIX...
Page 242 Technical Specifications Item Description User Environment Operating  -4° to 122° F (-20° - +50° C ) Temperature Storage Temperature -40° to 158° F (-40° to 70° C) Humidity 0 to 95% non-condensing Drop Specifications Scanner withstands >50 times 6.5' (2 m) drops to concrete Ambient Light ...
Page 243: Imager Labeling
Imager Labeling Imager Labeling Sample labels are shown for illustrative purposes only. Please view the labels on your product for actual details, as they may vary from those depicted. Scanner Regulatory Label Product Reference Guide...
Page 244: Standard Cable Pinouts
Technical Specifications Standard Cable Pinouts The data below provides standard pinout information for the interface cable. Figure 5. Standard Cable Pinouts: Handheld Table 48 The signal descriptions in apply to the connector on the reader and are for reference only. Table 48.
Page 245: Led And Beeper Indications
LED and Beeper Indications LED and Beeper Indications The reader’s beeper sounds and its LED illuminates to indicate various functions or errors on the reader. An optional “Green Spot” also performs useful functions. The tables below list these indications. One exception to the behaviors listed in the tables is that the reader’s functions are programmable, and may or may not be turned on.
Page 246: Error Codes
Technical Specifications Table 50 . Programming Mode Indications Programming Mode - The following indications ONLY occur when the reader is in Programming Mode. INDICATION DESCRIPTION BEEPER Label Pro- A valid programming label LED blinks continu- Reader sounds four low gramming has been scanned.
Page 247: Sample Bar Codes
Appendix B Sample Bar Codes The sample bar codes in this appendix are typical representations for their symbology types. 1D Bar Codes UPC-A EAN-13 978033029095 Code 39 Code 128 Code 128 Interleaved 2 of 5 Product Reference Guide...
Page 248 Sample Bar Codes Sample Bar Codes (continued) Code 32 Codabar 13579 Code 93 Code 11 123456789 PowerScan™ PD9530...
Page 249: Gs1 Databar™ (Rss)
GS1 DataBar™ (RSS) GS1 DataBar™ Omnidi- GS1 DataBar™ variants must be enabled to read the bar codes below (see rectional on page 148 GS1 DataBar™ Expanded Stacked 10293847560192837465019283746029478450366523 GS1 DataBar™ Expanded 1234890hjio9900mnb GS1 DataBar™ Limited 08672345650916 GS1 DataBar™-14 GS1 DataBar™ Omnidirectional Truncated 55432198673467 GS1 DataBar™...
Page 250: D Bar Codes
Sample Bar Codes 2D Bar Codes Aztec Datamatrix China Sensible Code MaxiCode Test Message PDF 417 Micro PDF 417 ABCabc BV17453 QR Code Micro QR Code 123456 35900G9 UCC Composite PowerScan™ PD9530...
Page 251: Standard Defaults
Appendix C Standard Defaults The most common configuration settings are listed in the “Default” column of the table below. Page references are also provided for feature descriptions and programming bar codes for each parameter. A column has also been provided for recording of your preferred default settings for these same configurable features.
Page 252 Standard Defaults Page Parameter Default Your Setting Number ACK NAK Error Handling Ignore Errors Detected Indicate Transmission Failure Enable Disable Character ‘D’ Enable Character ‘E’ KEYBOARD WEDGE Country Mode U.S. Keyboard Send Control Characters Wedge Quiet Interval 100 ms Intercode Delay No Delay Caps Lock State Caps Lock OFF...
Page 253 Standard Defaults Page Parameter Default Your Setting Number Good Read Beep Type Mono Good Read Beep Frequency High Good Read Beep Length 80 ms Good Read Beep Volume High Good Read LED Duration 300 ms Scanning Features Scan Mode Trigger Single Stand Mode Indication Disable Pick Mode...
Page 254 Standard Defaults Page Parameter Default Your Setting Number UPC-A UPC-A Enable/Disable Enable UPC-A Check Character Transmission Send Expand UPC-A to EAN-13 Don’t Expand UPC-A Number System Character Transmission Transmit 2D Component Not UPC-A 2D Component Required UPC-E UPC-E Enable/Disable Enable UPC-E Check Character Transmission Send 2D Component Not...
Page 255 Standard Defaults Page Parameter Default Your Setting Number UPC/EAN Global Settings UPC/EAN Price Weight Check Disable UPC/EAN Quiet Zones Two Modules Add-Ons Optional Add-ons Disable P2, P5 and P8 Optional Add-On Timer 70 ms Optional GS1-128 Add-On Timer Disable Code 39 Code 39 Enable/Disable Enable Code 39 Check Character Calculation...
Page 256 Standard Defaults Page Parameter Default Your Setting Number Code 128 Code 128 Enable/Disable Enable Expand Code 128 to Code 39 Don’t Expand Code 128 Check Character Transmission Don’t Send Code 128 Function Character Transmission Don’t Send Code 128 Sub-Code Exchange Transmission Disable Small Quiet Zones on two Code 128 Quiet Zones...
Page 257 Standard Defaults Page Parameter Default Your Setting Number Standard 2 of 5 Standard 2 of 5 Enable/Disable Disable Standard 2 of 5 Check Character Calculation Disable Standard 2 of 5 Check Character Transmission Send Standard 2 of 5 Length Control Variable Standard 2 of 5 Set Length 1 Standard 2 of 5 Set Length 2...
Page 258 Standard Defaults Page Parameter Default Your Setting Number ABC Codabar ABC Codabar Enable/Disable Disable ABC Codabar Concatenation Mode Static ABC Codabar Dynamic Concatenation Timeout 200 msec ABC Codabar Force Concatenation Disable Code 11 Code 11 Enable/Disable Disable Code 11 Check Character Calculation Check C and K Code 11 Check Character Transmission Send...
