Page 1 Travel Trailers 2021 Owner’s Manual A subsidiary of Thor Industries, Inc. 0335747.2021...
Page 3 Travel Trailer Hitching Procedure Travel Trailer Weight Distributing System (customer supplied) Travel Trailer Sway Control (customer supplied) Travel Trailer Safety Chains Wire Harness/Connector Plug Safety Chain Installation Weighing Your Tow Vehicle and RV 2021 Starcraft Super Lite RevA: Revise page 12...
Page 4 Table of Contents Section 4: Vehicle Operation Towing RV Brake System Electric Brakes Brake Controller (customer supplied) Travel Trailer Breakaway Switch Hydraulic Brakes (if so equipped) Towing Behind Your RV Entrance Door Step(s) Entrance Door Disc Brakes (if so equipped) Rear Vision Camera Prep/Camera (if so equipped) Campsite Hook-Up Stabilizer Jacks...
Page 5 Table of Contents Section 6: Electrical System The Electrical System In Case Of An Electrical Fire Command Center Command Center Panel Command Center Panel w/Switch Modules GFCI Receptacle Testing The Campsite Power Connection Power Converter Converter w/Charge Wizard (if so equipped) 12-Volt DC System 12-Volt Fuse Panel Replacing a Fuse...
Page 6 Table of Contents Section 8: Plumbing System Plumbing System Plumbing System Maintenance Monitor Panel Monitor Panel Command Center Fresh Water System Water Pressure Regulator (customer supplied) Draining The Fresh Water System Water Pump Strainer Exterior Fresh Water Drain Low Point Drains Sanitizing/Winterizing the Plumbing System Water Heater Bypass –...
Page 7 Table of Contents Attaching the “Quick Coupler” Connection Quick Connect Coupler Range Hood (if so equipped) Refrigerator Water Heater – See Plumbing Section Outside Kitchen (if so equipped) Quick Connect Coupler Exterior Refrigerator LP Gas Grill (if so equipped) Cleaning the Grill Section 11: Electronics Antenna HDTV Antenna (if so equipped)
Page 8 Table of Contents Section 15: Additional Information Featured Components Quick Reference Chart Vehicle Maintenance Record Ownership Notification...
Page 9: Section 1: Warranty & Service
Section 1: Warranty & Service WARNING: Read all instructions in this manual and component manufac- turer supplied information before using your RV. This manual has been provided by your recreational vehicle manufacturer for the sole pur- pose of providing instructions concerning the operation and maintenance of this recreational vehicle.
Page 10 Canada may differ to conform to Canadian Codes. Dealer Responsibility At the time of sale of the new RV, your Starcraft dealer is expected to: Deliver your RV in the best condition possible. Your RV must pass the dealer’s pre-delivery inspection (PDI), including all systems tests.
Page 11 (or any effect of the alterations) to any of the parts, components, systems or assemblies installed by Starcraft. Starcraft is not responsible for the safety or quality of design features, materials or workmanship of any alterations by such suppliers.
Page 12: About This Manual
Canada. In addition, the club offers a variety of local and regional activities throughout the year. By belonging to the Starcraft Camper Club, you will find new ways to enjoy your RV and make friends all across the country.
Page 13: Safety Alerts
Section 1: Warranty & Service Safety Alerts Throughout this manual, certain items are labeled NOTE, CAUTION, WARNING, and DANGER. These terms will alert you to precautions that can involve risk to your vehicle or to your personal safety. Read and follow them carefully. National Safety Associations and organizations require many of the instructions listed.
Page 14: Reporting Safety Defects
Section 1: Warranty & Service Reporting Safety Defects In the United States: If you believe that your recreation vehicle has an alleged defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying our Cus- tomer Service Department.
Page 15: Customer Responsibility
Section 1: Warranty & Service Customer Responsibility It is important you read and understand all instructions and precautions before operating the recreation vehicle. Even if you are an experienced RV’er we encourage you to thoroughly read this Owner’s Manual, as well as the information contained in your Warranty Packet and Chassis Guide (motorized only).
Page 16: Obtaining Service For Separately Warranted Items
Section 1: Warranty & Service Obtaining Service For Separately Warranted Items Your selling dealer is responsible for servicing your recreational vehicle before delivery, and has an interest in your continued satisfaction. We recommend your dealer perform all inspection, warranty and maintenance services. Some dealers may be authorized service centers for those OEMs whose products are warranted separately and excluded from the Limited Warranty.
Page 17 RV is delivered to the first retail purchaser by an independent, authorized dealer of Starcraft, or, if the dealer places the vehicle in service prior to retail sale, on the date the RV is first placed in such service.
Page 18 Pay any freight or transportation costs, import duties, fees and all incidental expenses associated with obtaining warranty service. If you need assistance you may contact Starcraft RV at 903 S. Main Street, P.O. Box 460, Middlebury, Indiana 46540, Attn: Customer Service, (800) 283-8267.
Page 19 10 days of your discovery of the substantial defect; AND (2) you deliver the RV to Starcraft or an authorized dealership at your cost and expense. If this primary repair remedy fails to successfully cure any substantial defect after a reasonable number of repair attempts, your sole and exclusive remedy shall be to have Starcraft pay an independent service shop of your choice to perform repairs to the substantial defect.
Page 20 Certain things completely discharge Starcraft from any obligation under this warranty and void it. By way of example, the following shall discharge Starcraft from any express or im- plied warranty obligation to repair or replace any defect that results from: any rental or other...
Page 21 In addition, this warranty is not intended to extend to future performance, and nothing in this warranty, or any action of Starcraft, or any agent of Starcraft, shall be interpreted as an extension of the warranty period or this limitation period. Some states do not allow a reduc- tion in the statute of limitations, so this reduction may not apply to you.
