VRTIKL-AUB
FREESTANDING STOVE
MODELS:
VRT-BZ-N-AUB
VRT-BZ-P-AUB
VRT-GY-N-AUB
VRT-GY-P-AUB
VRT-BK-N-AUB
• Important operating
a n d m a i n t e n a n c e
instructions included.
!
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result causing property damage, personal injury,
or death.
• DO NOT USE OR STORE FLAMMABLE MATERIALS
NEAR THIS APPLIANCE.
• DO NOT SPRAY AEROSOLS IN THE VICINITY OF
THIS APPLIANCE WHILE IT IS IN OPERATION.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch.
- DO NOT use any phone in your building.
- Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
- If you cannot reach your gas supplier, call the fire
department.
• Installation and service must be performed by a qualified
installer, service agency, or the gas supplier.
WARNING! DO NOT modify this appliance.
1
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe

installation and operation.

Heat & Glo • VRT-AUB • 2123-980_R14 • 12/14
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
!
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as fireplace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other flammable
materials.
• DO NOT place articles on or against this appliance.
• Keep clothing, furniture, draperies and other flammable
materials away.
This appliance has been supplied with an integral barrier to
prevent direct contact with the fixed glass panel. DO NOT
operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the barrier
is not present or help is needed to properly install one.
This is a room sealed appliance and no other ventilation is
required than what is provided.
SAI Global
Ref No GSCS20166
AS4553:2008
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VRT-BZ-N-AUB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heat & Glo VRT-BZ-N-AUB

Summary of Contents for Heat & Glo VRT-BZ-N-AUB

  • Page 1: Installation And Operation

    Owner’s Manual Installation and Operation VRTIKL-AUB FREESTANDING STOVE MODELS: SAI Global VRT-BZ-N-AUB VRT-BZ-P-AUB Ref No GSCS20166 VRT-GY-N-AUB AS4553:2008 VRT-GY-P-AUB VRT-BK-N-AUB NOTICE DO NOT DISCARD THIS MANUAL • Important operating • Read, understand and follow • Leave this manual with a n d m a i n t e n a n c e...
  • Page 2 PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING THIS APPLIANCE. MODELS: VRT-N-AUB AND VRT-P-AUB ARE SAI GLOBAL Failure to follow them will void your warranty and may present APPROVED FOR NATURAL GAS, PROPANE OR BUTANE a fire hazard. AS A BALANCED FLUE FIREPLACE. The Heat & Glo, a brand of Hearth & Home Technologies Refer to the appliance data plates for gas consumptions and warranty will be voided by, and Heat & Glo, a brand of Hearth pressures. & Home Technologies disclaims any responsibility for the following actions: Installation of this appliance should only be carried out by an authorized person in accordance with the manufacturer’s • Installation of any damaged fireplace or flue system instructions.

  • Page 3: Congratulations

    Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. A. Congratulations This owner’s manual should be retained for future reference. We suggest that you keep it with your other important Congratulations on selecting a Heat & Glo gas fireplace, an documents and product manuals. elegant and clean alternative to wood burning fireplaces. The The information contained in this owner’s manual, unless Heat & Glo gas fireplace you have selected is designed to noted otherwise, applies to all models and gas control provide the utmost in safety, reliability, and efficiency.

  • Page 4: Table Of Contents

    Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •...
  • Page 5 11 Gas Information A. Gas Pressure Requirements ..... . 53 B. Gas Connection ....... . 53 12 Electrical Information A. Wiring Requirements .

  • Page 6: Limited Lifetime Warranty

    B. Limited Lifetime Warranty AUSTRALIAN WARRANTY INFORMATION Warranty information in the attached manual is for international markets, not Australia. For Australian warranty information, please see below. Hearth & Home Technologies (HHT) 7571 215th Street West, Lakeville, MN 55044 0011-1-651-345-1777 www.heatnglo.com HHT extends the following manufacturer’s warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer.
  • Page 7 Warranty Period Heat & Glo Manufactured Appliances and Venting Components Covered Parts Labor Wood Pellet Coal Electric Venting Wood 5 years 1 years Castings & baffles Manifold tubs HEAT & GLO 7 years 3 years chimney and termination 10 years 1 year Burners, logs and refractory Limited 3 year...
  • Page 8 • Non Heat & Glo venting components, hearth components or other accessories used in conjunction with the appliance. • Any part of a pre-existing fireplace system in which an insert or a decorative gas appliance is installed. • Removal, installation, reinstallation, set up or any other costs associated with a claim including travel and shipping charges for parts •...

