User image 67fd1627018d3
0
Mr. Anderson
April 14, 2025

To check if the furnace in a Starcraft Travel Star camper is receiving power when the gas is on and the camper is plugged in, ensure the 12-volt power is available. The furnace requires 12-volt DC power to operate. Make sure the 12-volt battery disconnect switch is not turned off. If power is available and the furnace still does not operate, check for signs of soot on the vent, which may indicate a malfunction.

This answer is automatically generated

0
Nicki Christianson
June 7, 2025

We have a 1997 starcraft leisure craft 852. Could you tell me where the gray water tank and the black water tank are located

0

Subscribe to Our Youtube Channel

Related Manuals for Starcraft Travel Star

Summary of Contents for Starcraft Travel Star

  • Page 1 2012 OWNER’S MANUAL TRAVEL STAR TRAVEL TRAILERS & FIFTH WHEELS...
  • Page 2 RV. This manual has been provided by Starcraft RV for the sole purpose of providing instructions concerning the operation and maintenance of this vehicle and its components. Nothing in this manual creates any warranty, either expressed or implied.

  • Page 3: Table Of Contents

    TRAVEL STAR TRAVEL TRAILERS & FIFTH WHEELS TABLE OF CONTENTS . 1: W & S . 4: T & H ARRANTY ERVICE OWING ANDLING ........ 1-1 ........4-5 BOUT ANUAL HANGING THE . 1-5 ......4-7 HANGE OF WNERSHIP DDRESS MERGENCY TOPPING ......

  • Page 4: Table Of Contents

    TABLE OF CONTENTS TRAVEL STAR TRAVEL TRAILERS & FIFTH WHEELS . 7: P . 10: C & O LUMBING YSTEM AMPING PERATING CONTINUED & S -A-B ) ....10-3 VOLT ATER WITCH QUIPPED )........7-3 ......10-4 QUIPPED ASE OF REASE ....7-6 ™...

  • Page 5: Arranty

    STARCRAFT TOWABLE WARRANTY & SERVICE This is the safety alert symbol. It is ongratulations! Thank you for selecting a used to alert you to potential personal Starcraft RV. We are excited to welcome you injury hazards. Obey safety to our growing RV family. We are committed messages that follow this symbol to avoid to being the most respected name in RVs.
  • Page 6 SECTION 1 WARRANTY & SERVICE STARCRAFT TOWABLE To contact NHTSA by phone: Starcraft reserves the right to discontinue or Call the Department of Transportation (DOT) change specifications or design at any time Vehicle Safety Hotline at 1-888- 327-4236 without notice and without incurring any and a NHTSA representative will record your obligation whatsoever.
  • Page 7 Don’t expect to look over the technician’s Registration and Customer Delivery Form” shoulder… Please do not be offended if you to Starcraft within 10 days of delivery to are told you cannot watch the work being activate the applicable warranty coverage.

  • Page 8: Nformation

    Towable Limited Warranty. special body company, By belonging to the Starcraft Camper Club, assembler, equipment installer or upfitter is you will find new ways to enjoy your RV and solely responsible for warranties on the body make...
  • Page 9 SECTION 1 STARCRAFT TOWABLE WARRANTY & SERVICE ATTENTION! Notice of: CHANGE OF ADDRESS CHANGE OF OWNERSHIP TOTALED DESTROYED Check applic able block(s): STOLEN PLEASE PRINT OR TYPE Federal record keeping laws require that we maintain a file of owners of our RVs. This form must be completed by the RV owner in the case of change of address, stolen or destroyed RV, and by the RV purchaser in the case of change of ownership.
  • Page 10 If an authorized Starcraft dealer is not located the local telephone yellow pages. Or nearby, contact your selling dealer for contact Starcraft Customer Service or assistance. If your dealer is closed, check...
  • Page 11 Parts for Starcraft RVs distributed exclusively by authorized Starcraft dealers. Starcraft does not sell parts retail direct or to non-authorized dealers. If an original part is no longer available, Starcraft will try to provide an appropriate substitute. 1 - 7...
  • Page 12 The warranty period begins on the date that the RV is delivered to the first retail purchaser by an independent, authorized dealer of Starcraft, or, if the dealer places the vehicle in service prior to retail sale, on the date the RV is first placed in such service.

