INSTRUCTION MANUAL INSERT TYPE WOOD BURNING STOVES Model A ÍNDEX Page 1. Introduction 2. Technical characteristics 3. Wood 4. Installation 5. Combustion air 6. Running in your stove 7. Schematic drawing 8. Opening and closing the door 9. Combustion princilple 10.
8005-139 Faro 1. INTRODUCTION Thank you for buying a FOGO MONTANHA stove. To get the best ecological performance and highest output from this appliance please follow these installation and operating instructions. The guarantee will cease to apply if the stove is damaged as a result of a failure to follow the installation and operating instructions.
4. INSTALLATION Your flue and chimney For your stove to work properly the chimney must also work properly. Check out the following points whilst bearing in mind that this is for informational purposes only and is not binding for us in any manner whatsoever. It is an unfortunate fact that there are numerous factors that can play decisive roles in the correct functioning of a chimney.
The liner must be safely and securely connected to the outlet pipe of the stove. And your chimney or liner must be swept at least once each heating season and in accordance with local regulations. Your fireplace If cement mortar has been used on the inside or outside of the fireplace during construction or installation then a period of at least 7 days should be allowed before operation to prevent the cement cracking when drying out.
9. COMBUSTION PRINCIPLE The stove is designed so that full of wood, with a slow flame, it will burn at maximum efficiency for several hours. The stove can be made to burn overnight, very slowly, with little or no flame. This is not advisable because this incomplete combustion creates extra smoke, which, upon condensation, deposits tar on the stove, chimney and glass panel.
Open door This setting gives the charm and beauty of an open fire with very high radiant heat output but increased wood log con- sumption. First get the stove hot by fully opening the combustion hot air. Then open the door. 13.
Page 7
Broken glass The glass panel is heat resistant and very tough. However, it can be broken through lack of care. By reading and applying the following tips you will prevent any damage. Never leave wood sticking out in front of the stove. Otherwise, when closing the door the protruding wood could pierce the glass.
5. No modifications have been made to the product without prior written permission of FOGO MONTANHA. The guarantee is strictly limited to the replacement or repair, by FOGO MONTANHA or their appointed dealer, of parts recognized by us to be defective and excludes all other indemnities. The affected part must be returned to our factory.
