Page 1: Installation Guide
Installation Guide Included Installation Instructions Network Camera P-25 Model No. Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. The model number is abbreviated in some descriptions in this manual. - Page 2 For U.S.A WARNING: NOTE: This equipment has been tested and found to comply with the limits for a Class A digi- • To prevent injury, this apparatus must be tal device, pursuant to Part 15 of the FCC Rules. securely attached to the wall/ceiling in These limits are designed to provide reasonable accordance with the installation instructions.
-
Page 3: Table Of Contents
Contents Important safety instructions ......................4 Limitation of liability ........................5 Disclaimer of warranty ........................5 Preface ............................5 Main functions ..........................6 About the user manuals ........................ 7 System requirements for a PC ...................... 7 Trademarks and registered trademarks..................8 Copyright ............................ -
Page 4: Important Safety Instructions
Important safety instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not block any ventilation openings. Install in accordance with the manufacturer's instruc- tions. 6) Do not install near any heat sources such as radiators, heat registers, stoves, or other appara- tus (including amplifiers) that produce heat. -
Page 5: Limitation Of Liability
(7) LOSS OF REGISTERED DATA CAUSED BY ANY FAILURE. Preface The network camera P-25 is designed to operate using a PC on a network (10BASE-T/ 100BASE-TX), and can be installed outdoors. By connecting to a network (LAN) or the Internet, images and audio from the camera can be moni- tored on a PC via a network. -
Page 6: Main Functions
Main functions Equipped with a new codec engine The redesigned codec engine can output up to 60 frames per second in Full-HD quality. The equipped enhanced Super Dynamic function makes it possible to achieve 133 dB dynamic range. By combining images taken at different shutter speeds and using pixel level brightness correction, more natural looking pictures can be taken even when objects have large differences in illumination. -
Page 7: About The User Manuals
About the user manuals There are 2 sets of operating instructions for the P-25 as follows. • Installation Guide: Explains how to install and connect devices. • Operating Instructions (included in the CD-ROM): Explains how to perform the settings and how to operate this camera. ® ® Adobe Reader is required to read these operating instructions on the provided CD-ROM. -
Page 8: Trademarks And Registered Trademarks
IMPORTANT: • For information on the operation verification of the supported operating systems and web brows- ers, refer to our website at http://advidia.com/cameras/. • When using a PC that does not meet the above requirements, displaying of images may become slower or the web browser may become inoperable. • Audio may not be heard if a sound card is not installed on a PC. Audio may be interrupted depending on the network environment. -
Page 9: Network Security
Network security As you will use this unit connected to a network, your attention is called to the following security risks. ① Leakage or theft of information through this unit ② Use of this unit for illegal operations by persons with malicious intent ③... -
Page 10: Precautions
Precautions Refer installation work to the dealer. Do not use this product in an inflammable Installation work requires technique and experi- atmosphere. ences. Failure to observe this may cause fire, Failure to observe this may cause an explosion electric shock, injury, or damage to this product. resulting in injury. - Page 11 The screws and bolts must be tightened to Do not install this product on a place that is greatly influenced by wind. the specified torque. Installation on a place where the wind speed is Failure to observe this may cause a drop resulting in injury or accidents.
- Page 12 When an error is detected, this product Periodically images on the screen appear to be distorted will restart automatically. When the camera is installed in a location where This product will be inoperable for around 2 minutes after the restart just as when the power it is subject to small vibrations (for example, when it is installed near devices that vibrate), images is turned on.
-
Page 13: Code Label
About the MOS image sensor • When continuously shooting a bright light About the dehumidifying device source such as a spotlight, the color filter • This product has dehumidifying device to of the MOS image sensor may become keep the inside at low moisture level, pre- deteriorated and this may cause venting condensation and quickly dissipat- discoloration. -
Page 14: Precautions For Installation
Precautions for installation Advidia assumes no responsibility for injuries or property damage resulting from failures arising out of improper installation or operation inconsistent with this documentation. Installation area for this product Before installation Contact your dealer for assistance if you are • Use the camera mount bracket (accessory) unsure of an appropriate place in your particu- to install the camera on the ceiling or wall. - Page 15 Screw tightening When using the product in cold climates, take • The screws and bolts must be tightened notice of the ambient and internal temperatures with an appropriate tightening torque of the product. according to the material and strength of When this product is installed and operated in the installation area.