Page 259 Standard Defaults Page Parameter Default Your Setting Number Code 93 Code 93 Enable/Disable Disable Code 93 Check Character Calculation Enable Check C and K Code 93 Check Character Transmission Enable Code 93 Length Control Variable Code 93 Set Length 1 Code 93 Set Length 2 Small Quiet Zones on two Code 93 Quiet Zones...
Page 260 Standard Defaults Page Parameter Default Your Setting Number Aztec Code Set Length 1 China Sensible Code Enable / Disable Disable China Sensible Code Length Control Variable China Sensible Code Set Length 1 7,827 China Sensible Code Set Length 2 Data Matrix Enable / Disable Enable Both Square and Data Matrix Square/Rectangular Style...
Page 261 Standard Defaults Page Parameter Default Your Setting Number Micro QR Code Enable/Disable Disable Micro QR Code Length Control Variable Micro QR Code Set Length 1 0001 Micro QR Code Set Length 2 0035 UCC Composite Enable / Disable Disable UCC Optional Composite Timer Timer Disabled Postal Code Selection Disable all Postal codes...
Page 262 Standard Defaults NOTES PowerScan™ PD9530...
Page 263: Keypad
Appendix D Keypad Use the bar codes in this appendix to enter numbers as you would select digits/characters from a keypad. Product Reference Guide...
Page 264 Keypad Keypad (continued) PowerScan™ PD9530...
Page 265: Scancode Tables
Appendix E Scancode Tables Control Character Emulation Control character emulation selects from different scancode tables as listed in this appendix. Each of the control character sets below are detailed by interface type in the tables. These apply to Wedge and USB Keyboard platforms. Characters from 00 to 0x1F are sent as control character Ctrl+Keys, Control Character 00 .
Page 266: Interface Type Pc At Ps/2, Usb-Keyboard Or Usb-Keyboard For Apple
Interface Type PC AT PS/2, USB-Keyboard or USB-Keyboard for APPLE Table 52. Scancode Set When Control Character is 00 or 01 NULL C(S)+A C(S)+B C(S)+C C(S)+D C(S)+E C(S)+F C(S)+G C(S)+J C(S)+K C(S)+L Enter C(S)+N C(S)+O C(S)+P C(S)+Q C(S)+R C(S)+S C(S)+T C(S)+U C(S)+V C(S)+W...
Page 267 Interface Type PC AT PS/2, USB-Keyboard or USB-Keyboard for APPLE — cont. Table 53. Scancode Set When Control Character is 02 Enter Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑  S+ Tab Enter Pg Up Keypd Pg Dwn Home...
Page 268: Interface Type Pc At Ps/2 Alt Mode Or Usb-Keyboard Alt Mode
Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode Table 54. Scancode Set When Control Character is 00 or 01 Alt+000 Alt+001 Alt+002 Alt+003 Alt+004 Alt+005 Alt+006 Alt+007 Alt+010 Alt+011 Alt+012 Alt+014 Alt+015 Enter Alt+016 Alt+017 Alt+018 Alt+019 Alt+020 Alt+021 Alt+022...
Page 269 Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode — cont. Table 55. Scancode Set When Control Character is 02 Enter Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑  S+ Tab Enter Pg Up Keypd Pg Dwn...
Page 270: Digital Interface
Digital Interface Table 56. Scancode Set When Control Character is 00 or 01 NULL C(S)+A C(S)+B C(S)+C C(S)+E C(S)+F C(S)+G C(S)+J C(S)+K C(S)+L Enter C(S)+N C(S)+O C(S)+P C(S)+Q C(S)+R C(S)+S C(S)+T C(S)+U C(S)+V C(S)+W C(S)+X C(S)+Y C(S)+Z C(S)+\ C(S)+^ C(S)+_ Space “...
Page 271: Ibm31Xx 102-Key
IBM31xx 102-key Table 58. Scancode Set When Control Character is 00 or 01 NULL C(S)+A C(S)+B C(S)+C C(S)+E C(S)+F C(S)+G C(S)+J C(S)+K C(S)+L Enter C(S)+N C(S)+O C(S)+P C(S)+Q C(S)+R C(S)+S C(S)+T C(S)+U C(S)+V C(S)+W C(S)+X C(S)+Y C(S)+Z C(S)+\ C(S)+^ C(S)+_ Space “...
Page 272: Ibm Xt
IBM XT Table 60. Scancode Set When Control Character is 00 or 01 NULL C(S)+A C(S)+B C(S)+C C(S)+E C(S)+F C(S)+G C(S)+H C(S)+J C(S)+K C(S)+L Enter C(S)+N C(S)+O C(S)+P C(S)+Q C(S)+R C(S)+S C(S)+T C(S)+U C(S)+V C(S)+W C(S)+X C(S)+Y C(S)+Z C(S)+\ C(S)+^ C(S)+_ Space “...
Page 273: Microsoft Windows Codepage 1252
Microsoft Windows Codepage 1252 Microsoft Windows Codepage 1252 Windows-1252 is a character encoding of the Latin alphabet, used by default in the legacy components of Microsoft Windows in English and some other Western languages. Product Reference Guide...
Page 274 Scancode Tables NOTES PowerScan™ PD9530...
Page 275: Ascii Chart
ASCII Chart ASCII ASCII ASCII ASCII Char. Char. Char. Char. ‘ “ & ’ < >...
Page 276 ©2013 Datalogic, Inc. All rights reserved. Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.A. and the E.U. Datalogic ADC, Inc. 959 Terry Street Eugene |OR 97402 Telephone: (1) 541-683-5700 Fax: (1) 541-345-7140...
