Page 1: Operation Manual
INSTALLATION & OPERATION MANUAL Digital Video Recorder MPEG4 Model: Removable HDD / CD-RW Before trying to connect or operate this product, please read this manual completely... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS All the following safety and operated instructions which will prevent harm or damage to the operator and other persons should be read before the unit is operated. INFORMATION This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: Table Of Contents
CONTENTS 1. INTRODUCTION ......... 3 3.5.3 SD Card Backup Operations for Removable HDD Model ......26 1.1 Product Introduction........3 3.5.4 Backup the System setting info 1.2 Product Features ........3 into an SD card........28 3.5.5 Updating System Software ... 28 1.3. -
Page 5: Introduction
1. INTRODUCTION 1. INTRODUCTION 1.1 Product Introduction ‧Audio function included (16 bits, 8 kHz, The four channel Digital Video Recorder μ-law). ‧Built-in SD memory card slot to save (DVR) of MPEG4 format provides high quality storage of up to four video sources. The JPEG/AVI image(s) to an SD memory card. -
Page 6: Front / Rear View
INTRODUCTION ( continued ) 1.3. FRONT / REAR VIEW 1.3.1 Front View FOR CD-ROM MODEL FOR REMOVABLE HDD MODEL DISK A-rec T-rec Power Display Search Setup Seq./Save Enter Play Pause Stop ZOOM CD-RW device compartment: Hard-disk drive compartment: The compartment allows you to burn the data The compartment allows you to install a mostly for backup purposes. - Page 7 PAUSE button: In a playback display, press this to freeze the display. During the freeze, press it to display one frame/field of a picture at a time in the forward direction. (Illuminate green in PAUSE mode.) PLAY button: Press to play back a recorded video from the hard disk. (Illuminate green in PLAY mode.) STOP button: Press to stop playing back a recorded video.
- Page 8 the hard-disk drive is storing or retrieving data. The red light signals the hard-disk drive is filling up. The orange light indicates the hard-disk is retrieving at disk-full status. Shuttle Ring: The shuttle can be moved forward and backward for playback in either direction. Turn this left to play a recorded video in the reverse direction at faster or slower speeds than the recorded speed.
-
Page 9: Rear View
1.3.2 Rear View hi-z SD Card RS-485 RS-232 ETHERNET MONITOR AUDIO ALARM DC12V 29 30 35 36 37 31 32 VIDEO Connector: These connector including SWITCH OUT, GROUND, connectors are used to connect the video ALARM OUT, DISK FULL, RECORD IN, output from a camera ALARM RESET,... -
Page 10: Alarm In / Out
1.4 ALARM In / Out DISK FULL ALARM RESET ALARM OUT RECORD IN GROUND ALARM1 IN ALARM4 IN ALARM2 IN ALARM3 IN The above figure is the rear view. - Page 11 GND: Ground Contact. ALARM OUT (OUTPUT): This is an alarm output trigger. Connect this to external devices such as buzzers or lights. 0V(Active) 3. DISK FULL (OUTPUT): This is a disk full output trigger. Connect this to external devices such as buzzers or lights.
-
Page 12: Installation
2. INSTALLATION 2. INSTALLATION Please follow the instruction and the diagram below to set up the system. 2.1 Basic Connection . ATTACHING AN EXTERNAL DEVICE TO DVR Connect an alarm out, alarm input, and a . CONNECTING WITH 1 to 4 CAMERAS peripheral device as shown in the diagram Camera Camera... - Page 13 Table 2.2 Compatible SATA hard-disk drives Manufacturer Model Capacity Rotation Cache ST340215AS 7200 RPM Seagate ST340815AS 7200 RPM ST380215AS 7200 RPM ST380815AS 7200 RPM ST3120215AS 120G 7200 RPM ST3120815AS 120G 7200 RPM ST3160215AS 160G 7200 RPM ST3160815AS 160G 7200 RPM ST3200820AS 200G 7200 RPM...