  • Page 13: C Ondensation

    RV, or if it has taken longer than thirty (30) days for those types of repairs to be completed, you must, to the extent permitted by law, notify Starcraft directly, in writing, at the above address, of the unsuccessful repair(s) of the alleged defect(s) so that Starcraft can become directly involved in making sure that you are provided service pursuant to the terms of this limited warranty.
  • Page 14 Starcraft. Failure to file this warranty registration with Starcraft will not affect your rights under this limited warranty as long as you can present proof of purchase, but it can cause delays in obtaining the benefits of this limited warranty, and it may inhibit any servicing facility’s ability to provide...
  • Page 15 WHAT AND WHO IS COVERED The Starcraft limited tent warranty covers the tents on the bunk ends of the slide rooms of this travel trailer, when the RV is used only for its intended purpose of recreational travel and camping. This warranty covers parts, labor and freight for the first (1) year and parts, Starcraft factory labor and return freight from Starcraft for an additional six (6) years.
  • Page 16 Starcraft provides with the RV in any fashion. It only supplements the Starcraft limited warranty to provide for a limited, seven (7) year tent warranty (covering parts, labor and freight for the first (1) year and parts, Starcraft labor and return freight from Starcraft for an additional six (6) years).
  • Page 17 RV. The rental warranty, located on pages 14-16, applies in that situation. If, on the other hand, the Starcraft dealer sells this RV to a retail customer then the rental warranty would not be applicable. The rental...
  • Page 18 Dealer only, and it is not transferable. The warranty period begins on the date that Dealer first places the RV in rental service. In the event that a substantial defect in material or workmanship, attributable to Starcraft, is found to exist during the warranty period, Starcraft will reimburse the Dealer either the reasonable costs of repair or the reasonable costs of replacement of the defect, (Starcraft’s option), in accordance with the terms, conditions and limitations of this...
  • Page 19 RV to you. These items are usually detected and corrected at the factory. You must inspect the RV for this type of damage when you take delivery from Starcraft. If you find any such defect or damage you must notify Starcraft within three (3) days of delivery of the RV to you to have these items covered by this limited warranty and to have work performed on the items covered by this limited warranty.
  • Page 20 In addition, this warranty is not intended to extend to future performance, and nothing in this warranty, or any action of Starcraft, or any agent of Starcraft, shall be interpreted as an extension of the warranty or this limitation period.
  • Page 21 SECTION 2 TOWABLE OCCUPANT SAFETY 3. If it is large, or the fire is fuel-fed, get clear ECONDARY EANS OF SCAPE of the RV and have the Fire Department INDOW handle the emergency. Your RV has been equipped with a window(s) 4.
  • Page 22 SECTION 2 OCCUPANT SAFETY TOWABLE There are instances when the smoke detector alarm may not be heard. Though the alarm Do not check the pressure, test or practice horn in this detector meets or exceeds current using the fire extinguisher by squeezing UL standards, it may not be heard for many trigger, even...
  • Page 23 SECTION 2 TOWABLE OCCUPANT SAFETY Regardless of the manufacturer’s suggested battery life, you MUST replace the battery once the smoke alarm starts “beeping” (the Test the smoke alarm operation after the low battery warning). vehicle has been has been in storage, before each trip and at least once per For information on the correct battery and week during use.
  • Page 24 SECTION 2 OCCUPANT SAFETY TOWABLE The carbon monoxide detector installed is The following symptoms are related to intended ordinary indoor carbon monoxide poisoning and should be locations of recreation vehicles. It is not discussed with members designed to comply with Occupational household: Safety and Health Administration (OSHA) Mild exposure: Slight headache, nausea,...
  • Page 25 SECTION 2 TOWABLE OCCUPANT SAFETY If your alarm reactivates within a 24-hour period, repeat steps 1-4 and call a qualified appliance technician investigate The alarm will automatically sense when sources of carbon monoxide from fuel burning the level of carbon monoxide in the air equipment and appliances, and inspect for reaches below dangerous levels.

