AVE MultiView MV-DR3000 Installation & Operation Manual

Digital video recorder
Table of Contents

Advertisement

Quick Links

INSTALLATION &
ON MANUAL
OPERATI

Digital Video Recorder

MV-DR3000
AVE
Before trying to connect or operate this product, please read this manual completely

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MultiView MV-DR3000 and is the answer not in the manual?

Questions and answers

Summary of Contents for AVE MultiView MV-DR3000

  • Page 1: Digital Video Recorder

    INSTALLATION & ON MANUAL OPERATI Digital Video Recorder MV-DR3000 Before trying to connect or operate this product, please read this manual completely...
  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS All the following safety and operated instructions which will prevent harm or damage to the operator and other persons should be read before the unit is operated. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3: Table Of Contents

    4.6 SYSTEM Setting ... 40 5. NETWORK... 42 5.1 Network Configuration... 42 5.1.1 Cable Connections... 42 5.1.2 Configure Your DVR Network Settings ... 43 5.1.3 TCP/IP Communication Setup ... 45 5.1.4 Testing Connection... 47 5.2 TRIPLEX 1 CH DVR VIEWER SOFTWARE: Introduction ...
  • Page 4 7.2.2 Mobile Rack (FOR REMOVABLE HDD MODEL)...90 7.3 System Default...91 7.4 O.S.D Message...92 7.5 Time Index Table ...93 7.6 Specifications ...94 7.7 Compatible Multiplexer Devices...95 7.8 ScanIP ...96 APPENDIX 1. – Using CD Discs (FOR CD-RW MODEL ONLY) ... 98 APPENDIX 2.
  • Page 5: Introduction

    DVR will make your applications far more flexible and effective than ever before. For all, the DVR is going to prove the timely substitute for Time-lapse VCR. 1.2 Product Features...
  • Page 6: Front / Rear View

    INTRODUCTION 1.3. FRONT / REAR VIEW 1.3.1 Front View FOR CD-ROM MODEL Power Monitor Display Search Setup Enter CD-RW device compartment: The compartment allows you to burn the data mostly for backup purposes. This tray is for loading the CD disc. It will accept 120 mm and 80 mm discs.
  • Page 7: Disk Indicator

    PAUSE button: In a playback display, press this to freeze the display. During the freeze, press to display one frame/field of a picture at a time in the forward direction. (A green light is on the PAUSE mode.) PLAY button: Press to play back a recorded video from the hard disk.
  • Page 8 The orange light indicates the hard-disk is retrieving a disk-full status. Shuttle Ring: The shuttle can be moved forward and backward for playback in either direction. Turn this left to play a recorded video in the reverse direction at faster or slower speeds than the recorded speed. Turn this right to play a recorded video in the forward direction at faster or slower speeds than the recorded speed.
  • Page 9: Rear View

    MUX to the DVR. FROM MUX MAIN MONITOR Connector: This BNC connector is used to connect the live video output from a MUX to the DVR. AUDIO IN Connector: This connector is used to connect the audio output from a camera, a MUX or other devices to the DVR.
  • Page 10: Alarm In / Out

    DISK FULL ALARM OUT GROUND SWITCH OUT NO CONNECTION recording speed as the DVR. 7. NO CONNECTION 8. NO CONNECTION 9. ALARM IN (INPUT): This is an alarm input, which can be programmed in the menu system to Normally Open or Normally Closed.
  • Page 11: Installation

    2. INSTALLATION 2. INSTALLATION 2.1 Basic Connection Single Camera . Connecting with a Please set the MULTIPLEXER option to OFF on the REC SETTING page in the setup menu when it is connected with a single camera. (Please refer to section 4.1 MULTIPLEXER.) Multiplexer .
  • Page 12: External Device

