Programming Feature Banks - Code Alarm ca5153 Installation Manual

Feature Bank 1 - 3 Chirps
Transmitter Programming
Refer to transmitter programming.
Feature Bank 2 - 4 Chirps
Security Control
1 Silent Choice
Feature 2 - 8: N/A
9 DBI Port Protocol
Feature Bank 3 - 5 Chirps
Output Control
1 Extended Lock Pulse
Factory Disarm
Lt Green / Black
2
NOTE: On this model the Lt Green / Black Output wire can be configured in Bank 3 or Bank 5. Any changes to this feature in Bank
3 Ignition Controlled Locks
Trunk Output Timing
4
Red / White Output
5 Horn Output Timing
6 Real Panic
AUX 1
7
Violet / Black Output