  • Page 26: F Ormaldehyde

    SECTION 2 OCCUPANT SAFETY TOWABLE Repair or replace the combination carbon monoxide/propane alarm when the alarm no longer functions. As with any electronic product, it has a limited life. Alarms that do not work cannot protect you.  NOTE: The carbon monoxide/propane alarm manufacturer strongly recommends replacement of the detector five years after the date of purchase.

  • Page 27: Tow Vehicle

    “burnish” fit or “seat” the shoes to the brake drum. After the initial break-in period your brake shoes Vehicle weight labels are posted on Starcraft must be adjusted accurately for best manufactured RVs so you can make an performance and increased durability.
  • Page 28 If you have further questions, please contact countertop, cooking pans on the range or your dealer or Starcraft Customer Service. free-standing furniture items can become dangerous projectiles during a sudden stop. 3 - 2...
  • Page 29 SECTION 3 STARCRAFT TOWABLE PRE-TRAVEL INFORMATION Distribute cargo side-to-side so the weight on Have your RV weighed periodically at a each tire does not exceed one-half of the public scale to determine the proper load GAWR for either axle. For traveling safety, it distribution.
  • Page 30 (tires, wheels, can cause damage to the RV frame. brakes, springs, etc.) on the heavier side Starcraft cannot be responsible for the tow could be overloaded, even though the total vehicle suspension system. The final ball axle load is within the GAWR.
  • Page 31 SECTION 3 STARCRAFT TOWABLE PRE-TRAVEL INFORMATION Make sure your dealer is aware of the tow A low hitch will transfer additional weight to vehicle you are using so a compatible hookup the hitch. Refer to the hitch manufacturer is achieved.
  • Page 32 SECTION 3 PRE-TRAVEL INFORMATION STARCRAFT TOWABLE Make sure the stabilizer jacks and entry  RAVEL RAILER EIGHT step are retracted to the travel position. ISTRIBUTING YSTEM USTOMER Make sure the tongue jack is retracted to  UPPLIED the travel position and the dolly wheel A weight distributing hitch system provides a removed (travel trailer);...
  • Page 33 SECTION 4 STARCRAFT TOWABLE TOWING & HANDLING 10. Attach the safety chains. riving safety and protection against injury cannot be fully ensured. However, we 11. Plug in your wire harness/connector plug recommend you pay special attention to the from the tow vehicle to the travel trailer.
  • Page 34 SECTION 4 TOWING & HANDLING STARCRAFT TOWABLE Always have the safety chains attached when 2. Make sure the hitch lever is in its open or towing. Install them as shown below so they “cocked” position unless it has been do not restrict sharp turns, but tight enough so designed to open automatically.

  • Page 35: Tabilizer J Acks

    SECTION 4 STARCRAFT TOWABLE TOWING & HANDLING Electric stabilizer jacks (if so equipped) Control switches for the stabilizer jacks are located on the (door) side of the unit above Fig. 4.2 the stabilizer jack(s). 7-way trailer plug - Car end,...
  • Page 36 Turning Corners When turning, the tires do not follow the path Towing items behind your Starcraft trailer, of your tow vehicle tires. The RV will make a or overloading the rear, will void the tighter turn than the tow vehicle. You must...
  • Page 37 SECTION 4 STARCRAFT TOWABLE TOWING & HANDLING IRES Read and understand the following before It is recommended that the tire pressure be taking your first trip in your RV! checked at the beginning of each journey to obtain the maximum life of the tire.
  • Page 38 SECTION 4 TOWING & HANDLING STARCRAFT TOWABLE INYL OVER QUIPPED Your tires are manufactured with components Do not use the stabilizer jacks to support that cause “bleeding” onto the tire cover. To the RV while under the vehicle or changing prevent this, it is recommended to use a tires.

  • Page 39: E Mergency S Topping

    For more information Tires are warranted by the tire manufacturer and are to be serviced and warranted by an appropriate service center. They are not to be returned to your dealer or Starcraft. If you have questions regarding your...
  • Page 40 SECTION 4 TOWING & HANDLING STARCRAFT TOWABLE NTENTIONALLY LANK 4 - 8...

  • Page 41: C Ircuit B Reakers

    SECTION 5 STARCRAFT TOWABLE ELECTRICAL SYSTEM The RV electrical system is comprised of two LECTRICAL independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry...

