INSTALLATION &

OPERATING MANUAL

Digital Video Recorder

MV-DR4000
AVE
Before trying to connect or operate this product, please read this manual completely

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MV DR4000 and is the answer not in the manual?

Questions and answers

Related Manuals for AVE MV DR4000

Summary of Contents for AVE MV DR4000

  • Page 1: Digital Video Recorder

    INSTALLATION & OPERATING MANUAL Digital Video Recorder MV-DR4000 Before trying to connect or operate this product, please read this manual completely...

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS All the following safety and operated instructions which will prevent harm or damage to the operator and other persons should be read before the unit is operated. WARNING To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Do not block ventilation openings.

  • Page 4: Table Of Contents

    1. PRODUCT FEATURES ...4 1.1 Product Introduction ...4 1.2 Product Features...4 2. DESCRIPTION OF THE FRONT/REAR VIEW...5 2.1 Front View ...5 2.2 Rear View ...8 2.3 ALARM In/Out ...9 3. INSTALLATION ...10 3.1 Basic Connection ...10 3.2 Hard-Disk Drive Installation ... 11 3.3 System Information and channel selection...12 3.4 Updating System Software ...14 4.
  • Page 5 10.1 The Network Viewer ...56 10.2 The Image Viewer...64 11. INDEX TABLE ...65 12. NETWORK CONFIGURATION ...66 12.1 Cable Connections ...66 12.2 Configure Your DVR Network Settings ...67 12.3 TCP/IP Communication Software...70 12.4 TCP/IP installation ...71 12.5 TCP/IP Configuration setting ...72 12.6 Connection Testing...73 13.

  • Page 6: Product Features

    1. PRODUCT FEATURES 1.1 Product Introduction The MV-DR4000 four channel Digital Video Recorder (DVR) provides high quality storage of up to four video sources. Equipped with a range of comprehensive features, such as video motion detection, pre-alarm recording, thumbnail search, jog/shuttle function, hard drive expansion, and TCP/IP connectivity, this DVR will make your applications far more flexible and effective than ever before.

  • Page 7: Description Of The Front/Rear View

    2. DESCRIPTION OF THE FRONT/REAR VIEW 2.1 Front View Power Display Search Setup Hard-disk drive compartment. This compartment houses the removable (hot-swappable) hard disk drive. NOTE: The compartment must be locked before the hard drive can be used. Hard disk compartment lock: The key lock secures a hard disk in place.
  • Page 8 POWER button: Press and hold POWER button for 3 seconds to turn on the unit, press (and hold again) to turn the unit off. DISPLAY button: Press to show the system operation status on the screen. (See Section 3.3 for Display indications) Setup button: Press this to enter the setup menu.
  • Page 9 Jog Dial: The Jog Dial can be used to step frame by frame in the forward or reverse direction. SD CARD Slot: This is used for system software updating and archiving/accessing critical images. Mobile Rack Power LED: Indicates the power status of the Mobile Rack. The green light indicates the Mobile Rack is activate.

  • Page 10: Rear View

    AUDIO OUT: This connector is used to connect the device’s audio input. AUDIO IN Connector: This connector is used to connect the audio output from a camera or other devices to the DVR. ETHERNET 10/100 Connector: This is one standard RJ-45 connector for 10/100 Mbps Ethernet networks.

  • Page 11: Alarm In/Out

    2.3 ALARM In/Out ALARM RESET RECORD IN ALARM1 IN ALARM2 IN THIS FIGURE IS LOOKED FROM THE REAR VIEW GND: Ground Contact. ALARM OUT (OUTPUT): This is a common alarm output trigger. Connect this to external devices such as buzzers or lights. Switches Low (GND) ( DISK FULL (OUTPUT): This is a disk full output trigger.

  • Page 12: Installation

    CONNECTING WITH 1 to 4 CAMERAS Camera MONITOR ATTACHING AN EXTERNAL DEVICE TO DVR Connect an alarm out, alarm input, and a peripheral device as shown in the diagram below. Alarm In -> Alarm1 In, Alarm2 In, Alarm3 In, Alarm4 In...

  • Page 13: Hard-Disk Drive Installation

    3.2 Hard-Disk Drive Installation The MV-DR4000 is capable of supporting two hard drives - One internal drive (from factory) and one hot swappable mobile drive (factory option). The internal HDD (compartment HD1), is default-configured as a master. If adding an additional HDD to the Mobile Rack (compartment HD2), please set to Master and follow the install instructions in section.