Page 22 Section 1: Warranty & Service STARCRAFT RV 903 S. Main Street * P.O. Box 460 * Middlebury, IN 46540 Telephone: (800) 283-8267 Maintenance Record Table of Contents...
Page 23: Section 2: Occupant Safety
Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emer- gency if access to the main entrance door is not available.
Page 24: Fire Safety
Section 2: Occupant Safety Lever style latch Remove the screen by pulling the red tab (upper rightarrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the win- dow. Push the lever (and window) out to open and exit the ve- hicle.
Page 25: Smoke Alarm
Section 2: Occupant Safety Do not check the pressure, test or practice using the fire extinguisher by squeezing the trigger, even briefly. The fire extinguisher is not rechargeable or refillable. Once used, it will gradually lose pressure and will not be fully charged for use in an emergency.
Page 26: Combination Carbon Monoxide /Propane Alarm
Section 2: Occupant Safety cleared. The LED light will also give a visual indication of a sounding alarm. When the battery becomes weak, the alarm will “beep” about once a minute indicating a low battery. This warning should last for 30 days. You MUST replace the battery once the alarms low battery warning (beep) starts to assure continued protection.
Page 27 Section 2: Occupant Safety Do not cover or obstruct the carbon monoxide/propane alarm with any- thing that could prevent gas from entering the alarm. This alarm is not designed to detect smoke, fire or gases other than car- bon monoxide and propane. The carbon monoxide detector installed is intended for use in ordinary indoor locations of recreation vehicles.
Page 28 Section 2: Occupant Safety fumes, adhesives, lacquer, kerosene, glues, wine, liquor, most cleaning agents and the pro- pellants of aerosol cans. High temperatures can activate glue and adhesive vapors. If you close up a recreational vehicle on a hot day, the chemicals used in its construction may be detected for months after the vehicle was constructed (for more information, refer to Sec.
Page 29 Section 2: Occupant Safety recreation vehicle. If problems are identified during this inspection, have the alarm serviced immediately. Note any combustion equipment not inspected by the technician and consult the manufacturer’s instructions or contact the manufacturer directly for more information about carbon monox- ide safety and this alarm.
Page 30: Extended Or Full Time Usage
Section 2: Occupant Safety Repair or replace the combination carbon monoxide/propane alarm when the alarm no lon- ger functions. As with any electronic product, it has a limited life. Alarms that do not work cannot protect you. NOTE: The carbon monoxide/propane alarm manufacturer strongly recommends replacement of the detector five years after the date of purchase.
Page 31 Section 2: Occupant Safety Condensation Condensation may cause dampness, mildew, mold, staining and, if allowed to continue, it may result in damage to the recreation vehicle (damage caused by condensation is not warrantable). It can also lead to mold or mildew issues, which could be a health hazard.
Page 32 Section 2: Occupant Safety Maintenance Record Table of Contents...
Page 33: Section 3: Pre-Travel Information
Section 3: Pre-Travel Information Tow Vehicle If you plan to tow your recreation vehicle with a tow vehicle you already own, or if you plan to purchase a new one, make sure the Gross Vehicle Weight Rating (GVWR) or your recreation vehicle does not exceed your tow vehicles towing rating.
Page 34 Section 3: Pre-Travel Information OCCC Label (Occupant and Cargo Carrying Capacity The upper portion of this yellow label is federally required and includes the maximum Occupant & Cargo Carrying Capacity that may be placed in or on the trailer as it was manufactured and weighed before leaving the factory.
Page 35: Loading Your Recreation Vehicle
Section 3: Pre-Travel Information Loading Your Recreation Vehicle Never load the RV in excess of the GAWR for either axle. Overload- ing your RV may result in adverse handling characteristics and dam- age to the RV. DO NOT EXCEED YOUR GVWR! This means you should weigh your RV as loaded for your normal travel to determine the actual weight.
Page 36: Rear Bumper
Section 3: Pre-Travel Information Rear Bumper The rear bumper of your RV is not designed to carry cargo. Items that extend beyond the Do not add items to the recreation vehicle rear bumper. Add-on items will eventually damage your bumper. Damage caused by such aftermarket equip- ment installation or improper loading voids the Towable Limited Warranty.
Page 37 Section 3: Pre-Travel Information Travel Trailer Hitch Weight Maintain the proper tongue weight of the trailer. Stay within the target range of 10%-15% of the overall gross weight (travel trailer weight plus contents). Travel Trailer Hitch Height and Hitch Ball To determine the hitch height for your model, make sure that the trailer is level.
Page 38 Section 3: Pre-Travel Information Travel Trailer Weight Distributing System (customer supplied) This system provides a more stable tow vehicle/RV combination as it will spreads the weight evenly to distribute it to the tow vehicle front and rear axles and the trailer axle. Consult with your dealer for information on requirements and operation of this system.
Page 39: Wire Harness/Connector Plug
Section 3: Pre-Travel Information Safety Chain Installation Wire Harness/Connector Plug A 7-way wire harness/connector plug is wired into your trailer to connect electrical power from the tow vehicle for travel. This supplies power to the RV brakes, taillights, clearance lights, turn signals, brake lights, etc. Wiring to operate your brakes must be the same size in both the tow vehicle and RV (the RV brake wiring is 12-gauge wire).
Page 40 Section 3: Pre-Travel Information The connector plug may build up corrosion with extended use. It should be cleaned peri- odically to insure good electrical contact. Make sure the connector plug is kept clean and protected from road elements as you travel. NOTE: A 12V circuit tester is recommended to verify the trailer connections.
Page 41 Section 3: Pre-Travel Information With the RV still attached to the tow vehicle, weigh each wheel position separately to ensure each tire is not overloaded. To determine the wheel position weight: Pull the RV onto the scale so only one tire is on the scale. Record the weight. Your RV must remain as level as possible on the scale (even though an axle or side is not physi- cally on the scale).
