Manuals and User Guides for Alcolizer Centurion. We have 2 Alcolizer Centurion manuals available for free PDF download: User Manual, Work Instruction

For more information, please visit alcolizer.com

Alcolizer Centurion User Manual

Alcolizer Centurion User Manual (40 pages)

Zero Tolerance

Brand: Alcolizer | Category: Test Equipment | Size: 1 MB

Table of Contents

Table of Contents
2
1 Introduction

5
2 Description of Centurion

5
- The Instrument
  5
- Specifications
  5
- Equipment Overview
  6
  - External View
    6
  - Internal View
    7
3 Installation Procedure

8
- Installing the Back Plate
  8
- Mounting and Starting the Instrument
  9
  - Mounting
    9
  - Initial Starting
    9
4 Operating Instruction

10
- Providing a Breath Sample
  10
- Analysing the Breath Sample
  11
- Invalid Sample
  11
5 Owner Servicing

12
- Cleaning
  12
- Cleaning Frequency
  13
6 User Controls

13
- Buttons
  13
- Keyboard
  14
7 User Interface

16
- Accessing the User Menu
  16
- Status
  17
  - Instrument
    17
  - Alcohol Sample Module
    17
  - Status Items
    17
  - Network Connections
    18
- About
  18
8 Settings

19
- Instrument Information
  19
- Clock
  20
- Authorisation
  20
- Authorisation Code Entry
  20
- Shutdown Instrument
  21
9 Custom Appearance

22
- Background Image
  22
- Custom Text
  22
- Intervals
  23
10 Logs

23
- View
  23
- Export
  24
  - Exporting
    25
- Erase Event Logs
  25
11 Networks

25
- Configuration
  25
  - Network Setup
    26
- Services
  26
  - Authorisation over Network
    26
  - Alcolizer Portal
    27
12 Email

27
- Email Settings
  27
  - Settings - Template
    28
  - Settings - Server
    28
  - Test Mail
    29
- Email Status
  29
- Email Reports
  30
  - Breath Test Results
    30
  - Instrument Status
    31
  - Event Log Report
    31
13 Relays

31
- Hardware
  32
- Configuration
  33
14 Functions

33
- Functions Menu
  33
15 Self-Check

34
16 Upgrade Software

35
17 Calibration

38
18 Epsom TM20 Printer Setup

39
19 Troubleshooting

39