    ALARM MUX'S VCR IN MONITOR 2.2 Hard-disk Drive Installation The DVR is equipped with two compartments of hard disk drive (for removable model only). The unit usually comes with one hard-disk drive installed in the compartment HD1, which is default- configured as a master.
  • Page 13 CAUTION: Please don’t use the hard disk(s) you have employed with a particular model of the DVR (in recording and playing back data) with any other model of DVR, for you will lose the data you have stored in the hard disk(s) if you do so.
  • Page 14: System Information

    In the live or recording mode, the Manual Recording information is displayed. However, when the DVR is displaying a decoded image from a multiplexer, you must first switch the unit to encoded image...
  • Page 15: Updating System Software

    7. Hold down the the Up buttons simultaneously, and then turn on the DVR. 8. Keep holding down the buttons until the DVR sounds a tone and display the message “ XXXXXX BYTES READ” Now the DVR is updating the system software, which will take approximately 90 seconds to process.
  • Page 16: Operations

    3. OPERATIONS 3. OPERATIONS This section shows you how to operate and manage the DVR when it gets in the way. 3.1 Configuring Recording Settings Recording time will vary depending on the image size, recording rate, and the capacity of the hard-disk drives.
  • Page 17: Audio Off

    OPERATIONS NTSC (MUX ON) Audio ON (11KHz) BEST Image HIGH Quality STANDARD BASIC Refresh Rate (Field/Sec) REC Time Mode 2 hr NTSC (MUX ON) Audio OFF BEST Image HIGH Quality STANDARD BASIC Refresh Rate (Field/Sec) REC Time Mode 2 hr NTSC (MUX OFF) Audio ON (11KHz) BEST...
  • Page 18 NOTE: Recording times on the tables above are estimated. For actual available recording time of a recording configuration, please refer to the system information of the DVR. (Please refer to section 2.3 system information for more details.) NOTE: There is no audio function at the refresh rate in NTSC: 2.4 fields/sec ~ 1 fields/ 8...
  • Page 19: Recording Operations

    3.4 for more details. 3.2.2 Timer Recording Timer recording provides each day in a weekly table which programs the DVR to turn on and off at specified times. This way the DVR will start/ stop recording according to the programmed schedule. MAIN MENU...
  • Page 20: Alarm / Motion Recording

    By connecting/ disconnecting RECORD IN of ALARM I/O on the rear panel of the DVR, you can activate/deactivate the recording function of a DVR. The file will be kept with a prefixed “R”. ALARM/ MOTION : ON : 30 F/S...
  • Page 21 NOTE: The status of recording operations when an alarm takes place is shown in the diagrams below. Manual or Externally Triggered Recording Alarm Takes Place Actual Recording Speed Normal Alarm Timer Recording Alarm Takes Place Actual Recording Speed Normal Alarm Timer Recording Alarm Takes Place Actual Recording...
  • Page 22: Playback Operations

    DVR is in the playback status. 3.3.1 Normal Playback Once the user presses the PLAY button, the DVR will start playing back the recorded data at the recorded speed. The starting position varies according different sequences.
  • Page 23: Of The Mobile Rack (For Removable Hdd Model Only)

    3.3.3 Slow Forward/Reverse There are speeds available for a slow playback: 1/2, 1/4, 1/8, 1/16. While playing back recorded video at the recorded speed: (1) Press the PAUSE button for the slow playback mode. (2) Forward: Turn the Shuttle dial right to view the recorded video in the forward direction at a speed slower than the recorded speed.
  • Page 24: Search Operations

    MUX option has been set to OFF. Playback Live When the DVR is under PinP display mode, please use the “<”, “>”, “v”, “^” to move the position of the small windows as your desire. 3.4 Search Operations This section shows you how to access recorded video.
  • Page 25: Time Search