Page 42 Section 3: Pre-Travel Information Notes: Maintenance Record Table of Contents...
Page 43: Section 4: Vehicle Operation
Section 4: Vehicle Operation Towing If your RV is equipped with the Command Control Bluetooth system, make sure you turn off your battery disconnect switch according to the following instructions. BEFORE TOWING YOUR RV ON THE ROADWAY: TURN OFF THE BATTERY DISCONNECT SWITCH! Certain components inside the RV can unexpectedly activate which could result in personal injury or property damage.
Page 44 Section 4: Vehicle Operation When descending a long hill, drop down into a lower gear or range. Avoid conditions that require excessive and prolonged use of your brakes. Apply and release brakes at short inter- vals to allow them to cool. The tow vehicle transmission and engine will help in controlling downhill speed and can lengthen brake life.
Page 45 Section 4: Vehicle Operation system working properly. Brake Controller (customer supplied) The brake controller should be installed in the tow vehicle to work in conjunction with the RV electric brakes. Consult with your dealer or the brake controller OEM to decide what is right for your towing combination.
Page 46: Towing Behind Your Rv
Section 4: Vehicle Operation the bottom of its travel. Push the lever down to engage the locking notch. The RV will now back up. This lever will slide into the correct position when pulling forward. It is extremely important to keep the master cylinder full at all times. An empty cylinder invites moisture.
Page 47: Campsite Hook-Up
Section 4: Vehicle Operation Keys Several keys are provided when you purchase your vehicle. Most keys have an individual key number stamped on the plate. Record these key numbers and keep the information in a safe place. You can order a key blank from your dealer to have duplicate keys made. If you lose the keys, contact your dealer or a locksmith for assistance.
Page 48: Stabilizer Jacks
Section 4: Vehicle Operation NOTE: For extended dry camping, management of all your re- sources is essential. Check your battery levels and conserve battery power, use it sparingly Stabilizer Jacks DO NOT USE THE STABILIZER JACKS TO LEVEL THE RV. It is important to remember that the stabilizer jacks are to be used only for support while occupying and moving around the RV.
Page 49: Emergency Stopping
Section 4: Vehicle Operation NOTE: The gears can be stripped out if the stab jack is manually retracted/extended to its fullest extent and the operator continues to rotate the manual override. Emergency Stopping Always carry road flares or reflective warning signs. Pull off the roadway as far as possible for emergency stopping.
Page 50: Wheel Lugs
Section 4: Vehicle Operation Wheel Lugs After your first trip, check the wheel lug torque periodically for safety. Check the wheel lugs after winter storage, after a wheel removal, before starting a trip or following extensive braking: Use the correct star pattern sequence to attach the recreation vehicle wheels. Start all nuts by hand to prevent cross threading.
Page 51 Section 4: Vehicle Operation Wheel Lug Nut Torque Values Prior to travel and after excessive braking, wheel lug nuts should be checked for torque. Torque readings must fall within the Final Torque Values in chart above. Torque specifications should be checked using a proper torque wrench. If the torque falls below the Final Torque Values, additional torque is required.
Page 52 Section 4: Vehicle Operation Torque Wrench Usage Tools should be maintained, in good condition, and stored appropriately. • Avoid dropping or sliding a torque wrench. Dropping it can cause the instrument to lose reliable calibration. • Damaged tools must not be used and must be removed from service for evaluation and either reported and re-calibrated or replaced.
Page 53 Section 4: Vehicle Operation Tire wear should be checked frequently. Once a wear pattern becomes firmly established in a tire it is difficult to stop, even if the underlying cause is cor- rected. Maintenance Record Table of Contents...
Page 54: Changing A Tire
Section 4: Vehicle Operation NOTE: Cold tire inflation pressure is defined as a tire that has not been used for three or more hours, or has been driven less than one mile. Tire inflation pressure of a hot tire may show an increase of as much as 6 psi over a cold tire.
Page 55: Spare Tire Carrier (If So Equipped)
Section 4: Vehicle Operation If you experience a flat tire on your recreational vehicle while driving, gradually decrease your speed and move the recreational vehicle to a safe place on the side of the road. Keep the recreational vehicle attached to the tow vehicle. Block the tire on the opposite side of the recreational vehicle from the tire you are changing.
Page 56 Section 4: Vehicle Operation Raising and lowering the hoist The crank handle to raise and lower the tire will be located (fastened to the sidewall) in a basement compartment of the recreational vehicle. Insert the crank handle into the crank access port located either in the center of the rear bumper, or on the sidewall of the RV.
Page 57: Setting Up Your Recreation Vehicle
Section 4: Vehicle Operation To install the tire on the tire carrier Place the tire on the carrier with the top lug bolt inserted into one of the holes in the tire rim and the bottom lug bolt in the center of the rim. Install the top lug nut.
Page 58: Awnings (If So Equipped)
Section 4: Vehicle Operation Awnings (if so equipped) Awnings must be closed (and locked if applicable) while the RV is in transit. The effects of wind and rain on an awning are unpredictable and can cause severe damage to the awning and/or the recreation vehicle. Retract the aw- ning if: If wind or extended periods of rain are expected If you leave the RV unattended for a length of time, to avoid unexpected...
Page 59: Section 5: Slideout Systems
Section 5: Slideout Systems Electric Slide Room(s) (if so equipped) The mechanical components of the slide out are gear driven. Electric powered slideout room systems have a manual override to allow you to extend or retract the slideout room(s) in case of a power loss.
Page 60 Section 5: Slideout Systems To retract the slideout, press the in section of the slideout control switch and hold it until the slideout is fully retracted. Operating the switch after the room is fully extended or retracted may damage the switch and motor.
