Operating Instructions
Tumble dryer
Save these instructions for future reference
Dear Asko Customer,
Thank you for choosing this quality product from Scandinavia,
which was made in Sweden.
We want you to feel assured that the inside of your new ma-
chine is just as good as the outside and that the ethics and
standards that went into the production of this machine are
just as high as the quality and performance that you will re-
ceive from it. We hope that this product will give you many
years of pleasure.
To ensure that you get the most out of your new machine, we
recommend that you read the operating instructions before
using the machine. The operating instructions also contain
information on how to avoid damaging the environment.
Asko T793
Advertisement
Table of Contents
Related Manuals for Asko T793
Summary of Contents for Asko T793
-
Page 1: Operating Instructions
Operating Instructions Tumble dryer Save these instructions for future reference Dear Asko Customer, Thank you for choosing this quality product from Scandinavia, which was made in Sweden. We want you to feel assured that the inside of your new ma-... -
Page 2: Table Of Contents
Contents Before using your machine for the first time Do not tumble dry Important safety instructions Grounding instructions Interrupting a program Packing material Disposal Child safety General Activating Child-safe Start To deactivate Child-safe Start temporarily: Description of the tumble dryer Front panel Advice and tips before you tumble dry... -
Page 3: Before Using Your Machine For The First Time
Before using your machine for the first time Do not tumble dry Certain materials are not suitable for tumble drying. Always check and follow the instruc- tions on each item's laundry label. You can find more information in the "Advice and tips before you tumble dry"... -
Page 4: Important Safety Instructions
• The interior of the machine should be cleaned periodically by an authorized ASKO service agent. • Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may contribute to a chemical reaction that could cause a load to catch fire. -
Page 5: Grounding Instructions
Important safety instructions Grounding instructions A) Grounding instructions for a grounded, cord-connected appliance In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This appliance (Canadian market only) is equipped with a cord having an equipment-grounding conductor and a grounding plug. -
Page 6: Child Safety
Child safety General Do not allow children to play with the tumble dryer. The tumble dryer does not start automatically when the door closes (for example, if a child closes the door from inside the dryer). In order to prevent children from starting a program or changing one that has already started, you can activate the Child-safe Start option. -
Page 7: Description Of The Tumble Dryer
Description of the tumble dryer Main power switch Panel Lint filter holder Outer door Fan (behind hatch) Serial number tag and rating plate Lint filter Customer Care Center 1-800-898-1879 www.askousa.com... -
Page 8: Front Panel
Front panel Main power switch Program selector Display window Start Stop Customer Care Center 1-800-898-1879 www.askousa.com... -
Page 9: Advice And Tips Before You Tumble Dry
Advice and tips before you tumble dry Here are some tips that may help you before you begin tumble drying. Have the clothes been spun? Items to be tumble dried should be spun at 1000 rpm or faster. Higher spin speeds save both energy and drying time. -
Page 10: Operating Instructions
Operating instructions Warning! To reduce the risk of electric shock or injury to persons, read the "Important Safety Instruc- tions" section before operating this appliance. Below are step-by-step instructions to help you achieve the best possible tumble drying results. Sort your fabrics You will achieve the most uniform drying results if the items are made of the same type of material. -
Page 11: Programme Chart
Operating instructions Menu overview Heavy Normal Delicate Iron Dry Timed Dry Air Fluff Settings Temperature Normal Temperature Low Note! The illustration shows an example of a program. Programme chart For the consumption values given below, the requirements are as follows: Temperature of intake air: Moisture content of intake air: Drying temperature:... -
Page 12: Selecting Options
Operating instructions Selecting Options By selecting options, you can tailor dry- ing programs to suit your own laundry requirements. The machine remembers the selected option and uses it the next time you select the same program. You can, of course, change this if you want. -
Page 13: Press The Start Button
Operating instructions Setting the time for the Timed Dry and Air Fluff programs You can set the time so that it appears on the display as Start, End, or the number of min- utes. This will depend on how you have cho- sen to display times. -
Page 14: Drying Program Finished
Operating instructions Drying program finished The text "END" appears on the display when the program has finished. If the Anti Wrinkle option has been selected, the drum will rotate every minute for 2 hours after cooling. Important! • Clean the lint filter after each load. Caution! If the lint filter becomes clogged, the ma- chine’s automatic overheating cut-off may be... -
Page 15: Settings
Settings You can alter the following settings: • Clock • Buzzer Volume • Language • Child-safe Start • Back How to choose the settings: 1. Press the program selector (the big arrow) until the program selection menu on the left is highlighted. -
Page 16: Language