    SEARCH FULL LIST ALARM LIST TIME SEARCH THUMBNAIL SD CARD CD (For CD-RW model only) 1 08-12-04 10:02:15 1.00G 2 08-12-04 12:42:31 18.0M 3 08-12-04 12:42:47 10.0M 3.4.3 TIME Search Take the following steps to proceed with the time-list search function. (1) Press the Search button search mode.
  • Page 26: Sd Card Search

    the user can start playback by just clicking the PLAY button SEARCH THUMBNAIL FULL LIST ALARM LIST MM DD YEAR TIME SEARCH THUMBNAIL SD CARD CD (For CD- R W model only ) LEVEL : Interval = 1 Hour 00:00:00 01:00:00 02:00:00 03:00:00...
  • Page 27: Cd Menu (For Cd-Rw Model Only)

    NOTE: To delete a JPG file in the SD card, please return to the SD CARD JPG FILE list page, and highlight the specific JPG file, press the Setup button , then select “Yes” to delete the image. 3.4.6 CD Menu (For CD-RW model only) Take the following steps to proceed with the CD search function.
  • Page 28: Backup Operations

    3.5 Backup Operations 3.5.1 CD Rewritable unit Backup Operations (FOR CD-ROM MODEL ONLY) This device now includes a CD-RW unit. PAUSE SAVE SD JPEG SD AVI CD JPEG CD AVI EXIT (1) SD JPEG: Archive single image clips into an SD card. i ) Insert an SD Card into the SD card slot of the rear unit.
  • Page 29: Mobile Rack Hd Backup Operations (For Removable Hdd Model Only)

    Hear that beeping signal to confirm your disc is ready. ii ) Play the video back to find your desired item. Press PAUSE when you want to start. iii ) Press the Seq./Save button select # 4 ( "CD AVI" ) and enter. iv ) You're in the CD AVI menu now.
  • Page 30: Sd Card Backup Operations For

    recorded video from HD 1 to HD2. Stay on the DISK SETTING page. Use the “ ” and “v” buttons and button to highlight BACKUP; select ALARM, then press the Enter button to proceed. MAIN MENU RECORD ALARM / MOTION CLOCK/ TIMER COMMUNICATION DISK...
  • Page 31 DVR. Please refer to section 3.4.5. ● The AVI file format cannot be played and deleted in the DVR. It can only be played in a card reader connected to a computer. ●The file format can be selected from the “SD FILE”...
  • Page 32: Updating System Software

    The DVR offers a quick setup method by using the SD card. If a user wants to set many DVR devices with the same settings, the DVR could save the whole setting in the SD card, then transfer it to another DVR. MAIN MENU...
  • Page 33: Menu Setup

    4. MENU SETUP 4. MENU SETUP There are categories for operation setting in the setup menu system as shown below. The following sections will instruct you step by step to configure the operation setting and state each menu’s purpose and options. Press the Setup button to access the setup menu.
  • Page 34: Alarm / Motion Setting

    10(10), fields/sec. MULTIPLEXER: For optimum image recording please set this option to ON when the DVR is connected to a ( continued ) multiplexer for use. Set this option to OFF when it is only connected to a single camera or Quad processor.
  • Page 35: Rec Quality

    / deactivate the alarm recording when it detects an alarm input. ON: The device activates the alarm recording when it detects an alarm input. OFF: The device ignores the alarm signal when it detects an alarm input. REC RATE: This option is for the purpose of adjusting the number of pictures recorded every second into a storage disk when an alarm input is activated.
  • Page 36: Clock / Timer Setting

    GOTO CLOCK/ TIMER PAGE The DVR provides a weekly table consisting of two periods of time each day for scheduled recording. This option allows you to set the time each day when the DVR will start and stop recording. MAIN MENU RECORD...
  • Page 37: Daylight Saving

    ON: Enables the scheduled recording. OFF: Disables the scheduled recording. TIMER: This entry allows users to program the time each day when the DVR will start and stop recording. There are time periods each day available for scheduling. The time is displayed in a 24-hour clock format.
  • Page 38 This option enables or disables the Ethernet communication port. OFF: Disables it. ON: Enables it. NOTE: If provided with a DHCP server, the DVR can get an IP automatically by setting this option to ON. NET IP: This option is used to configure the Ethernet communication settings.
  • Page 39: Rec Mode