  • Page 42: Power Cord

    SECTION 5 ELECTRICAL SYSTEM STARCRAFT TOWABLE Exposure to voltages higher or lower than a circuit breaker identification label nominal 120-volts will damage or shorten the permanently attached to the inside surface of service life of the electrical system and the 120-volt load center.
  • Page 43 SECTION 5 STARCRAFT TOWABLE ELECTRICAL SYSTEM The power cord is also commonly referred to as the “shore power cord.” This power cord is designed to ground the RV electrical system Plugging the shoreline power cord into an through the external power source receptacle.

  • Page 44: Onverter

    SECTION 5 ELECTRICAL SYSTEM STARCRAFT TOWABLE When you are ready to leave, reverse the Test all GFCI receptacles monthly power cord connection process. Use care to Push in the GFCI “TEST” button.  prevent damaging the power cord electrical GFCI “RESET” button should pop out...
  • Page 45 SECTION 5 STARCRAFT TOWABLE ELECTRICAL SYSTEM Only connect the shore power cord to See the Specification section of this manual  properly wired power receptacles. for additional circuit breaker assistance. 30 amp systems: 30 amp NEMA TT30 120-volt UXILIARY ATTERY...

  • Page 46: Volt Fuse Panel

    SECTION 5 ELECTRICAL SYSTEM STARCRAFT TOWABLE To prevent this from occurring, disconnect the season, inspect all the 12-volt fuses and 7-way trailer plug or install a battery isolator. replace as needed. When the tow vehicle engine is operating with Replacing a fuse the RV connected, the tow vehicle charging system will charge both batteries.
  • Page 47 Your RV is equipped with a propane alarm system valve(s) and contact an independent (refer Sec. Safety Precautions, Starcraft dealer or qualified propane service Combination Carbon Monoxide (CO)/Propane representative immediately. Alarm.) Never use an open flame to test for a Propane cylinders should not be placed or propane leak.
  • Page 48 The capacity of ASME tanks is propane system inspected by an independent expressed in gallons. ASME tanks are filled Starcraft dealer or qualified propane service while the tank is tank is attached to the motor representative. home by a qualified propane facility. ASME...
  • Page 49 SECTION 6 STARCRAFT TOWABLE PROPANE SYSTEM  Servicing or filling NOTE: Tanks are to be installed, fueled and maintained in accordance to State and Local codes, rules, regulations or laws. Before entering a propane or fuel service Propane is a true gas compressed into a station make sure all pilot lights are liquid form.
  • Page 50 Keep the pigtail hose away from Starcraft dealer or a qualified propane sharp edges of the cylinder collar, rigid technician for assistance immediately. Do corners, walls, doors or other compartment not attempt to service a propane container structures including the cover.
  • Page 51 SECTION 6 STARCRAFT TOWABLE PROPANE SYSTEM 5. Place the cylinder on the bracket provided 4. Attach the second 24" hose to the tee on the A-frame and position it so the outlet check valve on the regulator and the right of the cylinder valve is pointed directly handed swivel nut to the cylinder valve.
  • Page 52 SECTION 6 PROPANE SYSTEM STARCRAFT TOWABLE 1. Check that ALL fittings are tight. After that, the cylinders must be "recertified" which provides another five years of use. The 2. Check that ALL connections are tested cylinders can be recertified every five years with a propane leak detector (or soapy thereafter.
  • Page 53 SECTION 6 STARCRAFT TOWABLE PROPANE SYSTEM The second stage is adjustable and will need It also has a left-handed thread, which means to be adjusted by your dealer or qualified that it is turned clockwise to remove, and propane service technician for optimum counter-clockwise to tighten.
  • Page 54 SECTION 6 PROPANE SYSTEM STARCRAFT TOWABLE If you have double cylinders on your RV, use only one at a time. Otherwise, the propane supply will be drawn equally from both cylinders until the supply has been totally Do not turn gas range burner controls ON exhausted.
  • Page 55 SECTION 6 STARCRAFT TOWABLE PROPANE SYSTEM RAVELING WITH ROPANE Use care when fueling your tow vehicle. Make certain your propane container is properly fastened in place. The label listed below should be kept permanently affixed to your Fig. 6.10 Refueling warning label...
  • Page 56 SECTION 6 PROPANE SYSTEM STARCRAFT TOWABLE NTENTIONALLY LANK 6 - 10...