Page 61 Section 5: Slideout Systems NOTE: For long-term storage it is recommend the room be closed (retracted). Trouble shooting the flush floor slideout Refer to the general troubleshooting check list before proceeding. Electric Operation NOTE: Install transit bars (if so equipped) on the slideout room during storage and transportation.
Page 62 Section 5: Slideout Systems DO NOT attempt to disengage the motor as the actuator is “manual ready”. Schwintek In-Wall Slideout System The in-wall slideout system requires no maintenance or adjustments. This system has two vertical columns with a drive motor located at the top of each column. The right and left motors are synchronized by a circuit board.Schwintek slideouts are typically used on both towables and motorhomes.
Page 63 Section 5: Slideout Systems Trouble shooting the in-wall slideout system Checking Fuses: The in-wall slide requires a minimum 30-amp fuse. Check the load center for blown fuses and replace any if necessary. If the fuse blows immediately upon replace- ment, there is a problem with the wiring to the in-wall slide control box. A qualified service person should be called to check and repair.
Page 64 Section 5: Slideout Systems Using either a wall or command center panel switch, press and hold the switch toward the word IN or RETRACT until the unit comes in completely. This will allow you to get the recreation vehicle to a service center to have the slideout malfunction diag- nosed.
Page 65 Section 5: Slideout Systems Repeat this process for both sides of the slide room. Physically push/ pull the room back into the opening; keep both sides relatively even. The room must be travel locked to keep the room in place for road travel. DO NOT MOVE THE RV UNLESS THE MOTORS ARE PLUGGED IN TO THE CONTROLLER AND THERE IS BATTERY POWER TO THE RV.
Page 66 Section 5: Slideout Systems Norco Slideout Manual Operation Locate the included flexible shaft in your own- er’s packet. Attach flexible shaft to the 1/4” hex fitting on the end of the motor. Attach 1/4” socket & ratchet, or drill to the other end, and turn in the proper direction to move the room.
Page 67 Section 5: Slideout Systems If the room does not move when the switch is pressed, check the following: Make sure the slideout system is turned on. Battery is fully charged and connected. Transit bars have been removed (if so equipped). When the motor brake is disengaged the slideout room WILL NOT lock into place and will not be sealed.
Page 68 Section 5: Slideout Systems The room is now free to move. Using either a 5/8” or 3/4” wrench or socket, crank the room either in or out completely. If the slideout system is supplied with a gearbox override (optional), use the crank handle to move the room.
Page 69 Section 5: Slideout Systems Turn ON the on/off switch or key. Press and hold the OUT button (Fig 4). To retract, press and hold the IN button. There will be a slight delay be- fore the room begins moving. The GREEN LED should be solid ON when room is in motion.
Page 70 Section 5: Slideout Systems -Check all connections at control box and motor. -Bad or loose connec- Excessive -Check the harness for bro- tion Major Battery Volt- ken wires. -Defective harness -Put 12.0 VDC direct to -Open or shorted motor the motor. If it does not run replace the motor.
Page 71 Section 5: Slideout Systems NOTE: After overriding the system, the room control will need to be re-programmed by an OEM authorized dealer. Emergency Retract Mode Use this procedure when there is NO loss of power or electrical problem with the system. Remove the touchpad (Fig 4) from the wall.
Page 72 Section 5: Slideout Systems Unplug the motor from the harness and remove the motor by lifting it up and out. Repeat steps 1-4 for the other side. Place a socket wrench with a 3-inch extension and a 5/8” deep well socket (Fig 12) through the motor access opening and seat the socket onto the coupler (Fig 13).
Page 73 Section 5: Slideout Systems Power Gear Ram Slideout System Typically used for Class C motorhomes. Manual Override Procedure The system has been equipped with 3/4” hex override couplers located on the drive compo- nent of the system. Due to the size and weight of some rooms, assistance may be needed to push the room in.
Page 74 Section 5: Slideout Systems 11. When the slideout is retracted, check to make sure you have a good seal, and re- place the skirting on the slideout. 12. Return the brake release lever back to the “engaged” position (parallel to the spring lock lever).
Page 75: Section 6: Electrical System
Section 6: Electrical System The Electrical System The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture. Because the electrical equipment and associated circuitry are engineered into a dedicated system specific to your RV, do not make unauthorized changes or add fixed appliances to it.
Page 76: Command Center
Section 6: Electrical System Command Center The command center is typically located inside the entrance door or in the living area of the RV, and contains switches and controls for various electrical functions. Command center applications, configurations and components will vary by model. Command Center Panel or Command Center Panel with Switch Modules Items found on these panels may include:...
Page 77: Gfci Receptacle
Section 6: Electrical System GFCI Receptacle There is a ground fault current interrupter (GFCI) engineered into the electrical system. It is designed to reduce the possible injury caused by electric shock. The GFCI will not protect against short circuits or circuit overloads. Test all GFCI receptacles monthly: Push in the GFCI “TEST”...
Page 78 Section 6: Electrical System Do not hook up the power cord to any receptacle until you have verified proper polarity and grounding. DO NOT plug the shore power cord into a campsite receptacle(s): That has reverse polarity With non-functioning ground circuits That shows outward signs of heat damage.
Page 79: Power Converter
Section 6: Electrical System The shore power cord should be unplugged when the recreation vehicle is left unattended When you are ready to leave, reverse the power cord connection process. Use care to pre- vent damaging the power cord electrical connection pins when connecting or disconnecting the shore power cord.
Page 80 Section 6: Electrical System An open wire between the converter and the RV battery Loose ground connection Improper torques If the converter fuses and AC voltage are good, but the converter output still reads zero volts, the converter is not functioning properly. Modes of Operation: Absorption (Normal) Mode: 13.6VDC range.