    This option allows you to clear out all the data in the hard-disk drive. You will be required to enter the pre-set password before proceeding with FTP ACCOUNT : 192.168.001.128 : [dvr : [00000000 : [/dvrvideo DISK SETTING : HD...
  • Page 40 Note: If you have not inserted the SD card during this function, a message reading 'SD CARD ERROR" will appear. Note: If there is no hard disk in your DVR recording during the "TEXT TO SD CARD" function, a message saying " NO BACKUP SOURCE"...
  • Page 41: Auto Erase

    AUTO ERASE: This item offers you two options. OFF: Choosing this alternative disables the "AUTO ERASE" function. SET: This choice enables the "AUTO ERASE" function. Select "SET" and press the ENTER button to enter the "AUTO ERASE SETTING" page, where you can enable the settings to save data for storage for any period of time from 1 to 365 days.
  • Page 42 SD SETUP: The DVR offers a quick setup method by using an SD card. If the user wants to set up a lot of the same devices with the same settings, he can save the whole settings to an SD card, then transfer them to another DVR.
  • Page 43: Network

    5. NETWORK 5.1 Network Configuration 5.1.1 Cable Connections Please follow the instructions below to connect your DVR to a computer or a network and to choose a proper RJ-45 cable configuration for connections. . Connect to a Use a crossover LAN cable to connect directly to a...
  • Page 44: Configure Your Dvr Network Settings

    NOTE: This function can only work if the LAN which the unit is connected to has a DHCP server. If the DHCP server is working, the DVR will obtain an IP address automatically from the DHCP server. In that case please skip section 5.1.2.3 (Set IP address) and follow...
  • Page 45 IPs. It’s not necessary to set MASK and GATEWAY; leave the settings as default. When a DVR is connected to a WAN, you must acquire a unique, permanent IP address and correctly configure the MASK and GATEWAY...
  • Page 46: Tcp/Ip Communication Setup

    5.1.3 TCP/IP Communication Setup Follow the instructions below to install the TCP/IP communication program into your computer. . Click the Start Menu from your computer, and point to the Control panel. Click the Network Connections icon twice to enter the Network setting windows. Point to the Local Area Connection and click the right bottom of the mouse.
  • Page 47 IP address and type in the IP address of your PC. This IP address must be different from the DVR IP but in the same class type. NOTE: The IP address of a DVR in a network...
  • Page 48: Testing Connection

    Command Programs Type in ping 192.168.1.1 then Enter. (See the sample screen below) ** This IP is the DVR IP address that is assigned for the connected DVR. If you receive a response as in the sample screen below, the connection hasn’t been successfully established.
  • Page 49: Triplex 1 Ch Dvr Viewer Software: Introduction

    Framework provides a very high performance environment to solve the network program. Therefore, please use our Viewer Software to connect the TRIPLEX 1CH DVR. It will satisfy our users as being safer, faster, and more stable and reliable than other software. See below for the chief features of this Viewer Software:...
  • Page 50: Short Introduction

    "Start Menu" in the computer and select "Programs" to open the "Program Selection" page. Then click the "AVE Viewer Software" tag to start the DVR Viewer Software Program. 5.2.2 Short introduction Now the "Login" page appears. Enter the default "User Name: admin" and the "Password: 9999"...
  • Page 51: Operation