  • Page 9: Listing And Code Approvals

    Listing and Code Approvals A. Appliance Certification The fireplace and its individual shut-off valve must be disconnected from the gas supply piping system during any pressure testing of the system at test pressures in excess MODELS: VRT-AUB of 6 kPa. LABORATORY: SAI Global If the fireplace must be isolated from the gas supply piping TYPE: Gas Space Heating Appliance system by closing an individual shut-off valve, it must be of the handle-less type. STANDARD: AS4553:2008 WARNING! Risk of Explosion! An in-line regulator MUST be installed if the gas pressure exceeds 3.7 kPa.

  • Page 10: User Guide

    User Guide Operating Instructions A. Gas Fireplace Safety B. Your Fireplace WARNING! DO NOT operate fireplace before reading WARNING and understanding operating instructions. Failure to operate fireplace according to operating instructions could HOT SURFACES! cause fire or injury. Glass and other surfaces are hot during C.

  • Page 11: Lighting Instructions (Ipi)

    H. Lighting Instructions (IPI) FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas sup- A.

  • Page 12: Control Module Operation

    I. Control Module Operation MODULE 1. The control module has an ON/OFF/REMOTE selector switch that must be set. See Figure 2.1. OFF Position: Appliance will ignore all power inputs and will not respond to any commands from a wall switch or remote. The unit should be in the OFF position during installation, service, battery installation, fuel conversion, and in the event that the control goes into LOCK-OUT mode as a result of an error code. SELECTOR SWITCH ON Position: Appliance will ignite and run continuously...

  • Page 13: After Fireplace Is Lit

    J. After Fireplace is Lit Initial Break-in Procedure • The fireplace should be run three to four hours continuously on high. • Turn the fireplace off and allow it to completely cool. • Remove fixed glass assembly. See Section 9.I through 9.K. • Clean fixed glass assembly. See Section 3. • Replace the fixed glass assembly and run continuously on high an additional 12 hours. This cures the materials used to manufacture the fireplace. NOTICE! Open windows for air circulation during fireplace break-in. • Some people may be sensitive to smoke and odors. • Smoke detectors may activate. K.

  • Page 14: Maintenance And Service

    Maintenance and Service Doors, Surrounds, Fronts Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace. Frequency: Annually By: Homeowner When properly maintained, your fireplace will give you Tools needed: Protective gloves, stable work surface many years of trouble-free service. We recommend annual service by a qualified service technician. • Inspect for scratches, dents or other damage and repair as necessary. A. Maintenance Tasks-Homeowner •...

  • Page 15: Maintenance Tasks-Qualified Service Technician

    B. Maintenance Tasks-Qualified Service Firebox Technician Frequency: Annually To prevent inadvertent burner operation while servicing this By: Qualified Service Technician appliance: Tools needed: Protective gloves, sandpaper, steel wool, • Unplug DC regulator from junction box. cloths, mineral spirits, primer and touch-up paint. • Remove batteries from battery pack (if installed). • Inspect for paint condition, warped surfaces, corrosion or perforation. Sand and repaint as necessary. • Shut off gas supply to the appliance. • Replace fireplace if firebox has been perforated.
  • Page 16 Burner Ignition and Operation Frequency: Annually By: Qualified Service Technician Tools needed: Protective gloves, vacuum cleaner, whisk broom, flashlight, voltmeter, indexed drill bit set, and a manometer. • Verify burner is properly secured and aligned with pilot or igniter. • Clean off burner top, inspect for plugged ports, corrosion or deterioration. Replace burner if necessary. • Replace Glowing embers with new dime-size pieces. DO NOT block ports or obstruct lighting paths. • Verify batteries have been removed from battery back-up IPI systems to prevent premature battery failure or leaking. • Check for smooth lighting and ignition carryover to all ports. Figure 3.1 IPI Pilot Flame Patterns Verify that there is no ignition delay.

  • Page 17: Installer Guide

    Installer Guide Getting Started A. Typical Appliance System NOTICE: Illustrations and photos reflect typical installations and are for design purposes only. Illustrations/diagrams are not drawn to scale. Actual product may vary from pictures in manual HORIZONTAL TERMINATION CAP (SECTION 10.H) VERTICAL TERMINATION CAP (SECTION 10.L) STORM COLLAR...

  • Page 18: Design And Installation Considerations

    B. Design and Installation Considerations D. Inspect Appliance and Components Heat & Glo direct vent gas appliances are designed to • Carefully remove the appliance and components from the operate with all combustion air siphoned from outside of the packaging. building and all exhaust gases expelled to the outside of the • The vent system components and decorative doors and building. No additional outside air source is required. fronts may be shipped in separate packages.

  • Page 19: Framing And Clearances

    Framing and Clearances A. Selecting Appliance Location NOTICE: Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams are not When selecting a location for the appliance it is important to drawn to scale. Actual installation may vary due to individual consider the required clearances to walls (see Figure 5.1). design preference. WARNING! Risk of Fire or Burns! Provide adequate clearance around air openings and for service access.