Page 81: Volt Dc System
Section 6: Electrical System 12-Volt DC System The majority of your recreation vehicle lighting is powered by 12-volt electricity. The 12- volt DC system is composed of components that will operate when the following conditions are met: Power is supplied by the tow vehicle alternator when the engine is running and the 7-way trailer plug is connected.
Page 82: Auxiliary Battery (Customer Supplied)
Section 6: Electrical System Auxiliary Battery (customer supplied) Do not store anything inside the battery compartment(s) or near the batteries that could touch the battery or battery cable terminals. Contact with the battery or battery cable terminals could cause an electrical short circuit, discharge the batteries, or start an electrical fire.
Page 83 Section 6: Electrical System Replacement and Maintenance Some equipment in your RV will draw small amounts of current even when turned OFF. To prevent the auxiliary battery from being discharged when your RV is not connected to shore line power, disconnect the auxiliary battery negative cable at the battery. During storage, it is important to check the voltage monthly and recharge the auxiliary battery as needed.
Page 84: Load Center
Section 6: Electrical System Load Center The Load Center contains 12VDC fuses and 120VAC circuit breakers for almost all of the electrical appliances and cir- cuits in the RV. The 120V main breaker may be located in this panel and will turn off all 120-volt power to the RV.
Page 85: Approximate Electrical Load Ratings
Section 6: Electrical System and must be replaced as needed as part of your RV maintenance. If you have any questions, contact your dealer. A label is provided to explain the function of every 120-volt circuit breaker. This label is located on or near the appropriate load center or sub-panel and must remain permanently affixed to the recreation vehicle.
Page 86 Section 6: Electrical System 120 VOLT SYSTEM Air Conditioner 18 AMPS Coffee Maker 6-12 AMPS Converter (each) 8 AMPS DVD System 3 AMPS Fireplace 15 AMPS Hair Dryer or Curling Iron 10-14 AMPS Microwave 15 AMPS Refrigerator 6 AMPS Satellite Receiver 2 AMPS 2-4 AMPS Vacuum Cleaner...
Page 87 Section 6: Electrical System 30 AMP Power Cord (if so equipped) Do not hook up the power cord to any receptacle until you have verified proper polarity and grounding. Polarity indicators can be purchased in most electrical and hardware stores. Do not use any cheater plug, adapter or extension cord to reconfigure incoming AC power or break the continuity of the circuit connected to the grounding pin.
Page 88 Section 6: Electrical System 120-Volt 50 AMP AC Electric System (if so equipped) The 50 amp 120-volt 60hz AC electrical system can be powered by an outside 120/240-volt 60hz utility service like those commonly found in campgrounds or by 120/240-volt 60hz generator power.
Page 89: Solar Prep (If So Equipped)
Section 6: Electrical System The shore power cord is designed to continuously carry the 50-amp current flow required to power each leg of the electrical system. It also creates a critical ground connection between the vehicle electrical system and the campground shore power receptacle. Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it.
Page 90 Section 6: Electrical System Notes: Maintenance Record Table of Contents...
Page 91: Exhaust Gas Fumes
Section 7: Fuel & Propane System Exhaust Gas Fumes Avoid inhaling exhaust gases as they contain carbon monoxide, which is a potentially toxic gas that is colorless and odorless. If you are in a recreation vehicle with either a nearby tow vehicle engine running or the generator (if so equipped) running there is a potential for exhaust fumes to filter back into the recreation vehicle.
Page 92 Section 7: Fuel & Propane System Continued periodic checks of the propane system at 5,000 miles of travel (or at least once a year), by a qualified propane service representative as part of your normal maintenance is recommended. Hand tighten the LP gas system valves only, do not use a wrench or pliers as over tightening may damage the valve seals and cause them to leak.
Page 93 Section 7: Fuel & Propane System Be sure to securely re-install DOT cylinder(s) after they have been removed for filling or replacement. Always close the service valve and install a dust cap or plug when transporting or storing disconnected containers whether full or empty. ASME tanks are permanently mounted to the RV and are commonly used on RV mo- torhomes.
Page 94 Section 7: Fuel & Propane System The position of the propane container(s) and the hoses are critical to proper operation and propane flow. Follow these instructions to make sure your propane container(s) are connected properly. LP Gas Container Overfill Never allow your propane tank to be filled above the maximum safe level as indicated by the fixed liquid level gauge.
Page 95 Section 7: Fuel & Propane System Fittings are used to connect the various system components to each other. The P.O.L. fitting at the end of the propane supply hose is made of brass so that pipe sealants are not necessary to prevent leaking.
Page 96: Propane Use And Safety
Section 7: Fuel & Propane System Propane Use and Safety Propane is a colorless and odorless gas that, in the lique- fied state, resembles water. An odorant (usually a sulfur compound) is added as a warning agent. If you smell propane within the vehicle, quickly and carefully per- form the procedure listed on the propane system label.
Page 97 Section 7: Fuel & Propane System tally exhausted. Using one cylinder until it is empty and then using the second cylinder will allow you to fill the empty cylinder at your convenience without running out of propane. Cooking With Propane Gas Do not turn gas range burner controls to ON and allow gas to escape before lighting.
Page 98: Installing Propane Cylinder(S)
Section 7: Fuel & Propane System Traveling With Propane NOTE: Some states prohibit propane appliances to be oper- ated during travel, especially in underground tunnels. Know the laws for the areas where you travel. Use care when fueling your motor fuel tanks and/or propane containers.
Page 99 Section 7: Fuel & Propane System Attach the 1/4” inverted flare x 24” Type 1 pigtail hose to the regulator inlet and the right hand swivel nut to the cylinder valve. Secure the cylinder to the A-frame bracket using the bolts, nuts and washers provided. Double Cylinder Mounted On A-Frame (if so equipped) When a second cylinder is installed, a tee check valve is used to replace the 90°...