-
Page 14: System Information And
2.3 System Information and Channel Selection FIGURE 3.3 A 2.3.1 System information 12.4 HR 1+2 :59G You can display system settings information as QUALITY : BEST NTSC shown in FIGURE 3.3 A below at any time by RATE : 6HR 30 F/S 200 K pressing the Display button... -
Page 15: Updating System Software
Restart the unit when the device sounds a tone twice displays message “PLEASE Mode Result Display RESTART”. The process is complete. Live / Quad (If you have already followed the procedures 1~5, Record and the unit is still unable to switch on, please first CH1/ ( Single channel ) check if the SD card you are using is functioning... -
Page 16: Operations
3. OPERATIONS 3. OPERATIONS quality at a 30 Frame/Sec record rate, normally a This section shows you how to operate and 80GB hard-disk drive will be filled in 38.7 hours manage the DVR when it gets in the way. (see the gray area in the table). If the total capacity of 240GB hard-disk drives is in use 3.1 Configuring Recording under the same refresh rate and picture quality, it... -
Page 17: Recording Operations
3.2 Recording Operations (2) Select the CLOCK / TIMER and press the This section details the way to record video Enter button to enter the CLOCK / into hard-disk drives. Before commencing with TIMER page. (3) Select the TIMER－SET. the recording function, please configure the recording setting properly according to your (4) Press the Enter button to enter the REC... -
Page 18: Alarm / Motion Recording
(8) Press the REC button for 3 seconds during the scheduled recording to stop it any MAIN MENU RECORD time. If you wish to continue the scheduled ALARM / MOTION TIMER/ SEQ/ TITLE recording, press the REC button COMMUNICATION DISK proceed. -
Page 19: Externally Triggered Recording
3.2.4 Externally Triggered Recording By connecting the RECORD IN of ALARM I/O on the rear panel of the DVR, you can activate/deactivate the recording function of a DVR. The file will be kept with a prefixed “R”. NOTE: The status of recording operations when an alarm takes place is shown in the diagrams below. -
Page 20: Playback Operations
3.3 Playback Operations This section shows you how to operate the fast, message ( use SEARCH functions or rewind to slow, and single-picture playback functions, replay the file if required ) and details how the unit is to playback a file in 3.3.2 Fast Forward/Backward a different operation status. -
Page 21: Play Back Picture-By-Picture
3.3.5 Playback Recorded Video from forward direction at a speed slower than an HDD of the mobile rack (for the recorded speed. Each subsequent turn removable HDD model only) of the shuttle to the right increases the forward rate, as 1/2, 1/4, 1/8, and 1/16. To play back a recorded video from an HD2, (3) Normal: Release the Shuttle dial... -
Page 22: Search Operations
3.4 Search Operations 3.4.2 ALARM LIST Search This section shows you how to access Take the following steps to proceed with the recorded video. alarm-list search function. (1) Press the Search button to enter the 3.4.1 FULL LIST Search search mode. (2) Select the ALARM LIST and press the Take the following steps to proceed with the Enter button... -
Page 23: Thumbnail Search
(3) Set the time period you wish to search for ● You can also set up by using the Shuttle the recorded video. Ring and the Jog Dial to move eye focus. (4) Press the Enter button to start searching is the equal of the “<”... -
Page 24: Sd Card Search
requirement press Enter LEVEL : Interval = 1 Min button to display the image. (5) If you need another, please return to the 15:30:00 15:31:00 15:32:00 15:33:00 SD card JPG file list page and repeat steps 3 and 4 again for another search. 15:34:00 15:35:00 15:36:00... - Page 25 requirement and press the Enter button to display the image. (5) If you need another, please press the Enter button to return to the CD MENU page and repeat step (4) again for another search. SEARCH FULL LIST ALARM LIST TIME SEARCH THUMBNAIL SD CARD...
-
Page 26: Backup Operations
3.5 Backup Operations iii ) Press the Seq./Save button 3.5.1 CD Rewritable unit Backup select # 3 ( "CD JPEG" ) and enter. Operations (FOR CD-ROM MODEL iv ) You've entered the CD JPEG menu. ONLY) Select item 1( “ADD” ) to add your image into the buffer. -
Page 27: Mobile Rack Hd Backup Operations (For Removable Hdd Model Only)
Hear that beeping signal to confirm your disc is ready. MAIN MENU RECORD ii ) Play the video back to find your desired ALARM / MOTION CLOCK/ TIMER item. Press PAUSE when you want to COMMUNICATION DISK SYSTEM start. iii ) Press the Seq./Save button GOTO DISK PAGE select # 4 ( "CD AVI"... -
Page 28: Sd Card Backup Operations For Removable Hdd Model
recorded video from HD 1 to HD2. Stay on the DISK SETTING page. DISK SETTING Use the “ ” and “v” buttons and HD REFORMAT button to highlight BACKUP; select HD2 USAGE ALARM, then press the Enter button HD BACKUP FULL HD FAT32... - Page 29 (1) Press the Setup button to enter the (1) Press the Setup button to enter the setup mode and select the DISK. setup mode and select the DISK. (2) Highlight DISK and press the Enter (2) Highlight DISK and press the Enter button to enter the DISK SETTING button...
