Model:
VRTIKL-AU
FREESTANDING STOVE
AUSTRALIAN GAS ASSOCIATION CERTIFIED
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
Certifi cate Number: 7153
CAUTION
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • VRTIKL-AU • 2123-900 • 7/07
Installation & Operation
Instructions
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
• Keep children away.
• CAREFULLY SUPERVISE children in same room as
appliance.
• Alert children and adults to hazards of high temperatures.
• Do NOT operate with protective barriers open or
removed.
• Keep clothing, furniture, draperies and other combustibles
away.
Installation and service of this gas stove should be
performed by qualifi ed personnel.
1
Advertisement
Table of Contents
Related Manuals for Heat & Glo VRTIKL-AU VRTIKL-AU
Summary of Contents for Heat & Glo VRTIKL-AU VRTIKL-AU
- Page 1 Model: VRTIKL-AU FREESTANDING STOVE AUSTRALIAN GAS ASSOCIATION CERTIFIED • Important operating a n d m a i n t e n a n c e instructions included. WARNING: If the information in these instructions is not followed exactly, a fi re or explosion may result causing property damage, personal injury, or death.
-
Page 2: Table Of Contents
1 Listing and Code Approvals A. Design and Installation Considerations ....4 B. Non-Combustible Materials Specifi cation....4 C. -
Page 3: Gas Pressure Requirements
Gas Information A. Gas Pressure Requirements Pressure requirements for VRTIKL-AU Stoves are shown in Table 1 below. Two taps are provided on the right hand side of the gas control for a test gauge connection to measure the inlet and outlet pressures. See Section 10: Maintaining and Servicing the Appliance. -
Page 4: Electrical Information
Electrical Information A. Ignition System Wiring • This gas stove is equipped with an electronic ignition system which operates on a 6 volt system. • The batteries are located within the ignition module which is located behind the glass door assembly. A wiring diagram is shown in Figure 7.1. -
Page 5: Appliance Setup
Appliance Setup A. Remove Glass Door Remove the front door assembly by pulling bottom of front away from gas stove and lifting it off of the hooks on top of the stove. Set door assembly aside. B. Remove Shipping Materials Remove shipping materials from inside or underneath the fi... -
Page 6: Accessories
Figure 7.4 The manufacturer recommends securing the lag bolt from the component bag in the center hole in the bottom plate (clearance hole). This bolt will help to prevent tip- ping forward. Figure 7.5 Using pliers, adjust the counter screws to level the gas stove. - Page 7 ON BACK OF APPLIANCE: Remove the four screws from the cover plate on rear of gas stove. Set cover plate aside. Retain screws. (See Figure 7.9). Attach DV adapter collar in its place. Install the inner extension collar. I NNER EXTENSION COLLAR NNER EXTENSION COLLAR Figure 7.9 Install the cover plate with gasket to the top of gas stove...
-
Page 8: Positioning The Logs
G. Positioning the Logs While still breakable, the logs do not become fragile until after the gas stove is burned and they have cured. After curing, any handling must be done with care as breakage can easily occur. PLEASE NOTE: Logs have been designed to work specifically with the burner of this gas stove. -
Page 9: Operating Instructions
Operating Instructions A. Before Lighting Appliance Read this entire manual prior to using the appliance. Failure to follow the instructions may result in property damage, bodily injury, or even death. • Remove all shipping materials from inside and/or underneath the fi rebox. •... -
Page 10: Lighting The Appliance
B. Lighting the Appliance Electronic Ignition FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. A. This heater is equipped with an electronic pilot ignition device which automatically lights the burner. -
Page 11: After Appliance Is Lit
C. After Appliance is Lit Initial Break-in Procedure When you light the appliance, you may notice that it pro- duces heat which does have an associated odor or smell. If you feel this odor is excessive it may require the initial three to four hour continuous burn on high followed by a second burn up to 12 hours to fully drive off any odor from paint and lubricants used in the manufacturing process. -
Page 12: Maintaining And Servicing Appliance
Maintaining and Servicing Appliance Although the frequency of appliance servicing and maintenance will depend on use and the type of installation, a qualifi ed service technician should perform an appliance checkup at the beginning of each heating season. WARNING Risk of injury or property damage. Before servicing: •... -
Page 13: Maintenance Tasks
B. Maintenance Tasks Inspect Doors 1. Inspect for scratches, dents or other damage and repair as necessary. 2. Verify no obstructions to air fl ow. 3. Verify maintenance of proper clearance to combustible household objects. Gasket Seal, Glass 1. Inspect gasket seal and its condition. Assembly and Glass 2. -
Page 14: Troubleshooting
Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualifi ed service person in the diagnosis of a problem and the corrective action to be taken. -
Page 15: Reference Materials
11 11 Reference Materials A. Appliance Dimension Diagram Without Stone Surround Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3. Height includes 9.53 mm hearth pad. Hearth Pad Millimeters Figure 11.1 Appliance Dimensions 1045 1035... -
Page 16: Appliance Dimension With Stone Surround Diagram
B. Appliance Dimension with Stone Surround Diagram Hearth Pad Height includes 9.53 mm hearth pad. Height includes 9.53 mm hearth pad. 1126 Millimeters Figure 11.2 Appliance Dimensions with Stone Surround Heat & Glo • VRTIKL-AU • 2123-900 • 7/07... -
Page 17: Flue Components List
C. Flue Components List Ceiling Support / Wall Thimble, Black 150 mm Pipe Length, Black 220 mm Pipe Length, Black 310 mm Pipe Length, Black 600 mm Pipe Length, Black 910 mm Pipe Length, Black 1210 mm Pipe Length, Black 280 - 370 mm Pipe Length, Black 310 - 430 mm Pipe, Adjustable, Black 90 degree Elbow, Black... -
Page 18: D. Service Parts
D. Service Parts VRTIKL-AU Beginning Manufacturing Date: July 2007 Service Parts Diagram VRT-GY-N-AU, VRT-BZ-N-AU Ending Manufacturing Date: ______ VRT-GY-P-AU, VRT-BZ-P-AU Log Set Assembly Part number list on following page. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07... -
Page 19: Service Parts
IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers’ VIP site. When ordering, supply serial and model numbers to ensure correct service parts. ITEM Log Set Assembly Removable Top Top Assembly Adaptor 4 inch fl ue collar DV Adaptor Adaptor Gasket Side Assembly Left... - Page 20 Service Parts Valve Assembly Parts List Valve Assembly IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers’ VIP site. When ordering, supply serial and model numbers to ensure correct service parts. ITEM Log Bracket Pilot Assembly N Pilot Assembly P Pilot Bracket Burner Support...
-
Page 21: Warranty Policy
E. Warranty Policy In order to presumptively establish the dates to which your HEAT & GLO Limited Warranty runs, you must mail the completed warranty card to HEAT & GLO, 20802 Kensington Boulevard, Lakeville, MN 55044, USA, within 60 days of the date of the stove installation. -
Page 22: Contact Information
F. Contact Information Heat & Glo, a brand of Hearth & Home Technologies, Inc. For the location of your nearest Heat & Glo dealer, For Service or Replacement Parts Contact: Melbourne Jetmaster 444 Swan Street Richmond 3121 (03) 9429-5573 VRTIKL-AU Balanced Flue Gas Appliance SERIAL NUMBER: __________________ __________________...