    DVR (Enhanced) ” and then click the "Available Devices" button. The software will automatically search the whole local LAN 1-channel DVR device to see a list. NOTE: If you want to create a new DVR, please press the button to add it. ※...
  • Page 52 Click the Refresh " " submit the settings. The DVR will send the viewer software an alert when the exception has reached a particular count. The alert window will show in the lower right corner. The following is the alert window page.
  • Page 53 " " next to the "Review Text". " DVR keep up to 100 records of Alert log for viewing and playback. The records marked as means it can be click to start playback. "Pause": Click to freeze the image. "Stop": Click to stop playing back the recorded video.
  • Page 54 than the recorded speed. "FWD": Click to play a recorded video in the forward direction at speeds, which are faster than the recorded speed. 5.2.3.2.2 Change Pan/Tilt/Zoom Setting Click the button on the home page to open the Speed Dome Controller. 1.
  • Page 55 5.2.3.3 Backup and video edit Use the button to see the "Backup" window. 【Backup up to AVI】 : Backup Settings: ● File Path : To set the backup file path and the file name, click the "Browser" button on the right. ●...
  • Page 56 5.2.3.4 Web Page Viewer This section provides instructions for using the Viewer Software to view the Web Page. NOTE: This device also provides the IE Browser function. Open the browser and view the images directly via the browser. Please refer to section 5.3 for more details. 5.2.3.5 Viewer setting 1.
  • Page 57: Microsoft Internet Explorer

    Start up the Microsoft Internet Explorer, and then follow the steps given below to connect the DVR: 1. Type in the URL address of the DVR into the URL block and press the “Enter” button to enter the login page. The default User Name and password are admin and 9999 respectively.
  • Page 58: Change Record / Alarm Setting

    The Timer Record setting page allows users to program the time each day that the DVR will start and stop recording. The time is displayed in a 24-hour clock format. If there is a time overlap showing between two...
  • Page 59: Pan / Tilt / Zoom Setting

    5.3.4 Pan / Tilt / Zoom Setting Click the button on the main page to open the Speed Dome Controller page. Then select a proper Speed Dome model on the left hand side. The function varies for different Speed Dome models. Here is an example.
  • Page 60: Text Insertion Function

    6. TEXT INSERTION FUNCTION 1. Purpose The purpose of the Text Insertion function is to make the DVR accept the text information coming from external devices like ATM machines, cash registers, and access control systems. The DVR stores the text information in the hard disk, and shows the information on the screen during a video playback.
  • Page 61: Operation

    For every 10.24 Giga bytes of hard disk capacity, the DVR reserves space for 32768 text records. Each hard disk keeps its own data in itself. In a DVR with two hard disks, the user can remove any one of them, and the remaining one will keep working.
  • Page 62: Text Color

    3.1.2 RS232 Baud Rate. SETUP / COMMUNICATION / BAUD Set at the same speed as that in the Text Input device. 3.1.3 Firmware version and capacity usage. SETUP / SYSTEM / VERSION. MAC : 00:0C:0C:00:00:10 BIOS : 1.00 SW : 1.11GBT DATE: Feb 24 2006 TEXT# : 0/ 229376 PRESS ENTER TO RETURN...
  • Page 63 3.1.5 Text display setting. There are 2 options (BY CHANNEL, MIXED); If the TEXT INSERTION option has been set as VSI-ADD protocol, and incoming texts come from different channels, all the messages of the channels could be set in different channels. By channel: This mode shows a 4-channel screen where each channel displays information text against a background of images -- both the text and the images belong to that channel only.
  • Page 64 PHRASE 1 [ACCOUNT 2 [ALCOHOL 3 [ALE 4 [AMERICAN EXPRESS 5 [ATM 6 [AX 7 [BALANCE 8 [BASS 9 [BEER 10 [BOURBON While the users input string data in the setup menu or search menu, they can also press the SETUP button to quickly acquire the required or relevant phrases;...
  • Page 65: Factory Default