  • Page 14: System Information And Channel Selection

    Press the Display button display. Press the Display button button one more time to back to the default display. once; the DVR will display the following sample message plus the default again; the unit will not display any OSD message. Press the...
  • Page 15 Figure 3.3 A. 1+ 2: 59G 12.4 HR QUALITY: BEST NTSC RATE: 6 HR 10 F/S HD P SIZE 20 G 39.5% P 39 G 0.0% R IP : 192 . 168 . 1 . 90 3.3.2 Channel Selection The CH1, CH2, CH3, CH4, Quad ( channels and zoom in factor.

  • Page 16: Updating System Software

    3. Hold down the Up and 4. Keep holding down the buttons until the 4CH DVR sounds a tone and display the message “ XXXXXX BYTES READ” Now the 4CH DVR is updating the system software, which will take approximately 90 seconds to process.

  • Page 17: Basic Operations

    Recording time will vary depending on the image size, recording rate, and the capacity of the hard-disk drives. Generally, the DVR comes with a built-in hard-disk drive for continuous recording from one to four weeks under most recording conditions. The table below shows the possible recording times based on a 80GB hard-disk drive at certain refresh rates and the corresponding image quality.

  • Page 18: Image Quality

    NOTE 1: Recording times on the tables above are estimated. For actual available recording time of a recording configuration, please refer to the system information of the DVR. (Please refer to section 3.3 system information for more details.) 2: No audio function at the refresh rate in NTSC: 30 frame/sec ~ 15 frame/sec, 1/8 frame/sec ~ 1/16 frame/sec.

  • Page 19: Recording Operations

    (3) To access just recorded video, please refer to section 4.4 for more details. 4.2.2 Timer Recording Timer recording provides two periods of time each day in a weekly table which programs the DVR Start and Stop recording at specified times. Please take the following steps to program the scheduled recording.
  • Page 20 NOTE: If a programmed schedule falls within the current set time of the DVR, recording will begin upon exiting programming. NOTE: If you activate the recording function before the scheduled recording, the unit will operate recording as shown in the diagram below and keep those Images in different files.
  • Page 21 MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM GOTO TIMER/SEQ/TITLE PAGE TIMER/ SEQ/ TITLE CLOCK : SET REC ENABLE : OFF TIMER : SET SEQUENCER : SET TITLE : SET MAIN PAGE SET REC SCHEDULE REC SCHEDULE START END START END S : 00:00-00:00...
  • Page 22 4.2.3 Alarm / Motion Recording Take the following steps to activate the programmed alarm recording. For ALM OPERATION , REC RATE , REC QUALITY , AUDIO , ALM TYPE , ALM DURATION , and PRE-ALARM settings, please refer to section 5.2 for more details. (1) Press the Setup button (2) Select ALARM/ MOTION and press the Enter button SETTING .

  • Page 23: Externally Triggered Recording

    4.2.4 Externally triggered Recording By connecting the RECORD IN of ALARM I/O on the rear panel of the DVR, you can activate/deactivate the recording function of a DVR. The file will be kept with a prefixed “R” . Please refer to section 2.3 for more details.

  • Page 24: Playback Operations

    This section outlines the controls and options available during playback of recorded video. When playing a file, the monitor should display a flashing PLAY message and the PLAY button up indicating that the DVR is in the playback status. To switch between channel 1..4 and quad view in the playback mode, please press...

  • Page 25: Slow Forward/ Reverse

    4.3.2 Slow Forward/ Reverse There are 4 speeds available for a slow playback: 1/2, 1/4, 1/8, 1/16. While playing back recorded video at the recorded speed: (1) Press the PAUSE button (2) Forward: Turn the Shuttle dial direction at a speed slower than the recorded speed. Each subsequent turn of the shuttle to the right increases the forward rate, as 1/2, 1/4, 1/8, and 1/16.

  • Page 26: Search Operations

    4.4 Search Operations This section shows you how to access recorded video. 4.4.1 Full List Search Take the following steps to proceed with the full-list search function. (1) Press the Search button (2) Select the FULL LIST and press the Enter button video.
  • Page 27 4.4.2 Alarm list Search Take the following steps to proceed with the alarm-list search function. (1) Press the Search button (2) Select the ALARM LIST and press the Enter button alarm-event recorded video. (3) Highlight the specific recorded video of your requirement and press the Enter button display the selected video.