-
Page 16: Major Operating Controls
Major operating controls Rear part of sunshield Sunshield Front cover Rear cover Safety wire Tilting lock screw Panning lock screw Network cable RJ45 (female) EXT I/O terminal Alarm input/output cable Power cable (12 V DC) Microphone/line input cable (white) Audio output cable (black) Camera mount bracket (accessory) - Page 17 Mount bracket cover x2 (accessories) Link indicator (lit when linking) SD slot 1 (SD1) Access indicator (lit when accessing) SD slot 2 (SD2) SD memory card error indicator/Auto focus SD memory card slot indicator (blinks when adjusting auto focus) Auto focus (AF) button TELE button WIDE button Initial set button...
-
Page 18: Preparations
Preparations • The camera mount bracket (accessory) can be directly mounted on the wall or ceiling using a junction box (locally procured) embedded in the wall or ceiling, or a wall or ceiling with a cable access hole. • The screws that secure the camera mount bracket on a wall are not supplied. Prepare the screws according to the material, structure, strength and other factors of the mounting area and the total weight of objects to be mounted. Installation Appropriate mount Recommended... -
Page 19: Installations/Connections
Installations/Connections Secure the camera to the camera mount bracket The tilt angle is locked downward at shipment. Loosen the tilting lock screw approx. 1 rotation and adjust the tilt angle of the camera to the horizontal position. Tighten the tilting lock screw again after tilt angle adjustment. Note: • Use a hexagonal wrench with width across flats of 4 mm (locally procured) to loosen or tighten the tilting lock screw. - Page 20 Remove the screws from the mounting boss of the safety wire and the mounting boss of the cable clamp. Secure the safety wire with the screw from the mounting boss. Then, bundle the wire and the cable using the cable clamp and secure them with each screw from the mounting boss as illus- trated.
-
Page 21: 4P Alarm Cable
Connect an external amplifier-embedded speaker to the audio output cable. Connect a stereo mini plug (ø3.5 mm) (Audio output is monaural.). • Output impedance: Approx. 600 Ω (unbalanced) • Recommended cable length: Less than 10 m {32.8 ft} • Output level: –20 dBV * Use an external powered speaker. IMPORTANT: • C onnect/disconnect the audio cables and turn on the power of the camera after turning off the power of the audio output devices. Otherwise, loud noise may be heard from the speaker. • M ake sure that the stereo mini plug is connected to this cable. When a monaural mini plug is connected, audio may not be heard. -
Page 22: Power Cable
Connect a LAN cable (category 5e or better, straight to the network connector. IMPORTANT: • Use all 4 pairs (8 pins) of the LAN cable (category 5e or better, straight). • The maximum cable length is 100 m {328 feet}. • Make sure that the PoE device in use is compliant with IEEE802.3af standard. • When connecting both the 12 V DC power supply and the PoE device for power supply, 12 V DC will be used for power supply*. * If a 12 V DC power supply and a PoE hub or router are used at the same time, network con- nections may not be possible. -
Page 23: Waterproof Tape
Waterproof treatment for the cable joint sections Adequate waterproof treatment is required for the cables when installing the camera with cables exposed or installing it under the eaves. The camera body is waterproof, but the cable ends are not waterproof. Be sure to use the supplied waterproof tape (accessory) at the points where the cables are connect- ed to apply waterproof treatment in the following procedure. - Page 24 Connection example when connecting to a network using a PoE hub Adjustment monitor PoE device (hub) Powered speaker LAN cable (category 5e or better, straight) LAN cable Microphone (category 5e or better, straight) Powered speaker LAN cable (category 5e or better, straight) Adjustment monitor Microphone Recommended...