    In the right-hand side of the Exception Setting page is the exception count. If a number has been specified, the DVR will alert the remote Viewer Software when the number of the exceptions exceeds the number set here.
  • Page 66 3.1.8.4 FLG ( Flag ). If the FLG has been set as ON, the DVR will show a mark ( *) on the screen, and keep flashing for a duration depending on the setting in DWELL( 3.1.8.7 ).
  • Page 67 In the EXCEPTION setting page, the #26 is a special item for POS data loss exception. If no data enters the DVR over a specified time, the DVR will generate an alert to notify the remote viewer, start the FTP function, etc.
  • Page 68 3.2.3 Multiple Devices Connection. By using AVE REGCOM and HYDRA, a multiple cash register can be linked together through an RS-485, and can finally connect to the DVR through the RS-232. The following is an example of 4 cash registers connected to a DVR.
  • Page 69 No need Text insertion on the Video. RS-232 Cash Register RS-232 Cash Register RS-232 Cash Register RS-232 Cash Register Text insertion on the Video . RS-232 Cash VSI-PRO Register RS-232 Cash VSI-PRO Register RS-232 Cash VSI-PRO Register RS-232 Cash VSI-PRO Register RegCom RegCom...
  • Page 70 By using AVE VSI-PRO MAX RS-232 RS-485 Cash Register RS-232 RS-485 Cash Register RS-232 RS-485 Cash Register RS-232 RS-485 Cash Register ATM application TCP/IP Multiple ATM application RS-232 VSSI-PRO RS-232 VSSI-PRO RS-232 VSSI-PRO RS-232 VSSI-PRO VSI-PRO VSI-PRO RS-485 VSI-PRO VSI-PRO RS-232 RS-232 VSSI-PRO...
  • Page 71 TCPIP 3.2.4 LIVE DISPLAY. After the hardware has been connected, please power up the DVR. The DVR is by default in the LIVE mode. Press the DISPLAY button to switch to different display modes; under any one of the following modes, the contents of the received text data will be shown on the screen.
  • Page 72 When the text data continuously inputs from the Text device, press the REC button to activate recording; while the DVR is in the RECORD mode, there is a small red ball periodically flashing in the right-upper corner of the screen. Please press the DISPLAY button to switch to a desired mode to observe the incoming TEXT data.
  • Page 73 3.2.7 REVIEW TEXT. Press the SEARCH button and hold for more than 3 seconds. The REVIEW TEXT mode will then be activated, with 6 items for selection. REVIEW TEXT FULL LIST BY STRING BY DATE / TIME BY AMOUNT BY COMBINATION ALERT LOG 3.2.7.1 FULL LIST.
  • Page 74 Once a channel is selected and the ENTER button is pressed, all the Text Data of the particular channel will be listed. 781 01-02-06 11:34:12 CASH 782 01-02-06 11:34:12 CHANGE 783 01-02-06 11:34:12 ALEX 0005 784 01-02-06 11:34:13 PLUM RED 785 01-02-06 11:34:13 10-01-97 1 786 01-02-06 11:34:13 NECTARINES 787 01-02-06 11:34:13 10-01-97 1...
  • Page 75 To search for a two-word string, please enter the words with one space between the words, for example, “SANDY 0004” BY STRING CHANNEL TEXT [SANDY 0004 3.2.7.3 BY DATE/ TIME. This function offers an interface to list the data within a specific time period. If the TEXT INSERTION is set as GENERIC, the "BY DATE/ TIME"...
  • Page 76 The selectable operations are ">=", “>”, "=", “<” and "<=". If the TEXT INSERTION is set as VSI-ADD, there is a channel item which will show on the screen, too. BY AMOUNT CHANNEL OPERATION AMOUNT >= 0000.00 0000.00 01-02-2006 19:31:33 The following are some examples for your operations.
  • Page 77 3.2.7.5 BY COMBINATION BY COMBINATION CHANNEL STRING BEER DATE/ TIME 00/00/0000 00:00:00 - 00/00/0000 23:59:00 AMOUNT >= 0010.00 ◄► MOVE ▲▼CHANGE BY COMBINATION is the combination of the above search interfaces. The user can give the different conditions on the same page.
  • Page 78: Alert Log