  • Page 20: Optional Stone Surround Installed

    B. Optional Stone Surround Installed STONE SURROUND Inches Millimeters Figure 5.2 WARNING Fire Risk. Odor Risk. Tipping Risk • Install gas stove on a stable, level platform/floor strong enough to support gas stove without tipping. • USE wood flooring, ceramic tile, brick hearth or high pressure laminate flooring applied directly over the sub-flooring material. Heat & Glo • VRT-AUB • 2123-980_R14 • 12/14...

  • Page 21: Termination Locations

    Termination Locations A. Vent Termination Minimum Clearances WARNING 6 in. (minimum) up to 20 in. 18 in. minimum Fire Risk. (152 mm (minimum) up to 508 mm) (457 mm minimum) Maintain vent clearance to combustibles as 20 in. and over 0 in. minimum (508 mm and over) (0 mm minimum) specified. • DO NOT pack air space with insulation or other Gas, Wood or Fuel Oil materials. Termination Cap Failure to keep insulation or other materials away from vent pipe may cause overheating and fire. HORIZONTAL OVERHANG 20 in MIN. Termination 24 in MIN.
  • Page 22 See note 3 openable window door See note 2 T = Flue terminal M = Gas meter Shading indicates prohibited I = Mechanical air inlet P = Electricity meter or fuse box areas for flue terminals a - Below eaves, balconies or other projections: MIN. CLEARANCE - in. (mm) Appliances up to 50 MJ/h input ..................12 (300) Appliances over 50 MJ/h input ................20-1/2 (500) b - From the ground or above a balcony ................12 (300) c - From a return wall or external corner ................. 20-1/2 (500) d - From a gas meter (M) ......................

  • Page 23: Flue Information

    Flue Information B. Use of Elbows A. Flue Components These models are approved to use Hearth & Home CAUTION Technologies series pipes, components and termination. Approved components are labeled for identification. This ALL flue configuration specifications MUST be followed. pipe is tested and listed as an approved component of the • This product is tested and listed to these specifications.

  • Page 24: Flueing Diagrams

    D. Flueing Diagrams STRAIGHT UP VERTICAL FLUE 38 ft. (11.58 m) Maximum For Natural, Propane and Butane Gases. Note: For this type of installation, the vertical flue restrictor must be added. See section H for instructions. Figure 7.2 STRAIGHT OUT HORIZONTAL FLUE 2 ft. (610 mm) Maximum For Natural, Propane and Butane Gases. Figure 7.3 Heat &...
  • Page 25 Natural Gas • One 90° Elbow System V Minimum H Maximum 1-1/2 ft. 457 mm 4-1/2 ft. 1.37 m 3 ft. 914 mm 9 ft. 2.74 m 4-1/2 ft. 1.37 m 13-1/2 ft. 4.12 m 6 ft. 1.83 m 16 ft. 4.88 m V + H = Max. 38 ft. (11.58 m) H Max. = 16 ft. (4.88 m) Propane • One 90° Elbow System V Minimum H Maximum 1-1/2 ft.
  • Page 26 Natural Gas • Two 90° Elbows System V Minimum H Maximum H1 + H2 Max. 1-1/2 ft. 457 mm 1-3/4 ft. 530 mm 3-1/2 ft. 1.07 m 3 ft. 914 mm 3-1/2 ft. 1.07 m 7 ft. 2.13 m 4-1/2 ft. 1.37 m 5-1/2 ft. 1.68 m 11-1/2 ft. 3.5 m 6 ft. 1.83 m 7 ft. 2.13 m 14-1/2 ft.
  • Page 27 Natural Gas • Two 90° Elbows System V Minimum H Maximum H1 + H2 Max. 1-1/2 ft. 457 mm 2 ft. 610 mm 3-1/2 ft. 1.07 m 3 ft. 914 mm 3-1/2 ft. 1.07 m 7-1/2 ft. 2.28 m 4-1/2 ft. 1.37 m 5-1/2 ft. 1.68 m 11-1/2 ft. 3.5 m 6 ft. 1.83 m 7 ft. 2.13 m 15 ft.
  • Page 28 Natural Gas • Two 90° Elbows System V Minimum H Maximum 1 ft. 305 mm 3 ft. 914 mm 2 ft. 610 mm 6 ft. 1.83 m 3 ft. 914 mm 9 ft. 2.74 m 4 ft. 1.22 m 12 ft. 3,66 m 5 ft. 1.52 m 15 ft. 4.57 m V1 + V2 + H = Max. 36 ft. (10.97 m) H = Max. 15 ft. (4.57 m) Propane • Two 90° Elbows System V Minimum H Maximum 1 ft.
  • Page 29 Natural Gas • Three 90° Elbows System V Minimum H Maximum H1 + H2 Max. 1-1/2 ft. 457 mm 1-3/4 ft. 530 mm 3-1/2 ft. 1.07 m 3 ft. 914 mm 3-1/2 ft. 1.07 m 7-1/2 ft. 2.28 m 4-1/2 ft. 1.37 m 5-1/2 ft. 1.68 m 11-1/2 ft. 3.5 m 6 ft. 1.83 m 7 ft. 2.13 m 15 ft.
  • Page 30 Natural Gas • Three 90° Elbows System V Minimum H Maximum H1 + H2 Max. 1-1/2 ft. 457 mm 1-3/4 ft. 530 mm 3-1/4 ft. 1,0 m 3 ft. 914 mm 3-1/2 ft. 1,07 m 6-1/2 ft. 1,98 m 4-1/2 ft. 1,37 m 5-1/2 ft. 1,68 m 10 ft. 3,05 m 6 ft. 1,83 m 7 ft. 2,13 m 13 ft. 3,96 m V + H1 + H2 = Max. 36 ft. (10.97 m) H1 Max. = 7 ft. (2.13 m) H1 + H2 = Max. 13 ft. (3.96 m) Propane •...