Page 100 Section 7: Fuel & Propane System Notes: Maintenance Record Table of Contents...
Page 101: Plumbing System
Section 8: Plumbing System Plumbing System There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, faucets and con- nections, water pump, outside shower assembly (if so equipped), water heater, tub/ shower, and water purification system (if so equipped).
Page 102 Section 8: Plumbing System Operation Press only one tact switch at a time. As you push either the FRESH, BLK GREY1 or GREY2 switch, one or more LED lights will illuminate (from left to right) indicating the content level for that tank. When pushing the “BATT” switch, the LED lights illuminate from left (lowest) to right (highest) to indicate the estimated auxiliary battery condi- tion.
Page 103: Fresh Water System
Section 8: Plumbing System NOTE: This light will not appear on touchscreens, RV remote con- trols or on a Wi-Fi app, only on the Command Center switch panel. Fresh Water System All water contains contaminant and mineral particles that can cause fresh water system odors.
Page 104: Draining The Fresh Water System
Section 8: Plumbing System 12-volt Water Pump and Switch There must be sufficient 12-volt DC power to run the water pump when your recreation vehicle is not hooked up to city water. Once activated, the water pump (also known as the demand pump) will self-prime, and provide water.
Page 105 Section 8: Plumbing System Open the “low point drains” by turning, then pulling the handles up. They are installed at the lowest point of the water lines. A label is placed on the outside of the RV to indicate where the drains are located. The drains will need to be operated from inside the RV.
Page 106 Section 8: Plumbing System Water heater switches (if so equipped) The water heater switches are typically located on the monitor panel. Refer to the Monitor Panel section for function details. When to sanitize When your RV is new. At the beginning and end of each season. When the water system becomes contaminated or every three months of use.
Page 107 Section 8: Plumbing System 10. Close the hot water lines and repeat with the cold water lines on the faucets. Turn water pump OFF when finished. 11. Let the solution remain in the system for at least four hours when disinfecting with 50 PPM residual chlorine.
Page 108 Section 8: Plumbing System NOTE: The water heater must be drained to prevent damage from freezing. It is recommended the water heater be drained and bypassed during the winterization process particularly if introducing RV antifreeze into the plumbing system. Do not drain the water heater while it is hot onder pressure! Antifreeze should be kept out of the water heater.
Page 109 Section 8: Plumbing System Water heater should be empty after perform- ing Step 2. Water heater bypass valves (if so equipped): supply valves OFF, bypass (center) valve ON. Remove water heater drain plug (ar- row in photo). Make sure the “fresh water tank drain” and “low point drains”...
Page 110 Section 8: Plumbing System 6 In 1 Utility Center (if so equipped) Your RV may be equipped with a small lockable enclosed docking station which provides convenient access to certain plumbing system functions at one central location. NEVER leave the recreation vehicle unattended while filling the fresh water system.
Page 111 Section 8: Plumbing System Water Heater Bypass – 3 Valves (if so equipped) Most models have a factory installed water heater bypass that enables you to avoid filling the water heater with RV antifreeze. The 3-Valve Bypass is typically located in close proximity to the water heater.
Page 112 Section 8: Plumbing System BYPASS Mode: Diverts the flow of water past the water heater keeping water out of the water heater. Hot water bypass valve handle (B) should point away from water heater. (inline with the hot water output). Cold water bypass valve handle (A) should point away from the water heater.
Page 113 Section 8: Plumbing System pump will run and pressurize the water lines, and water should flow from the fixture. Siphon Valve should be OFF. Gravity fill inlet (if so equipped): Used to fill the water tank if no pressurized water source is available.
Page 114 Section 8: Plumbing System How to sanitize Turn both the electric and LP gas water heater switch(es) to OFF. Set the water heater bypass valves to BYPASS: Refer to the appropriate water heater bypass diagram for your model. Level the RV and drain the fresh water system. See Draining the Fresh Water System. Close the low point drain valves and the fresh water tank drain valve.
Page 115 Section 8: Plumbing System NOTE: To thoroughly sanitize the fresh water tank, the unit should be driven around for a short while allowing the solution to splash the sides and top of the fresh water tank. Follow the steps outlined in Draining the Fresh Water System with one exception; do not drain the water heater.
Page 116 Section 8: Plumbing System Your RV may contain either a tank type (storage) water heater or a tankless style. Make sure you know which type you have in your RV. They are winterized differently and allowing antifreeze in the wrong type will damage it. NOTE: The tank type (storage) water heater must be drained to prevent damage from freezing.
Page 117 Section 8: Plumbing System If the recreation vehicle is going to be stored in a non-temperature controlled environment with a risk of temperatures reaching 32°F (0°C) or lower, the air pressure method is not adequate, winterizing with RV antifreeze must be used in the plumbing system.
Page 118 Section 8: Plumbing System Disconnect the compressor and blowout plug. Close the black tank drain. Winterizing with Antifreeze Method Requires non-toxic RV antifreeze in the water lines and does not require any special tools. Use ONLY RV ANTIFREEZE in your fresh water system for freeze protection. No other product or commodity should be used.
Page 119: Water Heater
Section 8: Plumbing System When lines have been flushed, replace the drain plug in the water heater. Set the bypass valves to NORMAL, and fill the water heater with water. Open the HOT water faucets until a steady stream of water runs out of them. Turn off the faucets. The water heater should now be full of water.
Page 120 Section 8: Plumbing System Water Heater Bypass Use the factory installed water heater bypass, available in most floor plans, to avoid filling the entire water heater with RV antifreeze. See the Utility Center section for details on using the bypass system. High Altitude Deration Operation of the water heater at high altitudes may require derating.