-
Page 30: Backup The System Setting Info Into An Sd Card
3.5.4 Backup the System setting info into 3.5.5 Updating System Software an SD card. Please refer to section 2.4 for more details. The DVR offers a quick setup method by 3.6 Key Lock Operation using the SD card. If a user wants to set many DVR devices with the same settings, The Key Lock operation protects the unit the DVR could save the whole setting in the... -
Page 31: Menu Setup
4. MENU SETUP 4. MENU SETUP 4.1 REC Setting MAIN MENU There are categories for operation setting in the RECORD menu setup system as shown below. The following ALARM/ MOTION TIMER/ SEQ/ TITLE sections will instruct you step by step how to COMMUNICATION configure the operation setting and state each DISK... -
Page 32: Alarm / Motion Setting
REC QUALITY: configuration of alarm recording only when an This option determines the image quality to alarm input is activated. The device will be recorded. The DVR stores images in the record as long as the alarm input is activated. compressed format and allows the image MAIN MENU quality to be altered by the image size. - Page 33 D uration Set ting Alar m r ecor ding REC QUALITY: D uration This option determines the image quality to Alar m Alar m be recorded when an alarm input occurs. activated deactivated There are 4 levels of image quality to choose N on-Stop Alar m r ecor ding from: BEST, HIGH, STANDARD, and BASIC.
-
Page 34: Timer / Seq / Title Setting
CH1/ CH2/ CH3/ CH4 : CLOCK: These options enable/disable the motion This entry allows users to set the system detection. time. ON: Enables the motion detection. OFF: Disables the motion detection. NOTE: Clock data is retained for about 3 months after the 15-hour power supply is used up (the SENSITIVITY(1 ~ 5): Operate On mode). -
Page 35: Communication Setting
4.4 COMMUNICATION Setting REC SCHEDULE MAIN MENU START END START END RECORD 00:00- 00:00 00:00- 00:00 ALARM / MOTION 00:00- 00:00 00:00- 00:00 CLOCK/ TIMER 00:00- 00:00 00:00- 00:00 COMMUNICATION 00:00- 00:00 00:00- 00:00 DISK 00:00- 00:00 00:00- 00:00 SYSTEM 00:00- 00:00 00:00- 00:00 00:00- 00:00... -
Page 36: Disk Setting
OFF: Disables the RS-232 communication entering the user name and password. The user who accesses with the admin name and port. password has the full power to even change the settings of the DVR. However, a user who RS-485: accesses with just the viewer name and The RS-485 communication port can be password has only the limited power to view. -
Page 37: System Setting
HD2 USAGE: CD-ROM or SD Card, please refer to This option determines the way to utilize the section 3.5 for more details. hard-disk drive in the mobile compartment. Used regular recording SD REFORMAT: hard-disk drives. This option allows you to clear out all the data BACKUP: Used for data backup only, which in the SD card. - Page 38 Situation OPERATION LOG Alarm occurs Video loss occurs Disk is full Load factory default 05/15/04 18:19:30 Buzzer set to ON 05/15/04 18:19:36 Enable/disable key lock function 05/15/04 18:23:10 Power on /off mobile rack HDD 05/15/04 18:23:50 05/15/04 18:25:05 STOP Backup operation complete 05/15/04 18:27:12 V-LOSS Timer activate/deactivate...
- Page 39 VERSION: This item is in the setup menu-revealing the network MAC, the BIOS version, the software version, and the last updated date. MAC : 00 : 0C : 0C : 00 : E1 : A0 BIOS : 1.00 : 1.00 DATE : Sep 10 2004...
