Inserting The Battery; Removing The Battery - MAXDATA NOTEBOOK PRO 5500 IR User Manual

Inserting the Battery

The battery is included with the notebook as purchased. This battery is only partially charged.
Note that the charging time for the battery is about .5 hours if the computer is switched
off, or about 4 hours if the computer is switched on.
It is absolutely essen-
tial to fully charge the
battery for initial op-
eration! Do not unplug
the power adapter
until the battery is fully
charged.

Removing the Battery

0
(1) Insert the battery into the battery slot in the direction of the arrow.
Gently push the battery until it locks into place.
() Lock the battery into position.
The battery can now be charged.
(1) Slide the release catch to the right.
() Slide and hold the left button to the left.
() Slide the battery backwards to remove it from the holder.
You can now run the notebook with the power adapter alone!
Fig. 3
Fig. 4
Preparation