Page 121: Outside Shower (If So Equipped)
Section 8: Plumbing System Draining and Winterization If the recreation vehicle is to be stored over the winter months, the water heater must be drained to prevent damage from freezing. Damage to the water heater caused by freezing is not warrantable. It is recommended the water heater be drained and bypassed during the winterization process, particularly if introducing RV antifreeze into the plumbing sys- tem.
Page 122: Bathroom Tub / Shower
Section 8: Plumbing System Bathroom Tub / Shower Keep the water heater and holding tank capacities in mind when using the fresh water sys- tem. The used water will drain through the plumbing pipes into the grey water holding tank. Be sure the water heater is ON and had sufficient time to heat the water.
Page 123 Section 8: Plumbing System terless valve may cause damage to the internal seal that may potentially allow sewer gases to escape into the RV interior. The waterless trap can be unscrewed from the water lines. A label has been placed near the location of the waste valve that reads as follows: REMOVE WATERLESS TRAP BEFORE USING MECHANICAL DRAIN CLEANING DEVICES Sewer Hose Storage...
Page 124 Section 8: Plumbing System Never leave the black tank drain in the open position continuously when connected to the campground sewer system. Leaving the drain open will allow the liquid to drain out increasing the potential for a blockage in the tank.
Page 125: Toilet (If So Equipped)
Section 8: Plumbing System Waste (grey) holding tank preparation No special preparation is required, however, placing a small quantity of chemicals into this tank, such as baking soda or an approved RV chemical, will reduce odors from food particles in the system. Cleaning and Maintenance The toilet should be cleaned regularly for maximum sanitation and operational efficiency.
Page 126 Section 8: Plumbing System Notes: Maintenance Record Table of Contents...
Page 127: Section 9: Heating And Cooling
Section 9: Heating and Cooling Air Conditioner The air conditioning system is controlled by a thermostat. Cooled air enters the RV through the grill. Make sure you have sufficient power available before operating the air conditioner. Do not operate the air conditioner without the return air filter. Operating the system without the filter allows the lint and dirt that is normally stopped by the filter to accumulate on the cooling coil of the air conditioner.
Page 128 Section 9: Heating and Cooling NOTE: For RV models with touch screens, the powered roof vent(s) may be controlled on one of the selectable screens on the touch screen. Furnace The furnace installed in your recreation vehicle is controlled by a 12-volt DC thermostat. Depending on your model, there may be up to two thermostats enabling you to control the temperature to your comfort level.
Page 129: Section 10: Appliances
Section 10: Appliances Microwave To prevent damage, remove the turntable from the microwave when trav- eling. Make sure you are connected to a 120-volt power source. Never use the microwave cavity for storage. The microwave cavity should always be empty when not in use. For details on operation, cleaning and safety information, refer to the manufacturer’s user guide.
Page 130 Section 10: Appliances Cooking With Propane (if so equipped) See the Propane System Section for important safety instructions. Refer to the manufactur- er’s owner’s manual for detailed operating and safety instructions for all propane appliances. Cooktops, Range and Oven (if so equipped) For detailed operating and safety information, refer to the manufacturer’s user guide.
Page 131 Section 10: Appliances Do not use aluminum foil on the electric range cooktop, as this material will damage the cooktop surface if it melts. Do not use aluminum foil under any circumstances on the electric range cooktop. Gas Drop-In Cooktops (if so equipped) Depending on your model, it may be equipped with either a 2 burner or 3 burner cooktop.
Page 132 Section 10: Appliances Place the “quick coupler handle in the OFF position and push back the sleeve. The valve handle must be OFF to make the connection. Insert the plug and release the sleeve. Push the plug until the sleeve snaps forward, locking the plug into the socket. Turn the handle ON to allow propane to flow to the drop in stove.
Page 133: Range Hood (If So Equipped)
Section 10: Appliances Range Hood (if so equipped) If your recreational vehicle is equipped with a range hood, it will be connected to an exterior vent. The vent has an inner flap with two snaps. This flap can be snapped shut when the vehicle is in motion, or during storage to keep insects, debris, snow, rain, etc.
Page 134 Section 10: Appliances The ice maker (if so equipped) should be turned off and the ice tray emptied when power to your recreation vehicle has been shut off. With no power, the ice will melt and water may “pool” in the refrigerator door. When power is restored, the vibration may cause this water to run out of the door and on to the vehicle floor.
Page 135 Section 10: Appliances If you need to clean the condenser: Remove the base grille. Use a vacuum cleaner with a soft brush to clean the grille, the open areas behind the grille and the front surface area of the condenser. Replace the base grille when finished.
Page 136 Section 10: Appliances Attaching the “quick coupler” connection The “quick coupler” is directly connected to the RV propane system. The “quick-coupler” con- nection has a positive shut-off valve as required by code and standards. Quick Connect Coupler Place the “quick coupler handle in the OFF position and push back the sleeve.
Page 137 Section 10: Appliances The grill requires proper ventilation. It is designed for RV outdoor use only. NEVER put lava rocks or charcoal or anything else on or under the grate. Grill is designed so it does not require those items. Serious injury or property damage can occur by placing foreign objects on the grate.
Page 138 Section 10: Appliances Notes: Maintenance Record Table of Contents...
Page 139 Section 11: Electronics Antenna HDTV Antenna (if so equipped) Your recreation vehicle may be equipped with an exterior fixed position High Definition TV antenna (HDTV). The an- tenna is capable of receiving any Over-The-Air (OTA) high definition television signals being broadcast in your receiv- ing area.
Page 140 Section 11: Electronics Notes: Maintenance Record Table of Contents...
Page 141: Cleaning The Interior
Section 12: Interior Cleaning The Interior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.
Page 142 Section 12: Interior Fill a spray bottle with water and a tiny amount of soap. Then spray a lint-free towel with the mixture and use the towel to wipe down each slat. While cleaning, try not to bend the slats. They can also be soaked in a bathtub to loosen up any debris so the slats can be wiped down easily.