  • Page 31: Flue Pipe Assembly

    E. Flue Pipe Assembly F. Horizontal Penetration Framing 90 DEGREE ELBOW PIPE LENGTH TERMINATION CAP WALL THIMBLE WALL THIMBLE COVER PIPE LENGTH Note: Align seams to engage pipe, then rotate counterclockwise to lock Figure 7.12 Step 1. Balanced flue pipe is designed with a locking connection. To connect the flue system to the gas stove flue outlet: • Lock the flue components into place by sliding the pipe section onto the collar.
  • Page 32 FIG. A 90 DEGREE ELBOW U S E H E AT S H IE L D OR W A L L T H IM B L E P lac e m ark w h ere p ro tru d es th ro u g h ex terio r w all to c u t o ff ex ces s.

  • Page 33: Slim Line Wall Thimble

    G. Slim Line Wall Thimble BEFORE YOU BEGIN: Review the flueing configurations in Figures A, B and C on the next page. CAUTION! Risk of Cuts, Abrasions or Flying Debris. Wear protective gloves and safety glasses during installation. Sheet metal edges are sharp. 1. Assembling Slim Line Trim Ring and Heat Shield Figure 7.17 Attach the heat shield to the trim ring with the four screws provided.

  • Page 34: Vertical Termination

    H. Vertical Termination VERTICAL TERMINATION CAP STORM COLLAR FLASHING FIRESTOP SUPPORT 11.58 m PIPE LENGTH (38 ft.) MAXIMUM On vertical terminations use SLP-TVHW. Figure 7.19 Figure 7.20 Step 2. Step 1. Check the installation instructions for required 10 in. et the gas stove in its desired location. Drop a plumb bob (254 mm) clearances (air space) to combustibles when down from the ceiling to the position of the gas stove flue passing through ceilings, walls, roofs, enclosures, attic...
  • Page 35 Step 3. SHINGLES OVERLAP ON To install the round support box/wall thimble cover in a flat TOP EDGE OF FLASHING ceiling, cut a 229 mm square hole in the ceiling, centered on the hole drilled in Step 2. Frame the hole as shown in Figure 7.22. CEILING JOISTS FRAMING CAP AND STORM COLLAR NOT SHOWN FOR CLARITY ROUND CEILING SUPPORT BOX/WALL THIMBLE COVER Figure 7.23 229 mm x 229 mm Step 7.

  • Page 36: Vertical Flue Restrictor

    I. Vertical Flue Restrictor Step 9. Twist-lock the flue cap and seal. If the fireplace installation requires a vertical flue off the top of the unit with no horizontal flue or elbows, the vertical Note: For multi-story vertical installations, a ceiling firestop flue restrictor must be added. Reinstall heat shield when is required at the second floor, and any subsequent floors completed. See Figure 7.26. (Figure 7.25). The opening should be framed to 9 in. x 9 in. (229 mm x 229 mm) inside dimensions, in the same manner as shown in Figure 7.22.

  • Page 37: Vent Clearances And Framing

    Vent Clearances and Framing A. Pipe Clearances to Combustibles B. Wall Penetration Framing WARNING! Risk of Fire! Maintain air space clearance to Combustible Wall Penetration vent. DO NOT pack insulation or other combustibles: Whenever a combustible wall is penetrated, you must •...

