SPECIFICATIONS
SIZE
WEIGHT
NONSTOP RUN TIME
FLAME TEMP.
FUEL CAPACITY
CONTENT AND PARTS IDENTIFICATIONS:
A - Burner Head
B - Soldering Tip
C - Heat Tip
1.) Flame Guard (Aperture)
2.) Fuel Adjustment wheel
3.) Safety lock
Master Model MT-76
3 in 1 Triggertorch
6.5" (L) x 3.8" (H) x 1.3" (W)
165 mm x 97 mm x 34 mm
8.1 oz / 230 g (empty)
120 minutes
Approx. 2500 °F, 1300 °C
(blue flame)
5/8 oz. / 20 ml
4.) Shutter lever
5.) Igntion button
6.) Removable stand
7.) Filler valve
8.) Hands Free
ON/OFF slide
Instructions
Advertisement
Related Manuals for Master Appliance Microtorch MT-76
Summary of Contents for Master Appliance Microtorch MT-76
- Page 1 Instructions Master Model MT-76 3 in 1 Triggertorch SPECIFICATIONS 6.5" (L) x 3.8" (H) x 1.3" (W) SIZE 165 mm x 97 mm x 34 mm WEIGHT 8.1 oz / 230 g (empty) 120 minutes NONSTOP RUN TIME Approx. 2500 °F, 1300 °C FLAME TEMP.
- Page 2 INSTRUCTIONS LOCK (+) gives you a longer broad flame, clockwise (-) gives you a THE MT-76 MICROTORCH DOES NOT CONTAIN BUTANE GAS shorter pinpoint flame. Don’t make the flame too long as it will WHEN PURCHASED only waste the gas and make the flame unstable. (fig. 3) GAS REFILLING STORAGE •...
