Word
53
15-3:
Reserved
2:
1 = the fields reported in word 88 are valid.
0 = the fields reported in word 88 are not valid
1:
1 = the fields reported in words (70:64) are valid.
0 = the fields reported in words (70:64) are not valid
0:
Obsolete
54-58
Obsolete
59
15-9:
Reserved
8:
1 = Multiple sector setting is valid
7-0:
xxh = Current setting for number of sectors that shall be transferred per
interrupt on R/W Multiple command
60-61
Total number of user addressable sectors
62
Obsolete
63
15-11: Reserved
10:
1 = Multiword DMA mode 2 is selected.
0 = Multiword DMA mode 2 is not selected
9:
1 = Multiword DMA mode 1 is selected.
0 = Multiword DMA mode 1 is not selected
8:
1 = Multiword DMA mode 0 is selected.
0 = Multiword DMA mode 0 is not selected
7-3:
Reserved
2:
1 = Multiword DMA mode 2 and below are supported
1:
1 = Multiword DMA mode 1 and below are supported
0:
1 = Multiword DMA mode 0 is supported
64
15-8:
Reserved
7-0:
PIO modes supported
ATA Bus Interface and ATA Commands
Content Description
Maxtor DiamondMax 8S 40GB SATA
5-8