  • Page 38: Install The Ceiling Firestop

    C. Install the Ceiling Firestop A ceiling firestop MUST be used between floors and attics. • SLP pipe only - Frame opening 9 in. x 9 in. (229 mm x 229 mm) whenever the vent penetrates a ceiling/floor (see Figure 8.3). • Frame the area with the same sized lumber as used in ceiling/floor joist. • The ceiling firestop may be installed above or below the ceiling joists when installed with a attic insulation shield. It must be under joists ATTIC ABOVE between floors that are not insulated. Refer to Figure 8.4. • Secure with three fasteners on each side. WARNING! Risk of Fire! DO NOT pack insulation around the vent.

  • Page 39: Install Attic Insulation Shield

    D. Install Attic Insulation Shield BEND ALL TABS INWARD 90° WARNING! Fire Risk. DO NOT allow loose materials or TO MAINTAIN CLEARANCE insulation to touch vent. Hearth & Home Technologies AND PREVENT INSULATION FROM FALLING INSIDE requires the use of an attic shield. An attic shield constructed of 26 gauge minimum metal that extends at least 2 in. (51 mm) above insulation is required.

  • Page 40: Appliance Setup

    Appliance Setup A. Remove Shipping Materials C. Leveling and Bolting Down the Appliance Remove shipping materials from inside or underneath the SECURING THE GAS STOVE IS REQUIRED. firebox. WARNING The gas line is shipped inside back panel. To access the gas line remove the top plate from the gas stove. Remove Fire Risk. and retain the two Allen head screws that hold the back panel in place. Replace panel when finished. Odor Risk.

  • Page 41: Accessories

    E. Top to Rear Flue Conversion CLEARANCE KIT CONTENTS: Top cover (without hole); HOLE Back panel (with hole). 1. Remove the front door assembly by pulling bottom of front away from gas stove and lifting it off of the hooks on top of the gas stove. Set door aside. ON TOP OF APPLIANCE: 2. Remove the top plate with hole and discard. (Figure 9.6) Figure 9.4 The manufacturer recommends securing the lag bolt from...

  • Page 42: Installing The Baffle

    ON BACK OF APPLIANCE: ON TOP OF APPLIANCE: 6. Remove the four screws from the cover plate on rear of 8. Install the new back panel (without hole) to the rear of gas stove. Set cover plate aside. Retain screws. (See gas stove. Replace the Allen head screws removed in Figure 9.8). Attach DV adapter collar in its place. Install Step 3 to hold the back panel in place.

  • Page 43: Positioning The Logs

    G. Positioning the Logs While still breakable, the logs do not become fragile until after the gas stove is burned and they have cured. After curing, any handling must be done with care as breakage can easily occur. PLEASE NOTE: Logs have been designed to work specifically with the burner of this gas stove. Exact placement will ensure proper operation of your gas stove.

  • Page 44: Front Door Glass Assembly Installation

    I. Front Door Glass Assembly Installation J. Inner Glass Door Assembly Replacement Remove the front door assembly by pulling bottom of front Turn the gas stove OFF and let it cool down before away from gas stove and lifting it off of the hooks on top of replacing the inner glass door assembly. the gas stove (see Figure 9.16). With the front door assembly removed from the gas stove, Refer to Figure 9.17: Position the four flat 6 mm spacer remove the inner glass door assembly by disengaging the washers on the front door so that the four mounting screws spring-loaded latches at the bottom of the gas stove and...

  • Page 45: Covers Removal For Servicing

    K. Covers Removal For Servicing Pilot Assembly/Ignition System • Remove the log set, log grate and burner assembly. Control Compartment Access Door • Disconnect the gas supply tube from the outlet side of • Lift the lower door up and out to access the gas controls. valve. Trim Door and Glass Door • Disconnect the orange ignitor wire (I) and white sensor • Lift the front trim door up and out away from the appliance wire (S) from module. side surrounds. Replace the door when servicing is • Unscrew the pilot assembly bracket and remove, the pilot complete.

  • Page 46: Installing Vent Pipe (Slp Pipe)

    Installing Vent Pipe (SLP Pipe) A. Assemble Vent Sections To attach the first vent component to the starting collars of the appliance: • Lock the vent components into place by sliding the pipe section onto the collar. • Align the seam of the pipe and seam of collar to allow engagement. Rotate the vent component to lock into place. Use this procedure for all vent components. See Figure 10.1. Note: Align seams to engage pipe, then rotate counterclockwise to lock • Slide the gasket over the first vent section and place it...

  • Page 47: Assemble Slip Sections

    B. Assemble Slip Sections C. Secure The Vent Sections • Slide the inner flue of the slip section into the inner flue • Vertical runs of pipe must be supported every 8 ft. (2.44 m). of the pipe section and the outer flue of the slip section • Horizontal sections must be supported every 5 ft. (1.52 over the outer flue of the pipe section. See Figure 10.3. • Slide together to the desired length. • Vent supports or plumbers strap (spaced 120º apart) may be used to support. See figures 10.5 and 10.6. • Wall shield firestops may be used to provide horizontal support. • Ceiling firestops have tabs that may be used to provide vertical support. WARNING! Risk of Fire, Explosion or Asphyxiation! Improper support may allow vent to sag and separate.

