Operating Instructions

Tumble dryer

Save these instructions for future reference
Dear ASKO Customer,
Thank you for choosing this quality product from Scandinavia,
which was made in Sweden.
We want you to feel assured that the inside of your new ma-
chine is just as good as the outside and that the ethics and
standards that went into the production of this machine are
just as high as the quality and performance that you will re-
ceive from it. We hope that this product will give you many
years of pleasure.
To ensure that you get the most out of your new machine, we
recommend that you read the operating instructions before
using the machine. The operating instructions also contain
information on how to avoid damaging the environment.
ASKO T793

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T793 and is the answer not in the manual?

Questions and answers

Related Manuals for Asko T793

Summary of Contents for Asko T793

  • Page 1: Operating Instructions

    Operating Instructions Tumble dryer Save these instructions for future reference Dear ASKO Customer, Thank you for choosing this quality product from Scandinavia, which was made in Sweden. We want you to feel assured that the inside of your new ma-...

  • Page 2: Table Of Contents

    Technical data Static electricity Service and guarantee Operating instructions Warranty Sort your fabrics How to contact the ASKO Appliances Inc. Turn on the main power switch. Installation instructions Open the door, load the items, and then close the door Positioning the tumble dryer...
  • Page 3 Contents Quick guide Fabrics Turn on the main power switch Load the laundry Select a program and any options Press the Start button Drying program finished Once tumble drying has finished Customer Care Center 1-800-898-1879 www.askousa.com...

  • Page 4: Before Using Your Machine For The First Time

    Before using your machine for the first time Do you need this Use&Care Guide in spanish? Log onto www.askousa.com/customercare to download. ¿Necesita esta Instrucciones de uso y cuidado en español? Entre en www.askousa.com/customercare y descárguesela. Do not tumble dry Certain materials are not suitable for tumble dry- ing.

  • Page 5: Important Safety Instructions

    See the "Installation" chapter. • The interior of the machine should be cleaned Warning! periodically by an authorized ASKO service agent. WARNING - To reduce the risk of fire, electric • Do not place items exposed to cooking oils in shock, or injury to persons when using your appli- your dryer.

  • Page 6: Grounding Instructions

    Important safety instructions B) Grounding instructions for a Grounding instructions permanently connected appliance: A) Grounding instructions for a grounded, This appliance must be connected to a grounded cord-connected appliance metal, permanent wiring system, or an equipment- In the event of malfunction or breakdown, grounding conductor must be run with the circuit grounding will reduce the risk of electric shock by conductors and connected to the equipment-...

  • Page 7: Child Safety

    Child safety General Activating Child-safe Start You can activate Child-safe Start to prevent chil- Do not allow dren from starting the machine. 1. Press the program selector until Child-safe children to play Start is highlighted. 2. Turn the program selector until On or Off is with the tumble displayed.

  • Page 8: Description Of The Tumble Dryer

    Description of the tumble dryer Main power switch Fan (behind hatch) Panel Serial number tag and rating plate Lint filter holder Lint filter Outer door Customer Care Center 1-800-898-1879 www.askousa.com...

  • Page 9: Front Panel

    Front panel Main power switch Start Program selector Stop Display window Customer Care Center 1-800-898-1879 www.askousa.com...

  • Page 10: Advice And Tips Before You Tumble Dry

    Advice and tips before you tumble dry Here are some tips that may help you before you Materials that should not be tumble begin tumble drying. dried Have the clothes been spun? This symbol means that the material is not suitable for tumble drying.

  • Page 11: Operating Instructions

    Operating instructions Warning! Auto Normal and Auto Delicate These programs shut off the heat once the load To reduce the risk of electric shock or injury to is dry but before it is "bone-dry". The Auto Normal persons, read the "Important Safety Instructions" program shuts off the heat slightly later than Auto section before operating this appliance.
  • Page 12 Operating instructions Air Fluff Use the Air Fluff program when you just want to refresh, air out,, or soften up items. Customer Care Center 1-800-898-1879 www.askousa.com...

  • Page 13: Program Chart

    Operating instructions Menu overview 1. Auto Heavy Anti Wrinkle 2. Auto Normal function 3. Auto Delicate Stop Clock Delayed Start 4. Auto Iron Dry 5. Jeans 10.20 09.20 6. Synthetic Start End time 7. Timed dry Time Saver / 8. Air fluff programme Time Saver Off Temperature 9.

  • Page 14: Selecting Options

    Operating instructions Delayed Start Selecting Options Choose the number of hours by which you want By selecting options, you can tailor drying to delay the start. programs to suit your own laundry require- 1. This option cannot be used with the Air Fluff ments.

  • Page 15: Press The Start Button

    Operating instructions Press the Start button Drying program finished The text "END" appears on the display Remaining drying time when the program is finished. If the Anti An estimate of the remaining drying time Wrinkle option has been selected, the drum will will be shown on the display a few minutes after rotate for 3 seconds every minute for 2 hours after the drying program starts.

  • Page 16: Once Drying Has Finished

    Operating instructions To install the automatic drain hose, please see Once drying has finished the section titled Installation Turn off the main power switch. Remove the clothes and close the door to prevent small children from climbing into the machine. Customer Care Center 1-800-898-1879 www.askousa.com...

