Cool Start DS7 Operating Instructions Manual

2-way remote start system
Hide thumbs Also See for DS7:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction and Installation Manual
DS7
2-WAY REMOTE START SYSTEM
CONGRATULATIONS on your choice of a Data Start™ Remote Engine Starter and Keyless Entry by Crimestopper
Security Products Inc. This system is designed to work exclusively thru the vehicle's Canbus using a Databus
interface module. This booklet contains the information necessary for operating your system. If any questions arise,
contact your installation dealer or Crimestopper Security Products Inc.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These are features that must be connected in order for the system to operate properly i.e. Remote
Start connections, Flashing lights, and Brake Reset. For programming, the program button is required.
-OPTIONAL: These features are to be connected only if desired or agreed upon by the customer and the installing
dealer i.e. Door Locks, Trunk Pop, Dome Light Illumination, Horn-Honk, Anti-Grind, etc. These features may also
require additional parts and/or labor fees. Consult with your installer beforehand to be sure of what is going to be
installed with your particular system.
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV 11.2012
OPERATING INSTRUCTIONS
This device complies with FCC Rules part 15. Operation is
subject to the following two conditions: 1) This device may not
cause interference, and (2) this device must accept any
interference that may be received, including interference that
may cause undesired operation.
responsible for any radio or TV interference caused by
unauthorized modification to this equipment. Such modification
could void the user's authority to operate the equipment.
The manufacturer is not

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cool Start DS7

Summary of Contents for Cool Start DS7

  • Page 1 2-WAY REMOTE START SYSTEM OPERATING INSTRUCTIONS CONGRATULATIONS on your choice of a Data Start™ Remote Engine Starter and Keyless Entry by Crimestopper Security Products Inc. This system is designed to work exclusively thru the vehicle’s Canbus using a Databus interface module. This booklet contains the information necessary for operating your system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Operation Cautions & Warnings…….……………..….………………………………….…………….….…………2 Using the 2-Way Pager……………………………………………….……………………….………..…………...3-4 Setting the Clock and Beep or Vibrate Selection…………………………………………………….……….….4-5 1-Way Sidekick and Battery Replacement………….………………...……………………..…………….………..6 Status LED………………………………………………………………………………………………..……….….……7 Remote Engine Control…………….…..……………………………………………………………….…….…..…7-10 Turbo Timer Mode……………………………….……………………………………...……………….…………..….11 Manual Transmission Mode……………………………….……………………………………...…………………..12 Convenience and Safety Features……………………………….………………………………….…...……..12-14 Transmitter Programming….…………….…………………………………………….……………….…………..…15 2 Vehicle Operation.…………………………………….………………...…………………………………….………16 No Factory Keyless Entry after Remote Start…………..………………………………………………………….17 Remote Start Diagnostics……………………………………………………………………………………………..17...

  • Page 3: Using The 2-Way

    USING THE 2-WAY PAGER TRANSMITTER SIDE BUTTONS LCD SCREEN ICONS Valet Mode (Tools) Transmit Signal Battery Life TRUNK Hood Open Ignition ON RELEASE Sensor Warning Lock/Unlock (Small Hammer) (Arm/Disarm) Sensor Trigger VEHICLE (Big Hammer) Silent no beeps SELECT Door Open CLOCK / Trunk Open Run Count Down...

  • Page 4: Setting The Clock And Beep Or Vibrate Selection

    USING THE 2-WAY PAGER TRANSMITTER The 2-Way LCD Pager remote transceiver is used to send and receive information from the vehicle. The Control Module transmits High Frequency FM signals from the vehicle to your pager over long distances. Your range will vary depending on location, terrain, and local RF noise/interference. This system is not guaranteed to page you if you are behind concrete walls, underground, in a large structure, or in an area with high levels of electronic interference.
  • Page 5 REMOTE BEEP & VIBRATE SELECTION The LCD pager remote BEEPS and VIBRATES when it receives a signal from the vehicle. The Beeps and Vibration are selectable (on/off). To enter program mode, 1. Press VEH Button on the side of the remote control 5 times. 2.

  • Page 6: 1-Way Sidekick And Battery Replacement

    1-WAY SIDEKICK The 1-Way sidekick remote adds flexibility to your system. You can have the convenience of operating your system without needing to carry the larger pager remote. The Sidekick remote has less range and offers all of the same operation features except for page- back confirmation.