- Page 25 Secure the camera mount bracket when the camera is directly installed on a wall 6 mm (W) x 10 mm (L) {1/4" (W) x 3/8" (L)} (long hole) 46 mm Use M5 screw x4 (locally {1-13/16"} procured) to secure the 20 mm camera mount bracket to a {13/16"}...
-
Page 26: Adapter Box
• If a junction box is used, putting the View from above (internal) boxes side by side is recommended as shown in the 46 mm 83.5 mm illustration at right. {1-13/16"} {3-1/4"} Unused junction (Use unused boxes junction boxes to 6 mm (W) x 10 mm (L) pass cables {1/4"... - Page 27 Secure the mount bracket cover x2 (accessories) to the camera Mount bracket cover x2 (accessories) mount bracket with the 2 mount bracket cover screws (accessories). IMPORTANT: • Ensure that the mount bracket cover screws are firmly secured. Camera mount bracket (accessory) Recommended tightening torque: 0.59 N·m {0.44 lbf·ft} Mount bracket cover screw x2 (M3 x 6) (accessories)
-
Page 28: Insert/Remove An Sd Memory Card
Insert/remove an SD memory card IMPORTANT: • Before inserting an SD memory card, make sure to turn off the power. • When inserting an SD memory card, make sure the direction. • Before removing the SD memory card, make sure to select “Not use” for “SD memory card” on ☞ the [SD memory card] tab of the “Basic” page on the setup menu first. ( Operating Instructions (included in the CD-ROM)) Label side Loosen the 4 fixing screws of the front cover to remove the front cover. -
Page 29: Adjustment
Adjustment Be sure to view the monitor for adjustment when the camera angle is adjusted. Supply power to this unit, connect the monitor for adjustment (e.g. a small LCD) to the monitor output jack, and adjust the camera angle (turn off the power after view angle adjustment for safety). ①... - Page 30 Adjust the angular field of view and the focus. Adjust the angular field of view in accordance with the distance between the camera lens and a photographic subject. These adjustments shall be performed together with the camera angle adjustment. Auto focus (AF) button TELE button WIDE button...
- Page 31 Note: • When shooting in the following place or the following subjects, focus may not be adjusted automatically. In this case, adjust the focus manually from the setup menu. Refer to the Operating Instructions (included in the CD-ROM) for how to perform the manual focus adjust- ment from the setup menu.
-
Page 32: Mounting The Front Cover
Mounting the front cover Mount the front cover. Fixing screw x4 IMPORTANT: • The tightening torque described below shall be followed for the 4 fixing screws of front cover. Recommended tightening torque: 0.59 N·m {0.44 lbf·ft} • The tightening sequence of the 4 fixing screws of the front cover shall be observed and repeat- ed twice as described in the illustration above. ((1) → (2) → (3) → (4), twice) • Make sure the packing has not come off or become askew. If this happens put it back into place. -
Page 33: Attaching The Mounting Surface On The Top Surface Of The Camera Body
Attaching the mounting surface on the top surface of the camera body When the mounting surface is changed to the top surface of the camera body Remove the 4 sunshield fixing screws from the camera body and remove the sunshield. Remove the 4 tripod head fixing screws from the camera body and remove the tripod head. - Page 34 Mount the tripod head on the top of the camera body with the 4 tripod head mounting screws that were removed in the step 2. IMPORTANT: • Caution shall be taken to prevent each cable from being caught between the camera body and tripod head. • Be sure to use the screws that were removed from the tripod head. Recommended tightening torque: 0.59 N·m {0.44 lbf·ft} Secure the camera to the camera mount bracket with the camera fixing screws x3. Pass each cable and the safety wire through the camera mount bracket, and connect the safe- ty wire to the camera mount bracket.