-
Page 40: Network
5. NETWORK 5. NETWORK 5.1 Network Configuration Physical Spec. of RJ-45 Cable for Ethernet Wire Type Cat. 5 Connector Type RJ-45 5.1.1 Cable Connections Max. Cable Length 100 m Please follow the instructions below to Hub Wiring Configuration Straight Through connect your DVR to a computer or a network Cross Over PC Wiring Configuration... -
Page 41: Configure Your Dvr Network Settings
NETWORK ( continued ) 5.1.2.2 Enable DHCP Function PIN NO. PIN Assignment MAIN MENU TX + RJ-45 socket RECORD TX - ALARM / MOTION CLOCK/ TIMER RX + COMMUNICATION DISK 1 2 3 4 5 6 7 8 Not Connected SYSTEM Not Connected GOTO COMM PAGE... - Page 42 You don’t need to set a NET IP for the unit if the LAN, which the unit is connected to, DHCP server. has a Otherwise, please follow the instructions given below: Enter the NET IP page and set the IP, MASK and GATEWAY.
-
Page 43: Tcp/Ip Communication Setup
5.1.3 TCP/IP Communication Setup Point to the Local Area Connection and click Follow the instructions below to install the the right bottom of the mouse. Click the TCP/IP communication program into your Properties enter Local Area computer. Connection. . Click the Start Menu from your computer, and point to the Control panel. - Page 44 If you are using a DHCP server, please select Obtain an IP address automatically. Any assigned IP address for the connected TCP/IP Configuration setting Click Start Control Panel DVRs must be in the same class type as Network.Connections Local the server.
-
Page 45: Connection Testing
5.1.4 Connection Testing With the previous settings, follow the instructions below to ensure whether you have established connection successfully. . Click Start Command Programs If you receive a response as in the sample screen below, have successfully made the connection. . -
Page 46: Triplex 4 Ch Dvr Viewer Software: Introduction
5.2 TRIPLEX 4 CH DVR VIEWER SOFTWARE: The programs can be operated by a selected Introduction PC equipped with the following requirements： Intel Pentium 4 2.4MHz (at least). This version of the TRIPLEX 4 CH DVR 512 MB RAM Viewer Software uses the Microsoft .Net Windows 2000, XP or above. -
Page 47: Short Introduction
Note: Please choose the "Next" button to Step 6 : After completing installation, you can ※ continue. double - click the file shown below. Or click the "Start Menu" in the computer and select Step 4: The installation screen will show the "Programs"... -
Page 48: Operation
search the whole local LAN 5.2.2.1 Program introduction 4 - channel DVR device to see a list. NOTE: If you want to create a new DVR connection via the Internet, please press the button. Enter the DVR’s Host name or IP address and its port, then press “OK”... - Page 49 3. Full Screen: Click this button to show the full screen for surveillance. All the "Print": Click the "Print Preview" button and setting buttons will be hidden in this go to the "Preview" option to adjust the mode. If you want to return to the image size.
- Page 50 5.2.3.2.1 Remote play stopping, in one of the four designated This device has the full triplex so you can use directions. The fifth button, in the center, will the Viewer Software in the remote without stop the camera at any point you prefer. affecting the performance of the 4 - channel DVR.
- Page 51 The ‘AutoPan’ section has three buttons. The ‘Start’ and ‘End’ buttons fix the two points of any panning movement you select. The third bottom button sets chosen movement in the play mode. 【Edit AVI】 ： ● File Path: To set the backup file and the file name, check the "Browser"...
- Page 52 ● Mark Day and Time : Sets the date and 5.2.3.4 Web Page Viewer time stamp. Play Options： This device also provides the IE Browser ● Time to play: To search the date and function. Open the browser and view the images time you want.
-
Page 53: Microsoft Internet Explorer
5.2.3.5 Viewer setting 2. "Playback Record Time". Click the "Display Mode" to select from a drop - down list of two choices, "Hide" and "Show". Your choice will decide whether the images will display their date and time or not. 3. -
Page 54: Change Record / Alarm Setting
Browsing images from the DVR Recorded video list box. This box allows you to access all recorded The images from the DVR will be displayed on video which are stored in the HDD of the home page while going online with the DVR. the connected devices. -
Page 55: Change Timer Record Setting
3. Set the TIMER RECORD to ON to enable the 3. Click the button to submit the new Record / Alarm setting. TIMER RECORD function. 4. There time-periods available 4. Click the button to return to the home page while the new image setting acts on the scheduling each day. -
Page 56: Miscellaneous
6. MISCELLANEOUS 6. MISCELLANEOUS 6.1 RS-232 & RS-485 Setup & Protocol 6.1.1 RS232 & RS485 Setup Use a Null Modem cable (the standard RS-232 9 Pin Cable with Pin 2 and Pin 3 exchanged, see pin configuration chart below for details) to connect the COM 1 on the rear panel of the DVR to a PC. - Page 57 MISCELLANEOUS ( continued ) 6.1.2.1 Keys and signals ( Main Category = 0x01 ) PC Send: <0x41>, <0x01>, <0x20>, <0x01>, <Key Value>, <0x4f> < The value of a specific front panel key > KEY_PLAY 0x01 KEY_STOP 0x 03 KEY_PAUSE 0x 04 KEY_REC 0x 06 KEY_SETUP...