    The Alert Log keep the latest 100 alerts for check and playback, the records marked as “>” are playable. Some alert could not be playbacked since it occurred when DVR was not in the RECORD mode. Please press ENTER button on the playable item to start the playabck.
  • Page 79 The AVI file playbacked in Microsoft Media Player 3.2.11 POS data backup The DVR will extract the POS data from the video data and save it to an SD card as a text-only file. Enter the Setup menu/ DISK / HD BACKUP/ TXT TO SD CARD...
  • Page 80 The exported pure text file. 3.2.12 Syncronize to VSI Connect the DVR with Hydra through RS232 ( or RS485 ). Enter the Setup menu/ TIMER/SEQ/TITLE / CLOCK page, move the highlight to SYNC TO VSI - START, press the ENTER button, and a new date/time will replace the old one.
  • Page 81 3.2.13 VSI-Pro Programming via DVR RS-232 RS-485 Cash VSI-PRO Register RS-232 RS-485 Cash VSI-PRO Register RS-232 RS-485 Cash VSI-PRO Register RS-232 RS-485 Cash VSI-PRO Register VSI-Pro MAX Programming via DVR RS-232 RS-485 VSI-PRO Cash Register RS-232 RS-485 Cash VSI-PRO Register...
  • Page 82 VSI-ADD to test the multiple-channel text input. 2. Set BAUD at 9600 in the SETUP Menu/ Communication page. 3. Connect at least one video source to the DVR for the recording. 4.2 Connect PC and DVR.
  • Page 83 PC. 4.3.1 Baud Rate setting Please set the BAUD Rate at 9600, the same as the setting in the DVR. 4.3.2 Protocol setting. There are two protocols for selection. Here we suggest you set your software to VSI-ADD for multi-channel testing.
  • Page 84 4.3.4 Speed Adjustment. Please adjust the transmission with the SPEED Slide Bar. 4.4 Test Procedure The Simulation software “RegOnPC” acts as the “Hydra”, 4 “RegCom”, and 4 cash registers. Please follow the steps below to test the DVR. Monitor RS-232 RegOnPC...
  • Page 85 Step 1. Please make sure that the DVR is in the LIVE mode. Press the DISPLAY button and switch the DVR display to the Full Text Display Mode. Now the continuously scrolled text will show on the screen. Step 2. Press the REC button to start recording for about 30 seconds or more.
  • Page 86: Miscellaneous

    Use a Null Modem cable (the standard RS-232 9 Pin Cable with Pin 2 and Pin 3 exchanged, see pin configuration chart below for details) to connect the COM 1 on the rear panel of the DVR to a PC. Set the RS-232 option to ON in the COMMUNICATION page of the setup menu.
  • Page 87 MISCELLANEOUS 7.1.2.1 Keys and signals ( Main Category = 0x01 ) PC message: <0x41>, <0x01>, <0x20>, <0x01>, <Key Value>, <0x4f> < The value of a specific front panel key > DEC HEX KEY_PLAY KEY_STOP KEY_PAUSE KEY_REC KEY_SETUP KEY_ENTER KEY_SEARCH KEY_DISPLAY KEY_UP KEY_DOWN KEY_LEFT...
  • Page 88 DVR Response: <0x41>, <0x20>, <0x01>, <0x02>, <0x08>, <0x00>, <0x4f> B. Request Time (Second Category=0x02) PC Request: <0x41>, <0x01>, <0x20>, <0x02>, <0x02>, <0x00>, <0x4f> DVR Response: <0x41>, <0x20>, <0x01>, <0x02>, <0x02>, <0x07>, <7 Time Value >, <0x4f> The following case is an illustration of < 7 Time Value>...
  • Page 89 <0x0>, <4 Bytes REC Position>, <2 Bytes Image NO.>, <0x4f> Get HDD#, REC Position and Image NO. used in Playback Immediately command Non REC Mode DVR Response ERROR: <0x41>, <0x20>, <0x01>, <0x02>, <0x11>, <0x01>, <0x45>, <0x4f> H. Playback Immediately (Second Category=0x12) PC message: <0x41>, <0x01>, <0x20>, <0x02>, <0x12>, <0x0a>,<HDD#>, <0x0>,...
  • Page 90: Hard Disk Installation