  • Page 48: Disassemble Vent Sections

    D. Disassemble Vent Sections • Level the support box both vertically and horizontally and temporarily tack it in place through the inside walls into • Rotate either section (see Figure 10.7) so the seams on the roof sheathing. both pipe sections are aligned as shown in Figure 10.8. • Use tin snips to cut the support box from the top corners • Pull carefully to separate the pieces of pipe. down to the roof line and fold the resulting flaps to the roof. See Figure 10.10. • Nail the flaps to the roof AFTER running a bead of non hardening sealant between the flaps and the roof. WARNING! Risk of Fire! Clean out ALL materials from inside the support box and complete the vertical vent run and termination.

  • Page 49: Install Support Brackets

    F. Install Support Brackets For Horizontal Runs - The flue system must be supported 10 in. (254 mm) every 5 ft. (1.52 m) of horizontal run by a horizontal pipe support. To install support brackets for horizontal runs: INTERIOR WALL SHIELD • Place the pipe supports around the flue pipe. • Nail the pipe supports to the framing members. 10 in. (254 mm) For Vertical Runs - The flue system must be supported every 8 ft. (2.44 m) above the fireplace flue outlet by wall brackets.

  • Page 50: Flue Termination

    If the area above the ceiling is NOT an attic, position and Rear Flue secure the ceiling firestop on the ceiling side of the previously Interior Heat Shield Wall Shield cut and framed hole. 38 mm min. overlap JOIST Outer Flue Inner Flue INTERIOR EXTERIOR CEILING Figure 10.16 Venting through the Wall NAILS (4 REQUIRED) CEILING FIRESTOP • The termination kit should pass through the wall firestops from the exterior of the building. Figure 10.14 Ceiling Firestop (Ceiling Side) • Adjust the termination cap to its final exterior position on If the area above the ceiling IS an attic, position and secure the building and interlock the flue sections.

  • Page 51: Heat Shield Requirements For Horizontal Termination

    I. Heat Shield Requirements for Horizontal J. Install Metal Roof Flashing Termination • See minimum vent heights for various pitched roofs (Figure 10.18) to determine the length of pipe to extend WARNING! Risk of Fire! To prevent overheating and fire, through the roof. heat shields must extend through the entire wall thickness. • Slide the roof flashing over the pipe sections extending •...

  • Page 52: Assemble And Install Storm Collar

    L. Install Vertical Termination Cap • Locate and mark the flue center point on the underside of the roof, and drive a nail through the center point. CAULK • Make the outline of the roof hole around the center point nail. • The size of the roof hole framing dimensions depend on the pitch of the roof. There MUST BE a 1 in. (25.4 mm) clearance from the vertical flue pipe to combustible materials. • Mark the roof hole accordingly. • Cover the opening of the installed flue pipes. • Cut and frame the roof hole.

  • Page 53: Gas Information

    Gas Information A. Gas Pressure Requirements B. Gas Connection Pressure requirements for VRT-AUB fireplaces are shown Note: Have the gas supply line installed in accordance with local in the table below. building codes by a qualified installer approved and/or licensed as required by the locality. Two taps are provided on the right hand side of the gas control for a test gauge connection to measure the inlet and outlet pressures.
  • Page 54 The gas is introduced to the appliance on the left hand side. Gas line and power cord are shipped inside back panel. To access the gas line and power cord, remove the top plate After the gas pipe installation is complete, check carefully from the appliance. Remove and retain the two Allen head all gas connections for leaks with a commercially-available, screws that hold the back panel in place. noncorrosive leak check solution. Be sure to rinse off all leak check solution following testing. DO NOT USE AN OPEN Using the black grommet located in the component bag, slide FLAME. it into the bottom of the back panel and feed the power cord through the grommet, as shown in Figure 11.1. NOTICE: the gas supply line should be purged of any trapped air prior to the first firing of the unit.

  • Page 55: Electrical Information

    Electrical Information A. Wiring Requirements B. IntelliFire Plus Ignition System Wiring NOTICE: This appliance must be installed by a qualified • Wire the appliance junction box to 220-240 VAC for proper electrician in accordance with the relevant national and local operation of the appliance. regulations. WARNING! Risk of Shock or Explosion! DO NOT wire • Wire the appliance junction box to 220-240 VAC. This is IPI controlled appliance junction box to a switched circuit.

