INSTALLATION AND MAINTENANCE INSTRUCTIONS
D2 Duct Smoke Detector
SPECIfICATIONS
Operating Temperature:
Storage Temperature:
Humidity:
Air Velocity:
Rectangular Footprint Dimensions:
Square Footprint Dimensions:
Weight:
Electrical
Power supply voltage:
Input capacitance:
Reset Voltage:
Reset Time (with RTS451/RTS151):
Reset Time (by power down):
Power Up Time:
Alarm response time:
Sensitivity Test:
Current Requirements (Using No Accessories)
Peak standby current
Average standby current
Max. alarm current

Table of Contents

[1] Limitations of Duct Smoke Detectors . . . . . . . . . . . . . . . . . . . . . . . . .1
[2] General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
[3] Contents of the Duct Smoke Detector Kit . . . . . . . . . . . . . . . . . . . . . .1
[4] Exploded View of Duct Smoke Detector Components . . . . . . . . . . . . .2
[5] Detector Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
[6] Sampling Tube Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
[7] Measurement Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
[8] Field Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
[9] Detector Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
[10] Verification of Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
[11] Dectector Cleaning Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
[12] Sensor Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
[13] Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4,6
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
The D2 model is a photoelectric detector approved for an extended air speed
range of 100 to 4000 feet per minute (0.5 m/s to 20.3 m/s) and an operational
temperature range of −4°F to 158°F (−20°C to 70°C).
BEfORE INSTALLINg
Read the System Sensor Guide for Proper Use of Smoke Detectors in Duct Appli-
cations (A05-1004), which provides detailed information on detector spacing,
placement, zoning, wiring, and special applications. Copies of this manual
are available online at www.systemsensor.com. NFPA Standards 72 and 90A
should also be referenced for detailed information.
NOTICE: This manual shall be left with the owner/user of this equipment.
IMPORTANT: This detector must be tested and maintained regularly following
NFPA 72 requirements. The detector should be cleaned at least once a year.

[1] LIMITATIONS Of DUCT SMOkE DETECTORS

The National Fire Protection Association has established that DUCT DETEC-
TORS MUST NOT BE USED AS A SUBSTITUTE FOR OPEN AREA DETECTOR
PROTECTION as a means of providing life safety. Nor are they a substitute for
early warning in a building's regular fire detection system.
System Sensor supports this position and strongly recommends that the user
read NFPA Standards 90A, 72, and 101. The D2 Air Duct Smoke Detectors are
listed per UL 268A.
SS-300-014
-4° to 158° F (-20° to 70° C)
-22° to 158° F (-30° to 70° C)
0% to 93% Relative Humidity Non-condensing
100 to 4000 ft./min. (0.5 to 20.3 m/sec.)
14.38 in L x 5 in W x 2.5 in D (37 cm L x 12.7 cm W x 6.36 cm D)
7.75 in L x 9 in W x 2.5 in D (19.7 cm L x 22.9 cm W x 6.35 cm D)
1.8 pounds; 0.82 kg
8.5-35 VDC
0.1 µF max.
2.5 VDC min.
.03 to 0.3 sec.
0.3 sec. max.
35 sec. max.
15 sec.
See detector label
120µA
60µA
130 mA
WARNING
ACCESSORY CURRENT LOADS AT 24 VDC
DEVICE
RA400Z/RA100Z
RTS451/RTS151
RTS451KEY/RTS151KEY
Page
This device will not operate without electrical power. Fire situations may
cause an interruption of power. The system safeguards should be discussed
with your local fire protection specialist.
This device will not sense smoke unless the ventilation system is operating
and the cover is installed.
For this detector to function properly, it MUST be installed according to the in-
structions in this manual. Furthermore, the detector MUST be operated within
ALL electrical and environmental specifications listed in this manual. Failure
to comply with these requirements may prevent the detector from activating
when smoke is present in the air duct.

[2] gENERAL DESCRIPTION

Smoke introduced into the air duct system will be distributed throughout the
entire building. Smoke detectors designed for use in air duct systems are used
to sense the presence of smoke in the duct.
Model D2 Duct Smoke Detector utilizes photoelectric technology for the de-
tection of smoke. This detection method, when combined with an efficient
housing design, samples air passing through the duct allowing detection of a
developing hazardous condition. When sufficient smoke is sensed, an alarm
signal is initiated and appropriate action can be taken to shut off fans,
blowers, change over air handling systems, etc. These actions can facilitate
the management of toxic smoke and fire gases throughout the areas served
by the duct system.
[2.1] DETECTOR fEATURE SET
- Utilizes 2151 plug-in head
- Sampling tubes installed from front or rear
- Compatible with existing accessories

[3] CONTENTS Of ThE DUCT SMOkE DETECTOR kIT

1. Sensor/power board assembly and covers
2. Three #10 sheet metal screws for mounting
3. Drilling template
4. One sampling tube end cap
5. One plastic exhaust tube
NOTE: A sampling tube must be ordered to complete the installation. It must
be the correct length for the width of the duct where it will be installed. See Ta-
ble 1 on page 3 to determine the inlet tube required for different duct widths.
1
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
www.systemsensor.com
STANDBY ALARM
0mA 12mA Max.
0mA 12mA Max.
0mA 12mA Max.
I56-3050-004R