Settings Language You can choose the language you prefer. 1. Select Language by pressing the up or down arrow button until Language is highlighted. 2. Press the program selector again (the big arrow) to access the options menu on the right of the display. -
Page 17: Care And Maintenance Instructions
Care and maintenance instructions Cleaning the lint filter The lint filter must be cleaned after each load. If you have very hard water, this can cause limescale deposits in the lint filter. Check for any limescale deposits when cleaning the lint filter and, if necessary, wash the filter by hand. -
Page 18: Troubleshooting
Troubleshooting The machine will not start Check • that the door is properly closed. • that the main power switch is on. • that the Delayed Start option has not been selected. To cancel Delayed Start, press the Stop button for 3 seconds. •... -
Page 19: Technical Information
Technical information Technical data Height: Width: Depth: Weight: Cylinder volume: Max. drying capacity: Speed: Rated power: Drum material: Outer casing material: Setup 33 1/2'' (850mm) 23 7/16'' (595mm) 23" (585 mm) 104lb (47kg) 29.3gal (111l) 15lb (7kg) 52 rpm See serial number tag and rating plate. Stainless steel Powder-coated and hot-galvanized sheet steel or stainless steel. -
Page 20: Service And Guarantee
For non-residential installations One-year Full Warranty From date of purchase. AM Appliance Group will pay for: ASKO replacement parts and/or repair labor to correct defect in materials or workmanship. Service must be provided by an authorized ASKO service agent. ASKO replacement parts and/or repair labor to correct defect in materials or workmanship. -
Page 21: Warranty
• Replacement parts or repair labor costs for units operated outside the continental United States. • Pickup and delivery. ASKO washers are designed to be repaired in the home. In no event shall AM Appliance Group be responsible for any incidental or conse- quential damages. -
Page 22: Installation Instructions
B. Stacked The tumble dryer can be placed on top of a Asko washing machine. To stack the dryer, you need the stacking attachments (foot cups and anti-tip devices) that come with the ma- chine: You will find 2 foot cups in a bag in the drum and 2 anti-tip devices attached to the bottom left corner at the back of the machine. - Page 23 Installation instructions How to assemble the stacking kit: 1. Undo the anti-tip device. 2. Remove the two screws indicated on the back of the washing machine. 3. Secure the anti-tip device using the screws as shown in the picture. 4. Attach the plastic cups for mounting the tumble dryer’s front feet to the washing machine’s top cover.
-
Page 24: Adjusting The Feet
Asko dryers have a “T-stile” exhaust vent that Vent allows you to connect the... - Page 25 Installation instructions Connecting the exhaust duct to the Left or Right Side Outlet To connect the exhaust duct to the left or right side outlet, follow the steps below: 1. Using a flathead screw-driver, turn the ex- haust outlet cover you plan to use to the right or left to align the tabs holding the cover in place.
-
Page 26: Electrical Installation
ONLY (rated 208–240 V.) To use this recep- tacle, you must use the ready-fitted plug supplied with the washing machine or an equivalent. ASKO washers rated 208–240 V have two internal fuses of 15 A each. Remove cover to access terminal box. (Requires a 20-Torx screw- driver.) - Page 27 Installation instructions Connecting a 3-wire Power Cord Warning! Before starting this procedure, be sure the power is turned off at the breaker/fuse box. Power Supply Cord You will need a 3-wire power supply cord with three No. 10 copper wires and a matching 3- wire receptacle of NEMA Type 10-30R, as il- lustrated below: To connect a 3-wire power cord to the dryer,...
- Page 28 Installation instructions 5. Remove ground wire (green with yellow stripes) from external ground connector screw. Fasten under center, silver-colored terminal block screw. 6. Connect ground (green) wire of cord to external ground conductor screw. 7. Connect ground (white) wire of cord under center screw of terminal block.
-
Page 29: Reversing The Door
Reversing the door Hinge pins (top and bottom) Cover washer Plastic plugs (on the upper and lower edges) Lock hook Hinges (left + right side) Toe kick Customer Care Center 1-800-898-1879 www.askousa.com... -
Page 30: Follow These Instructions
Reversing the door You can choose whether the door is hung on the right or the left. Follow these instructions: 1. Remove the Toe kick. 2. Unscrew the 2 screws on the hinges. 3. Lift the door up and remove it. Support the door while doing this. -
Page 31: Built-In Machine With Cover Door Fitted
Reversing the door Built-in machine with cover door fitted You can choose whether the door is hung on the right or the left. Follow these instructions: 1. Remove the Toe kick. 2. Remove the cover door by undoing the four screws. -
Page 32: Fitting The Wooden Door
Fitting the wooden door Front of the steel door 21 27/32” (555mm) 23 7/16” (595mm) Front of the wooden door Fitting the wooden door Height Width Front of the wooden door Back of the steel door Customer Care Center 1-800-898-1879 www.askousa.com 30.2"... - Page 33 Notes Customer Care Center 1-800-898-1879 www.askousa.com...
- Page 34 Notes Customer Care Center 1-800-898-1879 www.askousa.com...
- Page 35 Notes Customer Care Center 1-800-898-1879 www.askousa.com...
-
Page 36: Quick Guide
Quick guide Fabrics • Dry fabrics of the same type together to ensure they dry as evenly as possible. Turn on the main power switch Load the laundry • Close the door. Select a program and any options • Turn the program selector to the desired program. •...