  • Page 28: Thumbnail Search

    4.4.4 THUMBNAIL Search Take the following steps to proceed with the thumbnail search function. (1) Press the Search button (2) Select the THUMBNAIL and press the Enter button (3) Set the date you wish to search for the recorded video. (4) Press the Enter button ●...

  • Page 29: Backup Operations

    SEARCH FULL LIST ALARM LIST TIME SEARCH THUMBNAIL SD CARD NOTE: If you would like to delete JPG file in the SD card, please return to SD CARD JPG FILE list page and highlight the specific JPG file of your requirement and press the Setup button and then select the “Yes”...
  • Page 30 MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM GOTO DISK PAGE ALARM: Duplicate all the alarm-event recorded video from HD 1 to HD2. Stay on the DISK SETTING page. Use the “ ” and “v” buttons, press the Enter button MAIN MENU RECORD ALARM/ MOTION...
  • Page 31 MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM GO TO DISK PAGE A 1 2001-02-01 12:20 2 2001-02-01 03:30 + A 3 2001-03-02 04:20 + 4 2001-04-01 13:30 NOTE: If the capacity of HD 2 is not sufficient to store all selected video, a warning message “HD2 SPACE NOT ENOUGH”...
  • Page 32 SAVE TO M000N.AVI NOTE: ●The JPEG file format can be played and deleted in the DVR. Please refer to section 4.4.5. ●The AVI file format can not. It can only be played in a card reader connected to a computer.

  • Page 33: Key Lock Operation

    4.6 Key Lock Operation The Key lock operation protects the unit against unauthorized use by disabling the entire front panel controls. Press the Enter button (as shown below) for at least 3 seconds to lock the unit; to release the Key Lock , press the button again. DISK A-rec T-rec...

  • Page 34: Menu Setup

    5. MENU SETUP There are 6 categories of operation settings able to be configured from the setup menu. The following sections will provide step-by-step instructions for configuring/changing the setup options. Press the Setup button to access the setup menu. Once inside the menu system, the on-screen menu allows you to set up the key features of the unit.

  • Page 35: Rec Setting

    PAL unit) resolution REC QUALITY: This option determines the image quality to be recorded. The DVR stores images in the compressed format and allows the image quality to be altered by the image size. There are 4 levels of image quality you can select from: BEST , HIGH, STANDARD, and BASIC . Selecting the BEST image for use provides higher-resolution recorded images, and normally takes up more storage space than a HIGH, STANDARD or BASIC image does.

  • Page 36: Alarm / Motion Setting

    5.2 ALARM / MOTION SETTING This menu allows users to program the configuration of alarm recording only when an alarm input is activated. The device will record as long as the alarm input is activated. MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK...
  • Page 37 ALM TYPE: This option allows users to set a type of alarm input corresponding to the sensor signal in use. NO: Normally Open. This is to be used with the type of alarm sensor whose contact remains open in normal conditions and closes in case of activation. NC: Normally Closed.

  • Page 38: Motion Setting

    PRE- ALARM: This option determines whether images that occurred prior to an alarm prior to an alarm activation will be recorded. When an alarm is triggered the device will record the image prior to the alarm for 5 seconds. ( 10 frames/sec ON: Enables this function.

  • Page 39: Timer/ Seq/ Title

    The DVR provides a weekly table, consisting of two periods of time each day for scheduled recording. This option allows you to set the time each day that the DVR will start and stop recording. The SEQUENCER setting allow user to set the sequence dwell time (time interval) for each channel, and TITLE setting allow user to set TITLE for each channel.
  • Page 40 SEQUENCER: This entry allows users to set the DWELL time( time interval) for CH1, CH2, CH3, CH4, and quad view( ), the valid values are 01 ~ 99 seconds, set to 00 would disable the corresponding channels during the sequential jumping is proceed. In live mode, press the Seq./Save button to switch the screen to the sequential jumping mode.