- Page 35 Remove the sunshield backside. As illustrated, opening up the sunshield in both directions makes it easier to remove the rear part of the sunshield. • When installing the camera to a ceiling, the rear part of the sunshield and the fixing screws are not used.
-
Page 36: Configure The Network Settings
Configure the network settings Configuring the camera so that it can be accessed from a PC The following are descriptions for when the camera with default settings is configured. If you are using firewall software on your PC, the Setup Program may not be able to find any cameras on your network. - Page 37 Select the camera you want to configure, and click [Access Camera]. Note: • When cameras are displayed in [IP Setting Software] screen, click the camera with same MAC address as the MAC address printed on the camera that you want to configure. If the installation screen of the viewer software “Advidia WebViewer Plugin”...
-
Page 38: Troubleshooting
Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Reference Symptom Cause/solution pages When using DC power supply... - Page 39 Reference Symptom Cause/solution pages • Is there a wall or other reflecting surface or object near the camera (including areas not When the IR LED lights a displayed in images)? 29-31 part or all of the screen → Adjust the camera angle so that light from appears blurred. the IR LED is not reflected.
-
Page 40: Specifications
Specifications Basic • Power source: 12 V DC, PoE (IEEE802.3af compliant) Power consumption: DC 12V : 930 mA/Approx. 11.2 W PoE DC48 V : 260 mA/Approx. 12.5 W (Class 0 device) Ambient operating environ- ment: –40 °C to +50 °C {–40 °F to 122 °F}* Ambient operating humidity: 10 % to 90 % (no condensation) Monitor output (for adjust-... - Page 41 Camera • Image sensor: Approx. 1/3 type MOS image sensor Effective pixels: Approx. 2.4 mega pixels Scanning area: 5.28 mm (H) x 2.97 mm (V) {7/32 inches (H) x 1/8 inches (V)} Scanning system: Progressive Minimum illumination: Color : 0.04 lx {0.00372 foot-candle} (F1.3, Maximum shutter: Off (1/30 s), AGC: High) 0.003 lx {0.00028 foot-candle} (F1.3, Maximum shutter: max.
-
Page 42: Camera Mount Bracket
Lens • Zoom ratio: 3.6x Varifocal Lens 10.8x Extra optical zoom* is available. * 16:9 mode must be selected Digital (electronic) zoom: Choose from 3 levels of x1, x2, x4 Focal length: 2.8 mm – 10 mm {1/8 inches – 13/32 inches} Maximum aperture ratio: 1:1.3 (WIDE) –... - Page 43 Image compression method: H.264* Transmission priority: Constant bit rate / Variable bit rate / Frame rate / Best effort / Advanced VBR Frame rate: <When Variable bit rate, Frame rate, or Advanced VBR is selected> 1 fps / 3 fps / 5 fps* / 7.5 fps * / 10 fps* / 12 fps* / 15 fps* / 20 fps* / 30 fps* / 60 fps* * The frame rate is limited to "Max bit rate (per client)*".
- Page 44 Microsoft Windows 8.1 Microsoft Windows 8 Microsoft Windows 7 Microsoft Windows Vista Browser* Windows Internet Explorer 11 (32-bit) Windows Internet Explorer 10 (32-bit) Windows Internet Explorer 9 (32-bit) Windows Internet Explorer 8 (32-bit) Windows Internet Explorer 7 (32-bit) Maximum concurrent 14 (Number of sessions that can connect to cameras at the same access number: time)
-
Page 45: Standard Accessories
Standard accessories Installation Guide (this document) ............1 set CD-ROM* ..................1 pc. Code label* ..................1 pc. The following parts are used during installation procedures. 4P alarm cable ..................1 pc. 2P power cable .................1 pc. Waterproof tape .................1 pc. Adapter box ..................1 pc. Camera mount bracket ..............1 pc. - Page 48 advidia 5120 Woodway, Suite 5006 Houston TX, 77056 (832) 240-1768 http://advidia.com/ © advidia 2015 avs0615-0 PGQX1916ZA Printed in China...