  • Page 7: Status Led

    STATUS LED STATUS LED: Used for Remote Start Diagnostics – page 14 (Optional, requires Installation of LED) LED will flash when locking your doors with remote. LED will remain solid in Valet Service Mode. REMOTE ENGINE CONTROL REMOTE START & TRUNK POP – Button Press Selection (Option # 6): To eliminate the possibility of accidentally opening the trunk or starting the vehicle, there are (3) options for button press selection.
  • Page 8 REMOTE ENGINE CONTROL REMOTE ENGINE STARTING – UNSUCCESSFUL START In the event that the engine does not start on the first attempt, the system shuts down for a few seconds, then attempts to restart the engine a 2 and 3 time.
  • Page 9 REMOTE ENGINE CONTROL IDLE DOWN MODE: This mode allows the unit to take over operation of the parked vehicle while the ignition key is removed and you exit the vehicle. The vehicle will remain running for the programmed time or until canceled. The Run Time choices are: 10, 20, 30 minutes or Infinity Run.
  • Page 10 REMOTE ENGINE CONTROL SELECTABLE HOURLY COLD-START MODE (1-4 HOURS) This mode allows the vehicle to be programmed to self-start every 1, 2, 3 or 4 hours and run for the programmed run time. This can be helpful during extremely cold conditions where engine fluid freeze-up is a concern. TIMED SELF-START MODE –...

  • Page 11: Turbo Timer Mode

    TURBO TIMER MODE (Option 22) The optional Turbo Timer mode allows the CoolStart system to keep a Turbo or Turbo Diesel vehicle running for 1, 3 or 5 minutes [selectively] after you remove the key and exit the vehicle. This is handy for turbo cool- down without the need for expensive turbo timers.

  • Page 12: Manual Transmission Mode

    MANUAL TRANSMISSION MODE (Option 11) MANUAL TRANSMISSION EXIT PROCEDURE (Option #11-1 and 11-3) This system features a Manual Transmission Mode. When exiting the vehicle, there is a safety check out procedure required for the manual transmission mode to work. There are 2 choices of operation: 1.
  • Page 13 CONVENIENCE AND SAFETY FEATURES AUTO LOCK / UNLOCK (Option # 2) The Auto Lock feature controls whether the doors will automatically lock/unlock on your vehicle when driving or with turning the Ignition ON/OFF. If the Auto Lock feature is turned on, and your system is in “Tach” mode, then the doors should automatically lock as the engine RPM’s increase (driving).
  • Page 14 CONVENIENCE AND SAFETY FEATURES VALET MODE Before servicing your vehicle or handing the keys over to a Valet we recommend putting the unit into Valet Mode. The Remote Start function WILL NOT operate when in Valet Mode. 1. To Activate Valet Mode Manually: Turn the ignition on and press the Valet button [about 5-6 seconds] until the LED turns on solid.

  • Page 15: Transmitter Programming

    TRANSMITTER PROGRAMMING Note: All transmitter codes must be learned at time of programming!! The DS7 learns up to 4 different transmitter codes. 1. Turn Ignition Key to the ON position. 2. Press Programming button 4 times, then after a few seconds the unit flashes the parking lights 4 times.

  • Page 16: Vehicle Operation

    2-VEHICLE OPERATION & PROGRAMMING Your remotes have the ability to control a second vehicle with a Crimestopper system installed. To set up the 2-Vehicle operation you must first program your remotes to Vehicle #2. Follow the “Transmitter Programming” steps (Pg. 12) at the second vehicle and learn YOUR remote, along with vehicle #2’s existing remotes.

  • Page 17: No Factory Keyless Entry After Remote Start

    NO FACTORY KEYLESS ENTRY AFTER REMOTE START Most new cars Do Not allow the factory Remote Keyless Entry to function with the Ignition ON. This means you can’t use the factory remote to lock or unlock the doors. After remote start you have to use the keys to unlock the door. Also, many new vehicles unlock the doors when disarming the factory alarm.

  • Page 18: 2-Way Data Port

    2-Way DATA PORT This system only works on vehicles with a CANBUS computer system and requires a Databus Module to integrate with the factory computer. Databus modules are used to communicate with the vehicles computer at the OBD2 Data connector or Canbus wires.
  • Page 20 www.crimestopper.com ONLINE TECHNICAL SUPPORT email@crimestopper.com www.crimestopper.com Phone (800) 998-6880 FAX (805) 581-9500 © 2012 Crimestopper Security Products...
