Master Appliance MICROTORCH MT-11 Instructions

Designers and Manufacturers of Heat Tools for Industry
Flame Nozzle Cover
Main Body Cap
Fuel Cell Regulator
RC-30
Re llable Fuel Cell
Fuel Level View
SAFETY & WARNINGS:
After filling fuel cell, please verify that valve has seated
properly by visual inspection. Consult factory if problem
exists. Read and follow instructions before using. Keep away
from children. After filling: fuel cell contains gas under
pressure. Do not use near open flames, heaters or
combustibles. Store properly when not in use. Always make
sure Microtorch is cool before removing fuel cell. Remove fuel
cell before storage. Do no store fuel cell above 104°F/40°C.
CAUTION: Flame appears invisible in sunlight and could cause
severe injury if not used with extreme caution.
WARNING: This product, when used for soldering and similar
applications, produces chemicals known to the State of California
to cause cancer and birth defects or other reproductive harm.
WARNING: Department of Transportation Hazardous Materials
Regulations forbid the carriage of butane or other flammable gas
products on passenger aircraft. Do not pack this item or any other
flammable gas item, in any checked or carry-on baggage.
Contains flammable gas under pressure. Do not use near sparks
or open flame. Do not puncture or incinerate container or store
at temperatures above 120° F. Keep out of reach of children.
MSDS Sheet available upon request or see our website
for your convenience.
USE ONLY MASTER ULTRATANE
BUTANE FUEL
MASTER APPLIANCE CORP.
2420 - 18th Street, Racine, WI 53403 U.S.A.
PHONE: 262-633-7791 FAX: 262-633-9745
Visit our website www.masterappliance.com
(1)
Safety Lock
(2)
Ignition Button
Butano Gas • Butane Carburant
L E U F E N A T U B
ULTRATANE
Industry for Tools Heat of Manufacturers and Designers
Main Body–Re llable
Fuel Cell Holder
®
MICROTORCH MT-11
WITH "REFILLABLE" BUTANE FUEL CELL
INSTRUCTIONS
FEATURES:
• Built-in safety lock with improved easy to use
self-ignition system
• Runs on Master Ultratane
• Flame temperature up to approximately 2500°F, 1300
• Wind-proof flame and water-resistant ignition
• Compact size – unit fits easily into tool kit or
first aid/survival kit
• Child Resistant Ignition System
• Built-in fuel level viewing window
HOW TO USE THE MT-11:
Remove main body cap, then place the refillable fuel cell into
the holder. Replace the body cap tightly. (Refer to diagram.)
To ignite, Push Safety Lock toward Flame Nozzle. Place thumb
on Ignition button and apply downward pressure. Your MT-11
is now ignited and ready to use. Note: If no flame appears,
adjust the regulator on the fuel cell and activate the ignition
button again. As the gas in the fuel cell is consumed, the
regulator may need to be adjusted to ensure a proper flame.
When the ignition button is released, there will be a short delay
before the flame is completely extinguished and the Safety Lock
will move to locked position. When the MT-11 is not in use,
remove the fuel cell.
TO FILL/REFILL FUEL CELL:
Use only Master Ultratane® Butane fuel to fill fuel cell. Remove
fuel cell from Microtorch or package. Hold fuel cell firmly with
refill valve pointing up. Place nozzle of butane canister down
onto refill valve and press butane canister down and up in
short durations until fuel cell is filled. A pumping action is
required when filling fuel cell. It typically requires two or three
quick pumps to fill fuel cell. If you do not follow proper filling
instructions, the valve may stick open, causing butane to leak.
SIZE
WEIGHT
FUEL
NONSTOP RUN TIME
FLAME TEMP.
FUEL CAPACITY
Butane Fuel
®
SPECIFICATIONS:
1.0" (L) x 4.3" (H) x 2.5" (W)
25 mm x 110 mm x 65 mm
2.1 oz / 60 g (empty)
Butane Master Ultratane
Approx. 20 minutes
Approx. 2500°F, 1300°C (blue flame)
5.3 cc
°C
®