    7.2 Hard Disk Installation Usually the unit comes with one hard-disk drive installed in compartment HD 1, which is default-configured as a master. Serial ATA (SATA) interface disk drives are designed for easy installation. It is not necessary to set any jumpers, terminators, or other settings on this drive for proper operation.
  • Page 91: Mobile Rack (For Removable Hdd Model)

    7.2.2 Mobile Rack (FOR REMOVABLE HDD MODEL) Make sure that the key Pull the active handle is unlocked. outward to detach the carrier body from the mobile rack. Slide cover Place the hard disk in backward and remove. the rack. Place the HDD inside Place the top cover the mobile rack.
  • Page 92: System Default

    7.3 System Default REC SETTING AUTO START REC :OFF REC RATE :30 F/S REC QUALITY :BEST DISK FULL :REWRITE AUDIO :OFF MULTIPLEXER TEXT INSERTION MAIN PAGE ALARM/ MOTION ALM OPERATION : OFF REC RATE : 30 F/S : BEST REC QUALITY AUDIO : OFF ALM TYPE...
  • Page 93: Message

    7.4 O.S.D Message No. O.S.D Message NO DISK BATTERY LOW LOADING VIDEO LOSS VIDEO IN KEY LOCKED KEY UNLOCKED n1 OF n2 ITEMS PROGRESS n3 % BACKUP COMPLETE HD2 SPACE NOT ENOUGH NO ENTRY FOR BACKUP BACKUP INCOMPLETE NOT FOUND DISK FULL EMPTY SET TO NTSC, PLS RESTART...
  • Page 94: Time Index Table

    In the rewrite recording mode, when the archived hard disk drive is full, the DVR will start overwriting the oldest data recorded. As the previous recorded data is being overwritten...
  • Page 95: Specifications

    7.6 Specifications Model Number Model REMOVABLE HDD MODEL Image System Resolution Video In Video Out Audio In/Out Storage Media Compression Memory Card Hot Swappable Removable HD / Archive Watermark Recording Rate Image Size Recording Mode Alarm Recording Pre-Alarm Recording Playback Speeds Record Search Filter(thumbnail) / SD card OSD Language...
  • Page 96: Compatible Multiplexer Devices

    NTSC 16Ch Color Color, B/W Color, B/W 16Ch Color, B/W NTSC / PAL Color NTSC / PAL Color NTSC / PAL 16Ch COLOR Work with DVR ˇ ˇ ˇ ˇ ˇ ˇ ˇ ˇ ˇ ˇ ˇ ˇ ˇ ˇ...
  • Page 97: Scanip

    LAN. The Device List will display the connection of the all-type device. 2. Select the desired device of the DVR from the Device List. 3. Click the desired device to show the window while the DVR information acts to display the desired changes instantly.
  • Page 98 6. Auto search “Free IP Address”. If you clicked “Yes” the “Free IP Address” box will appear on the right. 1. Select and double click any of the addresses in the “Free IP Address” box on the right to enter it into an IP Address on the left. 2.
  • Page 99: Appendix 1. - Using Cd Discs (For Cd-Rw Model Only)

    APPENDIX 1. – Using CD Discs (FOR CD-RW MODEL ONLY) Please note that when using CD-ROM, CD-R and CD-RW discs, do not write or stick anything on the surface as this could cause an error in recording or the data on the disc may be damaged.
  • Page 100 3. Press the front of the tray or lightly and gently pull the tray out with two fingers. Caution When you use either a CD-RW or a CD-ROM, please pay heed to the following. 1. At the time of installation: As suggested in your specifications, please do not install in an unstable position or in one that causes vibrations.
  • Page 101: Appendix 2. -Default Text Insertion List

    APPENDIX 2. –Default Text Insertion List The following is a list of default phrases and exceptions. You can refer here to click and enter any item you need to check. Default phrases. ACCOUNT ALCOHOL AMERICAN EXPRESS BALANCE BASS BOURBON BREAKFAST BUDWEISER BUD LITE CASH...