  • Page 41: Communication

    GOTO COMM PAGE COMM ID: Communication ID for RS232 and RS485 communication. After the 4CH DVR receives a RS232 or RS485 command, it checks if the <Dest ID> within the code is the same as the COMM ID, in which case the particular command can be accept.
  • Page 42 This option selects enable or disable for the DHCP communication function. OFF: Disables it. ON: Enables it. NOTE: If provided with a DHCP server, the 4CH DVR can get an IP automatically by setting this option to ON. NET IP: This option is used to configure the Ethernet communication settings.
  • Page 43 FTP connection. Please consult with a qualified MIS professional to configure it. FTP ACCOUNT FTP IP : 192.168.001.128 USER : [ dvr PASSWORD : [ 00000000 PATH : [ /dvrvideo FTP IP : Every FTP server has to own an IP address to be identified on the network. Input the IP address of the FTP server.

  • Page 44: Disk Setting

    5.5 DISK SETTING MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM GOTO DISK PAGE REFORMAT: This option allows you to clear out all the data in the hard-disk drive. You will be required to enter the pre-set password before proceeding with clearing out the data. Enter the standard password “9999” if you don’t set your individual password.
  • Page 45 5.6 SYSTEM This section is used for accessing the history of the operation status, setting the password, resuming factory default, and determining the menu display background. MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM GOTO SYSTEM SETTING OPERATION LOG: This log shows the history of the operation status in chronological order.
  • Page 46 SD SETUP: The 4CH DVR offers a quick setup method by using a SD card. If the user wants to set up many a number of the same devices with the same settings, he can save the whole settings to a SD card, then transfer to another DVR.
  • Page 47 VERSION: This item is in the setup menu reveal network MAC, BIOS version, and software version, and last updated date. : 00 : 0c : 0c : 00 : 00 : 07 BIOS : 1.03 : 1.00 DATE : Mar 10 2003...

  • Page 48: Rs-232 & Rs-485 Protocol

    6.1.1 Use a Null Modem cable (the standard RS-232 9 Pin Cable with Pin 2 and Pin 3 exchanged, see pin configuration chart below for details) to connect the COM 1 on the rear panel of the DVR to a PC.
  • Page 49 6.2.2.2 Request Time (Second Category=0x02) PC Request: <0x41>, <0x01>, <0x20>, <0x02>, <0x02>, <0x00>, <0x4f> DVR Response: <0x41>, <0x20>, <0x01>, <0x02>, <0x02>, <0x07>, <7 Time Value >, <0x4f> The following case is an illustration of < 7 Time Value> 2003/06/20 17:05:00 = <0xD3>, <0x07>, <0x06>, <0x14>, <0x11>, <0x05>, <0x00>...
  • Page 50 DVR Playback Immediately DVR Response: <0x41>, <0x20>, <0x01>, <0x02>, <0x12>, <0x00>, <0x4f> DVR Playback ERROR DVR Response ERROR: <0x41>, <0x20>, <0x01>, <0x02>, <0x12>, <0x01>, <0x45>, <0x4f> NOTE: The DVR accepts RS-232 time search commands only under the live or playback Mode.

  • Page 51: Ide Hard Disk Installation

    7. IDE Hard Disk Installation Usually, the unit comes with one hard-disk drive installed in compartment HD 1, which is default-configured as a master. The jumper settings configuration of the installed hard-disk drives for the unit and compatible drives which can be used with this unit are listed in the table below. To install two hard disk drives in compartment HD 1 and HD 2, please take the following steps.

  • Page 52: Mobile Rack Hdd Installation

    Place the mobile rack back onto the device and screw it in. 7.2 Mobile Rack HDD Installation 1. Make sure that the key unlocked. 2. Pull the active-handle outward to remove the carrier body away from the mobile rack 6. Secure the driver in the rack using two mounting screws in both the side-mounting holes.
  • Page 53 3. Slide the top cover backward and remove. 4. Setting the jumper of your hard disk driver. The way to set the jumper of the drive varies between manufacturers; please refer to the instructions on the driver to set the jumpers in the master position. 5.
  • Page 54 8. Slide the carrier body back in the mobile rack. 9. Push the carrier body further into the mobile rack until fully inserted. 10. Push the active-handle inward. 11. Lock the Key.

  • Page 55: System Default

    8. System Default MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM GOTO REC PAGE MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM GOTO ALARM / MOTION PAGE MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM...
  • Page 56 MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM GOTO COMM PAGE MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM GOTO DISK PAGE MAIN MENU RECORD ALARM/ MOTION TIMER/ SEQ/ TITLE COMMUNICATION DISK SYSTEM GOTO SYSTEM SETTING COMM SETTING COMM ID : 01...

