Asus Terminator 2 Barebone System T2-P User Manual page 57

To use ASUS Instant Music:
1. Connect the PC power plug to an electrical outlet.
2. Use either one of the two sets of special function keys on your
keyboard to play audio CDs. These keys only function as indicated if
you enabled the Instant Music item in BIOS.
Instant Music function keys (Set 1)
CD
ON/OFF
Esc
To guide you in using Instant Music, place the Instant Music label over
the function keys on the keyboard. The Instant Music keyboard label
comes with your motherboard package.
Instant Music function keys (Set 2)
CD ON/OFF
3. Connect the speakers to the Line Out (lime) port on the rear panel for
audio output. You may also connect a headphone to the headphone
port on the rear panel or on the optical drive front panel.
4. Insert an audio CD to the optical drive.
5. Press Esc to turn on Instant Music.
6. Press F1 or the Space Bar to play the first track on the audio CD.
Iif there is no audio CD inside the optical drive, the drive tray ejects
when you press <F1> or <Space Bar>.
7. Refer to the Instant Music keyboard label to select other tracks or
control the volume.
Press <F2> or <Enter> once to stop playing the audio CD.
8.
Press <F2> or <Enter> again to eject the CD.
ASUS Terminator 2 barebone system
PLAY/PAUSE STOP/EJECT PREVIOUS
F1 F2 F3
PLAY/PAUSE
NEXT VOL. DOWN VOL. UP
F4 F5 F6
CAPS
LOCK
LED
STOP/EJECT
PREVIOUS NEXT
VOL. DOWN VOL. UP
F7 F8
SCROLL
LOCK
LED