  • Page 57: Monitor Panel

    SECTION 7 STARCRAFT TOWABLE PLUMBING SYSTEMS All water contains contaminant and mineral here are two different water systems in your particles that can cause fresh water system RV: the fresh water system and the waste odors. Untreated well water is a major source water system.
  • Page 58 SECTION 7 PLUMBING SYSTEMS STARCRAFT TOWABLE Water heater switch (if so equipped) To use the city water fill The "propane GAS" water heater switch 1. If needed, sanitize the water system. enables propane operation of the water 2. Remove the connection cap and attach a heater.
  • Page 59 SECTION 7 STARCRAFT TOWABLE PLUMBING SYSTEMS Follow the steps listed above; however, at step 3 put the other end of the non-toxic drinking water hose into your container of fresh water, and turn ON the water pump (instead of turning ON the water at the water source.) When the fresh water tank is full,...
  • Page 60 SECTION 7 PLUMBING SYSTEMS STARCRAFT TOWABLE Make sure the water heater is filled with water before use; even momentary operation of the water heater without water in it may result in Hydrogen gas may result if you have not damage to the tank and/or controls.
  • Page 61 SECTION 7 STARCRAFT TOWABLE PLUMBING SYSTEMS Anode rod protection To prevent a water leak when replacing the anode rod, a pipe thread sealant approved for potable water (such as Teflon Tape) must be applied to the threads of the anode rod.
  • Page 62 SECTION 7 PLUMBING SYSTEMS STARCRAFT TOWABLE The faucets operate much the same way as UTSIDE HOWER QUIPPED the faucets in your home. Make sure there is A handheld shower assembly with both hot sufficient water available and, if dry camping,...
  • Page 63 SECTION 7 STARCRAFT TOWABLE PLUMBING SYSTEMS 5. When you are finished, shut the water 2. Place a container beneath the water faucets OFF. cartridge filter to catch any spillage. Unlike your home, the RV does not contain a 3. Unscrew the fittings at the top and bottom water pressure balance valve.
  • Page 64 SECTION 7 PLUMBING SYSTEMS STARCRAFT TOWABLE 3. Prepare a chlorine solution using 1/4 cup of household bleach (sodium hypochlorite solution) to one gallon (3.785 liters) of Fig. 7.7 Low point water in a container. Prepare one gallon of drains solution for every 15 gallons of tank capacity.
  • Page 65 SECTION 7 STARCRAFT TOWABLE PLUMBING SYSTEMS  5. Pour one cup of non-toxic RV antifreeze NOTE: If a chlorine taste lingers in the into all drain P-traps (if so equipped). water, flush the water system with a solution consisting of one-quart vinegar to five gallons Demand or power plumbing system of clean water.
  • Page 66 SECTION 7 PLUMBING SYSTEMS STARCRAFT TOWABLE Drain pipes “P” trap (some models) The drain pipes may have a “P-trap” installed to help prevent odors from escaping into the Never travel with full black or grey water RV. During travel, water from the P-traps may holding tanks.
  • Page 67 SECTION 7 STARCRAFT TOWABLE PLUMBING SYSTEMS Guide and various other publications. Some LACK ATER OLDING ANKS fuel stations also have dump stations. When connected to the sewer drain line at a Please contact your RV dealer for assistance campground, keep the “black tank drain”...
  • Page 68 SECTION 7 PLUMBING SYSTEMS STARCRAFT TOWABLE 1. Release one to two quarts (1 or 2 liters) of water into the toilet bowl. 2. Follow the directions on your toilet chemical bottle (customer supplied), by placing the recommended quantity of holding tank chemical into the toilet bowl.
  • Page 69 SECTION 8 TOWABLE –EXPANDABLE MODELS TENT CARE If you note any water seepage or leaks after seasoning your tent let the tent dry, then spray water repellant using the instructions The tent canvas is a mildew resistant provided on the product container. One or fabric;...