Page 143 Section 12: Interior NOTE: Oil based soaps and cleaners are not recommended. No abrasive cleaners or alcohol cleansers should be used. If other cleaner solutions are used, first try on a spot in an inconspicuous area. Sofa and Dinette Your recreation vehicle may be equipped with one of the following sofa styles. Hide-A-Bed Sofa or Sofa Sleeper The hide-a-bed sofa functions much the same as a regular residential hide-a-bed sofa.
Page 144 Section 12: Interior Cube Sofa The Cube Sofa functions similar to a residential futon. The slanted back pillows offer nu- merous options as a sofa, along with the ability to extend the cushions for additional sleeping space. Booth Dinette (if so equipped) The dinette is designed to seat up to four adults.
Page 145: Pantry Or Hutch (If So Equipped)
Section 12: Interior Pantry or Hutch (if so equipped) Your recreation vehicle may have a pantry or hutch that you can use for storage. Make sure all items stored in the pantry or hutch are secured to prevent shifting during travel. This cabinetry has been designed to accommodate the normal camping items which may be bulky but not necessarily heavy.
Page 146: Bed Storage
Section 12: Interior Run cold water when pouring hot/boiling water into the sink. Solid surface sink maintenance Occasionally, clean the solid surface sink by filling one-quarter full with a 50/50 water/ bleach solution. Let soak for 15 minutes, and then wash sides and bottom of sink as solu- tion drains.
Page 147 Section 12: Interior Before lifting, be sure there is nothing on the bed that will restrict its movement or add extra weight. Use caution when opening or closing the bed to keep hands and fin- gers at the end ledge provided (not on the side or farther back than necessary).
Page 148 Section 12: Interior NOTE: Some types of bunk beds will not have a ladder. Exercise extreme care when entering or exiting the bunk beds and using the ladder (if so equipped). Do not allow more than one person on the top bunk. Do not allow children under 6 years of age to use the upper bunk.
Page 149: Cleaning The Exterior
Section 13: Exterior Cleaning The Exterior To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. For recreation vehicles with painted exterior graphics, if desired you may wash and wax your vehicle 60 days after purchase. The exterior paint needs time to cure before any wax is applied to the exterior surface.
Page 150 Section 13: Exterior Drying the recreation vehicle is just as important as washing your vehicle. Tap and well water contain many chemicals that could water stain your vehicle’s finish. We suggest using a damp natural or synthetic chamois. Other drying products such as lint-free micro-fiber towels work as well.
Page 151: E-Z Lube Or Super-Lube Axle (If So Equipped)
Section 13: Exterior in one direction. After polishing, flush the compound from the surface and apply a coat of wax to regain a beautiful luster. Damaged paint To prevent corrosion, touch up small cracks and scratches in the paint coat as soon as pos- sible with touch-up film or paint.
Page 152 Section 13: Exterior Windows Any ventilating window may permit water inside, especially during heavy rainstorms. Con- densation will also cause water to accumulate on windows and in the tracks. The window “glass” can normally be cleaned with a sponge and water. Use glass cleaner to remove wax, oil, grease, dead insects, etc.
Page 153 Section 13: Exterior Travel Trailers - Sealant Diagram Maintenance Record Table of Contents...
Page 154 Section 13: Exterior Notes: Maintenance Record Table of Contents...
Page 155: Section 14: Travel/Camping/Storage Checklists
Section 14: Travel/Camping/Storage Checklists Travel Checklist Following is a preliminary list of items that need to be checked before leaving your home or campsite. This is a general list, which you may want to customize as you determine your own needs. Safety Make sure you follow all safety precautions noted in this owner’s manual and in any manufacturer’s operators manual when preparing to travel.
Page 156 Section 14: Travel/Camping/Storage Checklists Before leaving the campsite Check the area under the RV after overnight parking and look for water or other fluid leaks. If leaks are detected, find the cause and correct it immediately. Turn off propane tanks. Empty black and gray holding tanks, rinse as needed (if so equipped).
Page 157 Section 14: Travel/Camping/Storage Checklists Close the propane cylinder valve(s). We recommend using a propane cylinder cover, and to make sure the propane regulator is covered. If is equipped with a gas/ electric DSI range, light a range gas burner to consume any gas remaining in the lines.
Page 158 Section 14: Travel/Camping/Storage Checklists Notes: Maintenance Record Table of Contents...
Page 159: Section 15: Additional Information
Your recreation vehicle may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components. All information is the latest available at the time of publication. Starcraft reserves the right to change any of the follow- ing information without notice.
Page 160 Section 15: Additional Information Tank Sprayer/BLK B & B Molders www.bandbmolders.com Thermostat Coleman Mach www.airxcel.com/coleman-mach Toilet Thetford Corp. www.thetford.com See manufacturers’ user guide TV Antenna Winegard Company www.winegard.com Water Heater, Tank DSI Atwood Greenbrier www.atwoodmobile.com Water Heater, Tankless Girard Systems www.greenrvproducts.com Shurflo East www.shrflo.com...
Page 161: Vehicle Maintenance Record
Section 15: Additional Information Vehicle Maintenance Record Make: Model: Model Year: Vehicle Serial#: Service Performed Mileage Work Performed Notes Date Maintenance Record Table of Contents...
Page 162 Section 15: Additional Information Service Performed Mileage Work Performed Notes Date Maintenance Record Table of Contents...
Page 163 Section 15: Additional Information Starcraft Ownership Notification Fax Form To: (574) 825-6092 ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □ □...

Starcraft SUPER LITE 2021 Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Starcraft SUPER LITE 2021

Summary of Contents for Starcraft SUPER LITE 2021

Table of Contents
