Milwaukee B51A Service Parts List

23
2
25
24
8
26
12
27 12 15
17
FIG. PART NO. DESCRIPTION OF PART
1 10-20-2705 Warning Label
2 12-20-2105 Service Nameplate Kit
3 --------------- PCB Assembly
4 49-81-0020 12/14.4 Volt Light Bulb (Pkg. of 2)
5 --------------- Connector Block
6 --------------- Negative Contact
7 --------------- Positive Contact
8 --------------- Handle Halve - Right
9 --------------- Handle Halve - Left
10 --------------- Housing - Right
11 --------------- Housing - Left
12 --------------- Bezel
13 --------------- Compression Spring
14 --------------- Contact Holder
15 --------------- Lens
16 --------------- Detent Pin
1 Black From PCB to Negative Contact
2 Red From PCB to Positive Contact
3 Red From PCB to Push Button Switch
4 Red From PCB to Push Button Switch
5 Yellow From PCB to Connector Block
6 Black From PCB to Connector Block
SERVICE PARTS LIST
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CORDLESS 12 VOLT WORKLIGHT
49-24-0145
CATALOG NO.
10
6
4
17
15
NO. REQ.
Connector
Block
STARTING
SERIAL NO.
1
3
16
13
7
14
11
22
FIG. PART NO.
(1) 17 ---------------
(1) 18 ---------------
(1) 19 ---------------
(1)
20 ---------------
(1) 21 ---------------
(1) 22 10-20-2750
(1) 23 ---------------
(1) 24 ---------------
(1) 25 ---------------
(1) 26 ---------------
(1)
27 31-58-0710
(1)
(1)
(1) NOTE: The use of a soft cloth is recommended
(1) when installing lightbulbs. Direct contact with oils or
(2) other contamination can shorten the life of lightbulbs.
Push Button
Switch
3
4
6
1
5
2
PCB
Assembly
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
BULLETIN NO.
54-06-8910
REVISED BULLETIN
WIRING INSTRUCTION
B51A
EXAMPLE:
00
Component Parts (Small #) Are Included
0
When Ordering The Assembly (Large #).
18
20
5
19
9
DESCRIPTION OF PART
Refl ector
Push Button Switch
Retainer Clip
Magnet
Protective Cover
Temperature Warning Label
6 x 15 Pan Hd. T-9 Screw
6 x 8 Pan Hd. T-9 Screw
M3 x 20 Pan Hd. T-9 Screw
6 x 12 Pan Hd. Phillips Screw
Bezel Assembly
Light Bulb
Contact
Holder
DATE
Sept. 2008
21
NO. REQ.
(1)
(1)
(1)
(1)
(1)
(1)
(2)
(1)
(1)
(3)
(1)
Drwg. 1