  • Page 70: Bulb

    SECTION 8 TENT CARE TOWABLE – EXPANDABLE MODELS 3. From the interior, place the C-shaped end of Front bed the bed bow brace onto the bed bow 1. Re move the bunk mat from the front bed connector (Fig. A). Push the bed bow brace platform , set aside.
  • Page 71 SECTION 8 TOWABLE –EXPANDABLE MODELS TENT CARE If the tent or hinge cover is not clear of the door Store the bunk mat between bed platform edges, the door will not close and seal tightly, and the interior wall. You will need to slide and/or damage to the bulb seal may occur.
  • Page 72 SECTION 8 TENT CARE TOWABLE – EXPANDABLE MODELS more stubborn stains, following products are recommended by the tent fabric manufacturer using either a sponge, soft cloth r soft bristle brush: ~OxiClean® ~Mild liquid detergent ~Resolve® Carpet Cleaner When using any of the above products, please follo...
  • Page 73 SECTION 9 TOWABLE SLIDEOUT SYSTEM 1. The auxiliary battery (customer supplied) must be fully charged and connected. If possible, the RV should be hooked up to Ensure that the trailer is level before 120-volt AC power so the converter operating the slideout room. Water leaks operates.
  • Page 74 SECTION 9 SLIDEOUT SYSTEM TOWABLE The Lippert Electric slide comes with a ROUBLESHOOTING LIDEOUT manual over ride system. Locate the crank If the slideout does not move when the extension with pin outside of the chassis main slideout switch is depressed, follow these rail as, Fig.
  • Page 75 SECTION 9 TOWABLE SLIDEOUT SYSTEM 4. Using the wall switch, press and hold the “in” button until the unit comes completely Fig 8.4 Crank Handle MANUAL OPERATION - IN FRAME Fig 8.7 Slideout System Circuit Board During this override procedure the motors are not synchronized.
  • Page 76 SECTION 9 SLIDEOUT SYSTEM TOWABLE NTENTIONALLY LANK 9 - 4...
  • Page 77 SECTION 10 STARCRAFT TOWABLE CAMPING & OPERATING y purchasing your RV you have entered into ONDENSATION lifestyle that encourages long-lasting friendships. People who camp next to one another for a few days are allowed the unique opportunity to cultivate new acquaintances Condensation needs to be taken seriously.
  • Page 78 SECTION 10 CAMPING & OPERATING STARCRAFT TOWABLE Uncontrolled condensation cause 6. Gently put your truck into reverse (don’t dampness, mildew, etc., inside your RV. Be give fuel/acceleration). This sure make strong effort control effectively moves the kingpin off the condensation. Repairs due to condensation...
  • Page 79 SECTION 10 STARCRAFT TOWABLE CAMPING & OPERATING -A-B & C QUIPPED TANDING ABLE HAIRS QUIPPED The hide-a-bed sofa functions much the same as a regular residential hide-a-bed sofa. To The free standing dinette table can be make the hide-a-bed sofa into a bed, remove positioned to seat up to four people.
  • Page 80 SECTION 10 CAMPING & OPERATING STARCRAFT TOWABLE Rotate the knob for best picture. REASE Fig. 10.4 Fig. 8.5 Do not attempt to use water to put out the fire. Water can spread some types of fire, and electrocution is possible with an Lowering the antenna electrical fire.
  • Page 81 SECTION 10 STARCRAFT TOWABLE CAMPING & OPERATING To pull the kitchen base out, first lift up on the latch pin on the front of the kitchen base During and after use, do not touch or let cabinet. Once the latch pin has cleared the...
  • Page 82 SECTION 10 CAMPING & OPERATING STARCRAFT TOWABLE Slowly push the kitchen unit back to the retracted position. Insert the front latch bolt into the locking sleeve. Push the latch bolt to the lock position (laying flat against the The maximum weight limit for the bracket cabinet).