  • Page 57: Message

    9. O.S.D. Message O.S.D. Message NO DISK BATTERY LOW LOADING VIDEO LOSS VIDEO IN KEY LOCKED KEY UNLOCKED n1 OF n2 ITEMS PROGRESS n3 % BACKUP COMPLETE HD2 SPACE NOT ENOUGH NO ENTRY FOR BACKUP BACKUP INCOMPLETE NOT FOUND DISK FULL EMPTY SET TO NTSC, PLS RESTART SOFTWARE UPDATE...

  • Page 58: Network Viewer And Image Viewer

    10.1 The Network Viewer 10.1.1 Introduction to Network Viewer The Network Viewer allows you to potentially access unit of the 4CH DVR from a remote desktop or a laptop in a TCP/IP networking environment. It can perform the following functions.
  • Page 59 3. After the installation is complete, pop up the START menu from your computer, and point to Programs / 4CH DVR Network Viewer to open up the program selection page as shown below. Click the 4CH DVR Network Viewer tag to start the 4CH DVR Network Viewer program.
  • Page 60 10.1.3 View the 4CH DVR video from a remote PC 1. Click the Find tag to connection of the all DVR device in the LAN. 2. Choose a channel number from the Channel drop-down list. 3. Type in the user name for the chosen 4CH DVR.
  • Page 61 Click to change the settings of a chosen device. Delete Click to remove the connection of a chosen device. Find Click to find the connection of the all 4CH DVR device in the LAN. Login Click to access the display page of the Network Viewer. Viewing images...
  • Page 62 To review a recorded video, just click an entry from the list and click the PgUp/PgDn : To scroll up and down the list. 4CH DVR Status Box. This box indicates the selected device status. PLAY : The device is in the playback mode.
  • Page 63 HOUR: MINUTE you wish to search and click GO to proceed. Every 4CH DVR has to own an IP address and a title to be identified on the network. This area displays the title and the IP address of the 4CH DVR.
  • Page 64 10.1.4 Change the Record & Timer Properties Via the Network Follow the instructions below to reconfigure the record and schedule recording settings via the network. Set the regular record settings 1. When in the single –device mode, click A above) 2.
  • Page 65 10.1.5 Archive Images to the Computer Playback images can be stored in a local PC in the JPEG format. Follow the instructions below to save the viewed images or videos to your PC. 1. Press to enter the following sample screen whenever in the playback mode. 2.

  • Page 66: The Image Viewer

    SD card or HDD of a computer, but also protects an archived image from reproduction or interpolation. If an image isn’t in the original format made by a 4CH DVR, the Image Viewer won’t display the image and instead will send a warning message” Wrong File, Can’t Open ”. Follow the instructions below to open an archived image from a SD card or a HDD.

  • Page 67: Index Table

    The following description details how the DVR manages an index table issue. The DVR will generate a time index table indicating recorded data is kept in a particular HDD. This allows to individually selecting recorded data to be displayed via the alarm list search and full list search.

  • Page 68: Network Configuration

    12. Network Configuration 12.1 Cable Connections Please follow the instructions below to connect your MV-DR4000 to a computer or a network and to choose a proper RJ-45 cable configuration for connections. Physical specification of RJ-45 cable for Ethernet Wire Type Connector Type Max.

  • Page 69: Configure Your Dvr Network Settings

    RS-232 ETHERNET MONITOR AUDIO ALARM RJ-45 12.2 Configure Your DVR Network Settings Upon network hardware connection, you need to activate the network function and configure the proper network settings of the DVR. 12.2.1 Enable DVR Network Function MAIN MENU RECORD...
  • Page 70 NOTE: This function can only work if the LAN which the unit is connected to has a DHCP server. If the DHCP server is working, the DVR will obtain an IP address automatically from the DHCP server. In that case please skip the section 2.3 (Set IP address) and follow section 3.
  • Page 71 NOTE: When only one unit of the DVR is connected to a computer or LAN, you can freely assign an IP address for the DVR. For example, there are a range of DVR IP addresses from 192.168.0.1 to 192.168.0.255. You can pick one for use from the range of the IP.