  • Page 56: Optional Accessories Requirements

    OPTIONAL ACCESSORY Note: if any of the original wire as supplied with the appliance must be replaced, it must be replaced with type 105 ºC rated wire. Wires must have high temperature insulations. Figure 12.2 Blower Diagram C. Optional Accessories Requirements D. Blower • This appliance may be used with a wall switch, wall These fireplaces have a factory installed Fan, Electrical mounted thermostat and/or a remote control. Junction Box. These components are located behind the lower door.

  • Page 57: Control Module Operation

    E. Control Module Operation MODULE 1. The control module has an ON/OFF/REMOTE selector switch that must be set. See Figure 12.3. OFF Position: Appliance will ignore all power inputs and will not respond to any commands from a wall switch or remote. The unit should be in the OFF position during installation, service, battery installation, fuel conversion, and in the event that the control goes into LOCK-OUT SELECTOR mode as a result of an error code. SWITCH ON Position: Appliance will ignite and run continuously in the HI flame setting, with no adjustment in flame...

  • Page 58: Installation Precautions

    Introduction Hearth & Home Technologies disclaims any responsibility for, The RC300AU multifunctional remote control is designed and the warranty will be voided by, the following actions: to control pilot light, flame height, blower speed, and up to • Installation and use of any damaged system component. two 220-240 VAC auxiliary functions on your gas fireplace. • Modification of the system component. The RC300AU is equipped with thermostat functions which can automatically control the temperature in the • Installation other than as instructed by Hearth & Home room in which it is installed. The control is only for use Technologies.
  • Page 59 Installation of Remote Control Housing FCC Requirements WARNING! Risk of Fire! Changes or modifications to this CAUTION! Risk of Fire! DO NOT install damaged or unit not expressly approved by the party responsible for modified components Warranty will be voided if damaged compliance could void the user’s authority to operate the or modified components are installed.

  • Page 60: Fan Installation

    5. Close the housing door. See Figure 12.7. Programming the RC300CE to the Control Module CAUTION! Risk of burns! DO NOT program the remote control to the control module when fireplace is hot. • Verify the ON/OFF/REMOTE switch is in the REMOTE position. Green LED light will blink three times and the control module will beep once 5 seconds later when ready. See Figure 12.10.
  • Page 61 Display Screen Idle When Remote is in ON Mode The remote control will go into an idle mode if no buttons THERMOSTAT DESIRED FIREPLACE STATUS are pressed within 5 seconds. Press any button to resume TEMP SETTING full functionality. In idle mode only active functions will show on the screen. THERMOSTAT CHILD LOCK FLAME HEIGHT INDICATOR FAN SPEED TRANSMISSION INDICATOR ADJUSTABLE...

  • Page 62: Adjusting Flame Height

    About ON Mode Adjusting Fan Speed • All functions can be accessed when the remote control is • Press the MENU button to activate the menu. in the ON mode. • Using the UP and DOWN arrows highlight the FAN icon • Only active functions will be displayed when the remote and press SELECT. control is in the ON mode. For example: if the fan is the • Use the UP and DOWN arrows to adjust the FAN SPEED, only function that’s active, the fan icon and flame will be then press SELECT.

  • Page 63: Power Outage

    Adjusting Thermostat Power Outage • Press the MENU button to activate the menu. • If fireplace battery backup system IS installed at time of power outage, fireplace operation will not be interrupted. • Using the UP and DOWN arrows highlight the THERMO icon and press SELECT. • If fireplace battery backup system IS NOT installed at time of power outage, fireplace will shut off. To resume • Use the UP and DOWN arrows to turn the THERMO ON fireplace operation, install battery backup.
  • Page 64 Frequently Asked Questions/Troubleshooting Symptom Possible Cause Corrective Action Batteries Verify batteries are functional and installed correctly. Remote control is in Child Disengage Child Lock mode. Remote control will not transmit Lock mode Buttons not being pressed Press button firmly for one to two seconds to ensure transmis- firmly sion to module. Control module is not in Ensure module switch is set to REMOTE. “REMOTE” mode Control module and remote The control module will beep when it successfully receives a control are not programmed command. If it does not beep, clear module memory and repro- Control module will not take...

  • Page 65: Troubleshooting

    Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualified service technician in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualified service technician. Contact your dealer to arrange a service call by a qualified service technician. A. IntelliFire Plus™Ignition System Symptom Possible Cause Corrective Action 1. Pilot won’t light. A. Incorrect wiring. Verify “S” wire (white) for sensor and “I” wire (orange) for ignitor are The ignitor/module connected to correct terminals on module and pilot assembly. makes noise, but no B. Loose connections or electrical Verify no loose connections or electrical shorts in wiring from mod- spark. shorts in the wiring. ule to pilot assembly. Verify connections underneath pilot assembly are tight; also verify igniter and flame sense wires are not grounding out to metal chassis, pilot burner, pilot enclosure, mesh screen if present, or any other metal object.
  • Page 66 IntelliFire Plus™ Ignition System - (continued) Symptom Possible Cause Corrective Action 4. Pilot lights but contin- A. A shorted or loose connection in flame Verify all connections to wiring diagram in manual. Verify ues to spark, and main sensing rod. connections underneath pilot assembly are tight. Verify burner will not ignite. flame sense or igniter wires are not grounding out to metal (If the pilot continues chassis, pilot burner, pilot enclosure or screen if present, or to spark after the any other metal object.