- Page 58 2004/06/20 17:05:00 = <0xD4>, <0x07>, <0x06>, <0x14>, <0x11>, <0x05>, <0x00> DVR Act: Changing the time and date. D. Request State (Second Category=0x06) PC Request: <0x41>, <0x01>, <0x20>, <0x02>, <0x06>, <0x00>, <0x4f> DVR Response: <0x41>, <0x20>, <0x01>, <0x02>, <0x06>, <0x01>, <System State = 0..>, <0x4f>...
-
Page 59: Hard Disk Installation
6.2 Hard Disk Installation Usually the unit comes with one hard-disk drive installed in compartment HD 1, which is default-configured as a master. Serial ATA (SATA) interface disk drives are designed for Secure the driver in the rack using 4 mounting screws in the side-mounting holes. -
Page 60: Mobile Rack (For Removable Hdd Model)
6.2.2 Mobile Rack (FOR REMOVABLE HDD MODEL) Make sure that the key Pull the active handle Push the carrier body Slide the carrier body is unlocked. outward to detach the further into the mobile back in the mobile rack. carrier body from the rack until fully inserted. -
Page 61: Message
6.3 O.S.D Message No. O.S.D Message Meanings NO DISK No hard-disk detected after power activated Suggest change the battery and reset the system BATTERY LOW time LOADING System Boot up VIDEO LOSS Video loss VIDEO IN Video input source KEY LOCKED Key lock function is on KEY UNLOCKED Key lock function is off... -
Page 62: Time Index Table
6.4 Time Index Table 12-02-03 12:20:55 12-02-03 12:20:55 12-02-03 13:30:33 01-30-04 16:00:34 01-30-04 16:00:34 3000 3000 Indexes Indexes 2999 02-03-04 16:00:56 3000 02-03-04 16:00:56 3000 02-08-04 17:30:58 Previously recorded data overwritten The point stops recording Previously recorded data remaining Time Index Table data. -
Page 63: Specifications
6.5 Specifications Model Number FOR REMOVABLE HDD MODEL FOR CD-ROM MODEL Image System NTSC/PAL Resolution NTSC: 720 x 480 pixels / PAL: 720 x 576 pixels Triplex(Recording、Playing and Viewing) Operation Video In Composite Video In (BNC) x 4 Video Out Composite Video Out (BNC) x 4, Monitor Out (BNC) x 1 Audio In/Out Line in / out (RCAx2), 8kHz... -
Page 64: Scanip
6.6 ScanIP Follow the instructions below to use the ScanIP software to search the DVR devices in a local network. 1. Click the button to discover the connection of the all-type device in the LAN. The Device List will display the connection of the all-type device. - Page 65 2. To change any IP address, type in the new address in the “Free IP Address” box on the right as well as the device “Login Name” and “Password” in their respective blanks at bottom left, then click “UPDATE”, and the new address will automatically be sent to the device.
-
Page 66: Appendix 1. - Using Cd Discs (For Cd-Rw Model Only)
3. Please do not touch the surface of the disc APPENDIX 1. – Using CD Discs where it has been recorded. (FOR CD-RW MODEL ONLY) 4. To insert the caddy please press the insert / eject button and hold the caddy lightly at the Please note that when using CD-ROM, CD-R or middle of its front and push gently to insert. - Page 67 3. Press the front of the tray or lightly and gently pull the tray out with two fingers. Caution When you use either a CD-RW or a CD-ROM, please pay heed to the following. 1. At the time of installation: As suggested in your specifications, please do not install in an unstable position or in one that causes vibrations.