  • Page 72: Tcp/Ip Communication Software

    12.3 TCP/IP Communication Software Follow the instructions below to install the TCP/IP communication program into your computer. Click the Start Menu from your computer, and point to the Settings/Control panel. Click the NETWORK icon twice to enter the NETWORK setting windows. Click on the Configuration tag;...

  • Page 73: Tcp/Ip Installation

    12.4 TCP/IP installation During the installation, you will be requested to insert the windows 98 CD ROM. After installation, the PC will be restarted.

  • Page 74: Tcp/Ip Configuration Setting

    DHCP server, please select specify an IP address and type in the IP address of your PC. This IP address must be different from the DVR IP but in the same class type. NOTE: The IP address of a DVR in a network must be unique to itself as opposed to...

  • Page 75: Connection Testing

    With the previous settings, follow the instructions below to ensure whether you have established the connection successfully. Click Start Programs Type in ping 192.168.0.1 then Enter. (See the sample screen below) ** This IP is the DVR IP address that is assigned for the connected DVR in step 2. MS-DOS Prompt...
  • Page 76 If you receive a response as in the sample screen below, the connection hasn’t been successfully established. Please re-check all the hardware and software installation by repeating steps 1 to 5. If you still can’t establish the connection after rechecking, please contact your dealer.

  • Page 77: Microsoft Internet Explorer

    Click the URL block at the top of the screen. Type in the URL address of the 4CH DVR into the URL block and press the “ Enter ” button to enter the login page. The default User Name and password is admin and 9999 respectively.
  • Page 78 Browsing images from the 4CH DVR: The images from the 4CH DVR will be displayed on the home page while going online with the 4CH DVR. There are some buttons provided on the bottom of the home page for further setting:...
  • Page 79 PgUp/PgDn : Enables you to scroll up and down the list. 4CH DVR Time & Status Box. This box indicates the selected device status. PLAY : The device is in the playback mode. LIVE : The device enters the live display mode.

  • Page 80: Change Record / Alarm Setting

    13.2 Change Record / Alarm Setting Please follow the steps given below to change the Record / Alarm setting through the network as and when necessary. Click the button on the home page to enter the Record / Alarm setting page. Adjust the Record / Alarm setting, including the “REC rate”, “REC quality”, “ALARM REC enable”, “ALARM REC rate”, and “ALARM REC quality”...

  • Page 81: Change Timer Record Setting

    4. There are two time-periods available for scheduling each day. The Timer Record setting page allows users to program the time each day that the 4CH DVR will start and stop recording. The time is displayed in a 24-hour clock format. If there is a time overlap showing between two continual time-period settings, the device will automatically combine the two time-period settings into one combined time-period setting.

  • Page 82: Change Pan/Tilt/Zoom Setting

    13.4 Change Pan/Tilt/Zoom Setting Please follow the steps provided below to control the Pan/Tilt/Zoom setting through the network as and when necessary. 1. Click the button on the home page to open the Speed Dome Controller. 2. Click the button to control the Zoom setting on the Speed Dome Controller. 3.
  • Page 83 The ‘AutoPan’ section has three buttons. The ‘Start’ and ‘End’ buttons fix the two points of any panning movement you select. The third or bottom button sets the chosen movement in the play mode.

  • Page 84: Specifications

    14. SPECIFICATIONS Model Number Image System Resolution Video In Video Out Audio In/Out Storage Media Compression Memory Card Archive Watermark Recording mode Recording Rate Image Size Recording Mode Alarm Recording Pre-Alarm Recording Playback Speeds Record Search Motion Detection Set-up Menu Log list Alarm In/Out Built-in Buzzer...

  • Page 85: Appendix 1. -Scanip

    2. Select the desired device from the Device List . 3. Click the desired device to show the window while the DVR information acts to display the desired changes instantly. 4. Do you want to auto search free IP? If and when you want to auto search the free IP, select “Yes”...
  • Page 86 If you have clicked “No”, please manually type in insertions as required in the “Free IP Address”, “Gateway Address”, and “NET Mask”. Follow each insertion you make by typing in the “Login Name” and “Password”, and click “UPDATE” to send your alterations to the DVR. 6. Auto search “Free IP Address”.
  • Page 87 8. To change any IP address, type in the new address in the “Free IP Address” box on the right as well as the device “Login Name” and “Password” in their respective blanks at bottom left, then click “UPDATE”, and the new address will automatically be sent to the device. 9.