  • Page 83: T Hermostat

    SECTION 10 STARCRAFT TOWABLE CAMPING & OPERATING Please refer to the awning manufacturer’s This also will lead to a loss of air volume, operators manual. Keep your awning in good possible equipment damage condition to prevent costly repairs. It is very expensive cleaning process.
  • Page 84 SECTION 10 CAMPING & OPERATING STARCRAFT TOWABLE Exterior _ Empty black holding tank furnace should inspected _ Empty gray holding tank periodically (monthly during the heating _ Lock all exterior compartments season) for presence of soot on the vent. _ Pack equipment into compartments and...
  • Page 85 SECTION 11 TOWABLE STORAGE & MAINTENANCE Vinyl Upholstery (if so equipped) roperly preparing your RV for storage during Do not dry clean vinyl components. If they are periods of non-usage will prevent problems dry cleaned, the vinyl on the reverse side will from arising.

  • Page 86: F Looring

    SECTION 11 STORAGE & MAINTENANCE TOWABLE Do not use harsh chemicals or sprays. A mild Always use a cutting board; never use a  solution of vinegar and water works well to knife on the countertop. remove hard water spots and stains from the Avoid harsh chemicals such as drain ...
  • Page 87 SECTION 11 TOWABLE STORAGE & MAINTENANCE To avoid problems of “yellowing” linoleum, the Anti-freeze, gasoline or washer solvents if flooring manufacturer recommends avoiding spilled on the painted surface should be cleaners that contain oil based solvents (i.e. rinsed off with water immediately. Bugs and cleaners containing lemon oil, Murphy’s Oil bird droppings should be rinsed off daily.
  • Page 88 SECTION 11 STORAGE & MAINTENANCE TOWABLE Some types of hot water washing equipment apply high pressure and heat to the RV. They may cause heat distortion and damage to the Do not use waxes containing high-abrasive resin parts and may flood the RV's interior. compounds.

  • Page 89: Rear Bumper.

    SECTION 11 TOWABLE STORAGE & MAINTENANCE & L OORS OCKS Locks on entrance and baggage doors need Do not allow plastic to come into contact biannual lubrication using a light coat of with brake fluid, engine oil, grease, paint silicone spray. Do not permit the spray to thinner, or battery acid.

  • Page 90: S Ealants

    SECTION 11 STORAGE & MAINTENANCE TOWABLE The rear bumper of your RV is not designed Always use the same type of sealant that  to carry cargo. Items that extend beyond the was removed. Your dealer service or bumper OR weigh over 100 lbs. (45kg) will parts manager can help you obtain the place undo strain on the bumper.
  • Page 91 SECTION 11 TOWABLE STORAGE & MAINTENANCE Although these diagrams may not accurately ~ To prevent weather checking and other UV reflect the exact model of your RV, make sure damage, cover tires that are exposed to you inspect all sealants as indicated in the sunlight.
  • Page 92 SECTION 11 STORAGE & MAINTENANCE TOWABLE Each Trip ~ Inspect and reseal as needed. ~ Check auxiliary battery equipped). ~ Have the propane system checked for leaks by your dealer. ~ Check running lights. ~ Check tire pressure and wear, including spare (if so equipped).

  • Page 93: Chart

    SECTION 12 TOWABLE SPECIFICATIONS OEM L The following chart provides information to contact some of the individual original equipment manufacturers (OEM) of appliances/component parts that may be installed on your RV. The information listed in this chart is the latest available at the time of publication of this manual. If you have questions or concerns on component parts not listed here, contact your RV dealer for further assistance.
  • Page 94 SECTION 12 SPECIFICATIONS TOWABLE HEEL ORQUE HART 12 - 2...
  • Page 95 SECTION 12 TOWABLE SPECIFICATIONS DC F ANEL AYOUT Below is a typical wiring layout. Your individual trailer may be different. Size Function — Open 15 amp fuse Bathroom Lights & Vent 15 amp fuse Pump/Monitor Panel/Range Hood/Sink Lights 15 amp fuse Refrigerator/Furnace 15 amp fuse Bedroom...
  • Page 96 SECTION 12 SPECIFICATIONS TOWABLE PPROXIMATE LECTRICAL ATINGS Use actual amperage (or wattage divided by 120) of appliance being used whenever possible. 120 VOLT SYSTEM AIR CONDITIONER - COLEMAN MACH 13,500 BTU (RUN) 13.50-16.25 AMPS AIR CONDITIONER - COLEMAN MACH 13,500 BTU (START UP) 15.75-16.25 AMPS* BLENDER (ESTIMATED 300-400W) 2.50-3.50 AMPS...
