Page 1: Installation Guide
Installation Guide for LinMot USB-CAN Converter for Configuration of E1100/B1100 Drives by CAN Bus Art. Nr. 0150-3134 CAN-USB Converter Installation Guide... - Page 2 NTI AG. ® LinMot is a registered trademark of NTI AG. Note The information in this documentation reflects the stage of development at the time of press and is therefore without obligation.
-
Page 3: Table Of Contents
2.2.2 CAN Pin Description of the CMD and ME Connector: ........6 2.2.3 CAN Termination ....................6 HOW TO INSTALL THE USB-CAN CONVERTER ............7 ..................7 YSTEM EQUIREMENTS ......................7 NSTALLATION CONTACT ADDRESSES ....................8 NTI AG / LinMot Installation Guide USB-CAN converter... -
Page 4: Introduction
USB-CAN Converter Installation Guide 1 Introduction The USB-CAN converter can be used to login from a PC with installed LinMot-Talk software to one or more E1100/B1100 drives over the CAN bus. It can help the user to debug and configure the system in case the serial communication port is occupied (for example if the active interface is LinRS). -
Page 5: Technical Data
(1M/10n to isolated GND) CAN_H N.C. N.C. Table 2-1: Pinning of the CAN connector 2.2 CAN connector on LinMot Drive E1100 & B1100 2.2.1 Pin Description of the COM Connector: DSBU 9 male: Pin 1 RS-485 TX+ Pin 6 RS-485 RX-... -
Page 6: Can Pin Description Of The Cmd And Me Connector
For easy installation, the LinMot CANopen drive has built in termination resistors, which can be activated if the LinMot drive is at the end of the bus line and if there is no termination in the connector. -
Page 7: How To Install The Usb-Can Converter
Unzip the downloaded file, run it to start the installation and follow the setup instruction as they appear). After the driver has been installed successfully connect the USB-CAN converter to the PC and follow the proposed actions and settings. NTI AG / LinMot Installation Guide USB-CAN converter... -
Page 8: Contact Addresses
Elkhorn, WI 53121 Sales and Administration: 877-546-3270 262-743-2555 Tech. Support: 877-804-0718 262-743-1284 Fax: 800-463-8708 262-723-6688 us-sales@linmot.com E-Mail: http://www.linmot- Web: usa.com/ ------------------------------------------------------------------------------------------------------ ----------------------- http://www.linmot.com/ Please visit to find the distribution near you. Smart solutions are… Installation Guide USB-CAN converter NTI AG / LinMot...