  • Page 67: Reference Materials

    Reference Materials A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 5. Height includes 9.5 mm hearth pad. Hearth Pad Inches Millimeters 1035 1025 Figure 14.1 Appliance Dimensions Heat & Glo • VRT-AUB • 2123-980_R14 • 12/14...

  • Page 68: Appliance Dimension With Stone Surround Diagram

    B. Appliance Dimension with Stone Surround Diagram Hearth Pad Height includes 9.53 mm hearth pad. Height includes 9.3 mm hearth pad. Inches Millimeters 1126 Figure 14.2 Appliance Dimensions with Stone Surround Heat & Glo • VRT-AUB • 2123-980_R14 • 12/14...

  • Page 69: Maintenance Tasks

    C. Maintenance Tasks Inspect Maintenance Tasks Doors 1. Inspect for scratches, dents or other damage and repair as necessary. 2. Verify no obstructions to airflow. 3. Verify maintenance of proper clearance to combustible household objects. Gasket Seal, Glass 1. Inspect gasket seal and its condition. Assembly and Glass 2. Inspect glass panels for scratches and nicks that can lead to breakage when exposed to heat. 3. Confirm there is no damage to glass or glass frame. Replace as necessary. 4. Verify that latches engage properly, clip studs are not stripped, and glass attachment components are intact and operating properly. Replace as necessary. 5. Clean glass. Replace glass assembly if severely coated with silicate deposits that cannot be removed. Valve Compartment 1. Vacuum and wipe out dust, cobwebs, debris or pet hair. Use caution when cleaning these areas. Screw tips and Firebox Top that have penetrated the sheet metal are sharp and should be avoided. 2. Remove any foreign objects. 3. Verify unobstructed air circulation. Logs 1. Inspect for broken, damaged, or missing logs. Replace as necessary. 2. Verify correct log placement and no flame impingement causing sooting. Correct as necessary. Firebox 1. Inspect for paint condition, warpage, corrosion or perforation. Sand and repaint as necessary.

  • Page 70: Vent Components Diagrams

    D. Vent Components Diagrams 6-1/2 in. 6-1/2 in. 165 mm 165 mm 8-3/4 in. 6-1/2 in. 222 mm 165 mm 9-1/4 in. 6 in. 235 mm 152 mm 6-5/8 in. 168 mm SLP45 45° Elbow 6-5/8 in. 168 mm 9-7/8 in. 251 mm SLP90 90°...
  • Page 71 D. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.

  • Page 72: Service Parts

    E. Service Parts Beginning Manufacturing Date: Mar 2011 Vertical Stove - DV Ending Manufacturing Date: Active VRT-GY-N-AUB, VRT-BZ-N-AUB: Active VRT-BK-N-AUB Beginning Manufacturing Date: Sept 2014 VRT-GY-P-AUB, VRT-BZ-P-AUB (Ending Manufacturing Date: May2012) Log Set Assembly Part number list on following page.

  • Page 73: Service Parts

    VRTIKL-AUB Service Parts Beginning Manufacturing Date: Mar 2011 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor. ITEM DESCRIPTION COMMENTS...
  • Page 74 VRTIKL-AUB Service Parts Beginning Manufacturing Date: Mar 2011 Ending Manufacturing Date: Active #14 Valve Assembly 14.1 14.2 14.3 14.4 14.5 14.15 14.6 14.14 14.7 14.8 14.13 14.12 14.11 14.9 14.10 IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers.
  • Page 75 VRTIKL-AUB Service Parts Beginning Manufacturing Date: Mar 2011 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor. ITEM DESCRIPTION COMMENTS...

  • Page 76: Contact Information

    F. Contact Information Heat & Glo, a brand of Hearth & Home Technologies 7571 215 Street West, Lakeville, MN 55044 www.heatnglo.com Please contact your Heat & Glo dealer with any questions or concerns. For the location of your nearest Heat & Glo dealer, please visit www.heatnglo.com. - NOTES - ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ NOTICE DO NOT DISCARD THIS MANUAL • Important operating • Read, understand and follow • Leave this manual with a n d m a i n t e n a n c e these instructions for safe party responsible for use...