  • Page 17: Settings

    Settings You can alter the following settings: • Clock • Buzzer Volume • Language • Child-safe Start • Back How to choose the settings: 1. Press the program selector until the program selection menu on the left is highlighted. 2. Turn the program selector until Settings is highlighted. 3.

  • Page 18: Child-Safe Start

    Settings Child-safe Start You can activate the Child-safe Start option to prevent children from starting the machine. Pressing the program selector and the Stop button at the same time for three seconds will temporarily disable the Child-safe Start option for three minutes. 1.

  • Page 19: Care And Maintenance Instructions

    Care and maintenance instructions Cleaning the lint filter Cleaning the outside of the machine The lint filter must be cleaned after each load. If Clean the outside of the machine and the program you have very hard water, this can cause panel with a mild cleaner.

  • Page 20: Troubleshooting

    Troubleshooting The machine will not start Drying takes too long • Check that the lint filter is not clogged (see the Check "Care and maintenance" chapter). • that the door is properly closed. • that the main power switch is on. The laundry does not dry, or is too •...

  • Page 21: Technical Information

    Technical information Technical data Height: 33 1/2'' (850mm) Width: 23 7/16'' (595mm) Depth: 23,0" (585mm) Weight: 104lb (47kg) Cylinder volume: 29,3gal (111l) Max. drying capacity: 13lb (6kg) Speed: 52 rpm Rated power: See serial number tag and rating plate. Drum material: Stainless steel Outer casing material: Powder-coated and hot-galvanized sheet steel or...

  • Page 22: Service And Guarantee

    ASKO replacement parts (labor cost not included) for the stainless steel tank if it exhibits a manufactur- ing defect such as cracking or rusting through. Ser- vice must be provided by an authorized ASKO ser- vice agent. For non-residential installations One-year Full War-...

  • Page 23: Warranty

    • Replacement parts or repair labor costs for units operated outside the continental United States. • Pickup and delivery. ASKO washers are de- signed to be repaired in the home. In no event shall ASKO Appliances Inc. be responsible for any incidental or con- sequential damages.

  • Page 24: Installation Instructions

    WARNING - Risk of fire. B. Stacked Install the clothes dryer according to the manufac- The tumble dryer can be placed on top of a ASKO turer's instructions and local codes. washing machine. To stack the dryer, you need Do not install a clothes dryer with flexible plastic the stacking attachments (foot cups and anti-tip venting materials.
  • Page 25 Installation instructions C. Built-in ASKO dryers can be installed beneath a cabinet or worktop with a minimum height of 34” (864 mm). There must be a gap of about 1/2” (12 mm) all around the machine, including between the rear edge of the machine top panel and the back wall.
  • Page 26 Installation instructions How to assemble the stacking kit: 5. Fit the plastic cups so that the "tags" marked 1. Undo the anti-tip device. with arrows are against the front edge or side edge of the cover and press them firmly onto the cover.

  • Page 27: Adjusting The Feet

    Note tached to either the right or left exhaust outlet. Maximum duct length of 60 feet and 4 elbows is Asko dryers have a allowed. Subtract 4 feet of duct for each 90° el- “T-stile” exhaust vent that Vent bow.
  • Page 28 Installation instructions Connecting the exhaust duct to the Left Connecting to a ventilation duct or Right Side Outlet You will need a UL-CSA-approved, 4-inch ridged To connect the exhaust duct to the left or right metal exhaust duct. If a flexible duct is used, it side outlet, follow the steps below: must comply with the Outline for Clothes Dryer 1.

  • Page 29: Electrical Installation

    ASKO washers rated 208–240 V have two internal fuses of 15 A each. Ventilation grill The machine should only be connected to a grounded wall socket.
  • Page 30 Installation instructions Electrical Connections Connecting a 3-wire Power Cord Warning! Warning! Read the Electrical requirements and grounding Before starting this procedure, be sure the power instructions before connecting the tumble dryer. is turned off at the breaker/fuse box. Electric models of the dryer are manufactured for a 3-wire connection system.
  • Page 31 Installation instructions 5. Connect ground (center) wire of power supply cord to the center, silver-colored terminal screw. Tighten screw. 6. Connect the other wires to outer screws. 7. Tighten the strain relief screws. 8. Replace terminal box cover on back of dryer. 9.

  • Page 32: Reversing The Door

    Reversing the door Hinge pins (top and bottom) Lock hook Cover washer Hinges (left + right side) Plastic plugs (on the upper Toe kick and lower edges) Customer Care Center 1-800-898-1879 www.askousa.com...

  • Page 33: Follow These Instructions

    Reversing the door You can choose whether the door is hung on the right or the left. Follow these instructions: 1. Remove the Toe kick. 2. Unscrew the 2 screws on the hinges. 6. Move the plastic plugs on the upper and lower edges of the door.
  • Page 34 Notes Customer Care Center 1-800-898-1879 www.askousa.com...
  • Page 35 Notes Customer Care Center 1-800-898-1879 www.askousa.com...

  • Page 36: Quick Guide

    Quick guide Fabrics Press the Start button • Dry fabrics of the same type together to ensure they dry as evenly as possible. Turn on the main power switch Drying program finished • "END" appears on the display when the program is finished.
